ELMETRON CC- 411 User Manual

Waterproof conductivity
Hide thumbs
Table of Contents

Advertisement

Quick Links

WATERPROOF
CONDUCTIVITY METER
CC- 411
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC- 411 and is the answer not in the manual?

Questions and answers

Related Manuals for ELMETRON CC- 411

Summary of Contents for ELMETRON CC- 411

  • Page 1 WATERPROOF CONDUCTIVITY METER CC- 411 USER’S MANUAL...
  • Page 3 USER’S MANUAL WATERPROOF CONDUCTIVITY METER CC-411 Before use please read the instruction carefully.

  • Page 5: Table Of Contents

    CONTENTS I. INTRODUCTION Exploitation notices Characteristics of the meter What is the meter designed for The outside view Switching the meter on and off Preparation to work 6.1. Choosing the measuring function and unit 6.2. Choosing the kind of temperature compensation 6.3.

  • Page 7: Introduction

    - 1 - INTRODUCTION...
  • Page 8 - 2 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 9: Exploitation Notices

    - 3 - 1. EXPLOITATION NOTICES Dear User! We present you a device distinguished by accuracy according to the technical data and by a high stability of displayed results. We believe that measurements will not cause you any trouble and that the meter will operate without any inconvenience.

  • Page 10: Characteristics Of The Meter

    - 4 - 2. CHARACTERISTICS OF THE METER The CC-411 conductivity meter belongs to the newest generation of measuring devices which ensure high accuracy and repeatability of readings and is easy in use. Two kinds of power source: battery and power adapter, enable work in the field and long-lasting measurements in the laboratory.

  • Page 11: What Is The Meter Designed For

    - 5 - 3. WHAT IS THE METER DESIGNED FOR CC-411 waterproof conductivity meter is a precise and easy-to-use meter designed for measurements of conductivity in µS/cm or mS/cm. The meter may be also used for accurate temperature measurement of solutions and air in °...

  • Page 12: The Outside View

    - 6 - 4. THE OUTSIDE VIEW On the front wall of the meter there is an LCD display (Pic.1) on which, depending on the chosen function, the result of conductivity measurement in µS/cm or mS/cm or temperature measurement in o C is displayed: A particular function is chosen by pressing the button.
  • Page 13 - 7 - The keyboard (pic. 2) placed under the screen has the following keys: - switching the meter on and off. - pressing shortly enters the unit choosing mode (with the button); pressing and holding returns to the measurement mode.
  • Page 14 - 8 - Pic. 2 User’s manual for CC-411 conductivity meter v5.30...

  • Page 15: Switching The Meter On And Off

    - 9 - 5. SWITCHING THE METER ON AND OFF After switching it on with the button, the meter tests the memory and the display on which all symbols are displayed after switching it on (Pic. 3). Pic. 3 If the test ends successfully, after about 1.5 s the meter switches automatically to the measuring mode, in which it was switched off.

  • Page 16: Preparation To Work

    - 10 - 6. PREPARATION TO WORK Before starting measurement: - connect the power adapter plug to the P input, if work with the power adapter is planned; - join the suitable conductivity cell to BNC-50 input (F1); - in case of using the temperature probe it should be connected with the temperature input Chinch (t);...

  • Page 17: Choosing The Kind Of Temperature Compensation

    - 11 - 6.2. Choosing the kind of temperature compensation The meter switches to the automatic temperature compensation mode automatically after connecting the temperature probe. Next to the temperature reading the symbol appears. The measurement will be compensated to the value of temperature measured by the probe Disconnecting the temperature probe switches the meter to the manual temperature compensation mode (the symbol disappears) and the value of...
  • Page 18 - 12 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 19: Conductivity Measurement

    - 13 - II. CONDUCTIVITY MEASUREMENT...
  • Page 20 - 14 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 21: Basic Information About The Conductivity Measurement

    - 15 - 7. BASIC INFORMATION ABOUT THE CONDUCTIVITY MEASUREMENT The conductivity measurement is based on applying electric current with proper voltage and frequency between two electrodes and measuring it. In CC-411 the frequency depends on the measuring range and may vary from 1 kHz up to 12 kHz.

  • Page 22: Choice And Maintenance Of The Conductivity Cell

    - 16 - 8. CHOICE AND MAINTENANCE OF THE CONDUCTIVITY CELL 8.1. Choice of the conductivity cell Conductivity CC-411 meter measured range 0 – 100 mS/cm. The meter co-operates with conductivity cells with K constant = 0.050 ÷ 1.500 cm -1 and equipped with BNC-50 connector. Depending on the required measuring range it is necessary to choose appropriate cell with K constant which enables obtaining accurate results.

  • Page 23: The Conductivity Cell Maintenance

    - 17 - 8.2. The conductivity cell maintenance In order to receive stable results, it is advisable to store the cell in water for a few hours before the measurement, this is especially required in case of distilled water measurements. The conductivity cell maintenance consists mainly in accurate washing the inside of the measuring cell with distilled water.

  • Page 24: Calibration Of The Conductivity Cell

    - 18 - 9. CALIBRATION OF THE CONDUCTIVITY CELL Characteristic feature of every conductivity cell is its K constant. Before displaying the result on the display the value is multiplied by the K constant value. The value of the K constant depends on the size of the electrodes’ surface and the distance between them.

  • Page 25: Calibration With Use Of Standard Solution

    - 19 - 9.2. Calibration with use of standard solution The meter enables one-point calibration in a freely chosen standard solution, to determine the K constant of the cell. In order to decrease the error, it is recommended to use solutions with value close to the estimated value of measurement.
  • Page 26 - 20 - 9.2.2. Calibration without the temperature compensation Accurate calibration should processed without temperature compensation. The sample solution should be brought to 25° C. It is possible to use the temperature probe for controlling. In order to calibrate, follow the steps: - connect the conductivity cell and the temperature probe to the meter;...
  • Page 27 - 21 - 9.2.3. Calibration with manual temperature compensation In order to calibrate the meter: - turn the meter on with the button; - enter the standard solution value (point 9.2.1) - disconnect the temperature probe (the symbol disappears); - enter the 25° C value with the buttons;...

  • Page 28: Conductivity Measurement

    - 22 - CONDUCTIVITY MEASUREMENT 10.1. Conductivity measurement without temperature compensation Accurate conductivity measurement should be made without the temperature compensation. The measured solution should be brought to 25 o C. It is possible to use the temperature probe for controlling. In order to make a measurement: - connect the conductivity cell and the temperature probe to the connectors F1 and t respectively (pic.2);...

  • Page 29: Compensation

    - 23 - 10.2. Conductivity measurement with automatic temperature compensation In case of measurement with automatic temperature compensation: - connect the conductivity cell and the temperature probe to the connectors F1 and t respectively (pic.2); - turn the meter on with the button;...

  • Page 30: Conductivity Measurement With Manual Temperature Compensation24

    - 24 - 10.3. Conductivity measurement with manual temperature compensation The measurement with manual temperature compensation may be made in stable work conditions, e.g. during measurements in laboratory, especially with use of thermostat, or in case of the temperature probe damage. Disconnecting the temperature probe switches the meter to manual temperature compensation.

  • Page 31: Conductivity Measurement In Honey

    - 25 - 10.4. Conductivity measurement in honey The unit of conductivity of honey given by literary sources is 10 S/cm, which means that one unit of conductivity of honey is equal 100 µS/cm. If the meter indicates 250 µS/cm, it will inform about 2,5 units of honey conuctivity. If the readout is equal 1,5 mS/cm, it will be equal 15 units of the conductivity of honey.

  • Page 32: Salinity Measurement

    - 26 - SALINITY MEASUREMENT Salts and minerals dissolved in natural water influence the conductivity, which in principle is proportional to the quantity of dissolved substances. This dependence enables, after certain calculations, to determine the salinity of the measured solution in concentration units (g/l or %). Received values are always approximate and the total accuracy depends on the way of making calculations, concentration of the measured solution and its temperature.

  • Page 33: Salinity Measurement With Conversion To Nacl

    - 27 - 11.1. Salinity measurement with conversion to NaCl The measurement of salinity with conversion to NaCl or KCl content should be done as follows: - choose the salinity measurement with conversion to NaCl content according to the chapter 6.1; - then act as during conductivity measurement (chapter 10);...
  • Page 34 - 28 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 35: Temperature Measurement

    - 29 - III. TEMPERATURE MEASUREMENT...
  • Page 36 - 30 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 37: Temperature Measurement

    - 31 - TEMPERATURE MEASUREMENT The temperature measurement is made in the following way: - connect the temperature probe to the Chinch connector; - by pressing the button switch the meter on; - choose the temperature measuring mode using the button;...
  • Page 38 - 32 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 39: Other

    - 33 - IV. OTHER...
  • Page 40 - 34 - User’s manual for CC-411 conductivity meter v5.30...

  • Page 41: Readout Of The Software Version Number

    - 35 - READOUT OF THE SOFTWARE VERSION NUMBER In order to check the software version number turn the meter off and next, holding the button, turn the meter on by pressing the button. Instead of the display test, the screen as in the picture below will appear (Pic.

  • Page 42: Power Source And Changing The Battery

    - 36 - POWER SOURCE AND CHANGING THE BATTERY The meter is powered by 9V battery or 12V stabilised power adapter. The adapter should be joined with the P connector (Pic.2). Connecting the power adapter disconnects the battery and is signalised by the symbol.

  • Page 43: Technical Data

    - 37 - TECHNICAL DATA CONDUCTIVITY MEASUREMENT: accuracy * ranges resolution Frequency (±1 digit) ±0.25 % 1 kHz 0.000 ÷ 199.9 µS/cm 0.1 µS/cm ±0.25 % 1.6 kHz 200 ÷ 1999 µS/cm 1 µS/cm 0.01 mS/cm ±0.25 % 4.6 kHz 2.00 ÷...

  • Page 44: Equipment

    - 38 - OTHER: -5 ÷ 45 o C OPERATING TEMPERATURE: POWER: 1. 9V battery type 6F22 2. 12V power adapter POWER CONSUMPTION: 60 mW DISPLAY: Custom LCD 55 x 45 mm DIMENSIONS: 149 x 82 x 22 mm WEIGHT: 220 g EQUIPMENT Standard set:...
  • Page 45 - 39 -...
  • Page 46 - 40 - User’s manual for CC-411 conductivity meter v5.30...
  • Page 47 W A R R A N T Y The “ELMETRON” company gives 24 months of warranty for the CC-411 conductivity meter number ......... In case of damage the manufacturer will repair the meter within 14 days from the day of delivery.
  • Page 52  Sp. j. 41-814 Zabrze, Witosa 10, POLAND tel. (+48) 32 2738106 fax (+48) 32 2738114 www.elmetron.com e-mail: info@elmetron.com.pl...
