2. Installation

This chapter offers information about installing your router. If you are not familiar with the
hardware or software parameters presented here, please consult your service provider for
the values needed.

2.1 System Requirement

1. Personal computer (PC)
2. Pentium III 266 MHz processor or higher
3. 128 MB RAM minimum
4. 20 MB of free disk space minimum
5. RJ45 Ethernet Port

2.2 Hardware Installation

Please connect the device to you computer as follow:
If connecting to the splitter, connect the "Line" splitter to wall jack using one
telephone cable
Use another telephone cable to connect "MODEM" port of the splitter and "LINE" port
of the modem. The "Phone" port of the splitter can be use to connect the telephone
by a telephone cable.
Use Ethernet cable to connect "LAN" port of the modem and "LAN" port of your
computer.
Figure 1 ADE-3400 connection diagram
