Service Manual
PT-70/PT-80
Rubber Track Loader
• Safety Overview
• Technical Specifications
• Circuit Diagrams
• Maintenance
• Controls & Instrumentation
• Component Removal & Installation
• Hydraulic Component Service
• Hydraulic Pressure & Flow Check & Adjustment
• Troubleshooting
ASVPT003
Part Number: 2046-159
Printed (1-08)
