  • Page 1 Home Appliances Laundry User Manual Washing Machine ES-GFD814QW3-FR ES-GFD814QI3-FR For Life...

  • Page 2: Table Of Contents

    CONTENTS CHAPTER-1: BEFORE USING THE APPLIANCE • Correct Usage • General warnings • Safety warnings • Packaging and Environment • Savings Information CHAPTER-2: OVERVIEW OF YOUR DEVICE • General Appearance • Techincal Specifications CHAPTER-3: INSTALLATION • Removing transportation safety screws • Adjusting Adjustable Stays • Electrical connection • Water inlet hose connection • Water discharge connection CHAPTER-4: INTRODUCTION OF CONTROL PANEL •...
  • Page 3 CONTENTS CHAPTER -7: PROGRAM TABLE CHAPTER -8: SELECTING SUB-PROGRAMS Synthetics Wool Extras CHAPTER -9: MAINTENANCE AND CLEANING OF YOUR MACHINE Warning Water inlet filters Pump filter Detergent drawer CHAPTER -10: FLUSH STOPPER / BODY / DRUM CHAPTER -11: TROUBLESHOOTING CHAPTER -12: AUTOMATIC MALFUNCTION WARNINGS AND WHAT SHOULD BE DONE THE ENERGY LABEL AND SAVING ENERGY DISPOSAL OF YOUR OLD MACHINE...

  • Page 4: Before Using The Appliance

    CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) Operating voltage / frequency: (V/Hz) (220-240) V~/50Hz; Total current (A): 10 Water pressure (Mpa) Maximum: 1 Mpa / Minimum : 0.1 Mpa Total power (W) : 2200 Maximum dry laundry capacity (kg): 8 Do not install your machine on a carpet or such grounds that would prevent the ventilation of its base. The appliance is not intended for use by people (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 5 CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) Use only the new water inlet hose coming with your machine when making water inlet connections to your machine.Never use old, used or damaged water inlet hoses. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children should not play with the appliance. Cleaning and user maintenance should not be made by children without supervision. Note: For a softcopy of this user manual, please visit our WEB page: sharphomeappliances.com. In your e-mail,...

  • Page 6: Correct Usage

    CHAPTER -1: BEFORE USING THE APPLIANCE (CORRECT USAGE) • Definitely read the user’s manual. • Your machine is designed to be used domestically. Commercial use will cause your warranty to be cancelled. • Keep your pets away from your machine • Please check the packaging of your machine before installation, and the outer surface after the package is opened. Do not operate damaged machines or machines with opened packaging.
  • Page 7 CHAPTER -1: BEFORE USING THE APPLIANCE (CORRECT USAGE) • Use your machine only for laundries that have been specified as suitable for washing by the manufacturer. • Before operating the washing machine, remove the 4 transportation screws and rub- ber spacers from the back of the machine. If the screws are not removed, it may cause heavy vibration, noise and product malfunc- tion, (voiding the guarantee).

  • Page 8: General Warnings

    CHAPTER -1: BEFORE USING THE APPLIANCE (GENERAL WARNINGS) • The necessary ambient temperature for your machine’s ideal operation is 15-25°. • Frozen hoses can tear and explode. In regions where temperature is below zero, ambient tem- perature might endanger the safe operation of electronic card. • Please ensure that the clothes you place in your machine do not contain any foreign sub- stances (nail, needle, coins, lighter, matches, clip etc.) in their pockets. These foreign substances can damage your machine. • It is recommended to perform the first washing operation with a 90˚ Cotton programme and without laundry by inserting ½ scale of detergent in 2nd compartment of the detergent drawer.
  • Page 9 CHAPTER -1: BEFORE USING THE APPLIANCE (GENERAL WARNINGS) • As detergent or softener exposed to air for a long time may cause residues, put your deter- gent or softener in the detergent drawer at the beginning of every wash. • It is advised that you unplug your machine and close the water inlet tap if you will not use your machine for a long time. Also, leaving the door of your machine will prevent the formation of bad odours due to humidity. • Some water might be left in your machine after the trials and tests conducted due to Quality Control procedures.
  • Page 10 CHAPTER -1: BEFORE USING THE APPLIANCE (GENERAL WARNINGS) • Never open the detergent com- partment when the appliance is running. • In case of any breakdown, unplug the appliance first and then turn the tap off. Do not attempt to repair by yourself, always contact an au- thorised service centre for advice. • The amount of laundry you put in your washing machine should not exceed the maximum amount indi- cated. • Never force the door to open when the machine is running. EN -10-...
  • Page 11 CHAPTER -1: BEFORE USING THE APPLIANCE (GENERAL WARNINGS) • Please adhere to detergent/fabric condition- er manufacturers’ advice regarding the use of fabric conditioner or similar products in your machine. • Set up your machine in a place where its door can be completely opened. EN -11-...

  • Page 12: Safety Warnings

    CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) You must read these warnings, to pro- tect yourself and others from harm. DANGER OF GETTING BURNT! Do not touch the discharging hose and water during discharging as the appliance may reach high temperatures when run- ning. EN -12-...
  • Page 13 CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) DEATH RISK DUE TO ELECTRICAL CURRENT! • Do not use multiple receptacles or extension cord. • Do not plug in damaged or torn plugs. • Never pull the cable when un- plugging – always grip the plug itself. • Do not plug-in or out the plug from the receptacle with wet hands to prevent electrocution! • Never touch the machine with wet hands or feet. • Call the nearest authorized ser- vice for a replacement if the power cord centre malfunctions.

  • Page 14: Flooding Risk

    CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) Flooding risk! • Check whether the water runs fast or not be- fore placing the discharge hose on the sink. • Take necessary measures to prevent the slipping of your hose. • The backfiring force of a hose that is not placed appropriately can displace the hose. Prevent the stopper inside your sink from blocking the sink hole. EN -14-...
  • Page 15 CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) Danger of Fire! • Do not keep inflammable liquids near your machine.. • The sulphure content of paint removers might cause corrosion. For this reason, never use paint-removing materials in your machine. • Never use products that contain solvent material (like washing gas) in your ma- chine. • Remove all objects in the pockets of your clothes (needles, paperclips, lighter, match- es etc.) when placing it in your machine. Fire and Explosion risk may occur. EN -15-...
  • Page 16 CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) Fall and injury hazard! • Do not climb on your machine. The upper ta- ble of your machine may break and you might get injured. • Tidy the hose, cable and packaging of your machine during installation. You might trip over and fall. • Do not turn your machine upside down, or on its side. • Do not lift your machine by holding it from extruding parts (detergent drawer, door). These parts might break and cause you to get injured. • There’s the risk of tripping and injury if the materials like hose and cables are not prop- erly stored after your machine is installed. The Machine must be carried by 2 people or more. EN -16-...

  • Page 17: Child Safety

    CHAPTER -1: BEFORE USING THE APPLIANCE (SAFETY WARNINGS) Child safety! • Do not leave children unattended near the machine. Children might lock themselves up into the machine and death risk might occur. • Door glass and surface might be extremely hot while your machine operates. Thus, especially touching the machine might give damage to the skins of children. • Keep packaging material away from children. • Poisoning might occur if the detergent and maintenance materials are consumed, and eyes or the skin might be irritated if they come into contact with the skin. Keep cleaning mate- rials away from the reach of children. EN -17-...

  • Page 18: Packaging And Environment

    CHAPTER -1: BEFORE USING THE APPLIANCE PACKAGING AND ENVIRONMENT Removal of packaging materials Packaging materials protect your machine from any damage that might occur during transportation. Packaging materials are en- vironment friendly as they are recyclable. Recycling material provides both raw mate- rial savings and decreases waste produc- tion. Disposal of old machine Electrical or electronical old devices might still contain salvagable parts. So, never throw away your old devices that you do not use into the waste. Ensure that the parts of your old electronic or electrical devices are reused by taking them to your local recycling facility.

  • Page 19: Savings Information

    CHAPTER -1: BEFORE USING THE APPLIANCE SAVINGS INFORMATION Some important information to get more effi- ciency out of your machine: • The amount of laundry you put in your wash- ing machine should not exceed the maximum amount indicated. By this way, your machine shall run in saving mode. • Not using the pre-wash feature for lightly and normal-dirty laundry will save electricity and water. EN -19-...

  • Page 20: Overview Of Your Device General Appearance

    CHAPTER -2: OVERVIEW OF YOUR DEVICE GENERAL APPEARANCE 1-Upper tray 2-Detergent drawer 3-Programme button 4-High-resolution LCD display 5-Touch buttons 6-Door 7-Pump filter cover EN -20-...
  • Page 21 CHAPTER -2: OVERVIEW OF YOUR DEVICE GENERAL APPEARANCE Transportation Safety Screw Water Inlet Valve Discharging Hose Power Cable Transportation Safety Screw Transportation Safety Screw Transportation Safety Screw EN -21-...
  • Page 22 CHAPTER -2: OVERVIEW OF YOUR DEVICE TECHNICAL SPECIFICATIONS Operating voltage / (220-240) V~/50Hz frequency (V/Hz) Total current (A) Water pressure Maximum: 1 Mpa (Mpa) Minimum : 0.1 Mpa Total power (W) 2200 Maximum dry laundry capacity (kg) Spinning revolution 1400 (rev / min) Programme number Dimensions (Height x Width x 845 x 597 x 582 Depth) (mm) EN -22-...

  • Page 23: Removing Transportation Safety Screws

    CHAPTER -3: INSTALLATION REMOVING TRANSPORTATION SAFETY SCREWS Before operating the wash- ing machine, remove the 4 transportation screws and rubber spacers from the back of the machine. If the screws are not removed, it may cause heavy vibration, noise and product malfunc- tion, (voiding the guarantee). For this reason, transporta- tion safety screws should be loosened by being rotated in counter-clockwise using an appropriate wrench. EN -23-...
  • Page 24 CHAPTER -3: INSTALLATION (REMOVING TRANSPORTATION SAFETY SCREWS) Transportation screws should be removed by pulling out. Fit the plastic transporta- tion screw taps delivered in accessories bag to the places where transporta- tion screws have been removed. The transportation safety screws should be stored to be used in case of transportation. NOTE: You must remove the trans- portation screws...
  • Page 25 CHAPTER -3: INSTALLATION (ADJUSTING ADJUSTABLE FEET) Adjusting Adjustable Feet • Do not install your machine on a carpet or such grounds that would prevent the ventilation of its base. • To ensure silent and vibration-free operation of your ma- chine, it should be deployed on a non-sliding and firm ground. • You can adjust the balance of your machine through the feet. • Loosen the plastic adjustment nut. EN -25-...
  • Page 26 CHAPTER -3: INSTALLATION (ADJUSTING ADJUSTABLE FEET) • Adjust the feet upward and downward by rotating them. • After maintaining the balance, compress the plastic adjust- ment nut upward again. EN -26-...
  • Page 27 CHAPTER -3: INSTALLATION (ADJUSTING ADJUSTABLE FEET) • Never put cardboard, wood or suchlike materials under your machine if you are intending to stabilize the distor- tions on the ground. • When cleaning the ground, on which your machine rests, be careful not to alter the feet height. EN -27-...

  • Page 28: Electrical Connection

    CHAPTER -3: INSTALLATION (ELECTRICAL CONNECTION) • Your washing machine is set to 220-240V and 50Hz. • The mains cord of your washing machine is equipped with a specific earthed plug. This plug should always be inserted to a earthed socket of 10 amps. The current value of the fuse should be 10 amps. The fuse current value of the power line connected to this plug should also be 10 amperes. If you don’t have such a receptacle and fuse confirming this, please have it done by a qualified electrician. • We do not take the responsibility of the damages that oc- cur due to ungrounded usage. NOTE: Operating your machine under low voltage will cause the life cycle of your machine to be reduced and its perfor- mance to be restricted. EN -28-...

  • Page 29: Water Inlet Hose Connection

    CHAPTER -3: INSTALLATION (WATER INLET HOSE CONNECTION) • Your machine may have either a single inlet (cold) or double water inlets (cold/hot) based on its specifications. White-capped hose should be connected to the cold water inlet and red-capped hose to hot water inlet (applicable for machines with double water inlets). • To eliminate water leakages in points of contact, 1 or 2 nuts are provided in the hose package (ap- 3/4” plicable for machines with double water inlets). Fit these nuts to the ends of new water inlet hoses on the side of faucet. • Mount the new water inlet hoses to a ¾ ˝, thread- ed faucet. • Connect the white-elbow end of the water inlet hoses to the white-filtered water inlet valve on the rear side of the machine and the red-elbow end to red-filtered one (applicable for machines with dou-...

  • Page 30: Water Inlet Hoses

    CHAPTER -3: INSTALLATION (WATER INLET HOSE CONNECTION) • Ensure that the new water inlet hoses are not bent, bro- ken, crushed or resized. • If your machine has double hot water inlets, the tempera- ture of hot water inlet should be maximum 70°C. Note: Use only the new water inlet hose coming with your machine while making Water inlet hose connections of your ma- chine.

  • Page 31: Water Discharge Connection

    CHAPTER -3: INSTALLATION (WATER DISCHARGE CONNECTION) • The end of the water discharge hose can be fitted to a specific apparatus directly attached to dirty water discharge hole or outlet joint of the basin elbow. • Never attempt to extend the water dis- charge hose by jointing. • Do not put the discharging hose of your machine in a vessel, bucket or sink. • Make sure that the water discharge hose does not bend, buckle, be crushed or ex- tended. Please note: • The water drain hose should be mounted at a height of minimum 60 cm, maximum 100 cm from the ground. EN -31-...

  • Page 32: Introduction Of Control Panel

    CHAPTER -4: INTRODUCTION OF CONTROL PANEL 1-Detergent drawer 2 - Programme Knob : Using the programme knob, you can select the washing programme for your laundry. You can select a programme by turning the programme knob to either direction. Please ensure that the programme knob is set exactly to the programme you want. 3- Info Screen: In this screen, you can see the features of the washing programs you selected and also have information about machine’s 4- Adjustment and additional control buttons: The buttons on your machine are touch-sensitive. You may just touch them to make a selection. 5-Start/Stand-by button: You can start your machine or take it to stand-by with EN -32-...

  • Page 33: Detergent Drawer

    CHAPTER -4: INTRODUCTION OF CONTROL PANEL (DETERGENT DRAWER) You can use the liquid level determination plate when you want to wash your laundry with liquid detergent. You can use your liquid detergents in all programs without prewashing. Place the liquid detergent aparatus in the second compartment (which is available inside the machine) of the detergent drawer (*) and set the detergent amount. (Use the recommended amount of liquid detergent by detergent producers). Do not exceed the MAX level, use only for liquid detergent, do not use this aparatus for powder detergent and take it out.) Liquid Detergent Apparatus Main wash detergent...
  • Page 34 CHAPTER -4: INTRODUCTION OF CONTROL PANEL (DETERGENT DRAWER) SECTIONS Main wash detergent compartment: In this compartment, only use materials like detergent (liquid or powder), lime preventer can be used. You can find the liquid detergent aparatus inside your machine at first installation. (*) Fabric conditioner, starch, detergent compartment: You can use softener for your laundry (recommended amount and type by the producer is recommended). Sometimes the fabric conditioners you use for your wash laundry may remain in this compartment. The reason for this is that the conditioner is not viscous. To prevent this situation, more viscous liquid softeners are recommended to be used or the softener could be thinned and then used. Pre-wash detergent compartment: This compartment must only be used when the pre-wash feature is selected.

  • Page 35: Programme Knob

    CHAPTER -4: INTRODUCTION OF CONTROL PANEL (PROGRAM KNOB) • You can select the programme you want to wash your laundry with by the programme knob. • You may set the programme selection operation by rotat- ing the programme knob in both directions. • Ensure that the programme knob is exactly on the pro- gramme you want to select. EN -35-...

  • Page 36: Machine Settings

    CHAPTER-5: MACHINE SETTINGS (DAY TIME) To make the first settings of your machine: • Plug your machine in. • Open the water faucet. • After the logo introduction, your machine will automatically be directed to the time selection setting menu for time selection. TIME 8 kg.
  • Page 37 CHAPTER-5: MACHINE SETTINGS (DAY TIME) • Please make the current hour and minute settings by touching the buttons of symbols TIME 8 kg. 8 kg.6 6 kg. 8 kg .6 kg. HAFIZA HAFIZA • After setting the current time, approve by touching the button of symbol TIME 8 kg.

  • Page 38: Select Language

    CHAPTER-5: MACHINE SETTINGS (SELECT LANGUAGE) TIME 8 kg.6 8 kg. 6 kg. 8 kg .6 kg. HAFIZA HAFIZA • You can select the language you wish by using the direction buttons TIME 8 kg. 8 kg.6 6 kg. HAFIZA EN -38-...
  • Page 39 CHAPTER-5: MACHINE SETTINGS (SELECT LANGUAGE) TIME 8 kg. 8 kg.6 6 kg. HAFIZA • Touch button to save the language you selected. • A question will be asked on the screen for whether you approve the selection. TIME 8 kg. 8 kg.6 6 kg.
  • Page 40 CHAPTER-5: MACHINE SETTINGS (SELECT LANGUAGE) • Touch button to approve the language change. • If you think you have selected the wrong language, touch the button and make the language selection again. • When you approve the language change, the language you have selected will be active.

  • Page 41: Set Economic Time Zone

    CHAPTER-5: MACHINE SETTINGS (SET ECONOMIC TIME ZONE) • The electrical energy consumption can change during the day according to the electricity provider. You can see these intervals from your electricity provider and set your eco time running hours, and have your machine run hours you have specified. Note: Your mains electricity must be connected to a counter with a smart-counter feature to be able to provide this energy saving.
  • Page 42 CHAPTER-5: MACHINE SETTINGS (SET ECONOMIC TIME ZONE) 9 kg. 6kg. • You can adjust the Eco Time interval by touching the buttons of symbols See page 61 to activate the Eco Time interval additi- onal function. 9 kg. 6kg. • Approve your selection by touching the symbol button.

  • Page 43: Volume Setting

    CHAPTER-5: MACHINE SETTINGS VOLUME SETTING • You can adjust the volume of your machines’ sounds by touching the buttons of symbols. TIME 8 kg. 8 kg.6 6 kg. HAFIZA symbol denotes that the warning sound of your machine is on. TIME 8 kg.
  • Page 44 CHAPTER-5: MACHINE SETTINGS (SCREEN BRIGHTNESS ADJUSTMENT SCREEN CONTRAST ADJUSTMENT • You can adjust the screen brightness of your machine by touc- hing the buttons of symbols. TIME 8 kg. 8 kg.6 6 kg. HAFIZA • Adjust the screen contract of your machine by touching the buttons of symbol.

  • Page 45: Revert To Factory Settings

    CHAPTER-5: MACHINE SETTINGS (REVERT TO FACTORY SETTINGS) If you want to revert your machine to the factory settings: • Touch the button of symbol. TIME 8 kg. 8 kg.6 6 kg. HAFIZA • A question will be asked on the screen for whether you appro- ve the selection.

  • Page 46: Preliminary Preparation For Laundering

    CHAPTER-6: PRELIMINARY PREPARATION FOR LAUNDERING (SEPARATING YOUR LAUNDRY) • Your laundry has product labels on it that specifies how they should be washed. Wash or dry your laundry according to the instructions on the product label. • Separate your laundries according to their types (cot- ton, synthetic, sensitive, wool etc.), their temperatures (cold, 30°, 40°, 60°, 90°) and degree of contamination (slightly stained, stained, highly stained). • Never wash your coloured and white laundry togeth- Wash your coloured laundries separately in the first washing as they may bleed. • Ensure that there are no metallic materials on your laundries or in the pockets; if so, remove them. WARNING: Malfunctions that will oc- cur due to penetration of foreign objects into your machine are not included within the scope of warranty.
  • Page 47 CHAPTER-6: PRELIMINARY PREPARATION FOR LAUNDERING (SEPARATING YOUR LAUNDRY) Whitening No whitening Normal available washing Ironing tempera- Ironing tempera- No ironing ture is maximum ture is maximum 150 °C 200 °C Dry cleaning No dry cleaning Leave on a flat available place Drying by Hang when wet Dry by hanging twirling is not allowed Dry cleaning in Perchloroethyl- Perchlorinetyhlene gas oil, pure al- ene R11, R113,...
  • Page 48 CHAPTER-6: LAUNDRY PREPARATION PLACING LAUNDRY IN THE MACHINE The maximum load capacity of your machine may change according to the program you select. Do not exceed maximum dry loading capacity indicated in the program table for washing programs • Open the loading door of your machine.
  • Page 49 CHAPTER-6: LAUNDRY PREPARATION; PLACING LAUNDRY IN THE MACHINE • Put the laundry in separately. • Ensure that no laundry is stuck between the cover and bellow seal when closing the door of your machine. • Make sure the door of the machine is closed completely. •...

  • Page 50: Detergent Selection And Adding Detergent To The Machine

    CHAPTER-6: LAUNDRY PREPARATION (DETERGENT SELECTION AND ADDING DETERGENT TO THE MACHINE) The amount of detergent you will put in your machine will depend on the following criteria: • Your detergent use will be based on the degree of contamina- tion of your laundry. Do not prewash your lightly stained laundry and put a small amount of detergent in the 2nd compartment of the detergent drawer.

  • Page 51: Operating Your Machine

    CHAPTER-6: LAUNDRY PREPARATION (OPERATING YOUR MACHINE) • Plug your machine in. • Open the water faucet. • Open the machine door. • Spread your laundry in your machine. • Push the door of your machine to close it until you hear the locking sound. EN -51-...

  • Page 52: Program Selection

    CHAPTER-6: LAUNDRY PREPARATION (PROGRAM SELECTION) • Select the washing program you desire by the program button. • Program name and features will be shown on the screen. TIME 8 kg. 8 kg.6 6 kg. HAFIZA • You can make temperature adjustments ( , 20°, 30°, 40°, 60°, 90°) by pressing the button of symbol.

  • Page 53: Stain Selection

    CHAPTER-6: LAUNDRY PREPARATION STAIN SELECTION Your machine has additional functions for removing 22 different types of stains. You can make use of these auxiliary functions according to the stain types on your laundry. Warning: For the stain selection auxiliary function to perform properly, you should not let the stains on your laundry to dry and stick. Remove solid materials beforehand. Warning: Before you start washing the new stains on your laundry, press on the stain once with a cloth. Do not rub! Your washing machine automatically adjusts the temperature, rotation movement and duration according to the stain type selected. For example, the stain removing methods of your machine are as such ; Blood stain: The blood stain auxiliary function combined with the selected washing program will dissolve the laundry with blood stains in cold water prior to the main program and work to clean the stained surfaces, and then your selected washing program will start. Egg stain: Egg stains will be softened in warm water for a certain time to clear the stain, and then the combined washing program will continue to complete the washing cycle. The stain type selection features in your machine are listed below. For other stain selections, similar stain removal solutions are available. For the stain selection to be active, touch the stain selection symbol button on the screen of your machine. (Picture1) Determine the stain selection by touching the arrow symbol buttons. (Picture2) To approve the selection, activate the stain removal auxiliary washing program you selected by touching the symbol button on the screen. (Picture2) Picture 1 Picture 2 TIME TIME 8 kg.

  • Page 54: Stain Level Selection

    CHAPTER-6: LAUNDRY PREPARATION STAIN SELECTION Picture 4 Picture 3 TIME TIME 8 kg. 8 kg.6 6 kg. 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. 9 kg. 6 kg. cotton Stain Selection HAFIZA HAFIZA On the screen you will see the symbol for the stain selection you selected. (Picture3) If you want to cancel the stain selection, you can touch the stain selection symbol button. The warning message that the selection is cancelled will be displayed on the screen for a short duration. “Stain selection”...
  • Page 55 CHAPTER-6: LAUNDRY PREPARATION STAIN LEVEL SELECTION You can change your wash settings according to how dirty your laundry TIME 8 kg. 9 kg. 8 kg.6 6 kg. 6 kg. and have your laundry is washed in cotton less or more time, lower or higher temperature. The dirtiness levels are automatically set in certain programs. HAFIZA You can make changes as you like.

  • Page 56: Auxiliary Functions

    CHAPTER-6: LAUNDRY PREPARATION (AUXILIARY FUNCTIONS) Before starting the program, you can optionally select an auxiliary function. • Press on the button of auxiliary function you would like to select. Additional functions may not be active according to the program you selected, the amount of load you put in your machine. The reasons for not activating: -It is not compatible with an additional function you have selected previously.
  • Page 57 CHAPTER-6: LAUNDRY PREPARATION: PRE-WASH AUXILIARY FUNCTION You can provide your very dirty laundry to prewashing operation prior to main washing by using this additional function. When using this function, you should put detergent in front washing compartment of the detergent drawer. •...
  • Page 58 CHAPTER-6: LAUNDRY PREPARATION: EXTRA RINSE FUNCTION You can make additional rinse or rinses to your laundry by using this additional function. Your machine offers you 3 different rin- sing options fort his auxiliary function : One additional rinse is made at the end of washing. : Two additional rinses are made at the end of washing.
  • Page 59 CHAPTER-6: LAUNDRY PREPARATION: ANTI-ALLERGIC AUXILIARY FUNCTION You can make an additional rinse operation for your laundry by using this additional function. Your machine will make all rinsing steps with hot water (it is recommended fort he laundry worn on sensitive skin, baby clothes, underwear) * To activate the anti-allergic auxiliary function, touch the button symbol until you see the symbol on the screen.
  • Page 60 CHAPTER-6: LAUNDRY PREPARATION: EASY IRONING AUXILIARY FUNCTION You can help your laundry to be taken out less wrinkled as the washing operation is completed by employing this auxiliary func- tion. * Touch the symbol button to activate the easy ironing additi- onal function touch the button of symbol.
  • Page 61 CHAPTER-6: LAUNDRY PREPARATION: ECONOMIC TIME INTERVAL AUXILIARY FUNCTION • You must make the Eco Time setting from the settings section for this function to work efficiently. (see page 41) • If you want to activate the Eco Time function, touch the button symbol.
  • Page 62 CHAPTER-6: LAUNDRY PREPARATION: ECONOMIC TIME INTERVAL AUXILIARY FUNCTION • Eco Time feature will be constantly displayed on the screen until it is shut off. To shut off, Eco time additional function button must be pressed. TIME 8 kg. 8 kg.6 6 kg.
  • Page 63 CHAPTER-6: LAUNDRY PREPARATION ECONOMIC TIME INTERVAL AUXILIARY FUNCTION • If you don’t want to run the program you have selected between the Eco Time hours, touch the button again. “Eco Time can- celled” text will be displayed on the screen. TIME 8 kg.
  • Page 64 CHAPTER-6: LAUNDRY PREPARATION: DELAYED START/PROGRAM FINISH TIME SETTING • By using this function, you can delay the start of the washing opera- tion from 10 minutes to 23 hours 50 minutes or you can set according to the hour you want it to end. •...
  • Page 65 CHAPTER-6: LAUNDRY PREPARATION DELAYED START/ PROGRAM FINISH TIME SETTING • The screen that shows current time will automatically turn into the screen that displays time delay / program end time. • On this screen you can use the buttons of symbols to delay the washing time, or make the washing operation end at a certain hour.
  • Page 66 CHAPTER-6: LAUNDRY PREPARATION MEMORY RECORD FUNCTION BUTTON (MEMORY) With this feature in your machine, you can record the washing program settings you have used before by touching a single button, saving you time, into 2 different memory locations. So you can wash your laundry without having to make these settings again.
  • Page 67 CHAPTER-6: LAUNDRY PREPARATION: MEMORY RECORD FUNCTION BUTTON (MEMORY) • When you touch the memory button, “Save as memory” question will be displayed on the screen. • If you want to make changes on the washing programs again before recording, you can go into the program menu by touching the X symbol button.

  • Page 68: Memory

    CHAPTER-6: LAUNDRY PREPARATION MEMORY RECORD FUNCTION BUTTON (MEMORY) • The question of “Save as memory?” question will be displayed on the screen. TIME 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. Save as memory? HAFIZA • You can record by touching 1(Memory 1) or 2 (Memory 2) Memory option buttons TIME 8 kg.
  • Page 69 CHAPTER-6: LAUNDRY PREPARATION: MEMORY RECORD FUNCTION BUTTON (MEMORY) •To wash, you can have your laundry washed by pressing start/ stand-by button or select other programs. TIME 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. HAFIZA • If you want to use these programs you have recorded, you can turn the program knob as shown in the Picture below and make your selection by moving on the memory steps.
  • Page 70 CHAPTER-6: LAUNDRY PREPARATION: MEMORY RECORD FUNCTION BUTTON (MEMORY) • When you want to change the settings you recorded in memory programs; navigate over the 1 (Memory 1) or 2 (Memory 2) prog- ram or while over any program, set the program combination you will select and press the (MEMORY) button.
  • Page 71 CHAPTER-6: LAUNDRY PREPARATION: MEMORY RECORD FUNCTION BUTTON (MEMORY) • If you are recording 1(Memory 1), 2(Memory 2) on a program you haven’t taken into memory before, a screen like the one be- low will be displayed. • Complete the selection by using the memory button you want. TIME 9 kg.
  • Page 72 CHAPTER-6: LAUNDRY PREPARATION: MEMORY RECORD FUNCTION BUTTON (MEMORY) • Another image will be displayed on the screen for you to app- rove your selection. You can approve your selection by pressing button. TIME 9 kg. 8 kg. 8 kg.6 6 kg. 6 kg.

  • Page 73: Start/Stand-By Button

    CHAPTER-6: LAUNDRY PREPARATION: START/STAND-BY BUTTON • You can start the program you have selected by touching the Start/Stand-by button • When you turn your machine on, the program you have se- lected will be activated. Throughout the washing operations the washing step screens as the examples below will be displayed.
  • Page 74 CHAPTER-6: LAUNDRY PREPARATION: START/STAND-BY BUTTON • Washing Washing step. • Rinsing Rinsing durulama step. • Spinning step. • Program Finished finished. • Program finished door unlocked. EN -74-...

  • Page 75: Stopping Program / Adding Laundry / Cancelling Program

    CHAPTER-6: LAUNDRY PREPARATION: Stopping program / Adding laundry / Cancelling program • You can pause or restart the program you have selected with button. You can use this function when you want to add laundry to your machine. * Touch the symbol button fort his.

  • Page 76: Program End

    CHAPTER-6: LAUNDRY PREPARATION: PROGRAM END Your machine will stop by itself as soon as the program you have selec- ted finishes. -“END“ is displayed on the screen. You can open the machine’s door and remove the laundry. - Leave the door of your machine open to allow the inner part of your machine to dry after removing your laundry.

  • Page 77: Key Lock

    CHAPTER-6: LAUNDRY PREPARATION: KEY LOCK To avoid program flow from being affected if function buttons are pressed or the program knob is turned when performing a washing operation in your machine, a child lock is available. The child lock engages after both of the buttons next to the symbol are pressed for more than 3 seconds.
  • Page 78 CHAPTER-6: LAUNDRY PREPARATION KEY LOCK The following text will be displayed if any buttons are pressed while the child lock is engaged. TIME 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. To unlock press for 3s HAFIZA If the child lock is engaged while any program is running and the program knob is switched to the STOP position and another prog- ram is selected, the program previously selected continues from where it was left.
  • Page 79 CHAPTER-6: LAUNDRY PREPARATION: HALF LOAD SENSING Your machine features a half-load detection system. If put approximately half or less amount of laundries of maximum laundry capacity in your machine, your machine will run so as to save washing time, water consumption and energy in some programs. When the half-load function is ac- tive, the machine can complete the program you have set in a shorter time. EN -79-...

  • Page 80: Program Table

    CHAPTER-7: PROGRAM TABLE COTTON Washing temperature (°C) *90°-80°-70°-60°-50°-40°-30°-” ” Maximum dry laundry amount Detergent Compartment Program duration (Min.) Very dirty, cotton and flax textiles. (Underwear, bedsheet, tablecloth, Laundry type / (towel maximum 4,0 kg), quilt Explanations cover.) COTTON Washing Temperature (°C) * 60°e - 60°- 40°e - 40°- 30°- ” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / Dirty, cotton and flax textiles. Explanations (Underwear, bedsheet, tablecloth, (towel maximum 4,0 kg), quilt cov- er.) * 60°e - 40°e Energy label declaration programs. (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL...

  • Page 81: Chapter -7: Program Table

    CHAPTER-7: PROGRAM TABLE ECO 20° Washing temperature (°C) *20°-” ” Maximum dry laundry 4,0 amount (kg) Detergent compartment Program duration (Min.) Less dirty, sweaty, cotton and flax Laundry type / textiles. (Underwear, bedsheet, Explanations tablecloth,(towel maximum 2 kg.) bedcloth, etc.) (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. EN -81-...

  • Page 82: Synthetics

    CHAPTER-7: PROGRAM TABLE SYNTHETICS Washing temperature (°C) *40°-30°-” ” Maximum dry laundry 3,5 amount (kg) Detergent compartment Program duration (Min.) Very dirty or synthetic-mixed textiles. Laundry type / (Nylon stockings, shirts, blouses, Descriptions trousers with synthetic content etc.) CURTAIN *40°-30°-” ” Washing temperature (°C) Maximum dry laundry 2,5 amount (kg) 1&2 Detergent compartment Program duration (Min.) Laundry type / Please wash only curtains in this Descriptions program. Synthetic and curtain programs are programs with sub-options, you can see the sub-programs chapter to make a selection. (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.

  • Page 83: Wool

    CHAPTER-7: PROGRAM TABLE WOOL Washing temperature (°C) *30°-” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / Woolen laundry with machine wash Descriptions labels. SILK Washing temperature (°C) *30°-” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / Laundry recommended for hand Descriptions wash or sensitive laundry. Wool and Silk programs are programs with sub-options, you can see the sub- programs chapter to make a selection. (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.
  • Page 84 CHAPTER-7: PROGRAM TABLE DUVET Washing temperature (°C) *40°- 30° ” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) You can wash fibre quilts that have Laundry type / machine washable label with this Descriptions program. (max.2.5 kg) (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. EN -84-...
  • Page 85 CHAPTER-7: PROGRAM TABLE RINSE Washing temperature (°C) *“ ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) If you want to additionally rinse your Laundry type / laundry upon completion of washing Descriptions operation, you may use this pro- gram for any kind of laundries. SPIN *“ ” Washing temperature (°C) Maximum dry laundry 8,0 amount (kg) Detergent compartment Program duration (Min.) When you want to make an Laundry type / additional spin to your laundry after Descriptions the washing step, you can use this programme for all kinds of laundry.
  • Page 86 CHAPTER-7: PROGRAM TABLE DRAIN *” ” Washing temperature (°C) Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / It discharges the water in the ma- Descriptions chine. DRUM CLEAN *”80°” Washing temperature (°C) Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / A drum cleaning programme. It must Descriptions be used without laundry. (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.
  • Page 87 CHAPTER-7: PROGRAM TABLE ALLERGY SAFE Washing temperature (°C) *60-50-40-30°-” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / Baby clothes Descriptions RAPID 15 MIN. Washing temperature (°C) *30°-” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) You can wash your lightly stained, Laundry type / cotton, coloured and flax textile Descriptions within only 15 minutes. As the washing period is short in this program, less amount of detergent is required to be used compared to other programs. The program period will increase if your machine detects instable loading. You can open the door of your washing machine just after the washing operation is complete. (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.
  • Page 88 CHAPTER-7: PROGRAM TABLE DAILY 60° 60’ Washing temperature (°C) *60°-50°-40°-30°-” ” Maximum dry laundry 4,0 amount (kg) Detergent compartment Program duration (Min.) You can wash your dirty cotton, Laundry type / colour and flax textiles at 60°C in 60 Descriptions minutes. SPORTSWEAR Washing temperature (°C) *30°-” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Laundry type / Sportswear. Descriptions (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.
  • Page 89 CHAPTER-7: PROGRAM TABLE BLOUSES/SHIRTS Washing temperature (°C) *60-50-40-30°-” ” Maximum dry laundry 4,0 amount (kg) Detergent compartment Program duration (Min.) Dirt, cotton, synthetics and synthetic Laundry type / mix shirts and blouses can be Descriptions washed together. (*Black parts are factory preset) NOTE: PROGRAM DURATION MIGHT CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. EN -89-...
  • Page 90 CHAPTER-7: PROGRAM TABLE NIGHT WASH Washing temperature (°C) *90°-80°-70°-60°-50°-40°-30°-” ” Maximum dry laundry amount (kg) Detergent compartment Program duration (Min.) Very dirty, cotton and flax textiles. Laundry type / (Underwear, linen, tablecloth, (towel Descriptions maximum 4.0 kg), bedclothes, etc.) NOTE: Night washing program is a program that will wash your laundry silently without any spinning stage during the washing. When your machine nears the end of the washing operation, it goes into sleep mode and can keep your laundry for a maximum of 10 hours without discharging the water inside. If the program waiting duration exceeds 10 hours, your machine will automatically perform water discharge and wringing operations. Starting from the time your machine goes into this waiting operation, you can cancel this operation and resume the washing program from where it is left. What you have to do is only to touch the Start / Standby button again. (In sleep mode, the remaining time is not calculated on the display, the remaining time on the display is the duration valid only for discharge and wringing operation.
  • Page 91 CHAPTER-8: SELECTING SUB-PROGRAMS (SYNTHETICS) When you select the synthetics program from the program knob, you will see two sub-program options. 1-Synthetics 2-Curtain • You can make the sub- program selections by pressing the buttons of symbols. TIME 8 kg. 9 kg. 8 kg.6 6 kg.
  • Page 92 CHAPTER-8: SELECTING SUB-PROGRAMS (SYNTHETICS) • You can activate the program you want to select by touching the button of the symbol. TIME 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. Synthetics HAFIZA • After the activation is completed the electronic display will return to the main screen of the program you have selected automa- tically.
  • Page 93 CHAPTER-8: SELECTING SUB-PROGRAMS (WOOL) When you select the wool program from the program knob, you will see two sub-program options. 1-Wool 2-Silk • You can make the sub- program selections by pressing the buttons of symbols. TIME 8 kg. 9 kg. 8 kg.6 6 kg.
  • Page 94 CHAPTER-8: SELECTING SUB-PROGRAMS (WOOL) • You can activate the program you want to select by touching the button of the symbol. TIME 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. Wool yünlüler HAFIZA • After the activation is completed the electronic display will return to the main screen of the program you have selected automatically.

  • Page 95: Extras

    CHAPTER-8: SELECTING SUB-PROGRAMS (EXTRAS) When you select the extras program from the program knob, you will see 4 sub-program options. 1-Rinse 2-Spin 3-Drain 4-Drum clean • You can make the sub- program selections by pressing the buttons of symbols. TIME 8 kg.
  • Page 96 CHAPTER-8: SELECTING SUB-PROGRAMS (EXTRAS) TIME 9 kg. 6 kg. 8 kg. 8 kg.6 6 kg. 0:03 durulama 1400 Drain HAFIZA TIME 8 kg. 8 kg.6 6 kg. 9 kg. 6 kg. 1:30 Drum Clean HAFIZA • You can activate the program you want to select by touching the button of the symbol.

  • Page 97: Maintenance And Cleaning Of Your Machine

    CHAPTER -9: MAINTENANCE AND CLEANING OF YOUR MACHINE (WARNING) Unplug your machine before starting the maintenance and cleaning of your machine. Turn the tap water off before starting the maintenance and cleaning of your machine. CAUTION: Your machine’s parts might be damaged if cleaned with solvent agents are used. Do not use cleaning materials with solvent agents. EN -97-...
  • Page 98 CHAPTER -9: MAINTENANCE AND CLEANING OF YOUR MACHINE (WATER INLET FILTERS) Filters to avoid dirt and foreign substances in the water from penetrating into the machine are available both on the side of faucet and on the ends of water valves along the water inlet hose of your machine. If your machine cannot intake sufficient amount of water despite water faucet being open, these filters should be cleaned. (It is recommended that you clean your pump filter once in 2 months.) • Detach the water inlet hoses. • Remove the filters on water inlet valves using pliers and then clean it with a brush in water.
  • Page 99 CHAPTER -9: MAINTENANCE AND CLEANING OF YOUR MACHINE (PUMP FILTER) The filter system avoids threads remaining from your laundry and tiny materials from entering into the pump during the water discharging operation carried out by your machine after completing washing, prolonging the lifecycle of your pump is. It is recommended that you clean your pump filter once in 2 months. To clean the pump filter: • To open the pump cover, you can use the powder detergent spade (*) or liquid detergent level plate coming out of your machine. • Fit the end point of the plastic part to the gap of the pump cover and push it back. This will open the cover. • Before opening the filter cover, place a vessel in front of the filter cover to prevent the water remained in the machine from flowing on the ground. • Loosen the filter cover by rotating counter- clockwise and then empty the water. Note: You may have to empty the water collection vessel several times according to the amount of water in the machine. (*) Machinery specifications may vary depending on the product purchased. EN -99-...

  • Page 100: Warning

    CHAPTER -9: MAINTENANCE AND CLEANING OF YOUR MACHINE (PUMP FILTER) • Clean off foreign materials in the filter with a brush. • After cleaning the filter, fit the filter cover and tighten it by rotating it in clockwise direction. • While closing the pump cover, ensure that the parts on the inner side of the cover to match the holes on the front panel side. • You can reattach the pump cover in the reverse order that you removed it. WARNING! As water in the pump may be hot, wait un- til it cools down. EN -100-...

  • Page 101: Detergent Drawer

    CHAPTER -9: MAINTENANCE AND CLEANING OF YOUR MACHINE (DETERGENT DRAWER) Your detergents may deposit residue in the detergent draw- er and housing of the detergent drawer over time. To clean the residue formed, disassemble the detergent drawer in particular periods. It is recommended that you clean your pump filter every 2 months. To eject the detergent drawer: • Pull the detergent drawer up to the end • Keep on pulling by depressing on the section shown below in the detergent drawer and keep pulling and then unsettle the detergent drawer. • Flush it using a brush. • Collect residues in the housing of the detergent drawer without dropping them inside the machine.

  • Page 102: Chapter -10: Flush Stopper / Body / Drum

    CHAPTER -10: FLUSH STOPPER / BODY / DRUM Flush stopper Disassemble the detergent drawer. Disassemble the flush stopper and clean the softener residues completely. Refit the flush stopper after cleaning it. Check whether it has settled properly. Body Clean the outer body of your machine with warm water and a non-inflammable and non-abrasive cleaning agent After rinsing with some water, dry it using a soft and dry cloth. Drum Do not leave metallic objects such as needles, paper clips, coins etc. in your machine. These objects lead to the formation of rust stains in the drum. To clean such rust stains, use a non- chlorine cleaning agent and follow the instructions of manufacturers of the cleaning agent. Never use wire wool or similar hard objects for cleaning rust stains. EN -102-...

  • Page 103: Chapter -11: Troubleshooting

    CHAPTER -11: TROUBLESHOOTING All repairing operations required for your machine should be carried out by our authorised service centre. If your machine requires a repair or if you cannot remove the fault by the help of the information provided as follows: • Unplug your machine. • Turn the water faucet off. POSSIBLE TROUBLE- FAULT CAUSE SHOOTING It is not pluggedin. Plug it in. Fuse blown. Replace the fuses. Electricity cut-off. Check mains power. Start/pause button Press on Start/ not pressed. Pause button Your machine does The On / Off button not start. Press the on / off button. has not been pressed. The machine door is Close the machine not completely closed. door. Water tap is turned off. Turn your faucet on. Check water inlet Water inlet hose hose and untwist.
  • Page 104 CHAPTER -11: TROUBLESHOOTING POSSIBLE TROUBLE- FAULT CAUSE SHOOTING Discharging Check the discharg- hose clogged or ing hose, then either twisted. clean or untwist. Your machine Pump filter Clean the does not dis- clogged. pump filter. (*) charge water. Laundry settled Spread your laun- in the machine dry in the machine unevenly. evenly. The feet of your ma- Adjust the feet on chine have not been your machine. (**) adjusted.
  • Page 105 CHAPTER -11: TROUBLESHOOTING POSSIBLE TROUBLE- FAULT CAUSE SHOOTING Press on Start/Pause button To eliminate foam formation, mix a spoon of softener with half litres of water, and pour the mixture in the deter- gent drawer. After 5-10 Excessive amount minutes, press on Start/ of detergent used. Pause button again. In Excessive foam is your next washing opera- formed in the detergent tion, Adjust the detergent drawer. dose accordingly. Use detergents produced only for Wrong deter- automatic washing gent used.
  • Page 106 CHAPTER -11: TROUBLESHOOTING POSSIBLE TROUBLE- FAULT CAUSE SHOOTING Water being hard. Adjust the amount of ( Contaminated, lime detergent based on the water etc.) instruction of detergent manufacturer. Unsatisfactory washing result. Laundries distributed Spread your laun- in your machine non- dries in the ma- evenly. chine properly and evenly. As soon as the ma- The end of water Set the water dis- chine is loaded with discharging hose charging hose on ap- water, water dis- is too low for the...
  • Page 107 CHAPTER -11: TROUBLESHOOTING POSSIBLE TROUBLE- FAULT CAUSE SHOOTING Unbalanced load control system will try to spread your laundries evenly. Spinning operation will Spinning operation is No fault. The begin after your laundry not performed or runs Unbalanced load is spread. Place the late. control system has laundry in the machine in a balanced fashion the next time. EN -107-...

  • Page 108: Chapter-12: Automatic Malfunction Warnings And What Should Be Done

    CHAPTER-12: AUTOMATIC MALFUNCTION WARNINGS AND WHAT SHOULD BE DONE Your machine is equipped with the systems which are capable of both taking necessary precautions and warning you in case of any breakdown by means of continuous self-checking during washing operations. ERROR CODE Check the door POSSIBLE...
  • Page 109 CHAPTER-12: AUTOMATIC MALFUNCTION WARNINGS AND WHAT SHOULD BE DONE WATER CUT OFF ERROR CODE Check water inlet. POSSIBLE Water cut-off or low mains water pressure. FAULT - Water tap may be closed. Check. - Mains water may be cut-off. Check. - If there is no water, turn off the appliance pressing the on / off button found above the programme knob.
  • Page 110 CHAPTER-12: AUTOMATIC MALFUNCTION WARNINGS AND WHAT SHOULD BE DONE PUMP Unplug the ERROR CODE machine The pump is faulty or pump filter is clogged POSSIBLE or electrical connection of the pump is FAULT faulty. Clean the pump(**)filter. WHAT TO DO If the problem persists, contact the nearest authorised service company.
  • Page 111 CHAPTER-12: AUTOMATIC MALFUNCTION WARNINGS AND WHAT SHOULD BE DONE WATER LEVEL HIGH Turn off the ERROR CODE tap. POSSIBLE Your machine has excessive amount of FAULT water. Your machine will drain water by itself. Pursuant to draining operation, turn off WHAT TO DO your machine and unplug it.
  • Page 112 CHAPTER-12: AUTOMATIC MALFUNCTION WARNINGS AND WHAT SHOULD BE DONE VOLTAGE Voltage is high ERROR CODE VOLTAGE Voltage low ERROR CODE POSSIBLE Mains voltage is high or low. FAULT There might be a fluctuation on the energy fed to your machine, check if the socket you have your machine plugged into is grounded.
  • Page 113 DESCRIBING ENERGY LABEL AND SAVING ENERGY Model Brand Energy Class Energy Consumption Noise Value While Washing Noise Value While Spinning Spinning Performance Class Dry Laundry Capacity Annual Water Consumption EN -113-...
  • Page 114 DESCRIBING ENERGY LABEL AND SAVING ENERGY Energy and water consumption may vary based on water pressure, water hardness, water temperature, ambient tem- perature, laundry amount, additional function selection, volt- age fluctuations. It will reduce energy and water consump- tion to use your machine with the laundry capacity proposed for the selected programme, wash your laundries less dirty or daily laundries in short programmes, carry out cleaning and maintenance periodically, use your machine in conveni- ent time intervals specified by electricity vendor. EN -114-...

  • Page 115: Disposal Of Your Old Machine

    DISPOSAL OF YOUR OLD MACHINE This symbol on the product or package implies that the product should not be treated as domestic waste. In- stead, it should be delivered to waste collection places recycling electrical and electronic equipment. You will help to to avoid potential harm to the environ- ment and human health, which will arise due to wrong waste procedure for the product by ensuring that this product is properly.
  • Page 116 Visit our website: www.sharphomeappliances.com Or contact us: Service & Support 52207959...
