TIG Welding is the most controllable, efficient and most versatile method of welding many metals including steel, stainless steel, aluminum and more. Your
EASTWOOD TIG 200 WELDER with High-Frequency Inverter Technology is capable of welding thin or heavy gauge steel and aluminum with precision and ease.
The Voltage self-sensing circuitry automatically detects a power source range of 110 to 240 Volts and delivers from 10 up to 200 Amps of AC or DC current at
super-high frequency with the added advantage of a light weight unit. The included foot pedal provides the operator with the precise Amperage control required
when welding. A high frequency start feature guarantees an instant arc strike with no tungsten contamination.
The Eastwood Company (hereinafter "Eastwood") warrants to the end user (purchaser) of all new welding and cutting equipment that it will be free of defects in workmanship
and material. This warranty is void if the equipme nt has been subjected to improper installation, improper care or abnormal operations.
All warranty periods begin on the date of purchase from Eastwood. Warranty Periods are listed below, along with the products covered during those warranty periods:
All other components are covered by the warranty and will be repaired or replaced at the discretion of Eastwood.
If Eastwood confirms the existence of a defect covered under this warranty plan, Eastwood will determine whether repair or replacement is the most suitable option
to rectify the defect. At Eastwood's request, the purchaser must return, to Eastwood, any products claimed defective under Eastwood's warranty.
EASTWOOD WILL NOT ACCEPT RESPONSIBILITY OR LIABILITY FOR REPAIRS UNLESS MADE BY EASTWOOD. EASTWOOD'S LIABILITY UNDER THIS WARRANTY SHALL NOT
EXCEED THE COST OF CORRECTING THE DEFECT OF THE EASTWOOD PRODUCT. EASTWOOD WILL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES (SUCH AS
LOSS OF BUSINESS, ETC.) CAUSED BY THE DEFECT OR THE TIME INVOLVED TO CORRECT THE DEFECT. THIS WRITTEN WARRANTY IS THE ONLY EXPRESS WARRANTY
PROVIDED BY EASTWOOD WITH RESPECT TO ITS PRODUCTS. WARRANTIES IMPLIED BY LAW SUCH AS THE WARRANTY OF MERCHANTABILITY ARE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY FOR THE EQUIPMENT INVOLVED. THIS WARRANTY GIVES THE PURCHASER SPECIFIC LEGAL RIGHTS.
SPECS
Function Output
Amperage Range
10-145A
AC/DC
TIG
10-200A
AC/DC
10-140A
STICK
10-185A

DUTY CYCLE

The Rated Duty Cycle refers to the amount of welding that can be done within an amount of time. The Eastwood TIG 200 has a duty cycle of 60% at 190 Amps.
It is easiest to look at your welding time in blocks of 10 Minutes and the Duty Cycle being a percentage of that 10 Minutes. If welding at 190 Amps with a
60% Duty Cycle, within a 10 Minute block of time you can weld for 6 Minutes with 4 Minutes of cooling for the welder. To increase the Duty Cycle you can
turn down the Amperage Output control. Going above 190 Amps will yield a lower duty cycle.
2
STATEMENT OF LIMITED WARRANTY
3 Year Warranty on Material, Workmanship, and Defects:
Items not covered under this warranty: Collets, collet bodies, tungsten, nozzles, and ground clamp and cable.
CONDITIONS OF WARRANTY TO OBTAIN WARRANTY COVERAGE:
Final determination of warranty on welding and cutting equipment will be made by Eastwood.
The purchaser is responsible for shipment to and from Eastwood.
THE PURCHASER MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Maximum Output Input
No Load Voltage Voltage
120VAC
220VAC
56V DC
120VAC
220VAC
WARRANTY PERIOD:
• Eastwood TIG 200 AC/DC Welder
2 Years:
• All Welding Helmets.
WARRANTY REPAIR:
FREIGHT COSTS:
WARRANTY LIMITATIONS:
Rated Pre Gas Flow Post Gas Flow
Duty Cycle
60% @
145 Amps
0.1-1.0 Sec
60% @
190 Amps
60% @
140 Amps
NA
60% @
185 Amps
Weight
2-8 Sec
19.1" [486mm] x
45 lbs.
9.8" [248mm] x
[20.4kg]
NA
Overall
Dimensions
20.0" [504mm]
