Setup
Read the ENTIRE IMpORTANT SAFETy INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Place the Welder on a level surface that can bear its weight near the work
area. Leave space around the Welder for proper air flow.
Note: The following instructions are for welding with Aluminum wire.
connect Shielding gas
1. With assistance, place an 100% Argon cylinder
(not included) onto a cabinet or cart near the
Welder and secure the cylinder in place with
two straps (not included) to prevent tipping.
2. Remove the cylinder's cap. Stand to the
side of the valve opening, then open the
valve briefly to blow dust and dirt from the
valve opening. Close the cylinder valve.
3. Close the Regulator's valve by backing off knob
until it is loose, then thread Regulator onto
cylinder and wrench tighten connection.
4. Attach the Gas Hose (included) to the
Regulator's Outlet and the Welder's Gas Inlet.
Wrench-tighten both connections.
Page 6
TO pREVENT SERIOUS INJURy FROM AccIdENTAL OpERATION:
Turn the power Switch off and unplug the welder before set up.
For technical questions, please call 1-888-380-0318.
1
4
3
Gas Inlet
Power Input
Reset
Briefly open valve
2
to clean,
then close
valve.
Item 63793
