Vornado 133 Instructions Manual

Vornado 133 Instructions Manual

Whole room circulator
Hide thumbs Also See for 133:

Advertisement

models
133, 533, 633, 683, 753
WHOLE ROOM CIRCULATOR
OWNER'S GUIDE
GUÍA DEL PROPIETARIO DEL
CIRCULADOR DE AIRE PARA TODA
LA HABITACIÓN
GUIDE DE L'UTILISATEUR DU
VENTILATEUR INTÉGRAL DE PIÈCE
READ AND SAVE
THESE INSTRUCTIONS
LEER Y GUARDAR ESTAS
INSTRUCCIONES
LISEZ ET CONSERVEZ CES
INSTRUCTIONS
vornado.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 133 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vornado 133

  • Page 1 133, 533, 633, 683, 753 WHOLE ROOM CIRCULATOR OWNER’S GUIDE GUÍA DEL PROPIETARIO DEL CIRCULADOR DE AIRE PARA TODA LA HABITACIÓN GUIDE DE L’UTILISATEUR DU VENTILATEUR INTÉGRAL DE PIÈCE READ AND SAVE THESE INSTRUCTIONS LEER Y GUARDAR ESTAS INSTRUCCIONES...
  • Page 2 PERFECT vornado.com 800.234.0604 help@vornado.com English...
  • Page 3: Table Of Contents

    CONTENTS Important Instructions ................ 4 Features ....................7 Stand Assembly & Adjustment ............8 Cleaning ....................9 Troubleshooting ................12 Warranty .................... 13 Español p. 14 Français p. 26 English...
  • Page 4: Important Instructions

    - Place this product away from curtains, draperies, tablecloths and hazard. Contact Vornado Consumer Service at 1-800-234-0604 other fabrics, since they may be drawn into the fan, damage the (phone) or consumerservice@vornado.com (email) for further...
  • Page 5 3. Risk of Fire. Replace fuse only with 2.5 Amp, 125 Volt fuse as - A loose fit between wall outlet (receptacle) and plug may cause approved by Vornado Consumer Service. For an authorized overheating and distortion of the plug. Discontinue use of the replacement fuse, please contact Vornado Consumer Service.
  • Page 6 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to contact Vornado Consumer Service. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to...
  • Page 7: Features

    FEATURES Save energy by maximizing the performance of heating and cooling systems. When you use a Vornado Air Circulator, you will not have to set your summertime thermostat as low or your wintertime thermostat as high. DIRECTABLE CONTROLS AIRFLOW FINGER FRIENDLY DESIGN...
  • Page 8: Stand Assembly & Adjustment

    STAND ASSEMBLY & ADJUSTMENT (MODEL 683) No tools required. STAND ASSEMBLY HEIGHT ADJUSTMENT (31 - 38 INCHES) 1. Insert power cord (A) into 1. Support the Circulator Head the top of Pole and pull through the bottom. (A) with one hand. Use your other hand to loosen the 2.
  • Page 9: Cleaning

    3. To reattach - position the Front Grill so the Vornado logo in the center of the Front Grill is straight. Replace all the screws. Screw Screw Use the brush attachment on your...
  • Page 10 CLEANING GRILL REMOVAL (MODELS 533, 633, 683, 753) Screwdriver required. WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing grill. 1. Remove the 3 screws located in between the ribs of the inlet grill at roughly 10, 2, Front Grill Clip Front Grill Clip and 6 o’clock positions.
  • Page 11 CLEANING BLADE REMOVAL Pliers required. WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing blade. 1. First, remove the nut from the shaft by turning the nut clockwise to loosen. Pull the blade straight out from the shaft.
  • Page 12: Troubleshooting

    Under certain conditions, it is possible for a reset GFCI (Ground Fault Circuit Interrupter) outlet to trip when the user is changing speeds on a Vornado circulator. In this event, change to an outlet that is not connected to a GFCI device. It could also indicate a weak or defective GFCI outlet. Contact a qualified electrician to check the GFCI outlet.
  • Page 13: Warranty

    All technical information, data, and instructions for the installation, connec- Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS 67002. For your tion, and operation contained in these instructions for use correspond to the latest avail- convenience, please have your model number and serial number when contacting able information at time of printing.
  • Page 14 Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | vornado.com CL3-0416 RA CL7-0416 RA, V00...

This manual is also suitable for:

533633683753
