iCT250 Setup Guide
Thank you for choosing talech and Elavon.
This guide shows you how to set up and connect your iCT250 device to talech Register.
If you have any questions, contact talech support at
support@talech.com
or
888.995.1998.
Your iCT device supports the following payment methods:
Chip & PIN
Contactless
*e.g. Apple Pay™
* * * * *
- 01 -
*Apple Pay™ is a registered trademark in the United States and other countries

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iCT250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elavon iCT250

Summary of Contents for Elavon iCT250

  • Page 1 Setup Guide Thank you for choosing talech and Elavon. This guide shows you how to set up and connect your iCT250 device to talech Register. If you have any questions, contact talech support at support@talech.com 888.995.1998. Your iCT device supports the following payment methods: Chip &...

  • Page 2: Installation

    Installation Remove box contents Your iCT box should include: iCT250 Terminal Magic Box Power Supply Phone Cable Paper Roll Insert paper roll and connect ethernet cable Lift flap on top of the terminal and Connect an ethernet cable from the insert the paper roll.

  • Page 3: Admin Menu

    Configuration Open “Admin Menu”. Select “Setup Menu”. Press the “#” button from the home screen To select an option press the green button to enter the Admin Menu. or corresponding # on the keypad. ADMIN MENU 1 - Clerk Menu...

  • Page 4: Ethernet Menu

    Configuration Select “Ethernet Setup”. Select “Dynamic IP”. NOTE: Write down IP address displayed. ETHERNET MENU ETHERNET SETUP 1 - Current Setup 1 - Dynamic IP 2 - Ethernet Setup 2 - Static IP 3 - Timers Setup Press yellow button to go back Press the “#”...

  • Page 5: Misc. Options

    Configuration Select “Misc. Options”. Select “Semi-Integrated”. ETHERNET MENU MISC. OPTIONS 6 - Security 1 - Semi-Integrated 7 - Terminal Info 8 - Host Managment 9 - Misc. Options Select “Enable SemiInteg”. Select the “On” option. NOTE: This enables semi-integration.
  • Page 6 Configuration Press yellow button to go back Select “Communication Type”. to the Semi-Integrated menu. SEMI-INTEGRATED 1 - Enable SemiInteg 2 - Communication Type 3 - Receipts Options Enter 6556 as the Select “Ethernet”. Communications Port. ETHERNET MENU SEMI-INTEGRATED 1 - RS232 192.168.2.2...

  • Page 7: Receipt Options

    Configuration Press yellow button to go back Select “Receipts Options”. to the Semi-Integrated menu. SEMI-INTEGRATED 1 - Enable SemiInteg 2 - Communication Type 3 - Receipts Options Select the “ECR” option. RECEIPT OPTIONS 1 - ECR 2 - Terminal...
  • Page 8 App Configuration Open talech Register on your iPad. Go to the setting menu. Select Card Reader. Select iCT220 and iCT250. (highlighted in light blue) - 07 -...
  • Page 9 Your iCT terminal now is connected to talech Register and ready to accept payments. Thank you again for choosing talech and Elavon to be part of your business experience. If you have questions, please don’t hesitate to contact us. We are here 24/7.
