- Page 1 XA-1 3D Mini HDMI Analyser OPERATION MANUAL...
-
Page 2: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 3: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Hardware Description ..............3 7.1 Front Panel ................ 3 7.2 Rear Panel ................ 3 7.3 Top Panel ................ -
Page 4: Introduction
1. Introduction The 3D mini HDMI Analyzer is a tool for checking both source and display devices. With touch button control and built-in OLED (Organic Light Emitting Diode) it can show status of both input and output device. The major purpose is to analyze input source info-frame and output sink EDID. -
Page 5: Specifications
6. Specifications TMDS Clock Frequency 225MHz Input Port 1 x HDMI (Female type) Output port 1 x HDMI (Female type) EXT Mode (HDMI input) HDMI Resolution 480i/p, 576i/p, 720p~1080p PC Resolution VGA~SXGA, WUXGA 3D Resolution Support all 3D timing INT Mode (internal pattern) HDMI Resolution 480i/p, 576i/p, 720p~1080p PC Resolution... -
Page 6: Hardware Description
7. Hardware Description The following sections describe the hardware components of the unit. 7.1 Front Panel HDMI IN DC 5V . HDMI input: Connect the HDMI input port to the HDMI output port of your source equipment such as DVD, Computer, Cables Box or any other source for testing and pulling EDID file. -
Page 7: Top Panel
7.3 Top Panel ① . Power: Press this button to turn on or set the device to standby mode. ② . INT/EXT: Press this button to select the internal patterns built-in the device or the external source device connected from the input port. To use this function the input slot must be connected with source signal in order to perform the function if not, the device will only send out the internal patterns to display on the TV/monitor. -
Page 8: Osd Menu
8. OSD Menu Press the M/ button from the device to bring up the OSD on the display. Press pattern’s [▲/▼] to highlight on option Press [M/ ] to confirm /exit the selection 8.1 System Info System Info.: Press this button to show both the input and output information while both input and output is connected, refers to below picture for information contents. -
Page 9: Sink Edid
8.2 Sink Edid Option Description Block Data To check the sink Block0 and Block1's table of EDID Description To check the sink description of EDID 8.3 Source Infoframe Option Description AVI (AVI infoframe data) To check the source video infoFrame Packet AUD (Audio infoframe data) To check the source audio infoFrame Packet 8.4 CEC Command Option Description... -
Page 10: Oled
9. OLED 96k 2CH ARC 1080P@60 H:1920 3DTB . Sampling Rate: The device support audio sampling rate of 48/96/192KHz and the OLED will display it according to the selection, if external audio is selected the OLED will display bypass. . Audio Channels: The device support audio channels from LPCM 2, 5.1 and 7.1CH, if external audio is selected the OLED will display bypass. -
Page 11: Support Pattern Table
11. Support Pattern Table GROUP PATTERN Description Primary colors: Red, Green, Blue P1: Red P2: Green P3: Blue P4: Horizontal RGB Bar P5: H Grey Scale P6: HDCP handshaking and link-integrity test... - Page 12 P*7(FP): Frame Packing (FP) P*7(SH): Side-by-Side (Half) (SH) P*7 (TB): Top-and-Bottom (TB) Note: *7 means Left hand side will present on 2D display, right hand side will present on 3D display. 3D FP means 3D Frame Packing 3D SH means 3D Side-by-Side (Half) 3D TB means 3D Top-and-Bottom...
-
Page 13: Connection And Installation
12. Connection and Installation... - Page 14 Acronyms Acronym Complete Term 3 Dimension EDID Extended Display Identification Data HDCP High-bandwidth Digital content protection HDMI High-Definition Multimedia Interface Standard Definition...
