Summary of Contents for Honda 450S CRF Moto X Bike

  • Page 2: Owners Manual

    OWNERS MANUAL GENERAL Thank you for purchasing our Moto X Bike. The bicycle you have purchased is 90% assembled. This manual is designed to help you finish the assembly and as a guide to help you maintain it in the future. If you are not mechanically minded or have any doubts regarding the assembly of the bike please contact info@motoxbike.com The Multi-tool / Allen keys that are provided and that are in the carton are sufficient to enable you to assemble the bicycle.

  • Page 3: Table Of Contents

    OWNERS MANUAL TOOLS & SERIAL NUMBER OVERVIEW BEFORE YOU RIDE ASSEMBLY 9-17 SERVICING 18-19 MAINTENANCE 20-21 TROUBLE SHOOTING 22-23 REGISTRATION AND GUARANTEE 24-25...

  • Page 4: Tools & Serial Number

    OWNERS MANUAL TOOLS & SERIAL NUMBER TOOLS INCLUDED Allen key wrenches: (Included) Adjustable / Multitool (Included) (Actual tool may differ) SERIAL NUMBER LOCATOR The bicycle you have purchased is a complex object. We recommend that you consult a bicycle specialist if you have doubts or concerns as to your experi- ence or ability to properly assemble, repair, or maintain your bicycle.

  • Page 5: Overview

    OWNERS MANUAL OVERVIEW MOTO X BIKE PARTS AND ACCESORIES Your new bicycle should arrive in good condition in a carton. Remove all packaging and dispose of responsibly. Once all packaging is removed you can then check that all the components of the bicycle are present. Some components are common to all bicycles but some will depend on which bicycle you have purchased.

  • Page 6: Before You Ride

    OWNERS MANUAL BEFORE YOU RIDE THIS BICYCLE HAS A FIXED SEATING POSITION When selecting a new bicycle, the correct choice of frame size is a very important safety consideration. SAFE SIZING FRAME WEIGHT LIMIT It is assumed that the bicycle you have bought is sized correctly for 16”...
  • Page 7 OWNERS MANUAL BEFORE YOU RIDE RESPONSIBILITY By choosing to ride a bicycle, you assume the responsibility for that risk; not the people who sold you the bike; nor the people who made it; nor the people who distribute it; nor the people who manage or maintain the roads and trails you ride on. Like any sport, bicycling involves risk of injury and damage.

  • Page 8: Handlebar Height

    OWNERS MANUAL BEFORE YOU RIDE HANDLEBAR HEIGHT Maximum comfort is usually obtained when the handlebar height is equal to the height of the seat. You may wish to try different heights to find the most comfortable position Over tightening the stem bolt or headset assembly may cause damage to the bicycle and/or injury to the rider. The stem’s “Minimum Insertion” mark must not be visible above the top of the headset.
  • Page 9 OWNERS MANUAL BEFORE YOU RIDE SAFETY CHECKLIST Before every ride, it is important to carry out the following safety checks: 1. Brakes • Ensure front and rear brakes work properly. • Ensure brake shoe pads are not over worn and are correctly positioned in relation to the rims. •...
  • Page 10 OWNERS MANUAL BEFORE YOU RIDE 5. Chain • Ensure chain is oiled, clean and runs smoothly. • Extra care is required in wet or dusty conditions. • On bicycles equipped with coaster brakes, check for proper chain tension 6. Bearings •...
  • Page 11 OWNERS MANUAL BEFORE YOU RIDE HELMETS It is strongly advised that a properly fitting, approved, bicycle safety helmet be worn at all times when riding your bicycle. The correct helmet should: be comfortable be lightweight have good ventilation fit correctly Always wear a properly fitted helmet when riding a bicycle.

  • Page 12: Assembly

    OWNERS MANUAL ASSEMBLY GETTING STARTED Remove all cardboard and bubble-wrap and again dispose of in a responsible manner. You should be careful not to scratch the paintwork or otherwise damage your bike during this process. FRONTWHEEL 1. Make sure the brakes are loose enough to allow the wheel to pass through the brake pads easily. (2) 2.
  • Page 13 OWNERS MANUAL ASSEMBLY REFLECTORS Your bicycle is supplied with one front (white), one rear (red), two wheel (white), and two pedal (orange) reflectors. These are an important safety and legal requirement, and should remain securely fitted and in good, clean conditions at all times. Periodically, inspect all reflectors, brackets, and mounting hardware for signs of wear or damage.
  • Page 14 OWNERS MANUAL ASSEMBLY HANDLEBARS Insert the handlebar stem into the head tube ensuring that the minimum insertion mark in not exceeded. The minimum insertion line is clearly marked on the handlebar stem and this should not be visible once the handlebar stem has been inserted. You must ensure that the handlebars are aligned correctly with the front wheel.
  • Page 15 OWNERS MANUAL ASSEMBLY PEDALS Check for the right (R, red) sticker and left (L, green) sticker on each pedal and crank arm. Match the appropri- ate pedal to each crank (right to right and left to left) for assembly. TO FIT RIGHTHAND PEDAL 1.
  • Page 16 OWNERS MANUAL ASSEMBLY V-BRAKE 1. Insert the brake body into the center spring hole in the frame mounting 2. While holding the shoe against the rim, adjust the amount of shoe protru- boss, and then secure the brake body to the frame with the link fixing bolt. sion by interchanging the Position of the B washers (i.e.
  • Page 17 OWNERS MANUAL ASSEMBLY 3. While holding the shoe against the rim, tighten the shoe fixing nut. 4. Adjust the balance with the spring tension adjustment screws. 5. Pass the inner cable through the inner cable lead, making sure that the 6.
  • Page 18 OWNERS MANUAL ASSEMBLY HAND BRAKE When properly adjusted, hand brakes are an efficient braking system. Keep the rim and brake shoes clean and free from wax, lubricants and dirt at all times. Determine which type of brake your bike is equipped with and refer to the appropriate assembly instructions. It is important to become familiar with the use of hand brakes.
  • Page 19 OWNERS MANUAL ASSEMBLY TRAINING WHEELS 1. Attach the legs to the bicycle frame: Put the alignment insert (1), a leg (2), and a nut (3) on each end of the rear wheel axle (4) Make sure the tab of the alignment insert (5), is tp the rear of the axle and in the slot (6) of the frame Make sure both training wheels are the same...
  • Page 20 OWNERS MANUAL ASSEMBLY TURBOSPOKE® Your bicycle comes with the Turbospoke® exhaust system which has both the look and sound of a real motor- bike exhaust pipe. The Turbospoke® is packed inside the inner carton shown in the picture. Parts of the Turbospoke® exhaust system attaches to the Moto X Bike through the specially designed bracket on the Moto X Bike.

  • Page 21: Servicing

    OWNERS MANUAL SERVICING SERVICE CHECKLIST Frequency Component Lubricant How to Lubricate Chain Chain Lube Brush on or Squirt Weekly Brake Calipers Oil Can Brake Levers OIL Can Monthly Shift Levers Grease Disassemble Every Six Months Freewheel 2 Squirts from Oil Can Brake Cables Grease Disassemble...
  • Page 22 OWNERS MANUAL SERVICING THINGS TO CHECK Wheels are secured in the front forks and rear drop outs (where the back wheel attaches to the frame). Wheels are true with the hubs correctly adjusted and free from side play. Both front and rear brakes function correctly and the wheel rims are free from dirt. Steering is free with no excess play.

  • Page 23: Maintenance

    OWNERS MANUAL MAINTENANCE TIRE INSPECTION Bicycle tires are available in many designs and specifications, ranging from general purpose designs to tires designed to perform best under very specific weather or terrain conditions. Your bicycle has been equipped with tires which the bike’s manufacturer felt were the best balance of performance and value for the use for which the bike was intended Tires must be maintained properly to ensure road holding and stability.
  • Page 24 OWNERS MANUAL MAINTENANCE CHAIN The chain must be kept clean, rust free and frequently lubricated in order to extend its life as long as possible. It will require replacement if it stretches, breaks. Make sure that there are no stiff links, they must all move freely. LUBRICATION The chain should be lubricated with light oil at least every month, or after use in wet, muddy, or dusty conditions.

  • Page 25: Trouble Shooting

    OWNERS MANUAL TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE REMEDY - Derailleur cables sticking or stretched or damaged. - Tighten, or replace cables. Gear shifts not working properly. - Front or rear derailleur not adjusted properly. - Adjust derailleurs. - Indexed shifting not adjusted properly. - Adjust indexing.
  • Page 26 OWNERS MANUAL TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE REMEDY - Freewheel internal pawl pins are jammed -Lubricate, if problem persists, Freewheel does not rotate. replace freewheel. - Brake blocks worn down. - Replace brake blocks. Brakes not working effectively. - Brake blocks/rim greasy, wet or dirty. - Clean blocks and rim.

  • Page 27: Registration And Guarantee

    OWNERS MANUAL REGISTRATION PLEASE RETAIN YOUR SALES RECEIPT AS PROOF OF PURCHASE. FILL OUT THE INFORMATION BELOW AND KEEP THIS MANUAL IN A SAFE PLACE. BRAND/DESCRIPTION: MODEL #: PRODUCTION DATE: SERIAL #: DATE OF PURCHASE: STORE/PLACE OF PURCHASE...
  • Page 28 OWNERS MANUAL GUARANTEE Unique Bike Co LTD guarantee against manufacturing defects or defects in materials used from the date of original purchase for major parts for 1 year. This excludes spare parts and components that experience wear and tear in normal use or any parts damaged by neglect or inappropriate riding (e.g. tires, inner tubes, brake- blocks) This guarantee will apply provided the bike has been cared for, maintained and used in accordance with the Instructions.
  • Page 29 Designed and manufactured by Unique Bike Co.. Ltd, Honda, the wing logo, Honda vehicle names and their trade dress are trademarks of Honda Motor Co., Ltd. used under license from American Honda Motor Co., Inc. All rights reserved...
