- Page 2 PARTS - PIÈCES 2 bottoms Partition Left vertical molding Panneau supérieur 2 fonds Cloison Moulure verticale gauche #35939306030 #35939000040 #35939306050 #35939306060 Left panel Right panel Panneau gauche Panneau droit #35939306020 #35939306010 3 left drawer fronts 3 right drawer fronts 6 left drawer sides Horizontal molding Right vertical molding 6 côtés du tiroir gauche...
- Page 3 PARTS - PIÈCES #A12100 #A53840 #A22920 #A22570 #A22910 7/16" pan head Angle bracket Connector Cam lock Tête ronde 7/16 po Connector bolt #A22510 Équerre Connecteur Serrure de came Boulon de connecteur Cam bolt Boulon de came #A54220 Drawer bracket Support de tiroir #A21110 #A11080 Nail...
- Page 4 This illustration shows how the cam fastening system works. Cette illustration montre le système de fixation de came et son fonctionnement. Tighten to fully seat. Do not over tighten. Proper orientation of cam. Serrez pour mettre le siège bien en Bonne orientation de la came.
- Page 5 proper orientation of cam lock bonne orientation de la serrure de came on each metal slide sur chaque glissière lightly tap the connector into the hole with a hammer tapez le connecteur légèrement dans le trou avec un marteau 14 a B345939306CTC 00 6 /24...
- Page 6 proper orientation of cam lock bonne orientation de la serrure de came on each metal slide sur chaque glissière lightly tap the connector into the hole with a hammer tapez le connecteur légèrement dans le trou avec un marteau B345939306CTC 00 7 /24...
- Page 7 proper orientation of cam lock bonne orientation de la serrure de came LEFT SIDE CÔTÉ GAUCHE RIGHT SIDE CÔTÉ DROIT on each metal slide sur chaque glissière 14 a x 18 B345939306CTC 00 8 /24...
- Page 8 proper orientation of cam lock bonne orientation de la serrure de came proper orientation of cam lock bonne orientation de la serrure de came B345939306CTC 00 9 /24...
- Page 9 note location of holes when fastening Panel (D) notez l'endroit des trous en fixant le Panneau (D) LOCK SERRER B345939306CTC 00 10 /24...
- Page 10 note location of holes when fastening Panel (D) notez l'endroit des trous en fixant le Panneau (D) LOCK SERRER B345939306CTC 00 11 /24...
- Page 11 finished edge bord fini LOCK SERRER B345939306CTC 00 12 /24...
- Page 12 Turn connector screw clockwise to lock in place. Tournez la vis du connecteur vers la droite pour verrouiller en place. B345939306CTC 00 13 /24...
- Page 13 WARNING notch is here l'encoche est ici Please make sure that the back panel is attached securely. All nails must be driven into the parts straight. Failure to do so could cause instability, product collapse, and/or serious injury. AVERTISSEMENT Veuillez vous assurer que le panneau arrière est solidement fixé. Tous les clous doivent être enfoncés perpendiculairement.
- Page 14 proper orientation of molding bonne position de la moulure B345939306CTC 00 15 /24...
- Page 15 hole Option 1: trou Securely screw (13c) into solid area of the wall as shown. Option 1: stud Vissez solidement (13c) dans une région solide du mur montant comme montré. Option 2: Drill a 3/16" diameter hole (5 mm) in the wallboard. Tap the wall anchor (13d) into the hole until it is flush.
- Page 16 Lay the drawer sides down on a flat hard surface. Carefully line up the drawer bracket with the holes in the drawer side as shown. Using a hammer, tap each drawer bracket stem part way into each hole. Repeat this process until the drawer bracket is fully seated on the drawer side.
- Page 17 left drawer assembly assemblage du tiroir gauche raw surface surface non finie finished surface surface finie finished edge bord fini B345939306CTC 00 18 /24...
- Page 18 left drawer assembly 14 d 14 c assemblage du tiroir gauche B345939306CTC 00 19 /24...
- Page 19 Drawer installation: Slightly tilt the back of the drawer downwards and engage the drawer runner on "both" sides of the drawer into the cabinet members (see illustration below). Gently push the drawer into the dresser, making sure that the drawer runners are properly rolling in the cabinet members.
- Page 20 right drawer assembly assemblage du tiroir droit raw surface surface non finie finished surface surface finie finished edge bord fini B345939306CTC 00 21 /24...
- Page 21 right drawer assembly 14 d 14 c assemblage du tiroir droit B345939306CTC 00 22 /24...
- Page 22 Drawer installation: Slightly tilt the back of the drawer downwards and engage the drawer runner on "both" sides of the drawer into the cabinet members (see illustration below). Gently push the drawer into the dresser, making sure that the drawer runners are properly rolling in the cabinet members.
- Page 23 MAXIMUM LOADS – CHARGES MAXIMALES This unit has been designed to support the maximum loads shown. Exceeding these load limits could 25 lb cause sagging, instability, product 11,3 kg collapse, and/or serious injury. 50 lb Ce meuble a été conçu pour 22,7 kg supporter les charges maximales indiquées.
