Sensor Status Display

The Sensor Status Display screen(s) will show you readings for whichever sensors you have attached.
CO
2
Current CO reading, in ppm.
2
Light
Current light reading. The light sensor is typically installed outdoors with a maximum reading of 2000
Watts/meter squared OR in Klux with a maximum of 120Klux.
Wind
This wind speed reading is displayed in miles per hour or kilometers/hour, along with the wind direction
display with one of 8 possible directions: N, NE, E, SE, S, SW, W, NW
Rain
The rain detector indication is either "Yes"-there is rain or "No"-there is no rain.
Temp Probe Number
You can have up to 5 temperature probes attached to your iGrow1800. By mapping your Input Settings,
you can assign each probe to whichever Temp Probe Reading (Temp1, Temp2, etc.) that you want.
iGrow 1800 Installation Guide
CO2 1000 ppm
Light 1000 W/m
Wind SSE 15 mph
Rain No
Temp1 77.0 °F
Temp2 79.4 °F
Temp3 69.8 °F
Temp4 71.2 °F
Temp5 70.5 °F
Page50
