Package Contents; Specification; System Requirements - i-tec USB-C 3.1 Display Port Adapter User Manual

i-tec USB-C 3.1 Display Port Adapter
INTRODUCTION
Thank you for purchasing the i-tec USB-C 3.1 Display Port adapter that will
allow you to connect Display Port monitor / TV / projector to a notebook, a
tablet, a PC or a smartphone with a USB-C port. It offers 1x 4K Display Port.
Thanks to its compact dimensions, low weight and application without a
power adaptor it is also convenient for travelling.

PACKAGE CONTENTS

i-tec USB-C Display Port adapter with cable (15 cm)
Ÿ
Quick Start
Ÿ

SPECIFICATION

1x USB-C 3.1 connector, transfer rate up to 10 Gbps
Ÿ
Graphic interface: 1x Display Port (spec. 1.2); max. resolution
Ÿ
3840x2160 / 60Hz
Resolution: 640x480, 800x600, 1024x768, 1280x720, 1280x768,
Ÿ
1280x800, 1280x1024, 1360x768, 1366x768, 1368x768, 1400x1050,
1600x1200, 1680x1050, 1920x1080, 1920x1200, 2048x1152
2048x1280 2048x1536 2560x1440 2560x1600 3840x2160
Mode: Extend, Mirror and Primary Display
Ÿ
Supported colors 16 / 32 bit
Ÿ
Powered through USB bus (no power adapter is needed)
Ÿ
Chipset: VL100 & CYPD1120
Ÿ
OS: Requires USB-C interface with "DisplayPort Alternate Mode"
Ÿ
support (not all devices / systems with USB-C interface supports the
standard) or Thunderbolt 3 port – Windows 10 32/64bit, Mac OS X,
Chrome OS (Google) with Intel Broadwell Processor and R51 and
higher
Product dimensions: 51 x 25 x 12 mm
Ÿ
Product weight: 25 g
Ÿ

SYSTEM REQUIREMENTS

Hardware requirements: notebook, tablet, PC, smartphone with OS
Windows, Mac or Google with a free port USB-C with "DisplayPort Alternate
Mode" support
Operating system: Windows 10, Mac OS X, Google (Chrome OS) with latest
updates
After connecting, the drivers for the adapter are installed automatically
from the system.
