SN3308 Navigation Display
Installation Manual
Document No. 90106-IM
Revision G(4)
9/25/03
SANDEL AVIONICS
2401 DOGWOOD WAY
VISTA, CA 92081
PHONE (760) 727-4900
FAX(760) 727-4899
WEBSITE WWW.SANDEL.COM
EMAIL SUPPORT@SANDEL.COM
90106-IM-G(4) INSTALLATION MANUAL W SIG.DOC

Advertisement

Table of Contents
loading

Related Manuals for Sandel SN3308

Summary of Contents for Sandel SN3308

  • Page 1 SN3308 Navigation Display Installation Manual Document No. 90106-IM Revision G(4) 9/25/03 SANDEL AVIONICS 2401 DOGWOOD WAY VISTA, CA 92081 PHONE (760) 727-4900 FAX(760) 727-4899 WEBSITE WWW.SANDEL.COM EMAIL SUPPORT@SANDEL.COM 90106-IM-G(4) INSTALLATION MANUAL W SIG.DOC...

  • Page 2: Table Of Contents

    UPS GXXX RS232 INTERFACE Configuration Notes: 1.4.12 Pilot-Controlled Switches 1.4.13 Autopilot Interface 1.4.14 Brightness Control Disclaimer TECHNICAL INFORMATION General SN3308 Approval, Physical, and Electrical Properties 2.2.1 Approval Data 2.2.2 Physical Dimensions 2.2.3 Operational Characteristics: Interface Conventions 2.3.1 Connector P1 2.3.2 Connector P2 2.3.3...
  • Page 3 Installation Manual ARINC 419/429 Serial Data Receivers Interfaces ARINC 419/429 Serial Transmitter Interfaces Basic Component Part Number and Variants Installation Kit And Accessories Bill of Materials – SN3308 Install Kit License Requirements 2.10 Technical Standard Order Stipulation 2.11 Installation and Operational Approval Procedures...
  • Page 4 Sandel Avionics SN3308 Navigation Display Installation Manual APPENDIX B: ENVIRONMENTAL QUALIFICATION FORM APPENDIX C: SAMPLE FAA FORM 337 APPENDIX D: SAMPLE AIRPLANE FLIGHT MANUAL SUPPLEMENT APPENDIX E: CHECKOUT PROCEDURES 11.1 Functional Ground Test Procedures/Report 11.1.1 Introduction 11.1.2 Test Procedures and Results 11.1.3...

  • Page 5: Revision History

    Sandel Avionics SN3308 Navigation Display Installation Manual Revision History Revision Date Comments 10 June 98 Initial release Added sample Flight Manual Supplement. Added requirements for dimmer pot and data port. Changed Maint. Page 4 to “Bearing Ptr Select”, 11 July 98 added composite nav selections.
  • Page 6 Sandel Avionics SN3308 Navigation Display Installation Manual MP16: Relay Sense, new page. MP17: SYS added info on inverter items MP21: Updated Brightness MP22-25: DVM pages added MP26: Serial Diagnostics added. 10/27/00 Incorporated A/R 245 Page 44 updated installation instructions for the new chassis and ejector lock tray.
  • Page 7 Sandel Avionics SN3308 Navigation Display Installation Manual 90106-IM-G(4) Installation Manual W SIG.doc Page 7...

  • Page 8: General Information

    The SN3308 is designed to display the downloaded flightplan data from a connected GPS receiver or from a Jeppesen database (available on software version 2.00 or later). The moving map database for the SN3308 as well as the internal operating system software are field uploadable through the use of a portable computer equipped with a Windows operating system and an RS-232C Serial Port.

  • Page 9: Installation Planning

    Contact the factory with any questions about interfacing to specific avionics equipment not covered in the installation drawings. To simplify installation and installation planning, signals are wired to the SN3308 pins per the installation diagrams and software setups are used in a post-installation procedure to assign protocols/gradients to each pin based on the equipment connected.

  • Page 10: Interface Planning

    SN3308 for reference. Review special items such as connection of the Nav receiver resolver wiring. Apply power to the SN3308, bring up in maintenance mode (see page 41) and sequentially access each SN3308 maintenance page to correctly select the installed equipment.

  • Page 11: Gps (Loran) Switching

    SN3308. This is referred to as “master” mode and it is the preferred mode of installation. In this configuration an additional remote switch/annunciator panel for a GPS receiver is not required.

  • Page 12: Gps Annunciators

    SN3308 Navigation Display Installation Manual used to ground an SN3308 input pin when the relay is in the energized position. If the low signal is not detected, the SN3308 annunciates the relay failure by redlining the nav source display. The actual pin number used for the RELAY SENSE input is selected in the RELAY SENSE maintenance page.

  • Page 13: Marker Beacon

    Sandel Avionics SN3308 Navigation Display Installation Manual damage from inadvertent miswiring. Refer to the Sandel installation drawing. This resolver will operate from 30Hz to 500Hz and is calibrated in the NAV maintenance page b) An electronic 400Hz differential resolver is provided for use with 400Hz receivers such as Collins VIR-30A.

  • Page 14: Rs232 / Rs422 Serial Communication

    Sandel Avionics SN3308 Navigation Display Installation Manual of these receivers as more data is available to the SN3308 and it also eliminates the requirement for the course resolver relay switching. See the installation drawings. Channel 2 (P3-9/27) is normally used for Digital DME-1 along with clock pin P3-8;...

  • Page 15: Garmin Gns430 Gps/Vor/Loc Combination Receiver

    The RS-232 and RS-422 transmitters are on separate pins and operate simultaneously. Note that the same receiver pins are used for either RS232/422. The SN3308 uses a differential receiver compatible with both standards. RS-232 is connected to the minus input of the receiver, and the plus input is grounded because RS-232 is an inverted signal, i.e.

  • Page 16: Required Sn3308 Setup Items

    Hardware MOD1 STATUS OR LATER 1.30 OR LATER Software Maintenance STUDY THE SANDEL MAINTENANCE PAGE ITEMS ON THE Page Items APPROPRIATE GNS430 INSTALLATION DRAWINGS, AND SET AS INDICATED. IN A DUAL GNS430 INSTALLATION MAKE SURE BOTH NAV-1 AND NAV-2 ARE DOUBLE-ASSIGNED TO ARINC PORT-2.

  • Page 17: Ups Gxxx Rs232 Interface

    A separate brightness control only for the SN3308 must be installed externally. The SN3308 does not have an internal photocell, so the pilot must be able to adjust the dimming of the SN3308 separately from the other avionics. This control allows the pilot to control the brightness of the display from 0% to 100% of normal brightness.

  • Page 18: Disclaimer

    Sandel Avionics does not assume any risk for nor accept any responsibility for the interface descriptions contained within this Installation Manual. It is the responsibility of the installer to ensure that such equipment is compatible with the SN3308 as described, and to ensure that the installation of the SN3308 is accomplished with such equipment using the specific equipment manufacturer’s installation and...

  • Page 19: Technical Information

    Bendix/King KI-525 series PNI. The SN3308 operates on an input voltage from 11 to 33 Volts DC and requires 3.3 amperes of current at 11 Volts DC when the AMLCD display is operating at maximum brightness.

  • Page 20: Operational Characteristics

    AC and DC sine, cosine, and discrete input and output voltages. The SN3308 design and operation is optimized for efficient adaptability to both new and existing avionics equipment and systems.

  • Page 21: Connector P1

    Sandel Avionics SN3308 Navigation Display Installation Manual 2.3.1 Connector P1 Display Primary Power Input Note 1 Display Primary Power Input Note 1 Clock Keep Alive Power See Install Diagrams N/C (Key) Display Power Return (Ground) Note 1 Display Power Return (Ground)

  • Page 22: Connector P2

    Sandel Avionics SN3308 Navigation Display Installation Manual 2.3.2 Connector P2 Vert. Superflag Out Reserved Lat. Superflag Out Reserved Vert. Deviation Out Reserved Lat. Deviation Out Reserved DME2 Hold/Analog DME Valid/DME1 Nav-2 Sense External Switch1 In 26VAC/400Hz Primary AC Excitation In...

  • Page 23: Connector P3

    Sandel Avionics SN3308 Navigation Display Installation Manual 2.3.3 Connector P3 Auxiliary Power Output Reserved Spare1 Discrete Out (Darlington) Reserved GPS OBS- or HOLD- Command Discrete Out (Darlington) GPS-2 Switching Relay Discrete Out (Darlington) GPS-1 Switching Relay Discrete Out (Darlington) Spare2 Discrete Out (Darlington)

  • Page 24: Arinc 419/429 Serial Data Receivers Interfaces

    SN3308 and peripheral avionics equipment. The bus conforms to 419/429 specifications for electrical characteristics, receiving, and transmission interval. The SN3308 is capable of receiving the following low speed ARINC 419/429 long- range Nav, VHF NAV, GS or DME inputs for processing and display as follows:...

  • Page 25: Arinc 419/429 Serial Transmitter Interfaces

    Sandel Avionics SN3308 Navigation Display Installation Manual ARINC 419/429 Serial Transmitter Interfaces The SN3308 is capable of transmitting the following low-speed ARINC 419/429 data: Label Description Rate (ms) Data Type 100G Selected Course (Using extended SDI) Magnetic Heading Basic Component Part Number and Variants...

  • Page 26: Bill Of Materials - Sn3308 Install Kit

    Sandel Avionics SN3308 Navigation Display Installation Manual Bill of Materials – SN3308 Install Kit Description Quan. Vendor Part No. 32001 Conn., D- 37 Pin Female ITT DCMAY-37SFO (part of 61013 tray assy) 32003 Connector, Female Pins D ITT 031-1007-073 32037 Conn., Jack, Phone...
  • Page 27 Manual, as Appendix B, and should be referenced to the categories appropriate to the aircraft type and environment into which the SN3308 is to be installed. environmental category for the SN3308 should be stipulated on the FAA Form 337, or other approval form.

  • Page 28: Installation

    However, it is extremely important that the mounting area below the Clamp Tray Fixture opening and the adjacent area above the SN3308 when inserted, be kept clear of any objects which would restrict the inflow of air at cabin ambient temperature.

  • Page 29: Mechanical Installation Considerations

    3.2.4 Electrical Installation Considerations Connections and functions of the SN3308 are described in this section. Refer to the SN3308 Interconnect Wiring Diagrams for detailed wiring information and appropriate notes. Refer to the Functional Pinout Descriptions for explanations of pin functions.
  • Page 30 Flux Gate (if installed), Gyro Reference, and Gyro XYZ (if installed). I. Power Wiring. To assure that the SN3308 will operate properly down to its rated minimum input voltage of 11Vdc, ensure that two power wires of at least the recommended size are connected from the EHSI circuit breaker to the SN3308 in accordance with the installation drawings.

  • Page 31: Connector P-1 Pinout Description

    Pin 2 is keep alive power. Connection to this pin is not required, but a voltage over 6.5VDC on this pin when the main power falls below 11VDC will reduce the re-boot time of the SN3308 after a power interruption to approximately 1.5 seconds instead of the typical 6 seconds for power interruptions under two minutes.
  • Page 32 These pins control the enabling of the Glideslope pointer. They are not related to the bearing pointer operation. These signals also control the ILS Lockout logic so the SN3308 can sense when a GPS receiver is inappropriately selected as the primary nav source when ILS Lockout is not disabled on the NAV maintenance page.
  • Page 33 A different calibration value setting is used for each possible nav source selectable on the SN3308. 24 AWG twisted shielded pair conductor is recommended for these functions. Please see the warnings on the installation drawings concerning the connection to P1-28.

  • Page 34: Connector P-2 Pinout Descriptions

    Sandel Avionics SN3308 Navigation Display Installation Manual Differential input supports VHF Nav or long-range navigation +TO pointer and +FROM pointer outputs. In-view is greater than 40 mVDC (to) and –40mVDC (from). Note that a 24 AWG twisted shielded pair wire is recommended functions.
  • Page 35 HDG Datum and CRS Datum outputs. It is intended for use with older Century autopilots and can potentially eliminate the need for a King KA52 autopilot adapter to be used. Contact Sandel for details of the use of this pin. It must be externally transformer isolated.
  • Page 36 Installation Manual P2-30: GPS SELECTED Input This input is used when the SN3308 is set up for slave mode so an external GPS switch can be used to switch to an external GPS receiver. Causes proper mode switching and annunciation on the SN3308 display. This input is active only when enabled in the System maintenance page.
  • Page 37 Sandel Avionics SN3308 Navigation Display Installation Manual The selection of the function for these inputs is in the ADF-2 Maintenance Page and the NAV maintenance page. When 400Hz differential resolver operation is required ADF-2 operation cannot be used. For AC inputs Z is grounded.

  • Page 38: Connector P-3 Pinout Descriptions

    P3-1: Auxiliary Power Output This output is filtered DC which is nearly the same as the DC potential supplied to the SN3308 but is restricted to 250 ma loads. It is provided to support future accessories. P3-20: Spare1 Discrete Out (DARLINGTON) Reserved for future use.
  • Page 39 Sandel Avionics SN3308 Navigation Display Installation Manual P3-9: Ch2 ARINC 429-A / 568 Data / King Serial Data P3-27 Ch2 ARINC 429-B / 568 / King DME-REQ Input P3-8: Ch2 ARINC 568 DME Sync / KING Serial Clock Input Serial data inputs for either ARINC 429 / 568 serial protocols to support ARINC DME’s as selected within the DME Maintenance page (Low speed...
  • Page 40 Sandel Avionics SN3308 Navigation Display Installation Manual P3-18: High Speed Clock+ P3-36: High Speed Clock- P3-19: High Speed Data+ P3-37: High Speed Data- Reserved for future use. 90106-IM-G(4) Installation Manual W SIG.doc Page 40...

  • Page 41: Setup Procedures

    Accessing The Maintenance Menus To access the Maintenance Menus perform the following operations: A. Prior to applying power to the SN3308, depress and hold the SHFT and the A- B pushbuttons, then apply power to the unit. Continue to hold until the first maintenance menu appears.

  • Page 42: Operating Details

    SN3308 Navigation Display Installation Manual Operating Details For an explanation of the operating controls of the SN3308, refer to the Pilot’s Guide for the SN3308, Sandel Avionics P/N 90106-PG, or to the Airplane Flight Manual Supplement.. 90106-IM-G(4) Installation Manual W SIG.doc...

  • Page 43: Instructions For Continued Airworthiness

    FAA Advisory Circulars 23.1309-1( ) and 25.1309-1( ) which identifies potential failure modes of the Sandel Avionics Model SN3308 Navigation Display. The assumption made is that all functions of the SN3308 will be used in an essential (primary) navigation function.
  • Page 44 Then remove the single size 8-32 screw at the lower-left of the SN3308. Insert a 7/64” Allen key into this hole approximately ¾” and you will engage a removal jackscrew. This jackscrew is used to assist in removing the SN3308 but cannot extract the SN3308 alone.
  • Page 45 Sandel Avionics SN3308 Navigation Display Installation Manual Remove the new projection lamp from its box but do not touch the new lamp glass envelope with bare fingers. Instead, touch the lamp using supplied finger cots or the lamps plastic bag. Slide the lamp out far enough to expose the leads.
  • Page 46 Make absolutely sure the SN3308 is fully engaged in its tray connectors, and tighten the two upper screws. Do this while continuing to apply a slight force on the SN3308 bezel to keep the unit fully engaged with its connectors.
  • Page 47 SN3308 Navigation Display Installation Manual Retest by verifying proper operation of the SN3308 and all associated avionics equipment. Enter the change of the projection lamp, and inspection and test record into the aircraft maintenance records and present a copy of the description of work accomplished to the aircraft owner or operator.

  • Page 48: Appendix A: Post-Installation Procedures

    Installation Manual Appendix A: Post-Installation Procedures After all wiring has been verified and the SN3308 has been installed into the panel, the maintenance pages must be accessed to properly configure the SN3308 for the installed equipment. Prior to applying power to the SN3308, depress and hold the SHFT and the A-B pushbuttons, then apply power to the unit.
  • Page 49 Align the aircraft to North. Turn the system on and step the “quadrant” adjustment to align the SN3308 display to North 20 . (Ensure the adjustments on Page-3 are set to zero). If you can’t get closer than 30 or 40 degrees, your “xyz”...
  • Page 50 Sandel Avionics SN3308 Navigation Display Installation Manual Note: When installing to existing wiring, ensure that the fluxgate center tap which exists on some Honeywell (Sperry) and Collins fluxgates is not connected. b) Ensure the compass card rotation is correct by observing that the displayed heading increases/decreases properly as the aircraft heading is changed or the fluxgate is rotated by hand.
  • Page 51 Sandel Avionics SN3308 Navigation Display Installation Manual COMPASS CALIBRATION North: > 0.00 East: 0.00 South: 0.00 West: 0.00 Purpose: Calibrates the compass slaving system. Instructions: to select the item and the HDG control knob to adjust. Align the aircraft at each cardinal heading and adjust the corresponding calibration item to the exact heading.
  • Page 52 Sandel Avionics SN3308 Navigation Display Installation Manual 429: Enables and forces the source to be the 429 port as selected for this receiver in the NAV setup page. 429+COMP Uses the 429 port (as described above) unless the cross-side receiver is the pilot’s current nav source, in which case defaults this pointer to the composite input.
  • Page 53 Sandel Avionics SN3308 Navigation Display Installation Manual 6:DME-2 SELECT CURRENT SELECTION NOT INSTALLED NOT INSTALLED ANALOG 40MV/MILE SERIAL ARINC 568 SERIAL KING DIGITAL Purpose: Selects DME-2. Instructions: or HDG control knob to choose, and use the SET softkey to select. When the SET softkey is depressed, the active selection will appear to the top under “current selection”.
  • Page 54 Sandel Avionics SN3308 Navigation Display Installation Manual 7: DME 1 / 2 CHANGE DME1: > NOT INSTALLED DME2: NOT INSTALLED DME-1 HOLD ACTIVE HIGH DME-2 HOLD ACTIVE HIGH DME-2 HOLD DME2 HOLD ANALOG 0mi 90mi ANALOG DIST 00.0 nm Purpose:...
  • Page 55 Sandel Avionics SN3308 Navigation Display Installation Manual 8: FCS EMULATION CURRENT SELECTION BENDIX IN-831 KING > KI-525 COLLINS PN-101 CENTURY NSD360 CENTURY 21/31/41 DC CENTURY 2000 DC CENTURY II OR III CENTURY CESSNA 400B AC CESSNA 400B DC SPERRY SPZ-500...
  • Page 56 Sandel Avionics SN3308 Navigation Display Installation Manual 9: FCS CHANGE KING KI-525 DEFAULT CURRENT SIGNAL HDG DATUM +RIGHT +RIGHT CRS DATUM +RIGHT +RIGHT HDG V/DEG 00.550 00.550 CRS V/DEG 00.210 00.210 MIN VOLTS -09.997 -09.997 MAX VOLTS 09.996 09.996 REF VOLTS 00.001...
  • Page 57 Sandel Avionics SN3308 Navigation Display Installation Manual (Note prior to software 1.34 CRS and HDG were a single item and have been separated in software 1.34 to support the Sperry SPZ-500 and similar autopilots which use opposite phase on CRS and HDG).
  • Page 58 Sandel Avionics SN3308 Navigation Display Installation Manual LNAV-1 SELECT CURRENT SELECTION NONE NONE AERO COMP LE-2004 ARNAV R-50 II MORROW II MORROW II MORROW II MORROW 2001 (RS-232) II MORROW 2101 (RS-232) II MORROW 2001 (ARINC) II MORROW 2101 (ARINC)
  • Page 59 Sandel Avionics SN3308 Navigation Display Installation Manual Purpose: Changes selection of primary nav LNAV-1. If none installed select NONE. Instructions: or right control knob to move the cursor, and use the SET softkey to select. Note Selection of LNAV 1 selects 429 Port 1 or #1 RS232 Maintenance Page 11 is identical and sets LNAV-2.
  • Page 60 Sandel Avionics SN3308 Navigation Display Installation Manual an ARINC-429 interface the OBS information is transmitted to the receiver via the ARINC-429 interface. 90106-IM-G(4) Installation Manual W SIG.doc Appendix-A Page 13...
  • Page 61 Sandel Avionics SN3308 Navigation Display Installation Manual MKR SELECT CURRENT SELECTION NONE NONE COLLINS AMR-350 KING KMA-20 KING KMA-24 KING KMR-675 KING KNR-634 KING KR-21 KING KR-22 TRIMBLE TMA-340 TRIMBLE TMS-350 Purpose: Changes selection of the marker beacon receiver. If none is installed select NONE.
  • Page 62 Sandel Avionics SN3308 Navigation Display Installation Manual 15: NAV CHANGE NAV-1 ENABLE PORT 429 PORT-3 NAV-2 ENABLE PORT ANALOG VALID LOW RELAY MODE MASTER ILS LOCKOUT NAV-2 OBS NORM OBS CAL 000.0 COMPOSITE-1 012.0 003.2 Purpose: Sets up functions associated with VHF NAV 1 & 2 and ILS.
  • Page 63 D/E/F/G of the receiver, not the grounded pins. Calibration problems See steps below SN3308 Nav Page Resolver Calibration (does not apply to VIR-30 or KNR-634) STEP COMMENTS 1. Set nav test set to zero degrees and SN3308 course pointer (OBS) to zero degrees.
  • Page 64 Purpose: Enables/disables relay sense from any relays which are driven from SN3308 relay control outputs. When a ground closure is not detected on the appropriate relay sense terminal (indicating that the relay did not close) the pilot’s NAV source selection will be redlined on the pilot’s display.
  • Page 65 CDI SRC SEL A special input related to Garmin GNS430 installations. When enabled, allows the SN3308 to control (ground) or not control (ungrounded) the CDI source select on the GNS 430. When turned off, the CDI select is always enabled.
  • Page 66 Sandel Avionics SN3308 Navigation Display Installation Manual 17: SYSTEM LCD SETUPS CONSULT FACTORY SET LEFT POS SET TOP POS TRIM BOT POS TRIM RT POS TRIM T/B CENT TRIM L/R CENT LCD SHP LCD PLL LCD TC1 Notes: These settings should be changed only on instructions from the factory, service bulletin, or service information letter.
  • Page 67 COLOR SEL: Used to select either the PILOT or COPILOT color scheme for cross-side receiver indications in a dual-SN3308 installation. BOOTSTRAP: Used to select OFF, NORMAL, or –180 for the RMI bootstrap output signals. This output may be used to provide a heading to an external RMI, moving map or weather detection equipment.
  • Page 68 Sandel Avionics SN3308 Navigation Display Installation Manual WX-500 SET WX-500 DISABLED IN SYSTEM PAGE. Purpose: Displays setup data used in WX-500 installations. Refer to the BFG WX-500 installation manual for instructions on the information contained in this page. WX-500 DATA WX-500 DISABLED IN SYSTEM PAGE.
  • Page 69 Sandel Avionics SN3308 Navigation Display Installation Manual BRIGHTNESS Button Lo Bright Button Hi Bright LAMP DATA V-Cal 14V -020 I-Cal 14V 1000 I-Cal 28V 1000 Lamp PWM Lamp Ma 2000 Lamp Init Ma 2010 2009 Lamp Peak Ma 2100 2100...
  • Page 70 During this operation the lamp will automatically be brought to maximum brightness and measured over a period of 30 seconds. If you want to abort this operation after selecting it, remove the SN3308 power early in the test cycle. 22-25: DVM Groups Various 90106-IM-G(4) Installation Manual W SIG.doc...
  • Page 71 Sandel Avionics SN3308 Navigation Display Installation Manual 90106-IM-G(4) Installation Manual W SIG.doc Appendix-A Page 24...
  • Page 72 Purpose: Shows the actual measured input voltages (AC or DC as appropriate) at the SN3308 input pins as well as power supply voltages. This may be helpful in diagnosing installation wiring problems. Please note that AC signals are shown peak so a 26 volt sine wave input will show as approximately 36 volts, while a 26 volt square wave will show as 26 volts.
  • Page 73 Counts occurrence of power fail sensing. Should normally always be 000000. Serial Ports Break: Usually indicates +/- inputs to SN3308 are wired backwards. If also associated with framing errors may indicate the wrong baud rate selected from the sender. Overrun: Usually indicates baud rate of sending unit is too high.

  • Page 74: Appendix B: Environmental Qualification Form

    Sandel Avionics SN3308 Navigation Display Installation Manual Appendix B: Environmental Qualification Form RTCA/DO-160C Environmental Qualification Form Product nomenclature: SN3308 ColorMap Navigation Display Manufacturer: Sandel Avionics, 2401 Dogwood Way, Vista, CA 92083 Section/ Description of Conducted Tests Conditions Paragraph Temperature and altitude Equipment tested to category F1 (-55 C to +70 C to 55,000’...
  • Page 75 Tests described in Sections 15, 16, 17, 18, 19, 20, 21, and 22 were conducted by Chomerics, Radiation Test Services, Woburn, MA. Tests described in Section 6 were conducted by National Technical Systems, Boxborough, MA. All test reports are on file at Sandel Avionics. 90106-IM-G(4) Installation Manual W SIG.doc Appendix-B Page 2...

  • Page 76: Appendix C: Sample Faa Form

    7. AlliedSignal Electronics and Avionics, KMT 112 Magnetic Azimuth Transmitter. (or as appropriate) (By example state the following functional interface properties)... C. The SN3308 receives and processes GPS navigation information for digital and waypoint display from the GPS 165. These operations are considered supplemental navigation.
  • Page 77 KX 165. These operations are considered primary means of navigation. E. The SN3308 receives and processes glideslope deviation and composite audio for bearing display from the KX 155. F. The SN3308 receives and processes radar (radio) altimeter information for digital and virtual display from the KRA 10A.

  • Page 78: Appendix D: Sample Airplane Flight Manual Supplement

    The following is being provided for installations in which the local FSDO requires an Airplane Flight Manual Supplement . This sample is from a Sandel STC in a Bonanza F33. It is simply being provided for the convenience of the installer.
  • Page 79 Sandel Avionics SN3308 Navigation Display Installation Manual Refer to the SN3308 Navigation Display Pilots Guide for other error messages and alerts. SECTION IV NORMAL PROCEDURES VOR-LOC-ILS 1 GPS1 VOR 1 VOR 2 GPS 1 Sandel Avionics SN3308 Navigation Display The selection of the primary navigation source between VOR-LOC-ILS 1 and GPS 1 is accomplished by the use of the NAV switch and will connect the source to the HSI course pointer and the autopilot.

  • Page 80: Appendix E: Checkout Procedures

    11.1 Functional Ground Test Procedures/Report The “Functional Ground Test Procedures/Report” below is for the purpose of simplifying ground tests of the SN3308. A copy of this report (and the “Operational Flight Check Procedures/ Report in Section C-2) must be retained by the installing agency and a copy must be installed in the aircraft maintenance records.
  • Page 81 Installation Manual COMPANY NAME COMPANY ADDRESS TELEPHONE/FAX Ground Test Procedures/Report Sandel Avionics SN3308 Installed in {aircraft make and model} Registration No. ________ SN3308 Serial No. ______________ Document No. ____________ Rev. - , Date 90106-IM-G(4) Installation Manual W SIG.doc Appendix-E Page 2...

  • Page 82: Introduction

    “Post-Installation Procedures”, but prior to performing flight test procedures. Successful completion of both the Ground Test and Flight Test procedures is necessary to support the claim that the SN3308, as installed, performs its intended function and is compatible with all aircraft systems.

  • Page 83: System Configuration

    Power check all wiring to ensure that 28 VDC and 26 VAC (if applicable) are applied to the proper pins and nowhere else. Completed _______ Comment __________________________________ Install the SN3308 into the clamp tray and verify full connector mating and that the unit installs without obstruction. Completed _______ Comment __________________________________ Activate the aircraft master switch and avionics master switch, if installed.

  • Page 84: System Functions

    Completed _______ Comment __________________________________ Remove power to (or otherwise disable) the remote directional gyro. Verify that the compass card is displayed in amber AND that a warning message is displayed on the SN3308 which requires operator acknowledgement. Completed _______ Comment __________________________________ 11.1.8 NAV Source Selection...

  • Page 85: Brg Source Selection

    Completed _______ Comment __________________________________ 11.1.9 BRG Source Selection Press SHFT>BRG on the SN3308 and verify that all installed nav sources are presented for each bearing pointer (NAV1, NAV2, ADF1, ADF2, GPS1, GPS2 as installed). In addition, bearing pointer 1 will have “AUTO” listed as a choice.

  • Page 86: Gps Interface And Control

    Sandel Avionics SN3308 Navigation Display Installation Manual appropriate DME readout on the SN3308 distance display. Press SHFT>BRG to configure bearing pointer 1 to be NAV1 and bearing pointer 2 to be NAV2. Press BRG to display both pointers simultaneously. Verify that the correct DME data is displayed in each bearing pointer data block.

  • Page 87: Marker Beacon Interface

    SN3308 Navigation Display Installation Manual Allow the receiver to acquire a valid position fix, and press NAV on the SN3308 to select that receiver as a nav source. Enter either a single destination waypoint or a flight plan on the GPS receiver and select normal (LEG) navigation mode. Verify that the course pointer automatically rotates to the desired track, and that groundspeed and waypoint ID are displayed on the SN3308.

  • Page 88: Flight Control System Interface

    Verify that “WX” is annunciated on the SN3308 display. Completed _______ Comment __________________________________ Press SHFT>NAV and select “WX TEST”. Verify that the word “TEST” is annunciated on the SN3308 display for approximately 10 seconds, and is then replaced by “WX”. Completed _______ Comment __________________________________ 11.1.15...

  • Page 89: Emi/Rfi Test Procedures

    SN3308, is operating normally. Open the squelch on the primary communications radio and tune the radio to each whole megahertz frequency sequentially. Attempt to discern any interference caused by the SN3308. Pull the SN3308 breaker if interference is noted, to verify that the SN3308 is the source.

  • Page 90: Additional Testing

    SN3308 Navigation Display Installation Manual Observe any unusual interaction between the transponder, DME, ADF or Marker Beacon receivers, and the SN3308 when switching power to any equipment. Completed _______ Comment __________________________________ 11.2.3 Additional Testing Perform any additional EMI/RFI-related tests deemed necessary.

  • Page 91: Operational Flight Test Procedures/Report

    11.3 Operational Flight Test Procedures/Report The “Operational Flight Check Procedures/Report” below is for the purpose of simplifying the in-flight operational check of the SN3308. A copy of this report (and the “Functional Ground Test Procedures/ Report” in Section C-1) must be retained by the installing agency and a copy must be installed in the aircraft maintenance records.
  • Page 92 Sandel Avionics SN3308 Navigation Display Installation Manual COMPANY NAME COMPANY ADDRESS TELEPHONE/FAX Flight Test Procedures/Report Sandel Avionics SN3308 Installed in {aircraft make and model} Registration No. ________ Serial No. ______________ Document No. ____________ Rev. - , Date 90106-IM-G(4) Installation Manual W SIG.doc...

  • Page 93: Introduction

    Verify that either the SN3308 external brightness control or the aircraft dimming bus control (as installed) can control the brightness of the SN3308 and that a satisfactory brightness level can be attained. Completed _______ Comment __________________________________ Evaluate the display of the SN3308 for readability.

  • Page 94: Enroute Operations

    Cycle various aircraft electrical equipment such as lights, landing gear, radar, pitot/windscreen heat, and anti-icing boots. Verify that none causes interference on the SN3308 display. Completed _______ Comment __________________________________ Verify proper operation of one or both VHF nav receivers (as installed), both as nav sources and as bearing pointer sources.

  • Page 95: Ils Approach Operations

    Installation Manual Resolver interface in OBS or HOLD mode GPS annunciator display on the SN3308 (as installed) External GPS mode control switches on the SN3308 (as installed) Waypoint display when map is enabled on the SN3308 11.5.4 ILS Approach Operations Conduct at least one fully coupled ILS approach (in VFR conditions) for each VHF nav receiver installed.
  • Page 96 SINGLE SN3308 / GNS430/530 90106-10 pp 26 SINGLE SN3308 / DUAL GNS430/530 90106-10 pp 27 SINGLE SN3308 / GNS430/530 / #2 VHF NAV 90106-10 pp 28 DUAL SN3308 / GNS430/530, FCS PILOT ONLY 90106-10 pp 29 DUAL SN3308 / GNS430/530, FCS SELECTABLE...
  • Page 99 1. THESE LOAD RESISTORS ARE REQUIRED FOR PS ENGINEERING MARKER RECEIVERS. RECOMMENDED FOR OTHER RECEIVERS TO PREVENT FAILURE OF THE SN3308 INDICATION IF THE ASSOCIATED MARKER LIGHT BULB FAILS. 2. SELECT THE APPROPRIATE MARKER BEACON RECEIVER ON THE SN3308 MARKER BEACON INSTALLATION PAGE. IF SPECIFIC RECEIVER NOT SHOWN USE KMA-24 SETTING.
  • Page 100 1. THESE LOAD RESISTORS ARE REQUIRED FOR PS ENGINEERING MARKER RECEIVERS. RECOMMENDED FOR OTHER RECEIVERS TO PREVENT FAILURE OF THE SN3308 INDICATION IF THE ASSOCIATED MARKER LIGHT BULB FAILS. 2. SELECT THE APPROPRIATE MARKER BEACON RECEIVER ON THE SN3308 MARKER BEACON INSTALLATION PAGE. IF SPECIFIC RECEIVER NOT SHOWN USE KMA-24 SETTING.
  • Page 101 1. THESE LOAD RESISTORS ARE REQUIRED FOR PS ENGINEERING MARKER RECEIVERS. RECOMMENDED FOR OTHER RECEIVERS TO PREVENT FAILURE OF THE SN3308 INDICATION IF THE ASSOCIATED MARKER LIGHT BULB FAILS. 2. SELECT THE APPROPRIATE MARKER BEACON RECEIVER ON THE SN3308 MARKER BEACON INSTALLATION PAGE. IF SPECIFIC RECEIVER NOT SHOWN USE KMA-24 SETTING.
  • Page 102 1. THESE LOAD RESISTORS ARE REQUIRED FOR PS ENGINEERING MARKER RECEIVERS. RECOMMENDED FOR OTHER RECEIVERS TO PREVENT FAILURE OF THE SN3308 INDICATION IF THE ASSOCIATED MARKER LIGHT BULB FAILS. 2. SELECT THE APPROPRIATE MARKER BEACON RECEIVER ON THE SN3308 MARKER BEACON INSTALLATION PAGE. IF SPECIFIC RECEIVER NOT SHOWN USE KMA-24 SETTING.
  • Page 103 EXTERNAL SWITCHING RELAY. IF AN EXISTING SWITCH CONTROL BOX IS OBS RESOLVER COS OUT INSTALLED AND IT IS DESIRED TO LEAVE IT OPERATIONAL, USE SN3308 P2-30 OBS COS TO SENSE GPS MODE. THIS WILL DISABLE THE NAV SOURCE SWITCH AND GPS DISPLAYED CHANGE THE SN3308 MODE TO GPS-1 WHEN ACTIVE.
  • Page 104 EXTERNAL SWITCHING RELAY. IF AN EXISTING SWITCH CONTROL BOX IS OBS RESOLVER COS OUT INSTALLED AND IT IS DESIRED TO LEAVE IT OPERATIONAL, USE SN3308 P2-30 TO SENSE GPS MODE. THIS WILL DISABLE THE NAV SOURCE SWITCH AND CHANGE THE SN3308 MODE TO GPS-1 WHEN ACTIVE. YOU MUST ENABLE P2-30 AS THE GPS SENSE INPUT IN THE SN3308 SYSTEM SETUP PAGE.
  • Page 105 DATA LOADER RS422-2 IN+ 1. FOR 3V COMPOSITE NAV SOURCES INSERT A 470K SERIES RESISTOR SEE NOTE 2 LOCATED AT THE SN3308 CONNECTOR. NOT REQUIRED FOR .5V RS422-2 IN- SOURCE. 2. MOUNT SOFTWARE DOWNLOAD JACK IN AN ACCESSIBLE LOCATION. 30 RS-232-2 TX JACK IS SWITCHCRAFT TYPE 14B OR EQUIVALENT.
  • Page 106 RECEIVED FROM SN3308) 4. A REMOTE-CLEAR SWITCH CONNECTED TO THE WX-500 CAN BE USED TO CLEAR THE CELL/STRIKE DISPLAY. THIS FUNCTION IS ALSO AVAILABLE ON THE FRONT PANEL OF THE SN3308 VIA SOFTKEYS. Sync X Sync X 5. MOUNT SOFTWARE DOWNLOAD JACK IN AN ACCESSIBLE LOCATION.
  • Page 107 REQUIRED. P6342 2. FOR ARINC NAV RECEIVER USING 400HZ DIFFERENTIAL RESOLVER: a) THE NAV RCVR AND SN3308 MUST BE ON THE SAME INVERTER. OBS 'E' COS OUT 400HZ DIFF RES. SIN IN b) ON NAV MAINTENANCE PAGE SET OBS TYPE TO "DIFF A".
  • Page 108 2. USED ON GARMIN AND KING RECEIVERS WHICH REQUIRE LATCHED MODE COMMANDS BUT NOT ON II-MORROW RECEIVERS. 3. SELECT APPROPRIATE RECEIVER ON THE SN3308 LNAV MAINTENANCE PAGE. IF INSTALLED RECEIVER IS NOT SHOWN ON THIS MATRIX USE NEAREST COMPATIBLE SETTING OF THE SAME MANUFACTURER AND INSURE THE TEXT AND COLORS OF THE ON-SCREEN ANNUNCIATORS ARE ACCEPTABLE.
  • Page 109 FLUXGATE EXISTING COMPASS SYSTEM SUCH AS A KI525A IS MOVED TO THE COPILOTS P51B1 SIDE AND AN SN3308 IS INSTALLED ON THE PILOTS SIDE. UNDER THIS CONDITION THE SN3308 CAN BE DRIVEN BY THE BOOTSTRAP OUTPUT OF FV EXT HI...
  • Page 110 NOTES SN3308 NOTE 8 1. THIS CONFIGURATION DOES NOT ALLOW FOR AN ADDITIONAL INVERTER DRIVING THE SN3308. EITHER USE THE 328A-3G AS THE INVERTER SOURCE, OR IF A DIFFERENT MASTER INVERTER IS FG X FG X USED THEN THE 328A-3G MUST BE REMOVED.
  • Page 111 GYRO AN EXTERNAL 400HZ INVERTER FOR ITS XYZ OUTPUTS. IF AN Exc C EXTERNAL INVERTER IS NEEDED TO DRIVE OTHER SYSTEMS WHICH ARE CONNECTED TO THE SN3308, THIS GYRO IS NOT Fluxgate Excitation PHASE 1 COMPATIBLE. 2200 (1/4 w or larger) 2.
  • Page 112 APPLIED TO ALL AVIONICS. IF VOLTAGE IS PRESENT, CONNECT SN3308 P1-4 TO FCS GROUND KMT112 FG KA51 AT THE ROLL COMPUTER WITH A NEW WIRE. IF PRIMARY POWER IS APPLIED TO SN3308 P1-4 P101 DAMAGE MAY OCCUR TO THE SN3308 RESULTING IN AN OPEN CIRCUIT AT P1-4. THIS CAN BE...
  • Page 113 NOTES: 400 Hz Ref Lo 1. THE SN3308 WILL NOT SUPPORT THE #2 DC ADF RECEIVER WHEN ALSO USED WITH A 400HZ #1 VHF NAV AS THE DIFFERENTIAL RESOLVER 400HZ INPUT AND THE SIN/COS ADF INPUT SHARE THE SAME PINS.
  • Page 114 RECEIVERS. RECOMMENDED FOR OTHER RECEIVERS TO PREVENT FAILURE LAMP COM OF THE SN3308 INDICATION IF THE ASSOCIATED MARKER LIGHT BULB FAILS. 2. SELECT THE APPROPRIATE MARKER BEACON RECEIVER ON THE SN3308 MARKER BEACON INSTALLATION PAGE. IF SPECIFIC RECEIVER NOT SHOWN USE KMA-24 SETTING.
  • Page 115 SELECTION. IF THE DME IS NOT ASSIGNABLE LEAVE THE CORRESPONDING SANDEL SN3308 PIN UNCONNECTED. 40MV/MILE DME ANALOG + 2. IN A DUAL DME CONFIGURATION THE SN3308 CAN ONLY DETECT DME HOLD. IT ALWAYS ASSOCIATES DME-1 WITH NAV-1 AND DME-2 WITH DATA DATA SIGNAL COM DME ANALOG - NAV-2.
  • Page 116 FORCES THE LOWEST SETTING OF THE BRIGHTNESS POT TO .6V OR ABOVE. 4. WITH THE EXCEPTION OF THE OBS RESOLVER ON PINS P1-13, P1-14, P1-28 AND P1-32, THE SN3308 REFERENCES ALL 400HZ INPUTS AND OUTPUTS TO THE SIGNAL ON THIS PIN. SEE ADDITIONAL NOTES ON OTHER SHEETS OF THIS MANUAL.
  • Page 117 1N4004 NOTES: NOTE 4 BACK COURSE 1. IF INSTALLATION ALREADY CONTAINS A KING KA52/57 AUTOPILOT ADAPTER IT MAY REMAIN IN THE SYSTEM. TREAT THE SN3308 AS A ACFT PWR KI525. 2. DATUM OUTPUTS ARE REFERENCED TO GROUND. BACK COURSE 3. CHECK AUTOPILOT INTERNAL SCHEMATIC TO INSURE THAT THE SN3308 IS...
  • Page 118 10K:10K (ABOVE COUPLERS DO NOT NORMALLY THESE VALUES WILL BE THE SAME. 3. GROUND CONNECTIONS TO SN3308 SIGNAL GROUND. SUPPORT COURSE DATUM.) 4. DO NOT GROUND ANY CENTURY II/III SIGNALS EVEN DURING TROUBLESHOOTING. THIS COULD DAMAGE THE AUTOPILOT. SEE THE CENTURY INSTALLATION MANUAL FOR DETAILS.
  • Page 119 HDG DATUM HI 1. SELECT KI525 FOR HSI EMULATION ON THE FCS MAINTENANCE PA SANDEL Vista, Ca. CRS/HDG SIGNAL GND DATUM LO Category SN3308 INSTALLATION DRAWING (AS AVAILABLE FROM GYRO) HDG VALID Title BENDIX/KING AUTOPILOTS Size Document Number 90106-10 Create:...
  • Page 120 NOTES 1. SELECT KI525 FOR HSI EMULATION ON THE FCS MAINTENANCE PAG HDG / CRS SANDEL SIGNAL GND RETURN Vista, Ca. GROUND Category SN3308 INSTALLATION DRAWING Title S-TEC AUTOPILOTS Size Document Number 90106-10 Create: Mod: Sheet Tuesday, September 19, 2000...
  • Page 121 2. SELECT IN831 FOR HSI EMULATION ON THE FCS MAINTENANCE PAGE. 400 HZ INPUT 3. ANY COMMERCIAL 75MW OR GREATER AUDIO TRANSFORMERS MAY BE USED. 4. TRANSFORMERS ARE MAGNA-TEK TY-141P OR EQUIVALENT. 5. THE AUTOPILOT 400HZ IS THE MASTER INVERTER FOR THE SN3308. SANDEL Vista, Ca. Category SN3308 INSTALLATION DRAWING...
  • Page 122 LNAV 1 (SDI1) VOR/LOC/GS ARINC-429 CONFIGURATION: SPD RX: SPD TX: SDI: VOR/ILS 1 (SDI1) SANDEL Vista, Ca. Category SN3308 INSTALLATION DRAWING Title SINGLE SN3308 / GNS430/530 Size Document Number 90106-10 Create: Thursday, January 07, 1999 Mod: Sheet Friday, September 26, 2003...
  • Page 123 SPD TX: SDI: VOR/ILS 2 (SDI2) RCVR 1/2 SANDEL PORT RELAY Vista, Ca. SELECT POWER Category SN3308 INSTALLATION DRAWING Title SINGLE SN3308 / DUAL GNS430/530 Size Document Number 90106-10 Create: Thursday, January 07, 1999 Mod: Sheet Friday, September 26, 2003...
  • Page 124 A/R 6XX ADDED GARMIN GNS 530 DATE REV COMMENTS 5/26/99 F INCORPORATED A/R 126 INITIAL RELEASE 6/25/99 F(1) INCORPORATED A/R 151 SN3308 P3 PORT 1 AND PORT 2/3 REVERSED GARMIN SANDEL SN3308 10/23/00 G ADDED MAX VOLTAGE FOR RELAY. P1 16 AND 34 P4006 P5006 REVERSED ILS2 WAS ILS1.
  • Page 125 2700 AND ABOVE 250 ma MAX (48/49) OR (50/51) SANDEL Vista, Ca. RELAY POWER 1-2 (PILOT) 1-2 (COPILOT) Category SN3308 INSTALLATION DRAWING Title DUAL SN3308 / GNS430/530, FCS PILOT ONLY Size Document Number 90106-10 Create: Thursday, January 07, 1999 Mod: Sheet Friday, September 26, 2003...
  • Page 126 2700 AND ABOVE 250 ma MAX Category SN3308 INSTALLATION DRAWING RELAY POWER 1-2 (PILOT) 1-2 (COPILOT) FCS PILOT / RCVR 1/2 Title SELECT DUAL SN3308 / GNS430/530, FCS SELECTABLE COPILOT Size Document Number 90106-10 Create: Saturday, January 09, 1999 Mod: Sheet Friday, September 26, 2003...
  • Page 127 DME2 HOLD DME2 HOLD RELAY ASSIGNABLE LEAVE THE CORRESPONDING PIN UNCONNECTED. 2. IN A DUAL DME CONFIGURATION THE SN3308 CAN ONLY DETECT DME HOLD. IT ALWAYS ASSOCIATES DME-1 WITH NAV-1 AND DME-2 WITH NAV-2. 3. DME-40 (ARINC 568) DME SUPPORTED IN SOFTWARE 1.32 AND LATER.
