Kia, THE COMPANY
Thank you for becoming the owner of a new Kia vehicle.
As a global car manufacturer focused on building high-quality vehi-
cles with exceptional value, Kia Motors is dedicated to providing you
with a customer service experience that exceeds your expectations.
All information contained in this Owner's Manual was accurate at the
time of publication. However, Kia reserves the right to make changes
at any time so that our policy of continual product improvement can
be carried out.
This manual applies to all models of this vehicle and includes descrip-
tions and explanations of optional as well as standard equipment. As a
result, you may encounter material in this manual that is not applica-
ble to your specific Kia vehicle.
Drive safely and enjoy your Kia!

Advertisement

Table of Contents
loading

Related Manuals for Kia Optima PHEV 2018

Summary of Contents for Kia Optima PHEV 2018

  • Page 1 Kia, THE COMPANY Thank you for becoming the owner of a new Kia vehicle. As a global car manufacturer focused on building high-quality vehi- cles with exceptional value, Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations.
  • Page 2 Thank you for choosing a Kia vehicle. The information and specifications provided in this manual were accurate at the time of printing. Kia reserves the right to When you require service, remember that your Kia dealer discontinue or change specifications or design at any time knows your vehicle best.
  • Page 3 F o r e w o r d HOW TO USE THIS MANUAL We want to help you get the greatest You will find various WARNINGs, possible driving pleasure from your CAUTIONs, and NOTICEs in this vehicle. Your Owner’s Manual can manual.

  • Page 5: Table Of Contents

    Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Audio system table of contents Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Index...
  • Page 6 Hybrid/Plug-in Hybrid System Overview HEV (HYBRID ELECTRIC VEHICLE) SYSTEM / H2 PHEV (PLUG-IN ELECTRIC VEHICLE) SYSTEM / H3 CHARGING THE PLUG-IN HYBRID VEHICLE / H4 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE / H21 ENERGY FLOW HYBRID/PLUG-IN HYBRID VEHICLE / H28 STARTING THE HYBRID/PLUG-IN HYBRID VEHICLE (SMART KEY) / H32 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE / H34...
  • Page 7 HEV (HYBRID ELECTRIC VEHICLE) SYSTEM The Kia Hybrid Electric Vehicle (HEV) uses both the gasoline engine and the electric motor for power. The electric motor is run by a 270V high-voltage HEV battery. Depending on the driving conditions, the HEV computer selectively operates between the engine and the electric motor or even both at the same time.
  • Page 8 PHEV (PLUG-IN ELECTRIC VEHICLE) SYSTEM The Kia Plug-in Hybrid Electric Vehicle (PHEV) shares the characteristics of both a conventional hybrid electric vehi- cle and an all-electric vehicle. When used as a conventional hybrid electric vehicle, the HEV computer selectively operates between the engine and the electric motor or even both at the same time.
  • Page 9 CHARGING THE PLUG-IN HYBRID VEHICLE Charging Information • Trickle Charger: The plug-in hybrid Charging Time vehicle can be charged by using • Normal Charger: The plug-in • Normal Charger: Takes about from household electricity. hybrid vehicle is charged by plug- 2 and a half hours to 3 hours at The electrical outlet in your home ging into a normal charger installed...
  • Page 10 Charging Status Scheduled Charging Charging Status Indicator (if equipped) Charging in Illuminates (green) • You can set reserved charging progress using the AVN. Fully charged Refer to the AVN for detailed infor mation about setting reserved Blinks (green) and charging. Scheduled charging then turns off •...
  • Page 11 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) • When scheduled charging is set, Charging Precautions charging is not initiated immediate- ■ Normal Charger ly when the normal charger or portable charging cable (ICCB: In- Cable Control Box) is connected. When immediate charging required, use the AVN to deacti- vate the scheduled charge setting.
  • Page 12 • Comply with the following in order WARNING WARNING to prevent electrical shock when Public Electric Outlets Touching the charging charging: connector Do not use old or worn out pub- - Use a waterproof charger lic electric outlets to charge Do not touch the charging con- - Make sure to not touch the charg- your vehicle.
  • Page 13 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) • Always keep the charging connec- WARNING - WARNING - Charging Cooling fan tor and charging plug in clean and cable dry condition. Be sure to keep the Do not touch the cooling fan charging cable in a condition where •...
  • Page 14 ✽ ✽ NOTICE Normal Charge How to Connect Normal Charger • The charging door does not open ■ Normal Charger when the theft alarm system is armed. • Close the charging door after door lock is released. OJFHPQ016021L OJFHPQ016010L 1. Depress the brake pedal and You can charge your vehicle by plug- apply the parking brake.
  • Page 15 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) ✽ ✽ NOTICE • The charging is in progress only with the shift lever is in P (Park). Charging the battery with the Engine Start/Stop button in the ACC position is possible. However, it may discharge the 12-V battery. Thus, if possible, charge the bat- tery with the Engine Start/Stop button in the OFF position.

  • Page 16: Hood

    Unlock Charging Door in Charging Status Emergency Checking Charging Status OJFHP046429L 7. After charging has started, the estimated charging time is dis- OJFHP076232N OJFHPQ016009L played on the instrument cluster If the charging door does not open You can monitor the charging status for about 1 minute.
  • Page 17 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) How to Disconnect Normal Charging Status Indicator Charger Charging in 1. The vehicle doors must Illuminates (green) progress unlocked in order to be able to dis- connect the charging connector. A Fully charged lock system prevents charger cable disconnection when the Blinks (green) and Scheduled charging...
  • Page 18 ✽ ✽ NOTICE Trickle Charger • Keep the charging connector and the charging plug clean and dry. The charging cable should be also kept dry. • Use an air gun to blow any foreign substances from the charging con- nector and the charging plug. WARNING Do not modify or disassemble OJFHPQ016013...
  • Page 19 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) How to Connect Portable Charging Cable (ICCB: In-Cable Control Box) OJFHPQ016016L OJFHPQ016010L 3. Check if all LED lamps on the con- 4. Depress the brake pedal and trol box blinks for 0.5 seconds. apply the parking brake. Then, check if the power lamp 5.
  • Page 20 OJFHPQ016026 OJFHPQ016016L OJFHP046428L 6. Remove any dust on the charging 8. Charging starts automatically. 9. Check if the charging cable con- connector and charging inlet. nection indicator of the high volt- Check if the power lamp and charg- age battery in the instrument clus- 7.
  • Page 21 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) ✽ ✽ NOTICE Checking Charging Status • The charging is in progress only with the shift lever is in P (Park). Charging the battery with the Engine Start/Stop button in the ACC position is possible. However, it may discharge the 12-V battery.
  • Page 22 Charge cable storage Charging Status Indicator Charging in Illuminates (green) progress Fully charged Blinks (green) and Scheduled charging then turns off Malfunction Blinks (red) OJFHPQ016029N We recommend that the trickle charger cable should be put in a stor- age box after use. Keep the storage box above the main battery pack inside the trunk.
  • Page 23 Mode is in Standby mode OJFHPQ016018L Charging Mode Charging OJFHPQ016019L ICCCB failure Stop charging immediately and we recommend Failure or electrical you contact an authorized Kia dealer for ICCB leakage detected check. OJFHPQ016020L...
  • Page 24 How to Disconnect PortableCharging Cable (ICCB: In-Cable Control Box) 1. Before disconnecting the charging connector, make sure the doors are unlocked. When the door is locked, the charging connector lock system will not allow discon- nection. CAUTION OJFHPQ016028 OJFHPQ016015N In order to disconnect the charg- 2.
  • Page 25 • Use the portable charging cable charging cable. electric outlet condition, have it that is certified by Kia. checked by a licensed electrician. • Do not let children operate or touch • Do not try to repair, disassemble, or the portable charging cable.
  • Page 26 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE Changing plug-in hybrid mode When the HEV button is pressed in Plug-in hybrid mode indicator the HEV-charging mode, the mode • CD (Charge Depleting, Electric) mode changes as below. : The high-voltage - Shortly pressed : It changes to the (hybrid) battery is CS mode.
  • Page 27 When the ready indicator goes OFF Kia dealer. or blinks, there is a problem with the system. In this case, we recommend that you have your vehicle inspected by an authorized Kia dealer.
  • Page 28 ✽ ✽ NOTICE Coasting guide (if equipped) • User settings A chime will sound and the coasting Press the Engine Start/Stop button Coasting guide is only a supplemen- guide indicator will blink four times to and put the shift lever in P(Park). In tal system to assist with fuel-efficient inform the driver when to take the the User Settings Mode, select...
  • Page 29 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE (CONT.) Unplug vehicle to start Remaining charge time Battery charged. Maintaining cur- (Plug-in hybrid) (Plug-in hybrid) rent (Plug-in hybrid) The message is displayed when you The message is displayed to notify This message is displayed when start the engine without unplugging the remaining time to fully charge the unable to convert to charging mode...
  • Page 30 Low battery temp. Maintaining Charger Error! (Plug-in hybrid) Switching to Hybrid mode to current (Plug-in hybrid) allow heating (Plug-in hybrid) This messages is displayed when the charging failed by external charg- This message is displayed when • When the coolant temperature is er error.
  • Page 31 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE (CONT.) Wait until fuel door opens Fuel door open (Plug-in hybrid) Refuel after stopping (Plug-in hybrid) (Plug-in hybrid) This message is displayed when the fuel filler lid is opened. The message is displayed when you This message is displayed when the attempt to open the fuel filler lid with fuel filler lid open button is pressed...
  • Page 32 Open fuel door after disconnecting Open fuel door after disconnecting EV / HEV/ CHG modes charging cable (Plug-in hybrid) charging cable (Plug-in hybrid) (Plug-in hybrid) This message is displayed when you This message is displayed when you press fuel filler lid open button while press fuel filler lid open button while charging.
  • Page 33 ENERGY FLOW HYBRID/PLUG-IN HYBRID VEHICLE Kia hybrid system notifies the drivers Vehicle Stop EV Propulsion of energy flow in various operating modes. Eleven Modes show drivers the current operating condition. OJFH045389L OJFH045390L Electric power is used to move the The mode means the vehicle at stop.
  • Page 34 Power Assist Engine Only Propulsion Engine Generation OJFH045392L OJFH045391L OJFH045393L Electric and Engine power are used Engine power is used to move the Vehicle is stopped with the Engine vehicle. (Engine ➞ Wheel) to move the vehicle. charging the hybrid battery. (Battery &...
  • Page 35 ENERGY FLOW HYBRID/PLUG-IN HYBRID VEHICLE Regeneration Engine Brake Power Reserve OJFH045394L OJFH045397L OJFH045395L Hybrid battery is being charged by The vehicle is being slowed by Engine is both driving the vehicle regenerative braking. engine compression. and charging the hybrid battery. (Wheel ➞...
  • Page 36 Engine Generation/Regeneration Engine Generation/Motor Drive Engine Brake/Regeneration OJFH045399L OJFH045396L OJFH045398L The engine and regenerative braking The vehicle is being slowed by engine The engine compression can be system charge the hybrid battery compression and regenerative brak- used to slow the vehicle. The regen- driving deceleration.
  • Page 37 STARTING THE HYBRID/PLUG-IN HYBRID VEHICLE (SMART KEY) Starting the Hybrid System • When the engine start/stop but- If the starting procedure is fol- lowed, the " " symbol on the ton is in the ACC or ON position, 1.Carry the smart key into the vehicle. instrument cluster will turn on.
  • Page 38 ✽ ✽ NOTICE ECONOMICAL and SAFE OPERATION of Hybrid system When the hybrid system is in READY mode, the engine will auto- • Drive smoothly. Accelerate at a matically start and stop as needed. moderate rate and maintain a The " "...
  • Page 39 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE 1. Engine : 2.0L 5. HPCU (Hybrid Power Control Unit) 2. Motor : 35kW 6. High voltage battery system 3. Transmission : 6AT 7. Genergative brake system 4. Hybrid starter generator (HSG) 8. Virtual Engine Sound System (VESS) ❈...
  • Page 40 HEV Battery additional warnings. Your vehicle is recommended to be serviced by an WARNING - Touching authorized Kia dealer. HPCU When replacing the fuses in the engine compartment, never touch the HPCU. The HPCU car- ries high voltage.
  • Page 41 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE(CONT.) Motor CAUTION - High Voltage WARNING - After-market Battery Damage Battery Charger When loading your vehicle, be Do not use an after-market bat- careful of transporting items in a tery charger to charge the manner that could damage the Hybrid battery.
  • Page 42 CAUTION - WARNING Cleaning WARNING - - High Waters Use of Water Engine or Liquids • Avoid high waters as this may When you clean the engine com- result in your vehicle becom- If water or liquids come into partment, do not wash using ing saturated with water and contact with the hybrid system water.
  • Page 43 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE(CONT.) Safety plug Some Special Features of the The HEV system may emit electromag- netic waves which can affect the per- Hybrid Vehicle. formance of electronic devices appli- Hybrid vehicles sound different than ances, such as laptop computers, gasoline engine vehicles.
  • Page 44 Virtual Engine Sound System High Voltage Battery Air Intake Plug-in Hybrid Vehicle (VESS) Hybrid battery air intake The Virtual Engine Sound System generates an engine sound for pedestrians to hear vehicle while at low speeds in EV mode. WARNING - Interference with electronic medical devices Electromagnetic waves that are...
  • Page 45 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE(CONT.) ✽ ✽ NOTICE If An Accident Occurs WARNING - Air Intake • Avoid the engine compartment. • If a small scale fire occurs, use a • Blocking the air intake behind fire extinguisher (ABC, BC) that is •...
  • Page 46 Hybrid system. Have the car brake. empty, the hybrid system may not towed to an authorized Kia dealer. operate. 2.Turn off the Hybrid system by If the Hybrid system stops operating pushing the Engine Start/Stop while the vehicle is moving, reduce Button.
  • Page 47 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE(CONT.) WARNING - Accident Vehicle Never touch electric wires or cable. If exposed electric wires or cables are visible inside or outside of your vehicle, an elec- tric shock may occur. WARNING - Putting out fire Never use a small quantity of water to put out a fire in your...

  • Page 48: Table Of Contents

    Introduction Fuel requirements ......1-2 • Gasoline containing alcohol and methanol ..1-2 •...

  • Page 49: Gasoline Containing Alcohol And Methanol

    Gasoline containing alcohol and what has been specified. (Consult an Discontinue using gasohol of any methanol authorized Kia dealer for details.) kind if drivability problems occur. Gasohol, a mixture of gasoline and • Tighten the cap until it clicks one...
  • Page 50 (Oxygen Content 2.7% weight) ance and damage to your vehicle's ing, clogging, abnormal corrosion, may reduce vehicle performance and engine and fuel system. Kia recom- life cycle reduction, etc. produce vapor lock or hard starting. mends that customers do not use...

  • Page 51: Do Not Use Methanol

    Gasoline containing MMT Fuel Additives Operation in foreign countries Some gasoline contains harmful man- Kia recommends that you use good If you are going to drive your vehicle ganese-based fuel additives Such as quality gasolines treated with deter- in another country, be sure to:...

  • Page 52: Vehicle Break-In Process

    Introduction VEHICLE BREAK-IN HEV/PHEV POWERTRAIN PROCESS By following a few simple precautions for the first 1,000 km (600 miles) you No special break-in period is needed. may add to the performance, econo- By following a few simple precautions my and life of your vehicle. for the first 1,000 km (600 miles) you may add to the performance, econo- •...

  • Page 53: Vehicle Data Collection And Event Data Recorders

    Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an These data can help provide a bet- To read data recorded by an EDR, event data recorder (EDR). The ter understanding of the circum- special equipment is required, and main purpose of an EDR is to stances in which crashes and access to the vehicle or the EDR is...
  • Page 54 Your vehicle at a glance Exterior overview ......2-2 Interior overview ......2-4 Instrument panel overview .
  • Page 55 Your vehicle at a glance EXTERIOR OVERVIEW ■ Front view 1. Hood............4-27 2. Head lamp (Features of your vehicle) ...4-100 Head lamp (Maintenance).....8-83 3. Wheel and tire........8-47, 9-4 4. Outside rearview mirror......4-48 5. Panorama sunroof .........4-36 6. Front windshield wiper blades (Features of your vehicle)....4-108 Front windshield wiper blades (Maintenance) ........8-44...
  • Page 56 Your vehicle at a glance ■ Rear view 1. Door locks ..........4-13 2. Fuel filler lid........4-29, 4-33 3. Rear combination lamp (Maintenance) ........8-83 4. High mounted stop lamp (Maintenance) ........8-93 5. Trunk ..........4-17, 4-19 6. Antenna ...........5-2 7. Rearview camera ........4-98 8.

  • Page 57: Table Of Contents

    Your vehicle at a glance INTERIOR OVERVIEW 1. Inside door handle ........4-14 2. Driver position memory button ....3-11 3. Power window switch.......4-23 4. Central door lock switch ......4-15 5. Power window lock button .......4-26 6. Outside rearview mirror control ....4-48 7.

  • Page 58: Table Of Contents

    Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Steering wheel audio controls ....5-3 2, Driver`s front air bag ......3-58 3. Horn.............4-45 4. Instrument cluster........4-51 5. Wiper and washer control lever ..4-108 6. Engine start/stop button ......6-6 7. Cruise control ........6-52 Advanced Smart Cruise Control ..6-56 8.

  • Page 59: Table Of Contents

    Your vehicle at a glance ENGINE COMPARTMENT ■ ■ Gasoline Engine (Nu 2.0L - GDI) 1. Engine coolant reservoir ....8-30 2. Engine oil filler cap ......8-26 3. Engine oil dipstick ......8-26 4. Brake fluid reservoir......8-33 5. Air cleaner.........8-36 6. Fuse box ...........8-65 7.

  • Page 60: Table Of Contents

    Safety features of your vehicle Important safety precautions ....3-2 Air bag - advanced supplemental restraint system ........3-43 •...

  • Page 61: Important Safety Precautions

    Safety features of your vehicle IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Restrain all children Driver distraction and recommendations throughout All children under age 13 should ride Driver distraction presents a serious this section, and throughout this man- in your vehicle properly restrained in and potentially deadly danger, espe- ual.

  • Page 62: Control Your Speed

    Safety features of your vehicle • ONLY use your mobile device Control your speed Keep your vehicle in safe con- when allowed by laws and when dition Excessive speed is a major factor in conditions permit safe use. NEVER crash injuries and deaths. Generally, Having a tire blowout or a mechani- text or email while driving.

  • Page 63: Seat

    Safety features of your vehicle SEAT Driver’s seat (1) Seat adjustment, forward / backward (2) Seatback recliner (3) Seat adjustment, height (4) Lumbar support * (5) Driver position memory system * (6) Headrest Front passenger’s seat (7) Seat adjustment, forward / backward (8) Seatback recliner (9) Seat cushion height...
  • Page 64 Safety features of your vehicle WARNING WARNING WARNING - Loose - Driver respon- - Driver’s seat objects sibility for passengers • Never attempt to adjust the Do not place anything in the dri- seat while the vehicle is mov- ver's foot well or under the front ing.
  • Page 65 Safety features of your vehicle Feature of Seat Leather WARNING WARNING - Rear seatbacks - Seat • Leather is made from the outer adjustment Always lock the rear seatback skin of an animal, which goes before driving. Failure to do so •...

  • Page 66: Front Seat Adjustment - Manual

    Safety features of your vehicle Front seat adjustment - manual Seatback angle CAUTION Forward and backward • Wrinkles or abrasions which appear naturally from usage are not covered by warranty. • Belts with metallic acces- sories, zippers or keys inside the back pocket may damage the seat fabric.

  • Page 67: Front Seat Adjustment - Power

    Safety features of your vehicle Seat height Lumbar support (if equipped) Front seat adjustment - power (if equipped) The front seat can be adjusted by using the control switches located on the outside of the seat cushion. Before driving, adjust the seat to the proper position so you can easily con- trol the steering wheel, pedals and switches on the instrument panel.
  • Page 68 Safety features of your vehicle Forward and backward Seatback angle CAUTION - Power seat adjustments The power seating controls function by electronic motor. Excessive operation may cause damage to the electrical equip- ment. CAUTION - Power Seating Do not operate two or more power seat control switches at OJF035008 OJFA035009...
  • Page 69 Safety features of your vehicle Seat height Lumbar support (if equipped) ■ Type B ■ Type A OJF035075L Type B OJF035010L OJF035011L 1. Press the front portion of the Pull the front portion of the control The lumbar support can be adjusted switch (1) to increase support, or switch up to raise or press down to by pressing the lumbar support...

  • Page 70: Outside Rearview Mirror

    Safety features of your vehicle Driver position memory system Storing positions into memory WARNING - Driver using the buttons on the door (if equipped, for power seat) Position Memory System Storing driver’s seat positions Never attempt to operate the 1. Shift the shift lever into P while the driver position memory system engine start/stop button is ON.

  • Page 71: Headrest (For Front Seat)

    Safety features of your vehicle Recalling positions from memory Easy access function (if equipped) Headrest (for front seat) The system will move the driver's 1. Shift the shift lever into P while the seat automatically as follows: engine start/stop button is ON. •...
  • Page 72 Safety features of your vehicle Also, adjust the headrest as close to Adjusting the height up and down your head as possible. For this rea- son, the use of a cushion that holds the body away from the seatback is not recommended.
  • Page 73 Safety features of your vehicle Removal and reinstallation To remove the headrest: ■ Type A 1. Recline the seatback (2) with the ■ Type A recline lever or switch (1). 2. Raise headrest as far as it can go. 3. Press the headrest release button (3) while pulling the headrest up (4).

  • Page 74: Seatback Pocket

    Safety features of your vehicle To reinstall the headrest : Seatback pocket Rear seat adjustment 1. Put the headrest poles (2) into the Headrest holes while pressing the release button (1) or switch(1). 2. Recline the seatback (4) with the recline lever or switch (3).
  • Page 75 Safety features of your vehicle For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head. Generally, the center of gravity of most people's heads is similar with the height as the top of their eyes.
  • Page 76 Safety features of your vehicle Armrest Folding the rear seat (if equipped) The rear seatbacks may be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING - Folded Seatback The purpose of the fold-down rear seatbacks is to allow you to carry longer objects than could OJF035027...
  • Page 77 Safety features of your vehicle CAUTION - CAUTION - Blocked HEV Blocked PHEV battery duct Battery Duct ■ ■ Hybrid Plug-in hybrid OJF035081L To fold down the rear seatback (for Hybrid, if equipped): 1. Make sure the rear seat belt web- OJFHQ015005 OJFHP036114L bing is in the guide to prevent the...
  • Page 78 Safety features of your vehicle 6. Return the rear seat belt to the WARNING - Objects proper position. Objects carried on the folded ✽ ✽ NOTICE down seatback should not extend higher than the top of After folding the rear seat, unless the front seatbacks.
  • Page 79 Safety features of your vehicle CAUTION - WARNING - Damaging WARNING Rear - Cargo rear seat belt buckles Seatback Cargo should always When you fold the rear seat- To ensure maximum protection secured to prevent it from being back, insert the buckle between in the event of an accident or thrown about the vehicle in a the rear seatback and cushion.

  • Page 80: Seat Belts

    Safety features of your vehicle SEAT BELTS Seat belt restraint system Seat belts are designed to bear upon WARNING - Shoulder Belt the bony structure of the body, and • For maximum restraint system pro- should be worn low across the front •...
  • Page 81 Safety features of your vehicle • No modifications or additions WARNING - Seat belt should be made by the user which would either prevent the seat belt buckle adjusting devices from operating to Do not allow foreign material remove slack, or prevent the seat (gum, crumbs, coins, etc.) to belt assembly from being adjusted obstruct the seat belt buckle.
  • Page 82 Safety features of your vehicle If you continue not to fasten the seat If you unfasten the seat belt while belt and you drive over 9km/h driving in case of under 20km/h (6mph), the warning light will stay illu- (12mph) the seat belt warning light minated until you drive under 6km/h will illuminate until the seat belt is (4mph).
  • Page 83 Safety features of your vehicle Seat belt - Driver's 3-point system Front seat with emergency locking retractor B200A02NF OJF035031 The seat belt automatically adjusts to Height adjustment You can adjust the height of the shoul- the proper length only after the lap B180A01NF-1 der belt anchor to one of the 4 posi- belt portion is adjusted manually so...
  • Page 84 Safety features of your vehicle Release the button to lock the Seat belts - Front passenger and It automatically adjusts to the proper anchor into position. Try sliding the rear seat 3-point system with length only after the lap belt portion height adjuster to make sure that it of the seat belt is adjusted manually combination locking retractor...
  • Page 85 Safety features of your vehicle CAUTION Do NOT fold down the left por- tion of the rear seat back when the rear center seat belt is buck- led. ALWAYS UNBUCKLE the rear center seat belt before fold- ing down the left portion of the rear seat back.

  • Page 86: Pre-Tensioner Seat Belt

    Safety features of your vehicle Pre-tensioner seat belt (1) Retractor Pretensioner If the system senses excessive ten- sion on the driver or passenger's The purpose of the retractor pre- seat belt when the pre-tensioner sys- tensioner is to make sure that the tem activates, the load limiter inside shoulder belts fit in tightly against the retractor pre-tensioner will release...
  • Page 87 Safety features of your vehicle ✽ ✽ NOTICE (1) SRS air bag warning light (2) Front retractor pre-tensioner • Both the driver's and front pas- assembly senger's seat belt pre-tensioner sys- tem may be activated not only in (3) SRS control module certain frontal collision, but also in (4) Emergency fastening device certain side collisions or rollovers,...

  • Page 88: Seat Belt Precautions

    Kia burn you. ✽ ✽ NOTICE dealer inspect the pre-tensioner seat belt and SRS air bag system as soon Small children are best protected as possible.
  • Page 89 Safety features of your vehicle Larger children If the shoulder belt portion slightly Restraint of pregnant women touches the child’s neck or face, try Children who are too large for child Pregnant women should wear placing the child closer to the center of restraint systems should always lap/shoulder belt assemblies when- the vehicle.

  • Page 90: Care Of Seat Belts

    Seatbelts can become hot in a protection if the person is lying down authorized Kia dealer. vehicle that has been closed up in the rear seat or if the front and rear in sunny weather. They could seats are in a reclined position.

  • Page 91: Child Restraint System (Crs)

    Safety features of your vehicle CHILD RESTRAINT SYSTEM (CRS) Children Always in the Rear Children under age 13 must always Child restraint systems must be ride in the rear seats and must always properly placed and installed in the be properly restrained to minimize the rear seat.

  • Page 92: Selecting A Child Restraint System (Crs)

    ✽ ✽ NOTICE • Always follow child restraint system. restraint system manufactur- After an accident, have a Kia dealer er’s instructions for installa- check the child restraint system, seat tion and use. belts, tether anchors and lower anchors. (Continued)
  • Page 93 Safety features of your vehicle Child restraint system types WARNING - WARNING - Holding Unattended There are three main types of child Children Children restraint systems: rear-facing seats, Never hold a child in your arms Never leave children unattended forward-facing seats, and booster or lap when riding in a vehicle.
  • Page 94 Safety features of your vehicle Convertible and 3-in-1 child seats typically have higher height and weight limits for the rear-facing posi- tion, allowing you to keep your child rear-facing for a longer period of time. Continue to use a rear-facing child seat for as long as your child will fit within the height and weight limits allowed by the child seat manufactur-...

  • Page 95: Installing A Child Restraint System (Crs)

    Safety features of your vehicle Booster seats Installing a Child Restraint • Secure the child in the child restraint. Make sure the child is System (CRS) A booster seat is a restraint designed properly strapped in the child to improve the fit of the vehicle’s seat After selecting a proper child seat for restraint according to the manufac- belt system.
  • Page 96 Safety features of your vehicle Lower Anchors and Tether for WARNING - LATCH Lower Children (LATCH) System Anchors The LATCH system holds a child Never attempt to attach a LATCH restraint during driving and in an equipped seat in the center accident.
  • Page 97 Kia dealer after an acci- dent. An accident can damage ❈ (1) : Lower Anchor position indicator the LATCH system and may (2) : Lower Anchor not properly secure the child restraint.
  • Page 98 Safety features of your vehicle Securing a child restraint seat WARNING with "Tether Anchor" system Take the following precautions when installing the tether strap: • Read and follow all installation instructions provided with your child restraint system. • NEVER attach more than one child restraint to a single teth- er anchor.
  • Page 99 Safety features of your vehicle 3. Check that the child restraint is Securing a child restraint with a securely attached to the seat by lap belt or lap/shoulder belt pushing and pulling the seat for- When not using the LATCH system, ward and from side-to-side.
  • Page 100 Safety features of your vehicle To install a child restraint system on the rear seats, do the following: 1.Place the child restraint system on a rear seat and route the lap/ shoul- der belt around or through the child restraint, following the restraint manufacturer’s instructions.
  • Page 101 Safety features of your vehicle ✽ ✽ NOTICE 5. Remove as much slack from the belt as possible by pushing down When the seat belt is allowed to on the child restraint system while retract to its fully stowed position, feeding the shoulder belt back into the retractor will automatically the retractor.

  • Page 102: System

    Safety features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side air bag (4) Curtain air bag (5) Driver’s knee air bag Even in vehicles with air bags, you and your passengers must always wear the safety belts provided in order to minimize the risk and sever-...

  • Page 103: How Does The Air Bag System Operate?

    Safety features of your vehicle How does the air bag system • The front air bags will completely • In order to help provide protection, operate? inflate and deflate in an instant. the air bags must inflate rapidly. The speed of the air bag inflation is It is virtually impossible for you to •...
  • Page 104 Safety features of your vehicle Noise and smoke WARNING WARNING - Airbag infla- - Hot compo- When inflated, the air bags make a tion nents loud noise and leave smoke and Sit as far back as possible from powder in the air inside the vehicle. Do not touch the air bag storage the steering wheel while still This is normal and is a result of the...

  • Page 105: Air Bag Warning Light

    Safety features of your vehicle Do not install a child restraint on Air bag warning light WARNING - Air bag the front passenger’s seat deployment When children are seated in the rear outboard seats of a vehicle equipped with side and/or cur- tain air bags, install the child restraint system as far away from the door side as possible.

  • Page 106: Srs Components And Functions

    2. Passenger's front air bag module properly and you should have your 3. Side air bag modules vehicle checked by an authorized Kia 4. Curtain air bag modules dealer. 5. Retractor pre-tensioner assemblies* 6. Air bag warning light 7.
  • Page 107 Driver’s front air bag (2) occur, this indicates a malfunction in the air bag system. Have an author- ized Kia dealer inspect the air bag system as soon as possible. • The light does not turn on briefly when you change engine start/stop button to ON.
  • Page 108 Safety features of your vehicle Driver’s front air bag (3) Passenger’s front air bag WARNING - Flying objects Do not place any objects (an umbrella, bag, etc.) between the front door and the front seat. Such objects may become dan- gerous projectiles if the side airbag inflates.

  • Page 109: Occupant Detection System (Ods)

    SRS is not working properly. If this occurs, have your vehicle immediately inspected authorized Kia dealer. ✽ ✽ NOTICE OJFA035078 Your vehicle is equipped with an Before you replace a fuse or discon- occupant detection system in the nect a battery terminal, change front passenger's seat.
  • Page 110 Safety features of your vehicle Main components of the occu- If the front passenger seat is occu- Always be sure that you and all vehicle pant detection system pied by a person that the system occupants are seated and restrained determines to be of appropriate size, properly (sitting upright with the seat in •...
  • Page 111 Safety features of your vehicle Condition and operation in the front passenger occupant detection CAUTION system • Do not install a child restraint seat in the passenger seat Indicator/Warning light Devices when the seat is heavily Condition detected by the "PASSENGER soaked with any type of liquid.
  • Page 112 ODS must be seat heater to the front passenger done at Kia service center. seat. This can adversely affect the • After the passenger seat has been occupant detection system.
  • Page 113 Safety features of your vehicle WARNING - ODS System Riding in an improper position adversely affects the Occupant Detection System and may result in the deactivation of the front passenger airbag. It is important for the driver to instruct the passenger as to the proper seating instructions as contained in this manual.
  • Page 114 Safety features of your vehicle (Continued) OJFA035107 OJFA035108 OJFA035109 - Never excessively recline the - Never place feet on the dash- - Never lean on the door or cen- ter console. front passenger seatback. board. - Never sit on one side of the front passenger seat.
  • Page 115 Safety features of your vehicle (Continued) OJFA035101 OJFA035102 OJFA035103 - Do not use car seat acces- - Do place electronic - Wet Passenger Seat sories such as thick blankets devices such as laptops, DVD Do not spill liquid in the pas- and cushions which cover up player, or conductive materi- senger seat.
  • Page 116 Safety features of your vehicle ✽ ✽ NOTICE If the PASSENGER AIR BAG “OFF” Proper position indicator is still on, ask the passen- The PASSENGER AIR BAG “OFF” ger to move to the rear seat. indicator illuminates for about 4 sec- onds after Engine Start/Stop button WARNING is turned to the ON position after the...

  • Page 117: Driver`s Front Air Bag

    Safety features of your vehicle • Even though your vehicle is Any child age 12 and under should Driver's and passenger's front equipped with the occupant detec- ride in the rear seat. Children too air bag tion system, never install a child large for child restraints should use ■...
  • Page 118 Safety features of your vehicle ■ Passenger’s front air bag The SRS consists of air bags These sensors provide the ability to installed under the pad covers in the control the SRS deployment based on center of the steering wheel and the whether or not the seat belts are fas- passenger's side front panel above tened, and how severe the impact is.
  • Page 119 Kia dealer using original tain conditions. For more detail, see below the deployment threshold. Kia parts designed for this vehi- "Occupant detection system" in this cle and model. Any other such chapter. replacement or modification...

  • Page 120: Side Air Bag

    Safety features of your vehicle Side air bag The purpose of the air bag is to pro- WARNING - No attaching vide the vehicle's driver and/or the objects front passenger with additional pro- tection than that offered by the seat No objects (such as crash pad belt alone.
  • Page 121 No attaching the driver's and the passenger's have the vehicle checked and seat belt systems and is not a sub- repaired by an authorized Kia deal- objects stitute for them. Therefore your er. Inform the dealer that your vehi- • Do not place any objects over...

  • Page 122: Curtain Air Bag

    This should only be impact. However, when side deploy- done by an authorized Kia dealer. ment threshold is satisfied at front- impact, side air bags may deploy. WARNING - No attaching •...

  • Page 123: Inflation And Non-Inflation Conditions Of The Air Bag

    Safety features of your vehicle Why didn’t my air bag go off in a Air bag collision sensors collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional pro- tection.
  • Page 124 Therefore, do not try to per- impact of the front collision. form maintenance around the air bag sensors. Have the vehicle checked and repaired by an authorized Kia dealer. 3 65...
  • Page 125 Safety features of your vehicle Side and/or curtain air bags Even where side and/or curtain air bags would not provide impact pro- Side and/or curtain air bags are tection in a rollover, however, they designed to inflate when an impact is will deploy to prevent ejection of detected by side collision sensors occupants, especially those who are...
  • Page 126 Safety features of your vehicle Air bag non-inflation conditions OJF035054 OJFHP036055N • Air bags are not designed to inflate • Front air bags may not inflate in OJF035053 in rear collisions, because occu- side impact collisions, because • In certain low-speed collisions the pants are moved backward by the occupants move to the direction of air bags may not deploy.
  • Page 127 Safety features of your vehicle OJF035056 OJF035057 OJF035058 • In an angled collision, the force of • Just before impact, drivers often • Front air bags may not inflate in all impact may direct the occupants in brake heavily. Such heavy braking rollover accidents where...

  • Page 128: Srs Care

    Kia dealer. must be scrapped, certain safety precautions must be observed. An Any work on the SRS system, such authorized Kia dealer knows these as removing, installing, repairing, or precautions and can give you the OJFHP036059N any work on the steering wheel, the necessary information.

  • Page 129: Bag-Equipped Vehicle

    Safety features of your vehicle Adding equipment to or modi- Air bag warning label WARNING - Tampering fying your air bag-equipped with SRS vehicle Do not tamper with or discon- If you modify your vehicle by chang- nect SRS wiring, or other com- ing your vehicle's frame, bumper sys- ponents of the SRS system.

  • Page 130: Door Locks

    Features of your vehicle Smart key ....... . . 4-4 Windows .
  • Page 131 • Heated steering wheel ......4-44 Warning and indicator lights ....4-82 •...
  • Page 132 Interior lights ......4-111 Clean air ....... . 4-133 •...
  • Page 133 WARNING - Smart key this number will enable an author- Never leave the keys in your ized Kia dealer to duplicate the keys vehicle with unsupervised chil- easily. Remove the bar code tag and dren. Leaving children unat- store it in a safe place. Also, record...
  • Page 134 Features of your vehicle Locking The hazard warning lights will blink Unlocking once to indicate that all doors (and Pressing the button of the front out- trunk) are locked. The button will only side door handles with all doors (and operate when the smart key is within trunk) closed and locked, unlocks all 0.7 ~ 1 m (28 ~ 40 in) from the out-...
  • Page 135 ✽ ✽ NOTICE authorized Kia dealer (tow the vehi- your smart key in possession, the cle, if necessary) to protect it from To stop the horn and lights, press trunk will unlock and open when you potential theft.
  • Page 136 Keep the transmitter away from unsure how to use your smart key or an authorized Kia dealer. water or any liquid, as it can replace the battery, contact an become damaged and not func- authorized Kia dealer.
  • Page 137 Kia dealer. ence, and (2) this device must inside the vehicle. • Using the wrong battery can cause...
  • Page 138 Turn the engine start/stop button to your keys, contact an authorized Operation is subject to the following the ON position by pressing the but- Kia dealer. two conditions: ton while carrying the smart key. CAUTION (1) This device may not cause inter-...
  • Page 139 Disarmed Theft-alarm 3. Lock the doors by depressing the stage stage tivated by an authorized Kia dealer. door lock button on the smart key. If you want this feature, consult an After completion of the steps above, authorized Kia dealer.
  • Page 140 Features of your vehicle Do not arm the system until all Theft-alarm stage Disarmed stage passengers have left the vehicle. If The alarm will be activated if any of The system will be disarmed when the system is armed while a pas- the following occurs while the system •...
  • Page 141 Engine Start/Stop button with the smart key. • If you lose your keys, consult your authorized Kia dealer. CAUTION - Adjusting alarm system Do not change, alter or adjust the theft alarm system in your vehicle.
  • Page 142 Features of your vehicle DOOR LOCKS Operating door locks from • From the driver’s door, turn the key WARNING to the right once to unlock the door outside the vehicle and once more within 4 seconds to • If you don’t close the door unlock all doors.
  • Page 143 Features of your vehicle Operating door locks from • If the inner door handle of the dri- ver’s (or front passenger’s) door is inside the vehicle pulled when the door lock button is With the door lock button in the lock position, the button will unlock and the door will open.
  • Page 144 Features of your vehicle If a power door lock ever fails to func- With central door lock switch • When pressing the left portion(2) tion while you are in the vehicle, try for driver side or the lower por- ■ Driver side one or more of the following tech- tion(2) for passenger side of the niques to exit:...
  • Page 145 Features of your vehicle Impact sensing door unlock Child-protector rear door lock 3. Close the rear door. system To open the rear door, pull the out- side door handle (2). In the event of air bag deployment resulting from a vehicle impact, all Even though the doors may be doors will automatically unlock.
  • Page 146 Features of your vehicle TRUNK Opening the trunk WARNING The trunk swings upward. Make sure no objects or people are near the rear of the vehicle when opening the trunk. CAUTION Make certain that you close the trunk before driving your vehi- OJF045008 cle.
  • Page 147 Features of your vehicle Closing the trunk Emergency trunk safety WARNING release To close, lower the trunk lid, then • No one should be allowed to press down on it until it locks. To be occupy the trunk at any time. sure the trunk lid is securely fas- The trunk is a very dangerous tened, always check by trying to pull...
  • Page 148 Features of your vehicle SMART TRUNK (IF EQUIPPED) ✽ ✽ NOTICE How to use the Smart Trunk The trunk can be opened with no- • The Smart Trunk does not operate touch activation satisfying all the when: conditions below. - The smart key is detected within 15 seconds after the doors are •...
  • Page 149 Features of your vehicle ✽ ✽ NOTICE ■ Type A Do not approach the detecting area if you do not want the trunk to open. If you have unintentionally entered the detecting area and the hazard warning lights and chime starts to operate, leave the detecting area with the smart key.
  • Page 150 Features of your vehicle How to deactivate the Smart WARNING Trunk function using the smart Make sure objects in the rear cargo area do not come out when opening the trunk on the slope way. It may cause serious injury. ✽...
  • Page 151 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE Detecting area • If you press the door unlock but- • The Smart Trunk function will not ton (2), the Smart Trunk function work if any of the following will be deactivated temporarily. occurs: But, if you do not open any door - The smart key is close to a radio...

  • Page 152: Power Window Switch

    Features of your vehicle WINDOWS ■ ■ Front (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing* (6) Automatic power window up/down* (Driver's and Passenger's window)

  • Page 153: Power Window Lock Button

    Features of your vehicle ✽ ✽ NOTICE Power windows Window opening and closing While driving with the rear windows The Engine Start/Stop button must down or with the sunroof (if be in the ON position for power win- equipped) in an open (or partially dows to operate.
  • Page 154 Features of your vehicle Auto up/down window (if equipped) 1. Turn to the Engine Start/Stop but- The distance may vary based on the ton ON position. size or position of the window. If the window detects the resistance while 2. Close the driver's and passenger's the power window switch is pulled up window and continue pulling up continuously, the window will stop...
  • Page 155 Features of your vehicle Power window lock button - The rear passenger's control can- WARNING not operate the rear passenger's power window. Always check for obstructions before raising any window to avoid injuries or vehicle dam- CAUTION - Opening /clos- age.
  • Page 156 Features of your vehicle HOOD Opening the hood Hood open warning OJFHP046407N 2. Go to the front of the vehicle, raise OJF045019 OJFHP046483N the hood slightly, push the second- 1. Pull the release lever to unlatch The warning message will appear on ary latch (1) upward inside of the the hood.
  • Page 157 Features of your vehicle Closing the hood CAUTION - Hood obstruc- 1. Before closing the hood, check the tion following: Before closing the hood, ensure • All filler caps in the engine com- that obstructions partment must correctly removed from the hood open- installed.
  • Page 158 Features of your vehicle FUEL FILLER LID (HYBRID) Opening the fuel filler lid Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks” once. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it in lightly making sure that it is securely closed.
  • Page 159 Features of your vehicle WARNING WARNING WARNING - Refueling - Fire/explo- - Static sion risk electricity Always remove the fuel cap carefully and slowly. If the cap Read and follow all warnings • Before touching the fuel noz- is venting fuel or if you hear a posted at the gas station facili- zle, you should eliminate hissing sound, wait until the...
  • Page 160 If the fuel filler cap requires replace- portable fuel container, be sure leave a lit cigarette in your vehi- ment, use only a genuine Kia cap or to place the container on the cle while at a gas station espe- the equivalent specified for your vehi- ground prior to refueling.
  • Page 161 Features of your vehicle Emergency fuel filler lid release OJFH045023 If the fuel filler lid does not open using the remote fuel filler lid release, you can open it manually. Remove the panel in the cargo area. Pull the handle out slightly. CAUTION Do not pull the handle exces- sively, otherwise the luggage...
  • Page 162 Features of your vehicle FUEL FILLER LID (PLUG-IN HYBRID) ✽ ✽ NOTICE Opening the fuel filler lid • It may take up to 20 seconds to open fuel filler door. • When the fuel filler door is frozen and does not open after 20 seconds at freezing temperature, slightly tap the fuel filler door and then attempt to open it.
  • Page 163 Features of your vehicle ✽ ✽ NOTICE CAUTION • Add fuel into the fuel tank within Do not leave the fuel filler door 20 minutes after opening the fuel open for an extended period of filler lid. After 20 minutes, the fuel time.
  • Page 164 Features of your vehicle Closing the fuel filler lid Emergency fuel filler lid release CAUTION 1. To install the cap, turn it clockwise Do not pull the handle exces- until it “clicks” once. This indicates sively, otherwise the luggage that the cap is securely tightened. compartment area trim...
  • Page 165 Features of your vehicle PANORAMIC SUNROOF (IF EQUIPPED) The sunroof cannot slide when it is in CAUTION - Sunroof motor the tilt position nor can it be tilted damage while in an open or slide position. To prevent damage to the sun- roof, periodically remove any WARNING - Roof cargo...
  • Page 166 Features of your vehicle Sunroof open warning CAUTION CAUTION (if equipped) Do not extend any luggage out- Make sure the sunroof is fully side the sunroof while driving. closed when leaving your vehi- cle. If the sunroof is opened, rain or snow may leak through the sunroof and wet the interior.
  • Page 167 Features of your vehicle Sunshade To close the sunshade when the Sliding the sunroof sunroof glass is closed Push the sunroof control lever for- ward to the 1st detent position. To stop the sliding at any point, press the sunshade control switch momen- tarily.
  • Page 168 Features of your vehicle When the sunshade is opened Automatic reversal WARNING - Sunroof Push the sunroof glass control lever backward to the 1st or 2nd detent Do not extend the face, neck, position, the sunroof glass will be arms or body outside the sun- opened.
  • Page 169 Features of your vehicle Tilting the sunroof Closing the sunroof CAUTION To close the sunroof glass with To prevent damage to the sun- the sunshade roof, periodically remove any Push the sunroof control lever for- dirt that may accumulate on the ward to the 2nd detent position.
  • Page 170 Features of your vehicle Resetting the sunroof When this is complete, the sunroof system has been reset and one Whenever the vehicle battery is dis- touch open and close should be connected or discharged, you must restored. reset your sunroof system as follows: 1.Start the engine.

  • Page 171: Steering Wheel

    Take your vehicle to vehicle may still be steered, but it will • The steering gets heavy immedi- an authorized Kia dealer and have require increased steering effort. ately after turning the Engine the vehicle checked as soon as Start/Stop button is ON position.
  • Page 172 Features of your vehicle (Continued) Tilt and telescopic steering • When the charging system warning Tilt and telescopic steering allows light comes on due to the low volt- you to adjust the steering wheel age (When the alternator or bat- before you drive.
  • Page 173 Features of your vehicle Heated steering wheel CAUTION WARNING • Do not install any type of grip If the steering wheel becomes cover for the steering wheel, it too warm, turn the system off. may impair the function of the The heated steering wheel may heated steering wheel system.

  • Page 174: Horn

    Features of your vehicle Horn OJF045030 To sound the horn, press the horn symbols on your steering wheel. Check the horn regularly to be sure it operates properly. ✽ ✽ NOTICE To sound the horn, press the area indicated by the horn symbol on your steering wheel (see illustra- tion).
  • Page 175 Features of your vehicle MIRRORS Inside rearview mirror Day/night rearview mirror WARNING - Mirror adjust- (if equipped) Adjust the rearview mirror so that the ment center view through the rear window Do not adjust the rearview mir- is seen. Make this adjustment before ror while the vehicle is moving.
  • Page 176 Features of your vehicle Electric chromatic mirror (ECM) CAUTION - Cleaning (if equipped) mirror The electric rearview mirror automat- When cleaning the mirror, use a ically controls the glare from the paper towel or similar material headlights of the vehicles behind you dampened with glass cleaner.
  • Page 177 Features of your vehicle Outside rearview mirror Adjusting outside rearview mirror CAUTION - Rearview Be sure to adjust the mirror angles mirror before driving. Do not scrape ice off the mirror Your vehicle is equipped with both face; this may damage the sur- left-hand and right-hand outside face of the glass.
  • Page 178 Features of your vehicle Reverse parking aid function L/R : When the remote control outside CAUTION - Outside mirror (if equipped) rearview mirror switch (1) is selected to the L (left) or R (right) • The mirrors stop moving when position, both outside rearview they reach the maximum mirrors will move downward.
  • Page 179 Features of your vehicle Folding the outside rearview mirror Center (AUTO, 3) : (if equipped) The mirror will fold or unfold automat- ically as follows: • The mirror will fold or unfold when the door is locked or unlocked by the folding key or smart key.

  • Page 180: Instrument Cluster

    Features of your vehicle INSTRUMENT CLUSTER ■ ■ For Hybrid 1. Hybrid system gauge 2. Fuel gauge 3. Speedometer 4. Warning and indicator lights 5. LCD display (including Trip computer) 6. Battery SOC (State of Charge) gauge ■ ■ For Plug in Hybrid ❈...
  • Page 181 Features of your vehicle Instrument Cluster Control LCD Display Control Adjusting Instrument Cluster ■ Type A Illumination OJFH046132N OJF045037L • If you hold the illumination control ■ Type B button (“+” or “-”), the brightness will be changed continuously. OJF045036 •...
  • Page 182 Features of your vehicle [Type A] Gauges Engine coolant temperature gauge : MODE button for changing Speedometer modes /OK : SELECT scroll switch for setting the select- ed item and RESET scroll switch for reset- ting items [Type B] : MODE button for changing modes OJFHP046419C /OK : SELECT scroll switch...
  • Page 183 Features of your vehicle ✽ ✽ NOTICE Hybrid System Gauge Hybrid Battery SOC (State of Charge) Gauge Accordance to the hybrid system gauge area the “EV” indicator ■ for Hybrid comes on or off. - “EV” indicator ON : Vehicle is driven using the electric motor or the gasoline engine is stopped.
  • Page 184 : The high-voltage near the “L (Low)” level, have your (hybrid) battery is vehicle inspected by an authorized used to drive the Kia dealer. vehicle. OJFHP046420L ✽ ✽ NOTICE • CS (Charge Sustaining, Hybrid) mode Never try to start the vehicle if the...
  • Page 185 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE - Odometer Fuel gauge • The fuel tank capacity is given in Running out of fuel can expose vehi- chapter 9. cle occupants to danger. You must • The fuel gauge is supplemented by top and obtain additional fuel as a low fuel warning light which will soon as possible after the warning...
  • Page 186 Features of your vehicle Outside Temperature Gauge To change the temperature unit (from Transaxle Shift Indicator °C to °F or from °F to °C) Automatic Transaxle Shift Indicator temperature unit changed using "User Settings" mode of the LCD display. ❈ For more details, refer to “LCD Display”...

  • Page 187: Lcd Display

    Features of your vehicle LCD DISPLAY LCD Modes Modes Symbol Explanation This mode displays driving information like the tripmeter, fuel economy, and so on. Trip Computer For more details, refer to “Trip Computer” in this chapter. Turn By Turn This mode displays the state of the navigation. (if equipped) This mode displays the state of the Advanced Smart Cruise Control (ASCC) and ASCC/LDWS...
  • Page 188 Features of your vehicle Service Mode Service Interval Tire Pressure (if equipped) OJF045294L Service required OJF045144L If you do not have your vehicle serv- OJFHP047487L Service interval iced according to the already inputted This mode displays the pressure sta- It calculates and displays when you service interval, “Service...
  • Page 189 Features of your vehicle ✽ ✽ NOTICE Master Warning Mode If any of the following conditions occurs, the mileage and days may be incorrect. • This warning light informs the driv- - The battery cable is disconnected. er the following situations - The fuse switch is turned off.
  • Page 190 Features of your vehicle User Settings Mode Edit settings after shifting to P This warning message appears if Description you try to adjust the User Settings while driving. For your safety, change the User Settings after parking the vehicle, applying the parking brake and mov- ing the shift lever to P (Park).
  • Page 191 Features of your vehicle Driving Assist (if equipped) Items Explanation Choose the sensitivity of the smart cruise control. Smart Cruise Control Response (if equipped) For more details, refer to “Advanced Smart Cruise Control System” in chapter 6. If this item is checked, the rear cross traffic alert function will be activated. Rear Cross Traffic Alert (if equipped) For more details, refer to “Blind Spot Detection System”...
  • Page 192 Features of your vehicle Door / Trunk Items Explanation • Enable on Speed: All doors will be automatically locked when the vehicle speed exceeds 15km/h (9.3mph). Automatically Lock • Enable on Shift: All doors will be automatically locked if the automatic transaxle shift lever is shifted from the P (Park) position to the R (Reverse), N (Neutral), or D (Drive) position.
  • Page 193 Features of your vehicle Light Items Explanation • Off: The one touch turn signal function will be deactivated. • 3, 5, 7 Flashes : The lane change signals will blink 3, 5, or 7 times when the turn signal lever is One Touch Turn Signal moved slightly.
  • Page 194 Features of your vehicle Service interval Items Explanation On this mode, you can activate the service interval function with mileage (km or mi.) and period (months). • Off : The service interval function will be deactivated. Service Interval • On :You can set the service interval (mileage and months). For more details, refer to “Service Mode”...
  • Page 195 Features of your vehicle Other features Items Explanation If this item is checked, the average fuel economy will reset automatically when refueling or after Fuel Economy Auto Reset ignition. Fuel Economy Unit Choose the fuel economy unit. (L/100km, km/L, US gallon, UK gallon) Temperature Unit Choose the temperature unit.
  • Page 196 Features of your vehicle TRIP MODES (TRIP COMPUTER) The trip computer is a microcomput- Trip Modes Fuel Economy er-controlled driver information sys- ■ Hybrid FUEL ECONOMY tem that displays information related to driving. • Distance To Empty • Average Fuel Economy ✽...
  • Page 197 Features of your vehicle • The range may differ from the actu- • If the estimated distance is below 1 ■ Plug-in hybrid al driving distance as it is an esti- km (1 mi.), the trip computer will mate of the available driving dis- display “---”...
  • Page 198 Features of your vehicle Average Fuel Economy (2) Automatic reset Instant Fuel Economy (3) • The average fuel economy is cal- To make the average fuel economy • This mode displays the instant fuel culated by the total driving dis- reset automatically whenever refuel- economy during the last few sec- tance and fuel consumption since...
  • Page 199 Features of your vehicle Trip A/B Average Vehicle Speed (2) Elapsed Time (3) • The average vehicle speed is cal- • The elapsed time is the total driv- culated by the total driving dis- ing time since the last elapsed time tance and driving time since the reset.
  • Page 200 Features of your vehicle Digital speedometer One time driving information Turn By Turn Mode (if equipped) mode OJFCH046222 OJF045223L OJF045285L This mode displays the current This mode displays the state of the This display shows trip distance (1), speed of the vehicle. navigation.
  • Page 201 Features of your vehicle ASCC/LDWS Mode A/V Mode (if equipped) Warning Messages (if equipped) Shift to P position (for smart key system) • This warning message illuminates if you try to turn off the engine without the shift lever in P (Park) position. •...
  • Page 202 Features of your vehicle Press start button while turn Check steering wheel lock sys- Key not in vehicle steering (for smart key system) tem (for smart key system) (for smart key system) • This warning message illuminates • This warning message illuminates •...
  • Page 203 Engine Start/Stop Button, have your vehi- Shift to P or N to start engine OJF045224L cle inspected by an authorized Kia (for smart key system) • It means that any door, hood, or dealer. trunk is open. • This warning message illuminates if you try to start the engine with •...
  • Page 204 Features of your vehicle ✽ ✽ NOTICE Sunroof Open (if equipped) Icy road warning light (if equipped) If the icy road warning light appears while driving, you should drive more attentively and safely refrain- ing from over-speeding, rapid accel- eration, sudden braking or sharp turning, etc.
  • Page 205 Kia dealer. - When the trip computer displays • It means that you should refill the “--- km (or mile)” as range.
  • Page 206 ❈For more details, refer - The air flap does not open ed by an authorized Kia dealer. “Autonomous Emergency Braking (AEB) system” in chapter 6. When all of the above conditions are Check Hybrid system. Do not fixed, the warning will disappear.
  • Page 207 Check brakes road conditions of the navigation. It the nearest authorized Kia dealer encourages the driver to remove foot This warning message illuminates and have the vehicle inspected.
  • Page 208 Features of your vehicle • User settings • Operation conditions Unplug vehicle to start (Plug-in hybrid) Press the Engine Start/Stop button To activate the system, take the fol- and put the shift lever in P(Park). In lowing procedures. Enter your desti- The message is displayed when you the User Settings Mode, select nation information on the navigation...
  • Page 209 Features of your vehicle EV/HEV/CHG modes Low battery temp. Maintaining Low/High System Temp. (Plug-in hybrid) current (Plug-in hybrid) Maintaining Hybrid (Plug-in hybrid) A corresponding message is dis- This message is displayed when played when a mode is selected by unable to convert to EV mode even This message is displayed when pressing the HEV button.
  • Page 210 Features of your vehicle Wait until fuel door opens Fuel door open (Plug-in hybrid) Open fuel door after disconnect- (Plug-in hybrid) ing charging cable This message is displayed when the (Plug-in hybrid) fuel filler lid is opened. The message is displayed when you attempt to open the fuel filler lid with This message is displayed when you Also means “Ready to refuel”.
  • Page 211 • When there is a malfunction with the SRS. In this case, have your vehicle This warning light illuminates: inspected by an authorized Kia when there is a malfunction with the dealer. hybrid system. In this case, have the vehicle inspected by an authorized Kia deal-...
  • Page 212 In this case, have your vehicle al engine braking and stop the vehi- - If the warning light illuminates towed to an authorized Kia dealer cle as soon as it is safe to do so. with the parking brake released, it and inspected.
  • Page 213 In this case, have your vehicle sudden braking thereby • When there is a malfunction with inspected by an authorized Kia increasing the risk of a crash the ABS (The normal braking sys- dealer. and injury. In this case, avoid...
  • Page 214 • When there is a malfunction with In this case, have your vehicle inspect- Warning light (red) and Regenerative the EPS. ed by an authorized Kia dealer as Brake Warning Light (yellow) to illu- soon as possible. minate simultaneously. In this case, have your vehicle...
  • Page 215 - Catalytic either the alternator or electrical Converter Damage charging system. In this case, have your vehicle inspected by an authorized Kia If the Malfunction Indicator dealer. Lamp (MIL) illuminates, poten- If there is a malfunction with either tial catalytic converter damage...
  • Page 216 Kia dealer as soon as immediately. In this case, have possible. your vehicle inspected by an authorized Kia dealer.
  • Page 217 In this case, have your vehicle Start/Stop Button to the ON posi- ly move to a safe position off the inspected by an authorized Kia tion. road. dealer as soon as possible. - It illuminates for approximately 3 ❈For more details, refer to “Tire...
  • Page 218 (if equipped) In this case, have the vehicle inspect- - Advanced Smart Cruise Control If there is a malfunction with the ed by an authorized Kia dealer. (ASCC) malfunction (if equipped) AFLS: - Tire Pressure Monitoring System 1. Drive carefully to the nearest safe (TPMS) malfunction (if equipped) location and stop your vehicle.
  • Page 219 • When there is a malfunction with the ESC system. CAUTION - Engine In this case, have your vehicle Overheating inspected by an authorized Kia Do not continue driving with the dealer. engine overheated. Otherwise engine may be damaged. This indicator light blinks: While the ESC is operating.
  • Page 220 6. seconds: the immobilizer system. • When the smart key is not in the In this case, have your vehicle vehicle. inspected by an authorized Kia - At this time, you can not start the dealer. engine. 4 91...
  • Page 221 Button is ON. the high beam position In this case, have your vehicle • When the turn signal lever is pulled inspected by an authorized Kia into the Flash-to-Pass position. If any of the following occurs, there dealer. may be a malfunction with the turn signal system.
  • Page 222 Kia In this case, have your vehicle inspect- ❈For more details, refer to “Cruise dealer. ed by an authorized Kia dealer. Control System” in chapter 6. ❈For more details, refer to “Auto ❈For more details, refer to “Lane Hold”...
  • Page 223 When the ready indicator goes OFF in chapter 6. or blinks, there is a problem with the This indicator illuminates when the system. In this case, have your vehi- vehicle is driven by the electric cle inspected by an authorized Kia motor. dealer.
  • Page 224 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING - Rear parking assist system assist system Operating condition Never rely solely on the rear • This system will activate when parking assist system. Always backing up with the ignition switch perform a visual inspection to make sure the vehicle is clear of...
  • Page 225 Features of your vehicle Types of warning sound Non-operational conditions of The detecting range may decrease when: rear parking assist system • When an object is 120 cm to 61 cm (47 in. to 24 in.) from the rear 1. The sensor is covered with foreign The rear parking assist system bumper: Buzzer beeps intermit- matter such as snow or water.
  • Page 226 Kia dealer as soon as possible. height or sensor installation has Always visually check behind the been modified or damaged. Any vehicle when backing up.
  • Page 227 Features of your vehicle REARVIEW CAMERA • This system is a supplementary WARNING - Backing & function only. It is the responsibility of the driver to always check the using camera inside/outside rearview mirrors and Never rely solely on the rear view the area behind the vehicle before camera when backing.
  • Page 228 Engine Start/Stop system should be checked by an Button is ON position authorized Kia dealer. - When the transaxle is on D, N or R • When the vehicle moves over 15 - When the vehicle speed is not over...
  • Page 229 Features of your vehicle LIGHTING Battery saver function Daytime running light Lighting control • The purpose of this feature is to The Daytime Running Lights (DRL) prevent the battery from being dis- can make it easier for others to see the charged if the lights are left in the front of your vehicle during the day.
  • Page 230 Features of your vehicle Auto light position Headlight position ( Parking & Tail light ( OJF045047 OJF045049 OJF045051 When the light switch is in the AUTO When the light switch is in the park- When the light switch is in the head- light position, the taillights and head- ing light position, the tail, license and light position, the head, tail, license...
  • Page 231 Features of your vehicle High beam operation WARNING - High beams Do not use high beam when there are other vehicles. Using high beam could obstruct the other driver’s vision. OJF045053 To flash the headlights, pull the lever OJF045055 towards you. It will return to the nor- To turn on the high beam headlamp, mal (low beam) position when push the lever away from you.
  • Page 232 Features of your vehicle High Beam Assist (if equipped) Operating condition The high beam switches to low beam in the below conditions. 1.Place the light switch in the AUTO position. - When the High Beam Assist is off. 2.Turn on the high beam by pushing - When the light switch is not in the the lever away from you.
  • Page 233 • When the road conditions are bad nate. We recommend you to contact front vehicle is covered with dust, such as being wet or covered with an authorized Kia dealer. snow or water. snow. • When the light from the on-coming •...
  • Page 234 Features of your vehicle ✽ ✽ NOTICE Turn signals and lane change If an indicator stays on and does not flash or if it flashes abnormally, one of signals • Do not place any accessories, the turn signal bulbs may be burned stickers or tint the windshield.
  • Page 235 Kia dealer. headlamp. Kia dealer. Do not attempt to inspect or replace Change the switch to the AUTO posi- ✽...
  • Page 236 If the AFLS malfunction indicator comes on, the AFLS is not working properly. Drive to the nearest safe location and restart the engine. If the indicator continuously remains on, have system be checked by an authorized Kia dealer. 4 107...
  • Page 237 Features of your vehicle WIPERS AND WASHERS Windshield wipers Auto control (if equipped) Windshield wiper/washer Operates as follows when the igni- tion switch is turned ON. MIST : For a single wiping cycle, move the lever to this (MIST) position and release it. The wipers will operate continu- ously if the lever is held in this position.
  • Page 238 Features of your vehicle (Continued) CAUTION CAUTION • When starting the vehicle in When the engine start/stop but- • When washing the vehicle, set winter, set the wiper switch in ton is in the ON position and the the wiper switch in the OFF the OFF position.
  • Page 239 Features of your vehicle Front windshield washers The reservoir filler neck is located in CAUTION - Wipers & the front of the engine compartment windshields on the passenger side. • To prevent possible damage to the wipers or windshield, CAUTION - Washer pump do not operate the wipers To prevent possible damage to...
  • Page 240 Features of your vehicle INTERIOR LIGHTS Do not use the interior lights for Automatic turn off function Room lamp extended periods when the engine is (if equipped) ■ Type A not running. The interior lights automatically turn It may cause battery discharge. off approximately 20 minutes after the ignition switch is turned off, if the lights are in the ON position.
  • Page 241 Features of your vehicle ✽ ✽ NOTICE Map lamp • (2) : DOOR mode The DOOR mode and ROOM mode ■ Type A - The map lamp and room lamp can not be selected at the same time. come on when a door is opened. The lamps go out after approxi- Front Room Lamp: mately 30 seconds.
  • Page 242 Features of your vehicle Trunk room lamp Vanity mirror lamp Glove box lamp OJFH045069 OJF045072 OJF045071 The trunk room lamp comes on Opening the lid of the vanity mirror The glove box lamp comes on when when the trunk is opened. will automatically turn on the mirror the glove box is opened.
  • Page 243 Features of your vehicle WELCOME SYSTEM (IF EQUIPPED) Headlight (Headlamp) escort Interior light Pocket lamp (if equipped) function When the interior light switch is in the When all doors are locked and DOOR position and all doors (and closed, the pocket lamp will come on The headlights (and/or taillights) trunk) are locked and closed, the for 15 seconds if any of the below is...
  • Page 244 Features of your vehicle DEFROSTER Rear window defroster activate rear window CAUTION - Conductors defroster, press the rear window defroster button located in the center To prevent damage to the con- facia switch panel. The indicator on ductors bonded to the inside the rear window defroster button illu- surface of the rear window, minates when the defroster is ON.

  • Page 245: Automatic Climate Control System

    Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM ■ ■ Type A 1. Driver’s temperature control knob 2. AUTO (automatic control) button 3. Front windshield defroster button 4. Rear window defroster button 5. Air conditioning button 6. Air intake control button 7.
  • Page 246 Features of your vehicle ✽ ✽ NOTICE Automatic heating and air con- ■ ■ Driver’s side Passenger’s side ditioning • To turn the automatic operation off, select any button or switch of the following: - Mode selection button - Air conditioning button - Front windshield defroster button (Press the button one more time to deselect the front windshield...
  • Page 247 Features of your vehicle Manual heating and air condi- 4. Set the air intake control to the ■ Type A outside (fresh) air position. tioning 5. Set the fan speed control to the The heating and cooling system can desired speed. be controlled manually by pressing buttons or turning knob(s) other than 6.
  • Page 248 Features of your vehicle Mode selection OJFH045087 The mode selection button controls the direction of the air flow through the ventilation system. The air flow outlet port is converted as follows: (if equipped) (if equipped) OJFA045076 4 119...
  • Page 249 Features of your vehicle Floor/Defrost-Level Face-Level (B, D) (A, C, D, E, F) Most of the air flow is directed to the Air flow is directed toward the upper floor and the windshield with a small body and face. Additionally, each amount directed to the side window outlet can be controlled to direct the defrosters.
  • Page 250 Features of your vehicle Temperature control ■ ■ Driver’s side Passenger’s side OJF045078 OJF045090 Instrument panel vents Adjusting the driver and passenger OJF045089 side temperature equally The outlet vents can be opened or The temperature will increase to the closed separately using the thumb- •...
  • Page 251 Features of your vehicle Adjusting the driver and passenger Air intake control Outside (fresh) air position side temperature individually With the outside (fresh) • Press the “SYNC” button again to air position selected, air adjust the driver and passenger enters the vehicle from side temperature individually.
  • Page 252 Features of your vehicle Prolonged operation of the heater in Fan speed control Air conditioning the recirculated air position (without air conditioning selected) may cause fog- ging of the windshield and side win- dows and the air within the passenger compartment may become stale.
  • Page 253 Features of your vehicle OFF mode Climate information screen WARNING - Recirculated selection (if equipped) Continued use of the climate control system in the recirculat- ed air position can cause drowsiness or sleepiness, and loss of vehicle control. Set the air intake control to the outside (fresh) air position as much as possible while driving.
  • Page 254 Features of your vehicle Driver Only Economy air conditioning Automatic Ventilation button (ECON) (if equipped) When the ignition is ON or when the engine is running and the outside temperature is below 15°C (59°F), the automatic ventilation feature will activate if the recirculated air intake position is selected for more than 5 minutes while A/C is off and floor mode is selected.
  • Page 255 Features of your vehicle System operation Operation Tips Air conditioning (if equipped) • To keep dust or unpleasant fumes All Kia Air Conditioning Systems are Ventilation from entering the vehicle through filled with R-1234yf refrigerant. 1.Set the mode to the position.
  • Page 256 Features of your vehicle Air conditioning system operation tips • When using the air conditioning CAUTION - Excessive A/C system, you may notice clear water • If the vehicle has been parked in dripping (or even puddling) on the direct sunlight during hot weather, ground under the passenger side When using the air conditioning open the windows for a short time...
  • Page 257 (fresh) air position is selected. If this hap- pens, have the climate control air fil- ter replaced by an authorized Kia dealer.
  • Page 258 Features of your vehicle CAUTION It is important that the correct type and amount of oil and refrigerant is used, otherwise damage to the vehicle may occur. To prevent damage, the air conditioning system in your vehicle should only be serviced by trained and certified techni- cians.
  • Page 259 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the Automatic climate control WARNING - Windshield temperature control to the extreme system heating right/hot position and the fan speed To defog inside windshield control to the highest speed. Do not use the posi- tion during cooling operation in...
  • Page 260 Features of your vehicle If the air conditioning and outside To defrost outside windshield Defogging logic (fresh) air position are not selected To reduce the possibility of fogging automatically, adjust the correspon- up the inside of the windshield, the ding button manually. If the posi- air intake or air conditioning is con- tion is selected, lower fan speed is...
  • Page 261 Features of your vehicle Automatic climate control system Auto defogging system This indicator illuminates (if equipped) when the auto defogging system senses the mois- ture on the inside of the windshield and operates. If more moisture is in the vehicle, higher steps operate as follow.
  • Page 262 Features of your vehicle CLEAN AIR (IF EQUIPPED) To cancel or reset the Auto Defogging System Press the front windshield defroster button for 3 seconds when the igni- tion switch is in the ON position. When the Auto Defogging System is canceled, ADS OFF symbol will blink 3 times and the ADS OFF will be dis- played on the climate control infor-...
  • Page 263 Features of your vehicle STORAGE COMPARTMENTS These compartments can be used to Center console storage Glove box store small items required by the driver or passengers. • To avoid possible theft, do not leave valuables in the storage compartment. • Always keep the storage compart- ment covers closed while driving.
  • Page 264 Features of your vehicle Sunglass holder WARNING - WARNING Glove Box - Sunglass holder To reduce the risk of injury in an accident or sudden stop, always Do not keep objects except sun- keep the glove box door closed glasses inside the sunglass while driving.
  • Page 265 Features of your vehicle INTERIOR FEATURES ■ Front seat Cup holder Bottle holder WARNING Hot liquids Do not place uncovered cups with hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you may burn yourself.

  • Page 266: Seat Warmer

    Features of your vehicle Seat warmer (if equipped) During mild weather or under condi- WARNING - Seat warmer tions where the operation of the seat ■ Front seat warmer is not needed, keep the burns switches in the “OFF” position. The seat warmer may cause •...

  • Page 267: Air Ventilation Seat

    Features of your vehicle Air ventilation seat (if equipped) • The seat warmer (with air ventila- Sunvisor tion) defaults to the OFF position whenever the ignition switch is turned on. CAUTION - Seat damage • When cleaning the seats, do not use an organic solvent such as paint thinner, ben- zene, alcohol and gasoline.

  • Page 268: Power Outlet

    Features of your vehicle * The actual sunvisor lamp in the vehi- Power outlet (if equipped) • Use the power outlet only when the cle may differ from the illustration. engine is running and remove the ■ Front seat accessory plug after use. Using the accessory plug for prolonged peri- CAUTION - Vanity mirror...

  • Page 269: Usb Charger

    Features of your vehicle • Plug in battery equipped electronic USB charger (if equipped) The battery charging state may be devices with reverse current pro- monitored on the electrical device. ■ Front seat tection. The current from the bat- Disconnect the USB cable from the tery may flow into the vehicle’s USB port after use.
  • Page 270 Features of your vehicle Wireless smart phone charg- For best wireless charging results, Wireless smart phone charging place the smart phone on the center ing system (if equipped) 1. Remove any object on the smart of the charging pad. phone charging pad including the The wireless charging system is smart key.
  • Page 271 Features of your vehicle If the wireless charging is not func- CAUTION WARNING - - Liquid in Distracted tioning properly, the orange light will Wireless Smart Phone blink and flash for ten seconds then driving Charger turn off. In such cases, remove the Driving while distracted can smart phone from the pad and To prevent liquid from damag-...
  • Page 272 Features of your vehicle ✽ ✽ NOTICE (Continued) (Continued) • The wireless charging will stop • Smart phones of some manufac- • If it is not possible to close the tray when any of the doors is opened turers may display messages on cover due to the size of your smart (applicable for vehicles equipped weak current.
  • Page 273 Features of your vehicle Coat hook (if equipped) Floor mat anchor (s) WARNING (if equipped) ■ ■ Type A Type B OJF046403 OJF045235 ❈ This actual feature may differ from the illus- Do not hang other objects such OXM043309 as hangers or hard objects tration.
  • Page 274 To avoid any back to the stowed position. Do not interference with pedal operation, release handle after disengaging Kia recommends that only the Kia from the hooks on the door. floor mat designed for use in your vehicle be installed.

  • Page 275: Audio System

    Audio system Audio System ......5-2 • Antenna ........5-2 •...
  • Page 276 Audio system AUDIO SYSTEM ✽ ✽ NOTICE Antenna Shark fin antenna (if equipped) The shark fin antenna will receive the If you install an aftermarket HID transmit data. head lamp, your vehicle’s audio and electronic device may malfunction. CAUTION • Do not clean the inside of the rear window glass with a cleaner or use a scraper to remove foreign deposits as...

  • Page 277: Steering Wheel Audio Controls

    Audio system Steering Wheel Audio Controls VOLUME ( / ) (1) (Continued) (if equipped) • Press the lever upward ( ) to • When putting a sticker on the increase the volume. inside surface of the rear win- ■ ■ Type A Type B •...
  • Page 278 Audio system RADIO mode MUTE (4, if equipped) AUX, USB port It will function as the PRESET STA- • Press the button to mute the TION buttons. sound. • Press the button to turn off the microphone during a telephone CD/USB/iPod ®...
  • Page 279 Audio system How Vehicle Eadio Works This can be due to factors, such as AM reception the distance from the radio station, FM reception closeness of other strong radio sta- tions or the presence of buildings, bridges or other large obstructions in the area.
  • Page 280 Audio system FM radio station JBM004 OJF045311L • Fading - As your vehicle moves • Station Swapping - As an FM sig- OJF045310L away from the radio station, the nal weakens, another more power- FM broadcasts are transmitted at signal will weaken and sound will ful signal near the same frequency high frequencies and do not bend to begin to fade.
  • Page 281 Audio system Using a cellular phone or a two- way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equipment. In such a case, try to operate mobile devices as far from the audio equipment as possible.
  • Page 282 Audio system Declaration of Conformity This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions : (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.

  • Page 283: Driving Your Vehicle

    Driving your vehicle Before driving ......6-4 • AEB warning message and system control ..6-44 •...
  • Page 284 Active ECO system......6-75 • Check battery and cables ..... . 6-96 •...
  • Page 285 2. Open side vents. exhaust system checked as soon as 3. Set the air intake control at possible by an authorized Kia dealer. "Fresh", the air flow control at "Floor" or "Face" and the fan WARNING - Engine at the highest speed.
  • Page 286 Driving your vehicle BEFORE DRIVING Before entering vehicle Necessary inspections Before starting • Be sure that all windows, outside Fluid levels, such as engine oil, • Close and lock all doors. mirror(s), and outside lights are engine coolant, brake fluid, and •...
  • Page 287 Driving your vehicle WARNING WARNING WARNING - Fire risk - Loose - Driving while objects intoxicated When you intend to park or stop the vehicle with the engine on, Securely store items in your Do not drive while intoxicated. be careful not to depress the vehicle.
  • Page 288 Driving your vehicle ENGINE START/STOP BUTTON Illuminated ENGINE ENGINE START/STOP button In an emergency situation while the vehicle is in motion, you are able to START/STOP button position turn the hybrid system off and to the ACC position by pressing the ENGINE START/STOP button for more than 2 seconds or 3 times suc- cessively within 3 seconds.
  • Page 289 Driving your vehicle ACC(Accessory) START/RUN Amber Super red Not illuminated Press the ENGINE START/STOP Press the ENGINE START/STOP To start the hybrid system, depress button while it is in the OFF position button while it is in the ACC position the brake pedal and press the without depressing the brake pedal.
  • Page 290 Driving your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE Starting the hybrid system If you leave the ENGINE START/ • The hybrid system will start by STOP button in the ACC or ON WARNING pressing the Engine Start/Stop position for a long time, the battery button, only when the smart key is •...
  • Page 291 Driving your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE 1. Always carry the smart key with you. • Do not wait for the engine to warm To prevent damage to the vehicle: 2. Make sure the parking brake is up while the vehicle remains sta- •...
  • Page 292 Driving your vehicle • When the stop lamp fuse is blown, WARNING - Unintended you can't start the hybrid system vehicle movement normally. Replace the fuse with a new one. If it is not possible, you can Never leave the smart key in the start the hybrid system by pressing vehicle with children or vehicle the ENGINE START/STOP button...
  • Page 293 Driving your vehicle AUTOMATIC TRANSAXLE Automatic transaxle operation The automatic transaxle has 6 for- ward speeds and one reverse speed. The individual speeds are selected automatically, depending on the position of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may be somewhat abrupt.
  • Page 294 Driving your vehicle For smooth operation, depress the Transaxle ranges CAUTION - Transaxle brake pedal and the lock release but- The indicator in the instrument clus- ton when shifting from N (Neutral) to avoid damage your ter displays the shift lever position a forward or reverse gear.
  • Page 295 Driving your vehicle R (Reverse) N (Neutral) 3. While depressing the brake pedal, turn the ignition button OFF. Use this position to drive the vehicle The wheels and transaxle are not backward. engaged. The vehicle will roll freely - For smart key equipped vehicles, even on the slightest incline unless the ignition switch can be moved the parking brake or service brakes...
  • Page 296 Driving your vehicle D (Drive) WARNING This is the normal forward driving • With the exception of parking position. The transaxle will automati- in neutral gear, always park the cally shift through 6-gear vehicle in [P] (Park) for safety sequence, providing the best fuel and apply the parking brake.
  • Page 297 Driving your vehicle In manual mode, moving the shift • In manual mode, the driver must • When driving on a slippery road, lever backwards and forwards will execute upshifts in accordance push the shift lever forward into the allow you to make gearshifts rapidly. with road conditions, taking care to +(up) position.
  • Page 298 Driving your vehicle Shift lock system WARNING - Shifting from For your safety, the automatic park transaxle has a shift lock system which prevents shifting the transaxle Always fully depress the brake from P (Park) into R (Reverse) pedal before and while shifting unless the brake pedal is depressed.
  • Page 299 D 7. Have your vehicle inspected by an • Never move the gear shift lever into (Drive). Select the appropriate gear authorized Kia dealer. P (Park) when the vehicle is in depending on load weight and steep- motion.
  • Page 300 Driving your vehicle BRAKE SYSTEM Power brakes Wet brakes may impair the vehicle’s CAUTION - Brake Pedal ability to safely slow down; the vehi- Your vehicle has power-assisted cle may also pull to one side when Do not drive with your foot rest- brakes that adjust automatically the brakes are applied.
  • Page 301 Driving your vehicle In the event of brake failure Disc brakes wear indicator WARNING - Brake wear If service brakes fail to operate while When your brake pads are worn and the vehicle is in motion, you can new pads are required, you will hear Do not ignore high pitched wear make an emergency stop with the a high-pitched warning sound from...
  • Page 302 Driving your vehicle Parking brake – Foot type Releasing the parking brake WARNING - Parking brake (if equipped) Applying the parking brake • Never allow a passenger to touch the parking brake. If the parking brake is released unintentionally, serious injury may occur.
  • Page 303 Driving your vehicle If at all possible, cease driving the Electronic parking brake (EPB) vehicle immediately. If that is not pos- (if equipped) sible, use extreme caution while Applying the parking brake operating the vehicle and only contin- ue to drive the vehicle until you can reach a safe location or repair shop.
  • Page 304 Driving your vehicle Also, the EPB is applied automatical- Do not operate the parking brake/ Releasing the parking brake ly if the Auto Hold button is on when EPB while the vehicle is moving the engine is turned off. except in an emergency situation. ✽...
  • Page 305 EPB has 4. Depress the accelerator pedal been released, have the system while the shift lever is in R (Rear), checked by an authorized Kia dealer. D (Drive) or Sports mode. Make sure the brake warning light CAUTION goes off.
  • Page 306 Driving your vehicle System warning If the above situation occurs, depress • A click or electric brake motor the brake pedal and release EPB by whine sound may be heard while pressing the EPB switch. operating or releasing the EPB, but these conditions are normal and indicate that the EPB is functioning WARNING...
  • Page 307 Driving your vehicle ✽ ✽ NOTICE System warning System warning Depress the brake pedal when the ■ ■ Type A Type A above message appears for the Auto Hold and EPB may not activate. OJF055249L OJF055251L ■ ■ Type B Type B OJF055250L OJF055252L...
  • Page 308 EPB malfunction indicator If this occurs, have your vehicle • The EPB warning light may illumi- (if equipped) checked by an authorized Kia dealer nate if the EPB switch operates as soon as possible. abnormally. Shut the engine off and turn it on again after a few min- The EPB malfunction indicator may utes.
  • Page 309 EPB switch. Braking is Kia dealer by loading the vehicle on the system is operating. possible only while you are holding a flatbed tow truck and have the sys- the EPB switch.
  • Page 310 Driving your vehicle AUTO HOLD (if equipped) The Auto Hold maintains the vehicle in a standstill even though the brake pedal is not depressed after the driv- er brings the vehicle to a complete stop by depressing the brake pedal. OJFA055020 OJF055021 1.Depress the brake pedal, start the...
  • Page 311 Driving your vehicle ✽ ✽ NOTICE 4. If you press the accelerator pedal Cancel with the shift lever in D (Drive) or • The following are conditions when manual mode, the Auto Hold will the Auto Hold will not engage be released automatically and the (Auto Hold light will not turn vehicle will start to move.
  • Page 312 Auto Hold may not indicator changes from green to work properly. white, and a warning sounds and a Take your vehicle to an authorized Kia message will appear to inform you dealer and have the system checked. that EPB has been automatically engaged.
  • Page 313 Driving your vehicle ✽ ✽ NOTICE ■ ■ Type A Type A When this message is displayed, the Auto Hold and EPB may not oper- ate. For your safety, depress the brake pedal. OJF055120L OJF055126L ■ ■ Type B Type B OJF055121L OJF055127L AUTO HOLD deactivating.
  • Page 314 Driving your vehicle Anti-lock brake system (ABS) The ABS continuously senses the speed of the wheels. If the wheels ABS (or ESC) will not prevent acci- are going to lock, the ABS system dents due to improper or dangerous repeatedly modulates the hydraulic driving maneuvers.
  • Page 315 ABS. Contact an the ABS warning light may turn on at authorized Kia dealer as soon as the same time. This happens because possible. of low battery voltage. It does not mean your ABS has malfunctioned.
  • Page 316 Driving your vehicle Electronic stability control Electronic stability control (ESC) will The Electronic Stability Control (ESC) not prevent accidents. Excessive system is an electronic system (ESC) speed in turns, abrupt maneuvers designed to help the driver maintain and hydroplaning on wet surfaces vehicle control under adverse condi- can still result in serious accidents.

  • Page 317: Esc Off Button

    Driving your vehicle ESC operation When operating ESC operation off When the ESC is in opera- ESC ON condition ESC OFF state tion, the ESC indicator light • When the engine start/stop This car has 2 kinds of ESC blinks. button is turned ON, ESC off states.
  • Page 318 Driving your vehicle ■ Type A ■ Type A Indicator light ■ ESC indicator light ■ ESC OFF indicator light OJF055253L OJF055255L ■ Type B ■ Type B When engine start/stop button is turned to ON, the indicator light illu- minates, then goes off if the ESC system is operating normally.
  • Page 319 Driving your vehicle ✽ ✽ NOTICE ESC OFF usage WARNING - Electronic sta- When driving • When operating the vehicle on a bility control dynamometer, ensure that the • ESC should be turned on for daily Drive carefully even though your ESC is turned off (ESC OFF light driving whenever possible.
  • Page 320 Driving your vehicle Vehicle stability management VSM operation VSM operation off (VSM) When the VSM is in operation, ESC If you press the ESC OFF button to indicator light ( ) blinks. turn off the ESC, the VSM will also This system provides...

  • Page 321: Brake Pedal

    2 seconds. authorized Kia dealer and have the even with installed VSM. Always fol- The HAC is activated only for about 2 system checked.
  • Page 322 Then release the parking brake. vehicle is stopped. ized Kia dealer for assistance. • Do not hold the vehicle on an • Be cautious when parking on a hill. • Don't coast down hills with the incline with the accelerator pedal.
  • Page 323 Driving your vehicle AUTONOMOUS EMERGENCY BRAKING (AEB)/ FORWARD COLLISION WARNING (FCW) (IF EQUIPPED) ✽ ✽ NOTICE The AEB system is to reduce or to System setting and activation avoid accident risk. It recognizes the Take the following precautions when System setting distance from the vehicle ahead or using the Autonomous Emergency ■...
  • Page 324 The driver can monitor the AEB ON/OFF status on the LCD display. When the warning light remains ON with the AEB acti- vated, have your vehicle inspected by an authorized Kia dealer. OJFA055277 OJFA055278 OJF055179L OJF055075L The driver can select the initial warning activation time in the User Settings in the instrument cluster LCD display.
  • Page 325 Driving your vehicle • EARLY - When this condition is Prerequisite for activation • The AEB automatically activates selected, initial when you turn the vehicle on. The AEB will activate activated when Forward Collision Warning the AEB is selected on the LCD dis- The driver can deactivate the AEB is activated earlier than play, and when the following prereq-...
  • Page 326 Driving your vehicle AEB warning message and Forward Warning (1st warning) Collision Warning (2nd warning) system control The AEB produces warning mes- sages, warning alarms, and emer- gency braking based on the level of risk of a frontal collision, such as when a vehicle ahead suddenly brakes, when there is no following dis- tance from the vehicle in front, or...
  • Page 327 Driving your vehicle Emergency braking (3 warning) Brake operation WARNING • In an urgent situation, the braking The AEB cannot avoid all colli- system enters into the ready status sions. The AEB might not com- for prompt reaction against the dri- pletely stop the vehicle before ver’s depressing the brake pedal.
  • Page 328 Kia dealer. sensing performance. It may even • Use only the genuine Kia sensor temporarily cancel the AEB. Always This is not a malfunction with the cover. Do not arbitrarily apply keep the sensor lens clean.
  • Page 329 After the message disappears, the master warning light ( ) will illu- minate. In this case, have your vehi- cle inspected by an authorized Kia dealer. 6 47...
  • Page 330 Driving your vehicle Limitation of the system Recognizing vehicles - The vehicle in front does not turn ON the rear lights, does not have - The radar or the camera is con- The AEB is an assistant system for a rear lights, has asymmetric rear taminated with foreign substances.
  • Page 331 Driving your vehicle OJF055025 OJF055026 OJF055027 - Driving on a curve While driving on a curve, the AEB - Driving on a slope may recognize the vehicle in front in The AEB performance decreases The AEB performance decreases the next lane. Exercise caution, and, if while driving on a curve.
  • Page 332 Driving your vehicle OJF055028 OJF055029 OJF055030 - Changing lanes When the stopped vehicle in front - Recognizing the vehicle gets out of the lane, it may not be Even though the vehicle in the next When the vehicle in front has heavy recognized by your AEB.
  • Page 333 Driving your vehicle Recognizing pedestrians • Pay great caution to the vehicle in WARNING - Testing the front, when it has heavy loading - The pedestrian is not fully captured extended rearward, or when it has by the camera sensor, or the higher ground clearance.
  • Page 334 Driving your vehicle CRUISE CONTROL SYSTEM ✽ ✽ NOTICE Use the cruise control system only when traveling on open highways in • During normal cruise control oper- good weather. ation, when the SET switch is acti- Do not use the cruise control when vated or reactivated after applying driving in heavy or varying traffic, or the brakes, the cruise control will...
  • Page 335 Driving your vehicle To set cruise control speed: To increase cruise control set speed: OJF055039 3. Move the lever down (to SET-), OJF055038 and release it at the desired OJF055040 1. Press the CRUISE button on the speed. The SET indicator light in steering wheel to turn the system Follow either of these procedures: the instrument cluster will illumi-...
  • Page 336 Driving your vehicle To decrease the cruising To temporarily accelerate with To cancel cruise control, do speed: the cruise control on: one of the following: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with the cruise control operation or change the set speed.
  • Page 337 Driving your vehicle Each of these actions will cancel To resume cruising speed at To turn cruise control off, do cruise control operation (the SET more than approximately 30 one of the following: indicator light in the instrument clus- km/h (20 mph): ter will go off), but it will not turn the system off.
  • Page 338 Driving your vehicle ADVANCED SMART CRUISE CONTROL SYSTEM (ASCC) (IF EQUIPPED) WARNING WARNING - Advanced Smart Cruise Control - Advanced Smart Cruise Inadvertent Activation Control Limitations If the advanced smart cruise • The advanced smart cruise control is left on (CRUISE indi- control is a supplemental sys- cator in the instrument cluster tem and is not a substitute for...
  • Page 339 Driving your vehicle Speed setting (ASCC) (Continued) To set cruise control speed: • Use advanced smart cruise control system only when traveling on open high- ways in good weather condi- tions. CAUTION Cruise function should not be used when the vehicle is being OJF055043 towed to prevent any damage.
  • Page 340 Driving your vehicle ✽ ✽ NOTICE To increase cruise control set To decrease the cruise control speed: set speed: Make sure to check road conditions, for driving speed will sharply increase if the lever is pushed upwards. OJF055044 OJF055043 Follow either of these procedures: Follow either of these procedures: •...
  • Page 341 Driving your vehicle To temporarily accelerate with the ASCC will be temporarily can- Cancelled automatically cruise control on: celed when: • The driver's door is opened. If you want to speed up temporarily • The shift lever is shifted to N when the cruise control is on, (Neutral), R (Reverse) or P(Parking).
  • Page 342 If you move the lever up (to RES+), Always check the road conditions. checked by an authorized Kia dealer. the speed will resume to the recently Do not rely on the warning chime. set speed. It will not resume if the vehicle speed has dropped below approximately 30 km/h (20 mph).
  • Page 343 Driving your vehicle ✽ ✽ NOTICE To turn cruise control off: WARNING - Following When pushing the lever up for reset- Distance ting, the speed might sharply • To avoid collisions, always be increase or decrease to the speed set aware of the selected speed just before it was cancelled.
  • Page 344 Driving your vehicle Vehicle to vehicle distance The vehicle to vehicle distance will For example, if you drive at 56 mph automatically activate when the (90 km/h), the distance is maintained setting (ASCC) ASCC is on. as follows; To set vehicle to vehicle distance: Select the appropriate distance according to road conditions and Distance 4 - approximately 52.5 m...
  • Page 345 Driving your vehicle • If the vehicle ahead speeds up, your vehicle will travel at a steady cruising speed after accelerating to the selected speed. • The warning chime sounds and LCD display blinks if it is hard to maintain the selected distance to the vehicle ahead.
  • Page 346 Driving your vehicle ✽ ✽ NOTICE Collision Alert • Even when the indicator display- ing the distance with the vehicle in front does not blink or the colli- sion alert does not sound, always drive safely. • Depending on the use of radio, sound quality, and driving condi- tions, you may not be able to hear the warning sound.
  • Page 347 Driving your vehicle In heavy traffic Radar to detect distance to the Radar check message vehicle ahead OJFA056100CF OJFA056188CF OJFH056162N In traffic, your vehicle will stop if the If the radar or cover is dirty or obscured with foreign matter such as vehicle ahead of you stops.
  • Page 348 To adjust the sensitivity of Control) malfunction message bumper clean. Advanced Smart Cruise Control • Use only a genuine Kia sensor cover for your vehicle. • Do not install accessories around the sensor and do not replace the bumper by yourself. It may interfere with the sensor performance.
  • Page 349 Driving your vehicle • Normal: To convert to cruise control 1.Turn the ASCC on (the cruise indi- cator light will be on but the system mode: Vehicle speed following the front will not be activated). vehicle to maintain the set distance is normal 2.Push the distance to distance switch for more than 2 seconds.
  • Page 350 Driving your vehicle Limitations of the system On curves • On curves, the ASCC may not detect a moving vehicle in your lane, and then your vehicle could accelerate to the set speed. Also, the vehicle speed will rapidly slow down when the vehicle ahead is recognized suddenly.
  • Page 351 Driving your vehicle On inclines Lane changing OJF055049 • Your vehicle may accelerate when OJF055027 OJF055028 a vehicle ahead of you disappears. • During uphill or downhill driving, the • A vehicle which moves into your • When you are warned that the ASCC may not detect a moving lane from an adjacent lane cannot vehicle ahead of you is not detect-...
  • Page 352 Driving your vehicle Vehicle recognition A vehicle ahead cannot be recog- nized correctly by the sensor if any of following occurs: - When the vehicle is pointing upwards due to overloading in the trunk - While making turns by steering - When driving to one side of the lane - When driving on narrow lanes or on curves...
  • Page 353 Driving your vehicle WARNING - Safe Use of ASCC The ASCC can provide you with an additional level of safety and fatigue reduction. However you must maintain careful observa- tion of the roadway in front and around you and maintain control of your vehicle and spacing around other vehicles as you normally would.
  • Page 354 Driving your vehicle This device complies with WARNING - Inclines & Industry Canada licence-exempt Towing RSS standard(s). Do not use ASCC on steep Operation is subject to the following inclines or when towing another conditions: vehicle or trailer since such (1) This device may not cause inter- extreme loading can interfere ference, and...
  • Page 355 Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM (IF EQUIPPED) Hybrid vehicle The drive mode may be selected ECO mode (Active ECO) according to the driver’s preference Active ECO helps improve ■ Type A or road condition. fuel efficiency by control- The system resets to be in the ECO ling certain engine and mode, when the hybrid system is...
  • Page 356 Driving your vehicle When Active ECO is activated: Limitation of Active ECO opera- SPORT mode tion: • The acceleration may slightly be SPORT mode focuses on reduced even though you depress If the following conditions occur while dynamic driving by auto- SPORT the accelerator fully.
  • Page 357 Driving your vehicle ACTIVE ECO SYSTEM (IF EQUIPPED) Plug-in hybrid vehicle The mode changes whenever the ECO mode (Active ECO) DRIVE MODE button is pressed. Active helps improve fuel efficiency by NORMAL controlling certain engine transaxle system operating parameters. ❈ When normal mode is selected, it Fuel efficiency depends is not displayed on the cluster.
  • Page 358 Driving your vehicle When Active ECO is activated: Limitation of Active ECO operation: • The acceleration may slightly be If the following conditions occur while reduced eventhough you depress Active ECO is operating, the system the accelerator fully. operation is limited even though there is no change in the ECO indicator.
  • Page 359 Driving your vehicle BLIND SPOT DETECTION SYSTEM (BSD) (IF EQUIPPED) (1) BSD (Blind Spot Detection) WARNING - BSD The warning range depends on Limitations your vehicle speed. However, if your vehicle is about 10 km/h (6 • The Blind Spot Detection mph) faster than the other vehi- System (BSD) is a supplemen- cle, the system will not warn you.
  • Page 360 Driving your vehicle BSD (Blind Spot Detection) / When the system is not used turn the Warning type system off by turning off the switch. LCA (Lane Change Assist) The system will activate when: When the system is turned on the 1.
  • Page 361 Driving your vehicle - The second stage alarm may be 1st stage 2nd stage deactivated. • To activate the alarm: Go to the User Settings Mode → Sound and select "BSD" on the LCD display. • To deactivate the alarm: Go to the User Settings Mode →...
  • Page 362 “Blind Spot Detection disabled. Radar removed, take your vehicle to an blocked” authorized Kia dealer and have the The message will appear to notify system checked. the driver with one of followings. The light on the switch and the system will turn off automatically.
  • Page 363 Have your vehicle inspected by an standby to activate. information to the driver. authorized Kia dealer. • Select RCTA again, to turn the sys- tem off. • If the vehicle is turned off, the RCTA system will remember the last settings upon restart.
  • Page 364 Driving your vehicle • The system operates when the Warning type • If the vehicle detected by sensors vehicle speed is below 10 km/h approaches your vehicle, the warn- (6.2 mph) with the shift lever in R ing chime will sound and the warn- (Reverse).
  • Page 365 Driving your vehicle Limitations condition - A fixed object is near such as a WARNING guardrail, etc. Driver's Attention Blind Spot Detection - A substantial amount of metallic The driver must be cautious in the System with Lane Change objects such as a construction below situations for the system may Assist and Rear Cross Traffic area.
  • Page 366 Driving your vehicle - When the temperature of the rear Outside rearview mirror may not This device complies with bumper is high or low. alert the driver when: Industry Canada licence-exempt RSS standard(s). - When the temperature near the - The outside rearview mirror hous- rear bumper is high or low.
  • Page 367 Driving your vehicle LANE DEPARTURE WARNING SYSTEM (LDWS) (IF EQUIPPED) This system detects the lane with a • The LDWS does not make the sensor at the front windshield and vehicle change lanes. It is the dri- notifies you if it detects that your ver's responsibility to always check vehicle leaves the lane.
  • Page 368 Driving your vehicle • Do not turn the steering wheel sud- ■ Left lane departure warning denly, when the LDWS warns you that your vehicle is leaving the lane. To operate the LDWS, press the but- ton with the engine start/stop button in the ON position.

  • Page 369: Hazard Warning Flasher

    Driving your vehicle 2. Auditory warning Warning indicator Take your vehicle to an authorized Kia dealer and have the system If you leave the lane, the warning checked. sound operates for maximum 3 sec- onds. The color of symbol will change...
  • Page 370 Driving your vehicle Conditions that cause missed • The lane line is damaged or indis- • Driving with the sun in front of you. tinct. warnings and false warnings: • Driving in areas under construc- • The windshield is fogged up by tion.
  • Page 371 Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Don't "ride" the brake pedal. This • Keep your vehicle in good condi- mainly on your style of driving, where can increase fuel consumption and tion. For better fuel economy and you drive and when you drive.
  • Page 372 Driving your vehicle • Remember, your vehicle does not • Use your air conditioning sparingly. WARNING - Engine off require extended warm-up. After The air conditioning system is the engine has started, allow the operated by engine power so your during motion engine to run for 10 to 20 seconds fuel economy is reduced when you...
  • Page 373 Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions • If stalled in snow, mud, or sand, Rocking the vehicle use the second gear. Accelerate When hazardous driving conditions If it is necessary to rock the vehicle slowly to avoid spinning the drive are encountered such as water, to free it from snow, sand, or mud, wheels.
  • Page 374 Driving your vehicle Smooth cornering Driving at night CAUTION - Vehicle rocking Prolonged rocking may cause engine overheating, transaxle damage or failure, and tire dam- age. CAUTION - Spinning tires Do not spin the wheels, espe- cially at speeds more than 35 mph (56 km/h).
  • Page 375 Driving your vehicle • Adjust your mirrors to reduce the Driving in the rain • A heavy rainfall will make it harder glare from other driver's head- to see and will increase the dis- lights. tance needed to stop your vehicle, so slow down.
  • Page 376 Driving your vehicle Driving in flooded areas Highway driving WARNING - Tire tread Avoid driving through flooded areas Tires Always check the tire tread unless you are sure the water is no Adjust the tire inflation pressures to before driving your vehicle. higher than the bottom of the wheel specification.
  • Page 377 Driving your vehicle WINTER DRIVING Severe weather conditions in the Snowy or icy conditions Snow tires winter result in greater wear and If you mount snow tires on your vehi- To drive your vehicle in deep snow, it other problems. To minimize the cle, make sure they are radial tires of may be necessary to use snow tires problems of winter driving, you...
  • Page 378 8. The level of charge in your as these may damage the paint fin- battery can be checked by an author- ish. ized Kia dealer or a service station.
  • Page 379 Driving your vehicle Don’t let your parking brake Carry emergency equipment freeze Depending on the severity of the weather, you should carry appropri- Under some conditions your parking ate emergency equipment. Some of brake can freeze in the engaged the items you may want to carry position.
  • Page 380 Driving your vehicle VEHICLE LOAD LIMIT Tire and loading information The label located on the driver's door Vehicle capacity weight: sill gives the original tire size, cold label 410 kg (904 lbs.) tire pressures recommended for your Vehicle capacity weight is the maxi- vehicle, the number of people that mum combined weight of occupants can be in your vehicle and vehicle...
  • Page 381 Driving your vehicle Towing capacity: Steps For Determining Correct 5. Determine the combined weight of Load Limit - luggage and cargo being loaded We do not recommend using this on the vehicle. That weight may vehicle for trailer towing. 1. Locate the statement "The com- not safely exceed the available bined weight of occupants and cargo and luggage load capacity...
  • Page 382 Driving your vehicle Example 1 Example 2 Example 3 C190F01JM C190F02JM C190F03JM Item Description Total Item Description Total Item Description Total Vehicle Capacity 385 kg Vehicle Capacity 385 kg Vehicle Capacity 385 kg Weight (849 lbs) Weight (849 lbs) Weight (849 lbs) Subtract Occupant Subtract Occupant...
  • Page 383 Driving your vehicle Certification label WARNING - WARNING Over loading - Over loading The certification label is located on Never exceed the GVWR for Do not overload your vehicle. the driver's door sill at the center pillar. your vehicle, the GAWR for Overloading your vehicle can This label shows the maximum allow- either the front or rear axle and...
  • Page 384 Driving your vehicle VEHICLE WEIGHT This chapter will guide you in the Base curb weight GAWR proper loading of your vehicle and/or (Gross axle weight rating) This is the weight of the vehicle trailer, to keep your loaded vehicle including a full tank of fuel and all This is the maximum allowable weight within its design rating capa- standard equipment.

  • Page 385: What To Do In An Emergency

    What to do in an emergency Road warning ......7-2 If you have a flat tire (With Tire Mobility Kit). . 7-15 •...
  • Page 386 What to do in an emergency ROAD WARNING Hazard warning flasher Depress the flasher switch with the ignition switch in any position. The flasher switch is located in the center facia panel. All turn signal lights will flash simultaneously. • The hazard warning flasher oper- ates whether your vehicle is run- ning or not.
  • Page 387 If you have a flat tire while again. If your vehicle will not start, from traffic. driving contact an authorized Kia dealer 4. When changing a flat tire, follow or seek other qualified assistance. the instruction provided later in If a tire goes flat while you are driv- this section.
  • Page 388 4. If the engine still does not start, charged. call an authorized Kia dealer or 4. Check the starter connections to seek other qualified assistance. be sure they are securely tight- ened.
  • Page 389 What to do in an emergency EMERGENCY STARTING Jump starting WARNING - Frozen Jump starting can be dangerous if batteries done incorrectly. Therefore, to avoid Do not attempt to jump start the harm to yourself or damage to your vehicle if the discharged battery vehicle or battery, follow these jump is frozen or if the electrolyte starting procedures.
  • Page 390 If the cause of your battery discharg- ing is not apparent, you should have your vehicle checked by an author- ized Kia dealer.
  • Page 391 If this happens, you should: the engine immediately. Then, call check connecting parts the nearest authorized Kia dealer between the radiator hose, heater for assistance. If the “Engine hose, and water pump for any 1. Turn on the emergency warning Warning”...
  • Page 392 This possible by an authorized Kia dealer. can allow coolant to blow out of the open- CAUTION ing and cause seri- ous burns.
  • Page 393 What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED) ✽ ✽ NOTICE Check tire pressure • You can check the tire pressure in • The tire pressure may change due the information mode on the clus- to factors such as parking condi- ter.

  • Page 394: Maintenance

    What to do in an emergency Each tire, including the spare (if pro- Please note that the TPMS is not a Always check the TPMS malfunction vided), should be checked monthly substitute for proper tire maintenance, telltale after replacing one or more when cold and inflated to the inflation and it is the driver’s responsibility to tires or wheels on your vehicle to...
  • Page 395 3 seconds, take your vehicle Then the TPMS malfunction indicator to your nearest authorized Kia deal- and the Low Tire Pressure telltale er and have the system checked. may turn on and illuminate after...
  • Page 396 Significantly low tire pres- Have the system checked by an sure can cause the tires to over- authorized Kia dealer as soon as heat and fail making the vehicle possible to determine the cause of unstable resulting in increased the problem.
  • Page 397 Kia dealer as soon as possible or deactivated. If the TPMS sensor on After you replace the low pressure replace the flat tire with the spare...
  • Page 398 What to do in an emergency You may not be able to identify a low • The TPMS cannot alert you to This device complies with tire by simply looking at it. Always severe and sudden tire damage Industry Canada licence-exempt use a good quality tire pressure caused by external factors such as RSS standard(s).
  • Page 399 Have your tire repaired as soon as fix to the tire and the tire should be possible. The tire may lose air pres- inspected by an authorized Kia deal- sure at any time after inflating with er as soon as possible.
  • Page 400 What to do in an emergency Introduction It is possible that some tires, espe- Notes on the safe use of the cially with larger punctures or dam- Tire Mobility Kit age to the sidewall, cannot be sealed • Park your car at the side of the completely.
  • Page 401 6 mm (0.24 in). • Do not leave the compressor run- Please contact the nearest Kia ning for more than 10 min. at a time dealership if the tire cannot be or it may overheat.
  • Page 402 What to do in an emergency 8. Pressure gauge for displaying the Components of the Tire Mobility Kit tire inflation pressure 9. Button for reducing tire inflation pressure Connectors and cable are stored in the compressor housing. WARNING - Expired sealant Do not use the Tire sealant after the sealant has expired (i.e.
  • Page 403 What to do in an emergency Using the Tire Mobility Kit 1. Detach the speed restriction label (1) from the sealant bottle (2), and place it in a highly visible place inside the vehicle such as on the steering wheel to remind the driv- er not to drive too fast.
  • Page 404 What to do in an emergency OJF067055 OJFH065013 OJF067057 4. Connect the filling hose (3) onto 6. Unscrew the valve cap from the 7. Insert the sealant bottle into the the connector of the sealant bottle. valve of the defective wheel and housing (5) of the compressor so screw filling hose (3) of the sealant that the bottle is upright.
  • Page 405 What to do in an emergency 10. With the engine start/stop button 11. Switch off the compressor. position on: switch on the com- 12. Detach the hose from the sealant pressor and let it run for approxi- bottle connector and from the tire mately 5~7 minutes to fill the valve.
  • Page 406 20 km/h (12 mph). directly and then connect the filling including sealant hose (3) (opposite side) to the tire approved by Kia, the tire pres- While driving, if you experience any valve. sure sensors may be damaged unusual vibration, ride disturbance or by sealant.
  • Page 407 What to do in an emergency ❈ Sealant and spare parts can be Technical Data obtained and replaced at an System voltage: DC 12 V authorized vehicle or tire dealer. Working voltage: DC 10 - 15 V Empty sealant bottles may be dis- Amperage rating: max.
  • Page 408 If the EPB does not release normal- dolly ly, take your vehicle to an author- OMC045012 ized Kia dealer by loading the vehi- If emergency towing is necessary, cle on a flatbed tow truck and have we recommend having it done by an the system checked.
  • Page 409 What to do in an emergency When towing your vehicle in an Removable towing hook emergency without wheel dollies : (if equipped) 1. Set the ignition switch in the ACC position. 2. Place the transaxle shift lever in N (Neutral). 3.
  • Page 410 • Avoid towing a vehicle heavier than the vehicle doing the towing. OJFH065019 • The drivers of both vehicles should If towing is necessary, have it communicate with each other fre- done by an authorized Kia dealer quently. or a commercial tow truck service.
  • Page 411 • Fasten the towing cable or chain easy visibility. We recommend that you con- securely to the hook. tact an authorized Kia dealer • Drive carefully so that the towing or a commercial tow truck strap is not loosened during tow- •...
  • Page 412 What to do in an emergency Emergency towing precautions • If the car is being towed with all four wheels on the ground, it can • Turn the ignition switch to ACC so be towed only from the front. Be the steering wheel isn’t locked.
  • Page 413 Immediately cal fires could cause serious injury contact an authorized Kia dealer or death from electrical shocks. and advise them that a hybrid vehi- cle is involved.
  • Page 414 Maintenance Engine compartment ......8-3 Parking brake ......8-35 •...

  • Page 415: Glove Box

    • All season tires ......8-59 • Rear turn signal lamp bulb replacement ..8-89 •...

  • Page 416: Engine Coolant Reservoir

    Maintenance ENGINE COMPARTMENT ■ ■ Gasoline Engine (Nu 2.0L - GDI) 1. Engine coolant reservoir 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air cleaner 6. Fuse box 7. Inverter coolant reservoir 8. Radiator cap 9.
  • Page 417 Kia dealer perform this work. nical support from Kia in order to pro- dance with the scheduled mainte- vide you with a high level of service An authorized Kia dealer has factory- nance service charts shown on the satisfaction.
  • Page 418 As explained earlier in this section, become entangled in moving several procedures can be done only parts, if you must run the by an authorized Kia dealer with spe- engine while working under the cial tools. hood, make certain that you remove all jewelry (especially ✽...
  • Page 419 • Check the engine oil level. ized Kia dealer at the frequencies exhaust fumes in the vehicle. indicated to help ensure safe, • Check the coolant level in coolant •...
  • Page 420 Maintenance At least monthly: At least twice a year At least once a year : (i.e., every Spring and Fall) : • Check the coolant level in the • Clean the body and door drain engine coolant reservoir. holes. • Check the radiator, heater and air conditioning hoses for leaks or •...
  • Page 421 Maintenance SCHEDULED MAINTENANCE SERVICE Follow the Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, follow the Maintenance Under Severe Usage Conditions. • Repeatedly driving short distance of less than 8 km (5 miles) in normal temperature or less than 16 km (10 miles) in freezing temperature.

  • Page 422: Normal Maintenance Schedule

    If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
  • Page 423 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace engine oil and filter ommended. Additives are available from your authorized Kia dealer along with (24,000 km (15,000 miles) or 24 months) information on how to use them. Do not mix other additives.
  • Page 424 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Inspect vapor hose and fuel filler cap ommended. Additives are available from your authorized Kia dealer along with ❑ Replace climate control air filter (for evaporator and blower unit) information on how to use them.
  • Page 425 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace engine oil and filter ommended. Additives are available from your authorized Kia dealer along with (72,000 km (45,000 miles) or 72 months) information on how to use them. Do not mix other additives.
  • Page 426 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace climate control air filter (for evaporator and blower unit) ommended. Additives are available from your authorized Kia dealer along with ❑ Replace air cleaner filter information on how to use them.
  • Page 427 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace engine oil and filter ommended. Additives are available from your authorized Kia dealer along with (120,000 km (75,000 miles) or 120 months) information on how to use them. Do not mix other additives.
  • Page 428 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Inspect vapor hose and fuel filler cap ommended. Additives are available from your authorized Kia dealer along with ❑ Replace climate control air filter (for evaporator and blower unit) information on how to use them.
  • Page 429 ❑ Replace spark plugs (iridium coated) If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with ❑ Replace engine oil and filter information on how to use them. Do not mix other additives.
  • Page 430 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Inspect parking brake ommended. Additives are available from your authorized Kia dealer along with ❑ Inspect vapor hose and fuel filler cap information on how to use them. Do not mix other additives.
  • Page 431 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
  • Page 432 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace engine oil and filter ommended. Additives are available from your authorized Kia dealer along with (216,000 km (135,000 miles) or 216 months) information on how to use them. Do not mix other additives.
  • Page 433 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace engine oil and filter ommended. Additives are available from your authorized Kia dealer along with (240,000 km (150,000 miles) or 240 months) information on how to use them. Do not mix other additives.

  • Page 434: Maintenance Under Severe Usage Conditions

    Maintenance Maintenance Under Severe Usage Conditions The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE ITEM MAINTENANCE INTERVALS...
  • Page 435 If the connections for leakage and dam- dence of heat and/or mechanical vehicle is being driven in severe con- age. Have an authorized Kia dealer damage. Hard and brittle rubber, ditions, more frequent oil and filter replace any damaged or leaking cracking, tears, cuts, abrasions, and changes are required.
  • Page 436 Maintenance Air cleaner filter Automatic transaxle fluid CAUTION A Genuine Kia air cleaner filter is Automatic transaxle fluid should not Use only specified automatic recommended when the filter is be checked under normal usage transaxle fluid.The use of a non- replaced.

  • Page 437: Parking Brake Pedal

    Maintenance Brake fluid Exhaust pipe and muffler Steering gear box, linkage & boots/lower arm ball joint Check the brake fluid level in the Visually inspect the exhaust pipes, brake fluid reservoir. The level should muffler and hangers for cracks, dete- With the vehicle stopped and engine be between “MIN”...
  • Page 438 Maintenance CHECKING FLUID LEVELS When checking engine oil, engine coolant, brake fluid, and washer fluid, always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant or fluid. This is espe- cially important in dusty or sandy areas and when the vehicle is used on unpaved roads.
  • Page 439 Maintenance ENGINE OIL Checking the engine oil level ■ Gasoline Engine (Nu 2.0L - GDI) WARNING - Radiator hose ■ Gasoline Engine (Nu 2.0L - GDI) Be very careful not to touch the radiator hose when checking or adding the engine oil as it may be hot enough to burn you.
  • Page 440 Maintenance Changing the engine oil and filter Have engine oil and filter changed by an authorized Kia dealer according to the Maintenance Schedule at the beginning of this chapter. WARNING Used engine oil may cause irrita- tion or cancer of the skin if left in contact with the skin for pro- longed periods of time.
  • Page 441 Maintenance ENGINE MAINTENANCE MODE(FOR PLUG-IN HYBRID) Starting Engine Maintenance If you press the HEV switch to shift Stopping Engine Maintenance EV mode during engine mainte- Mode Mode nance mode, the above message will appear due to priority of the engine maintenance mode.
  • Page 442 Maintenance COOLANT The high-pressure cooling system Checking the coolant level • Turn the engine off and wait until it has a reservoir filled with year round cools down. Use extreme care antifreeze coolant. The reservoir is when removing the radiator cap. WARNING filled at the factory.
  • Page 443 Bring the level to F, but do not over- fill. If frequent additions are required, see an authorized Kia dealer for a cooling system inspection.
  • Page 444 Maintenance Recommended coolant For mixture percentage, refer to the following table. • When adding coolant, use only deionized water or soft water for Mixture Percentage your vehicle and never mix hard Ambient (volume) water in the coolant filled at the fac- Temperature Antifreeze Water...
  • Page 445 Maintenance Changing the coolant WARNING Have the coolant changed by an Radiator cap authorized Kia dealer according to the Maintenance Schedule at the beginning of this chapter. Put a thick cloth around the radiator cap before refilling the coolant in...
  • Page 446 In the event the brake system CAUTION - Proper fluid requires frequent additions of fluid, the vehicle should be inspected by Only use brake fluid in brake an authorized Kia dealer. system. Small amounts improper fluids (such as engine When changing and adding brake oil) can cause damage to the fluid, handle it carefully.
  • Page 447 Maintenance WASHER FLUID Checking the washer fluid WARNING WARNING - Flammable - Windshield level fluid fluid Do not allow the washer fluid to Do not drink the windshield come in contact with open washer fluid. The windshield flames or sparks.The windshield washer fluid is poisonous to washer fluid reservoir is flamma- humans and animals.
  • Page 448 (66 lb) of force. Also, the parking brake alone should securely hold the vehicle on a fairly steep grade. If the stroke is more or less than specified, have the parking brake adjusted by an authorized Kia dealer. Stroke : 6~7 notch 8 35...

  • Page 449: Air Cleaner

    Maintenance AIR CLEANER Filter replacement OJFH075070 OJFH075012 1. Pull out the air cleaner cover. OJFH075011 It must be replaced when necessary, and should not be washed. You can clean the filter when inspect- ing the air cleaner element. Clean the filter by using compressed air.
  • Page 450 • Use a Kia genuine part. Use of a non-genuine part could damage the air flow sensor. 8 37...
  • Page 451 Maintenance CLIMATE CONTROL AIR FILTER (IF EQUIPPED) Filter inspection The climate control air filter should replaced according Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
  • Page 452 Maintenance OJFC075125 OJFC075126 3. Remove the climate control air fil- 4. Replace the climate control air fil- ter cover while pressing the lock ter. on the right side of the cover. 5. Reassemble in the reverse order of disassembly. When replacing the climate control air filter install it properly.
  • Page 453 Maintenance WIPER BLADES Blade inspection Contamination of either the wind- Blade replacement shield or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windshield wipers. or cracked, and require replacement.
  • Page 454 Maintenance Front windshield wiper blade CAUTION - Wiper arms Do not allow the wiper arm to fall against the windshield, since it may chip or crack the windshield. OHM078060 OJF075016 For your convenience, move the windshield wiper blades to the serv- ice position as follows;...

  • Page 455: Engine Start/Stop Button

    Maintenance 4. Return the wiper arm on the wind- shield. 5. Turn the engine start/stop button to the ON position and wiper arms will return to the normal operating position. 1JBA7037 1LDA5023 Type B 1. Raise the wiper arm and turn the wiper blade assembly to expose the plastic locking clip.
  • Page 456 Maintenance 5. Return the wiper arm on the wind- shield. 6. Turn the engine start/stop button to the ON position and wiper arms will return to the normal operating position. 8 43...
  • Page 457 Wear protection Please return the battery to solution of water and baking soda. when charging or work- an authorized Kia dealer to • If the vehicle is not going to be near battery. be recycled. used for an extended time, discon-...
  • Page 458 Maintenance ✽ ✽ NOTICE Recharging the battery WARNING - Risk of elec- If you connect unauthorized elec- Your vehicle has a maintenance-free, trocution tronic devices to the battery, the bat- calcium-based battery. Never touch the electrical igni- tery may be discharged. Never use •...
  • Page 459 Maintenance When recharging battery, • Before performing maintenance or Reset items observe the following precautions: recharging the battery, turn off all Items should be reset after the bat- accessories and stop the engine. • The battery must be removed from tery has been discharged or the bat- the vehicle and placed in an area •...
  • Page 460 Maintenance TIRES AND WHEELS Tire care WARNING - Tire underin- For proper maintenance, safety, and flation maximum fuel economy, you must Inflate your tires consistent with always maintain recommended tire the instructions provided in this inflation pressures and stay within manual.
  • Page 461 1.6 spare tire. refilling, have it checked by an km (one mile) since startup.) authorized Kia dealer. • Check the pressure of your spare • Overinflation produces a harsh How to check tire each time you check the pres-...
  • Page 462 • Remember to check the pressure Replace the tire if you find either of the valve stems. They help prevent of your spare tire. Kia recommends these conditions. Replace the tire if leaks by keeping out dirt and mois- that you check the spare every fabric or cord is visible.
  • Page 463 Maintenance Disc brake pads should be inspected Wheel alignment and tire bal- Without a spare tire for wear whenever tires are rotated. ance Rotate radial tires that have an The wheels on your vehicle were asymmetric tread pattern only from aligned and balanced carefully at the front to rear and not from right to left.
  • Page 464 Maintenance Tire replacement The ABS works by comparing the Wheel replacement speed of the wheels. The tire size When replacing the metal wheels for affects wheel speed. When replacing any reason, make sure the new tires, all 4 tires must use the same wheels are equivalent to the original size originally supplied with the vehi- factory units in diameter, rim width...
  • Page 465 Tire sidewall labeling CAUTION - Wheel Tire traction can be reduced if you Wheels that do not meet Kia's drive on worn tires, tires that are specifications may fit poorly improperly inflated or on slippery and result in damage to the road surfaces.
  • Page 466 Maintenance 2. Tire size designation 89 - Load Index, a numerical code Tire speed ratings associated with the maximum A tire’s sidewall is marked with a tire The chart below lists many of the dif- load the tire can carry. size designation.
  • Page 467 Maintenance 3. Checking tire life (TIN : Tire 5. Maximum permissible inflation WARNING - Tire age Identification Number) pressure Replace tires within the recom- Any tires that are over 6 years old, This number is the greatest amount of mended time frame. Failure to based on the manufacturing date, air pressure that should be put in the replace tires as recommended...
  • Page 468 Maintenance Tread wear Tires degrade over time, even when Traction - AA, A, B & C they are not being used. Regardless The tread wear grade is a compara- The traction grades, from highest to of the remaining tread, we recom- tive rating based on the wear rate of lowest, are AA, A, B and C.
  • Page 469 Maintenance Temperature -A, B & C Tire terminology and definitions Cold Tire Pressure: The amount of air pressure in a tire, measured in The temperature grades are A (the Air Pressure: The amount of air kilopascals (kPa) or pounds per highest), B and C representing the inside the tire pressing outward on square inch (psi) before a tire has...
  • Page 470 Maintenance GVWR: Gross Vehicle Weight Rating Maximum Inflation Pressure: The Occupant Distribution: Designated maximum air pressure to which a seating positions. GAWR FRT: Gross Axle Weight cold tire may be inflated. The maxi- Rating for the Front Axle. Outward Facing Sidewall: The side mum air pressure is molded onto the of a asymmetrical tire that has a par- GAWR RR: Gross Axle Weight...
  • Page 471 Maintenance Production options weight: The Speed Rating: An alphanumeric Vehicle Maximum Load on the combined weight of installed regular code assigned to a tire indicating the Tire: Load on an individual tire due production options weighing over 2.3 maximum speed at which a tire can to curb and accessory weight plus kg (5 lb.) in excess of the standard operate.
  • Page 472 Maintenance All season tires Snow tires Radial-ply tires Kia specifies all season tires on If you equip your car with snow tires, Radial-ply tires provide improved some models to provide good per- they should be the same size and tread life, road hazard resistance and...
  • Page 473 • If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized Kia dealer. • To prevent damage to the tire, inspect the tire condition and pressure every 3,000 (1,900 miles).
  • Page 474 Maintenance • It is not easy to recognize the tire damage with your own eyes. But if there is the slightest hint of tire damage, even though you cannot see it, have the tire checked or replaced because the tire damage may cause air leakage from the tire.
  • Page 475 ■ BFT indicates an electrical problem. Avoid using the system involved and imme- CAUTION diately consult an authorized Kia dealer. Do not use a screwdriver or any Three kinds of fuses are used: blade other metal object to remove...
  • Page 476 Maintenance ✽ ✽ NOTICE Inner panel fuse replacement CAUTION • When replacing fuse, turn the • When replacing a blown fuse ignition “OFF” and turn off or relay, make sure the new switches of all electrical devices fuse or relay fits tightly into then remove battery (-) terminal.
  • Page 477 4. Check the removed fuse; replace it lamps, have the vehicle checked by if it is blown. an authorized Kia dealer for assis- tance. Spare fuses are provided in the engine compartment fuse panel.

  • Page 478: Fuse Box.

    4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized Kia dealer. CAUTION After checking the fuse panel in engine...
  • Page 479 Incorrect or partial assembly torque may cause a fire. Have the vehicle checked by an authorized Kia dealer. OJFH075072 OJFH075168 If the multi fuse is blown, it must be If the main fuse is blown, it must be...
  • Page 480 Kia dealer. Use of random wiring in the vehicle munication device, etc.). It might might cause danger due to failure cause malfunction of the vehicle, and damage of the vehicle’s per-...
  • Page 481 Maintenance Fuse/relay panel description Driver’s side fuse panel OJF075027 Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. ✽ ✽ NOTICE OJFH076169N Not all fuse panel descriptions in this manual may be applicable to your vehicle.

  • Page 482: Cruise Control

    Maintenance Instrument panel (Driver’s side fuse panel) Fuse Name Fuse rating Circuit Protected Around View Monitor Unit, Front Air Ventilation Seat Control Module, Front Seat Warmer Control Module, MODULE 7 Rear Seat Warmer Control Module A/C Control Module, Electro Chromic Mirror, Driver IMS Module, Head Lamp LH/RH, Auto Head Lamp MODULE 5 Leveling Device Module, Fuel Lid &...
  • Page 483 Maintenance Fuse Name Fuse rating Circuit Protected MDPS MDPS Unit (Column/Rack) PCB Block (Fuse - OPCU2/ELECTRICAL WATER PUMP/TCU2/ACTIVE HYDRAULIC BOOTER 3/HEV ECU2/ECU3) MODULE 9 Smart Key Control Module WASHER Multifunction Switch (Wiper Low & Washer Switch) MODULE 8 Driver/Passenger Door Module CLUSTER Instrument Cluster MULTI MEDIA...
  • Page 484 Maintenance Fuse Name Fuse rating Circuit Protected A/BAG IND Instrument Cluster (Air Bag IND. Power) TRUNK Trunk Lid Relay, Fuel Filler & Trunk Open Switch, ICM Relay Box (Fuel Filler Open Relay) SUNROOF 2 Sunroof Control Unit (Roller) BATTERY BMS Control Module MANAGEMENT Instrument Cluster, A/C Control Module, Data Link Connector, BCM, Wireless Charger, Driver IMS Module, MEMORY 1...
  • Page 485 Maintenance Fuse Name Fuse rating Circuit Protected Power Window RH Relay, Rear Safety Power Window Module LH, Rear Power Window Switch LH, Power Window Main Switch, P/WDW RH [LHD] Passenger Safety Power Window Module [RHD] Driver Safety Power Window Module P/SEAT PASS Passenger Seat Manual Switch, Walk In Relay Module, Passenger Reclining Limit Switch BRAKE SWITCH...
  • Page 486 Maintenance Engine compartment fuse panel (For Hybrid) OJFH075029 OJFH076170N 8 73...
  • Page 487 Maintenance Engine compartment fuse panel (For Plug-in Hybrid) OJFH075029 OJFHP076228N...
  • Page 488 Maintenance Engine room compartment fuse panel Fuse Name Fuse rating Circuit Protected MDPS 1 MDPS Unit (Column) COOLING FAN RLY. 2 (Cooling Fan Relay) PCB Block (Engine Control Relay, Fuse -FUEL PUMP/ECU2/TCU1/HORN/WIPER1/BATTERY C/FAN) Smart Junction Block (IPS 2 (IPS 5), IPS 3 (IPS 6), IPS 7, IPS 8) MULTI REAR HEATED RLY.
  • Page 489 Maintenance Fuse Name Fuse rating Circuit Protected Smart Junction Block (Fuse - TRUNK, SUNROOF2, S/HEATER REAR, SUNROOF1, P/WDW RH, P/SEAT PASS, P/WDW LH, P/SEAT DRV) EEWP Engine Electric Water Pump Smart Junction Block (IPS 1, IPS 4, Fuse - FOG LAMP REAR, S/HEATER FRONT, AMP) MULTI ACTIVE FUSE...
  • Page 490 Maintenance Fuse Name Fuse rating Circuit Protected EPB1 Electric Parking Brake Module H/Lamp Washer RLY. 9 (H/Lamp Washer Relay) Smart Junction Block (Leak Current Autocut Device Fuse - INTERIOR LAMP, MULTI MEDIA, MEM- ORY2, MEMORY1, Fuse - MODULE1, DR LOCK, SMART KEY, BRAKE SWITCH) EPB 2 Electric Parking Brake Module OPCU 1...
  • Page 491 Maintenance Fuse Name Fuse rating Circuit Protected FUEL PUMP Fuel Pump Relay ECU 1 Mass Air Flow Sensor, Fuel Pump Relay, Oil Control Valve #1/#2, Canister Close Valve, Camshaft SENSORS 2 Position Sensor #1/#2, Purge Control Solenoid Valve TCU 2 Transaxle Range Switch ACTIVE HYDRAULIC...
  • Page 492 Maintenance Fuse Name Fuse rating Circuit Protected SENSOR 1 Oxygen Sensor (Up/Down), E/R Junction Block (Cooling Fan Relay) IGN COIL Ignition Coil #1/#2/#3/#4 ECU 2 TCU 1 HEV ECU 2 HPCU, E/R Junction Block (Battery C/Fan Relay) FUSE ECU 3 POWER OUT- Front Power Outlet #1 LET2...
  • Page 493 Maintenance Relay Relay Name Type COOLING FAN Relay MINI BLOWER Relay MICRO BATTERY C/FAN Relay MICRO H/LAMP HI Relay MICRO POWER OUTLET Relay MICRO H/LAMP WASHER Rela MICRO DEICER Relay MICRO REAR HEATED Relay MINI PTC HEATER 1 MINI PTC HEATER 2 MINI IG3 3 MICRO...
  • Page 494 Maintenance Battery terminal cover OJFH075172 ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 495 Please have the vehicle or receiving an electric shock. checked by an authorized Kia dealer immediately.
  • Page 496 ■ Type A ■ Rear combination lamp consult an authorized Kia dealer. In many cases, it is difficult to replace vehicle light bulbs because other parts of the vehicle must be removed before you can get to the bulb. This is...
  • Page 497 (2) Stop lamp (LED type) (3) Tail lamp (LED type) If the light bulb does not operate, have the vehicle checked by an (4) Back-up lamp authorized Kia dealer. (5) Side marker (6) License plate lamp WARNING - HID (7) High mounted stop lamp...
  • Page 498 Maintenance ✽ ✽ NOTICE Headlamp (Low beam) bulb 5. Insert a new bulb by inserting it into the bulb-socket. replacement (For Hybrid) HID lamps have superior perform- 6. Install the bulb-socket in the head- ance vs. halogen bulbs. HID lamps lamp assembly by aligning the are estimated by the manufacturer to tabs on the bulb-socket with the...
  • Page 499 Maintenance Headlamp bulb • Always handle them carefully, and CAUTION avoid scratches and abrasions. If the bulbs are lit, avoid contact with If your vehicle is equipped with liquids. Never touch the glass with High Intensity Discharge (HID) bare hands. Residual oil may headlights, these headlights cause the bulb to overheat and contain mercury.
  • Page 500 If the head lamp (LED) (1,2) does not 2. Remove the headlamp bulb cover operate, have the vehicle checked by by turning it counterclockwise. an authorized Kia dealer. The LED 3. Disconnect the headlamp bulb lamps cannot be replaced as a sin- socket-connector.
  • Page 501 If the position lamp + DRL* (1) does ing it counterclockwise until the not operate, have the vehicle tabs on the bulb align with the checked by an authorized Kia dealer. slots in the bulb-socket. Pull the bulb out of the bulb-socket...
  • Page 502 If the Side repeater lamp does not 2. Open the service cover. operate, have the vehicle checked by an authorized Kia dealer. The LED lamps cannot be replaced as a single unit because it is an inte- grated unit. The LED lamps has to be replaced with the unit.
  • Page 503 Maintenance 7. Remove the bulb from the socket by pressing it in and rotating it counterclockwise until the tabs on the bulb align with the slots in the socket. Pull the bulb out of the socket. 8. Insert a new bulb by inserting it into the socket and rotating it until it locks into place.
  • Page 504 If the stop and tail lamp (LED) does 1. Open the trunk lid. not operate, have the vehicle 2. Loosen the retaining screw of the checked by an authorized Kia dealer. trunk lid cover and then remove OJF075083 The LED lamps cannot be replaced the cover.
  • Page 505 Maintenance 3. Remove the nuts from the vehicle. License plate lamp bulb replacement 4. Disconnect the rear combination lamp (inside) connector. 5. Remove the rear combination lamp (inside) assembly from the body of the vehicle. 6. Remove the socket from the assembly by turning the socket counterclockwise until the tabs on the socket align with the slots on...
  • Page 506 OJF075051 If the map lamp (bulb and LED type) does not operate, have the vehicle If the high mounted stop lamp (LED) checked by an authorized Kia dealer. does not operate, have the vehicle WARNING - Interior lamps checked by an authorized Kia dealer.
  • Page 507 Maintenance 1. Using a flat-blade screwdriver, Room lamp bulb replacement WARNING - Interior lamps gently pry the lamp assembly from ■ Type A interior. Prior to working on the Interior 2. Remove the bulb by pulling it lamps, ensure that the “OFF” straight out.
  • Page 508 If the personal lamp (LED) does not 1. Using a flat-blade screwdriver, operate, have the vehicle checked by gently pry the lamp assembly from an authorized Kia dealer. interior. The LED lamps cannot be replaced 2. Remove the bulb by pulling it as a single unit because it is an inte- straight out.
  • Page 509 Maintenance Trunk lamp bulb replacement OJF075053 1. Using a flat-blade screwdriver, gently pry the lens cover from lamp housing. 2. Remove the bulb by pulling it straight out. 3. Install a new bulb in the socket. 4. Align the lens cover tabs with the lamp housing notches and snap the lens into place.
  • Page 510 Maintenance APPEARANCE CARE Exterior care Even prompt washing with plain water High-pressure washing may not completely remove all these • When using high-pressure wash- Exterior general caution deposits. A mild soap, safe for use on ers, make sure to maintain suffi- It is very important to follow the label painted surfaces, may be used.
  • Page 511 Maintenance Waxing CAUTION - Drying vehicle Wax the vehicle when water will no • Wiping dust or dirt off the longer bead on the paint. body with a dry cloth will Always wash and dry the vehicle scratch the finish. before waxing.
  • Page 512 Maintenance Finish damage repair Underbody maintenance • Immediately seek an inspection of your vehicle if you become visually Deep scratches or stone chips in the Road salt and other corrosive chemi- aware of corrosion flaking or scal- painted surface must be repaired cals are used in cold weather states to ing or if you become aware of a promptly.
  • Page 513 Maintenance • Avoid washing the wheels with Corrosion protection High-corrosion areas highspeed vehicle wash brushes. If you live in an area where your vehi- Protecting your vehicle from corrosion • Do not use any alkaline or acid cle is regularly exposed to corrosive By using the most advanced design detergents It may damage and cor- materials, corrosion protection is...
  • Page 514 Maintenance High temperatures can also acceler- Keep your vehicle clean • When cleaning lower door panels, ate corrosion of parts that are not rocker panels and frame members, The best way to prevent corrosion is properly ventilated so the moisture be sure that drain holes are kept to keep your vehicle clean and free can be dispersed.
  • Page 515 Maintenance Keep paint and trim in good con- Interior care CAUTION - Electrical dition Interior general precautions components Scratches or chips in the finish Prevent chemicals such as perfume, Never allow water or other liq- should be covered with "touch-up" cosmetic oil, sun cream, hand clean- uids to come in contact with paint as soon as possible to reduce...
  • Page 516 Maintenance Taking care of leather seats Cleaning the leather seats Fabric seat cover using precau- tions (If equipped) • Vacuum the seat periodically to • Remove all contaminations instant- remove dust and sand on the seat. ly. Refer to instructions below for Please clean the fabric seats regu- It will prevent abrasion or damage of removal of each contaminant.
  • Page 517 Maintenance Cleaning the upholstery and inte- Cleaning the lap/shoulder belt Window tinting precaution rior trim webbing Window tint(especially metallic film) might cause communication disorder Clean the belt webbing with any mild Vinyl or poor radio reception, and malfunc- soap solution recommended for Remove dust and loose dirt from tion of the automatic lighting system cleaning upholstery or carpet.
  • Page 518 (The ORVR system is designed to an authorized Kia dealer in accor- allow the vapors from the fuel tank to dance with the maintenance sched- be loaded into a canister while refu- ule in this manual.
  • Page 519 Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (carbon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present Exhaust Emission Control onboard canister. When the engine is with other exhaust...
  • Page 520 Maintenance • Do not operate the engine in con- Operating precautions for catalyt- WARNING - Fire fined or closed areas (such as ic converters (if equipped) garages) any more than what is • Do not park, idle or drive the necessary to move the vehicle in or vehicle over or near flamma- WARNING...
  • Page 521 All inspections and adjustments must be made by an authorized Kia dealer. • Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, dam- aging the catalytic converter.

  • Page 522: Specifications & Consumer Information

    Specifications & Consumer information Dimensions ....... . 9-2 Engine ........9-2 Bulb wattage .
  • Page 523 Specifications & Consumer information DIMENSIONS Item Unit : mm (in) Overall length 4,855 (191.1) Overall width 1,860 (73.2) Overall height 1,460 (57.7) 205/65 R16* 1,614 (63.5) Front 215/55 R17 1,602 (63.1) Tread 205/65 R16* 1,621 (63.8) Rear 215/55 R17 1,609 (63.3) Wheelbase 2,805 (110.4) * : Only for Hybrid vehicle.

  • Page 524: Bulb Wattage

    Specifications & Consumer information BULB WATTAGE Light Bulb Wattage (W) Bulb type Headlamps (Low) H7SL Headlamps (Low) – LED type Headlamps (High) HB3 HYPER L/L(9005HL) Headlamps (High) – LED type Front Front turn signal lamps 28/8W AMBER L/L Front position lamps 0.7W Bulb type HB3 HYPER L/L(9005HL)
  • Page 525 Specifications & Consumer information TIRES AND WHEELS Inflation pressure [bar(psi, kPa)] Wheel lug Load Speed nut torque Capacity capacity Item Tire size Wheel size Normal load Maximum load [Kgf·m (lbf·ft, N·m)] LI * SS * Km/h Front Rear Front Rear 205/65 R16 * 6.5J ×...
  • Page 526 Hybrid Plug-in hybrid 380L (13.4 cu ft) 280L (9.9 cu ft) AIR CONDITIONING SYSTEM ITEM Weight of volume Classification Refrigerant 570 ± 25g R-1234yf Compressor lubricant 130 ± 10g POE (RB100EV) Have your vehicle inspected by an authorized Kia dealer.

  • Page 527: Recommended Lubricants And Capacities

    Specifications & Consumer information RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification...
  • Page 528 Specifications & Consumer information Recommended SAE viscosity Temperature Range for SAE Viscosity Numbers number °C Temperature Engine oil viscosity (thickness) has (°F) an effect on fuel economy and cold 10W-30 weather operating (engine start and Engine Oil 5W-20, 5W-30 engine oil flowability). Lower viscosi- ty engine oils can provide better fuel An engine oil displaying this API Certification Mark con- economy and cold weather perform-...
  • Page 529 Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL ■ Frame number ■ VIN label OJF085001 OUM084005 The vehicle identification number The VIN is also on a plate attached OJF085003 (VIN) is the number used in register- to the top of the dashboard. The vehicle certification label...
  • Page 530 Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER AIR CONDITIONER PRESSURE LABEL COMPRESSOR LABEL ■ Gasoline engine (Nu 2.0 GDI) OJFH085004 OJF085012 OJFHP086014 The engine number is stamped on the The tires supplied on your new vehi- engine block as shown in the drawing. A compressor label informs you the cle are chosen to provide the best type of compressor your vehicle is...
  • Page 531 Index...

  • Page 532: Advanced Smart Cruise Control

    Index Appearance care ......8-97 Exterior care ....... 8-97 Active ECO system.
  • Page 533 Index Brake system....... . . 6-18 Bulb wattage ........9-3 Battery.

  • Page 534: Exterior Overview

    Index To temporarily accelerate with the cruise control on. . 6-54 Energy flow hybrid/plug-in hybrid vehicle..H28 To turn cruise control off ..... 6-55 Engine .
  • Page 535 Index Gasoline containing alcohol and methanol ..1-2 If you have a flat tire (With Tire Mobility Kit) ..7-15 Operation in foreign countries ....1-4 Checking the tire inflation pressure .

  • Page 536: Interior Overview

    Index Coat hook ....... . 4-144 User settings mode ......4-61 Cup holder .
  • Page 537 Index Lighting........4-100 AFLS (Adaptive Front Lighting System) ..4-106 Panoramic sunroof .
  • Page 538 Index Driving at night ......6-92 Driving in flooded areas..... . 6-94 Scheduled maintenance service .
  • Page 539 Index Low tire pressure position telltale ....7-11 Fuel economy ......4-67 Tire specification and pressure label .
  • Page 540 Index Wiper blades ....... . . 8-40 Blade inspection ......8-40 Warning and indicator lights.

Table of Contents
