iData 55HC User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 55HC and is the answer not in the manual?

Questions and answers

Related Manuals for iData 55HC

Summary of Contents for iData 55HC

  • Page 2: Table Of Contents

    4.2 Wi-Fi Network Connection ........................18 4.3 Bluetooth ..............................18 4.4 GPS ................................20 4.5 Connecting the iData 55HC to a PC ....................20 4.6 Synchronization ............................21 5 Enabling the Scan Function ....................22 5.1 To start the iScan program and enable scanning, do as follows: ........... 22 6 Enabling the NFC Function .....................

  • Page 3: Introduction

    55HC User Manual 1 Introduction 1.1 Appearance of iData 55HC Figure 1-1 Front view of iData 55HC Figure 1-2 Rear view of iData 55HC - 1 -...

  • Page 4: Installing The Battery

    1.4 Inserting a SIM Card 1. Insert a SIM card by following the direction in the figure below. (Note: Micro SIM cards are applicable to the iData 55HC. After replacing a SIM card, restart the iData 55HC.) - 2 -...

  • Page 5: Inserting A Tf Card

    3. Close the card cover, as shown in the figure below. 4. Pull back the card cover by following the LOCK direction marked on the card cover. (Note: TF cads, namely Micro SD cards, are applicable to the iData 55HC. After replacing a TF card, restart the iData 55HC.)

  • Page 6: Charging

    (3) the charging indicator blinks in red. ★ Tips  The following operations help obtain a longer standby duration of the iData 55HC.  Shorten the time to sleep by selecting Settings > Display > Sleep.  Set the screen brightness to a small value by selecting Settings > Display > Brightness.

  • Page 7: Powering On/Off The Idata 55Hc

    2 Using the iData 55HC 2.1 Powering On/Off the iData 55HC After installing a SIM card and a battery and charging the iData 55HC completely, you can use the iData 55HC. 1. To power on the iData 55HC, press the On/Off key on the right for some time.

  • Page 8: Home Screen

    Home key 2.4 Home Screen By default, the iData 55HC has one home screen. You can add home screens by placing applications to the home screen and slide to the left or right to switch to another home screen. On the home screen, click the icon of any application to open the application.

  • Page 9: Basic Settings

    As software is upgraded continuously, status indicators may be different from those displayed on the iData 55HC. The actual status indicators prevail. 2.6 Basic Settings 2.6.1 Date and Time Settings To change the date and time in the iData 55HC, do as follows: - 7 -...

  • Page 10: Display Setting

    55HC User Manual 1. Find the following icon. 2. Select Settings > Date & time > Set date or Set time. 2.6.2 Display Setting 1. Find the following icon. 2. Select Settings > Display > Lock screen notification/Wallpaper/Brightness/Auto-rotate screen/Sleep/Interactive screensaver/Font size/Cast screen.
  • Page 11 55HC User Manual 2.6.3 Ringtone Setting 1. Find the following icon. 2. Select Settings > Audio profiles > General/Silent/Meeting/Outdoor. Click different modes and set the ringtone in the modes. - 9 -...
  • Page 12 2.6.4 Security Setting 1. Find the following icon. 2. Select Settings > Backup & reset > Factory data reset. The iData 55HC starts to restore factory settings. ★ Caution If you perform the preceding operation, the following data will be cleared: ...
  • Page 13 2.6.6 Shortcuts You can add shortcut icons on the home screen of the iData 55HC. On the home screen, click the icon of application tray, press and hold an icon and drag it to the home screen.
  • Page 14 55HC User Manual - 12 -...

  • Page 15: Call Function

    55HC User Manual 3 Call Function 3.1 Making a Call 1. Find the following icon. 2. Enter a phone number. 3. Click to make a call. 4. Click to terminate the call. Call records Voice call Keypad for dialing Contacts 3.2 Contacts...

  • Page 16: Sms And Mms

    55HC User Manual 3.3 SMS and MMS 1. Find the following icon. 2. Click enter a receiver and text to be sent. 3. Click to send the message. 4. On the message editing page, press the menu key, click Add subject to convert the message into a multimedia message.

  • Page 17: Email

    You can send or receive emails. ★ Note To create an email account on the iData 55HC, first set the account on a PC. Take a QQ email account as an example. Log in to the QQ email account, click Settings in the upper right corner of the email account page, find and select the server option and inbox option and then save.
  • Page 18 55HC User Manual To synchronize or delete an account, do as follows: 1. On the home screen, click Settings. 2. Under the ACCOUNTS option, click POP3 to open added accounts and click the name of an account to be synchronized or deleted. On the Sync page, click in the upper right corner and select Sync now or Remove account.

  • Page 19: Network Connection And Connection Synchronization

    After a GPRS data connection is established, you can access the Internet. To establish a GPRS data connection, ensure that a SIM card is installed in the iData 55HC. In general, the Internet access configuration is set on the iData 55HC. If you delete the default...

  • Page 20: Wi-Fi Network Connection

    1. Find the following icon. 2. Select Settings > WIRELESS & NETWORKS > WLAN. 3. Click Enable/disable WLAN. The iData 55HC starts to search for networks. If WLAN is enabled, click Scan. The iData 55HC lists networks in the range of search.
  • Page 21 55HC User Manual 5. In the dialog box that is displayed, confirm the PIN and click Pair to connect the device. Click to make other devices able to detect the device Click to enable Bluetooth and search for Bluetooth devices 6.

  • Page 22: Gps

    4.5 Connecting the iData 55HC to a PC Connect the iData 55HC to a PC by using a USB data cable so that you can transmit and process files such as photo, video and music files between the memory card of the iData 55HC and the PC.

  • Page 23: Synchronization

    55HC User Manual Click the option to open the USB storage device and copy files between the PC and the device 4.6 Synchronization 1. Find the following icon. 2. Select Settings > Accounts & sync. 3. Click Add account to set a new account.

  • Page 24: Enabling The Scan Function

    55HC User Manual 5 Enabling the Scan Function 5.1 To start the iScan program and enable scanning, do as follows: 1. Click the iScan icon on the menu page. 2. Click the blue slider on the right of Enable Barcode Scanning to enable the scanning function (if you click the slider again, the scanning function is disabled).

  • Page 25: Enabling The Nfc Function

    3. Click the blue slider on the right to enable NFC (if you click the blue slider again, NFC is disabled). 4. Put an NFC card close to the back of the iData 55HC. After a beep is heard, the card is read successfully.

  • Page 26: Managing The Idata 55Hc

    2. Download software installation packages, store them on the SD cad and install the software through file manager. 3. Connect the iData 55HC to a PC by using a USB data cable and install software for the iData 55HC on the PC. However, first of all, you need to install phone assistant software such as APK install, pea pod and phone assistant 91.

  • Page 27: Managing Applications

    55HC User Manual 7.3 Managing Applications Select Settings > App. On the application management screen, you can view application status in the options such as Downloaded, SD Card and Running, click an application, access the application information screen, and perform operations such as forcibly stopping, uninstalling and stopping an application.

  • Page 28: Precautions And Troubleshooting

     Do not store or use the iData 55HC in dusty or dirty places.  Do not store the iData 55HC in a place that is too hot. High temperature will shorten the service life of electronic components.

  • Page 29: Troubleshooting

    The volume is too low or is No sound can be heard. Adjust the volume. disabled. The iData 55HC is in the After being inactive for a period of time, the iData 55HC inactive state.
  • Page 30 Remove applications installed on the iData installed on the iData 55HC. 55HC. The scan application is not Load the scan application in the iData 55HC. loaded. The iData 55HC cannot Reading a barcode fails. Check that the barcode is indefective.
  • Page 31 Table 8-2 Bluetooth troubleshooting Fault Cause Solution The iData 55HC system is Move the iData 55HC close to other too far away from other Bluetooth devices, making the distance Bluetooth devices. between them within 10 meters. The iData 55HC cannot...

  • Page 32: Appendix

    One-slot USB charging base Optional Power adapter Optional , used to charge the battery. Bottom charging cable Optional Table 2 Technical specifications of the iData 55HC Item iData 55HC System configuration High-performance quad-core 1.25 GHz processor Operating System Android 6.0...
  • Page 33 55HC User Manual Item iData 55HC TDD LTE: Band38/39/40/41; FDD LTE: Band1/3 Wireless WAN GPRS/EDGE/HSPA+/TDD-LTE/FDD-LTE (Data service) Wireless LAN Wi-Fi 802.11a/b/g/n（Dual-band Wi-Fi: 2.4G+5G） Bluetooth Bluetooth 4.0 GPS (optional) Supporting GPS/ AGPS Operating environment Development tools Android SDK+JDK+Eclipse Programming Language Java Operating Temp.
  • Page 34 55HC User Manual Item iData 55HC MaxiCode MicroPDF417 PDF417 Postal Codes Australian Post British Post Canadian Post China Post , Japanese Post , Korea Post , Netherlands Post , Planet Code , Postnet ) , Plessey Code , PosiCode...
  • Page 35 55HC User Manual Power Adapter: Manufacturer: SHENZHEN FUJIA APPLIANCE CO.,LTD. Model: FJ-SW126055HC2000UE Input: AC 100-240V; 55HC/60Hz;0.4Amax Output: DC5.0V;2000mA Battery: Manufacturer:WUXI IDATA TECHNOLOGY COMPANY LTD. Model: 1ICP9/65/85 Capacity:3300 mAh 12.2Wh Nominal Voltage:DC 3.7V Maximum Charge Voltage:DC 2.4V CE marking: CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
  • Page 36 55HC User Manual If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna.
  • Page 37 If you have any question, you are free to send an email to idata@idatachina.com. - 35 -...
