SMC 7.1 – Quickstart
Power up
13
Turn down the volume of the SMC 7.1.
Switch on mains switch on the back of the SMC 7.1 (On = I).
14
The 7.1 Input 1 is active and the button lights up. All 7.1 Speaker are active but muted. All 7.1 buttons and the Mute
button light up.

Power down

15
Turn down the volume of the SMC 7.1.
Switch off mains switch on the rear of the SMC 7.1 (Off = O).
16
4
Surround Monitor Controller
7.1 Inputs Stereo Inputs Solo
1 2 1 2 In Place To C Mono L/R Alt
L C R LFE LS RS LB RB Mute
7.1 Speakers
14 16
Mains Switch
L
R
~ 115V AC / ~230V AC, 50 Hz / 60 Hz, P max. 15 W
R
METER OUT SUB OUT ALT SPEAKER OUTPUT
C A U T I O N
Voltage Selection 1. Remove Fuse Holder 2. Exchange Fuses
RISK OF ELECTRIC SHOCK
D O N O T O P E N
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
Serial
7.1 SPEAKER OUTPUT
Number
XLRs: balanced
W I R I N G
1 = GND, 2 = Hot (+), 3 = Cold (-)
SMC 7.1
Made in Germany
SMC 7.1 – Quickstart
SMC 7.1
Standard
13 15
Volume
L R L R L
STEREO INPUT 2 STEREO INPUT 1
3. Flip Over 4. Reinstall Fuses 115V AC: T 630 mA L 250 V | 230V AC: T 320 mA L 250 V
7.1 INPUT 2 7.1 INPUT 1
1 2 3 4 5 6 7 8 H=Hot (+)
Meter Output: unbalanced DB25 comply with
GCHGCHGCHGCHGCH GCH GCH GCH C=Cold (–)
1 = GND, 2 = Hot (+), 3 = n.c. TASCAM Standard
13 1
G=GND
25 14
5
