6 - VTX A12 INTRODUCTION

JBL VTX A12 is a complete tour sound solution for mid- to large-size touring applications and high-end fixed installations. VTX A12
was designed from scratch to address the unique challenges of rental companies, FOH engineers and tour sound production crews.
Next-generation JBL transducer technology and a high-frequency waveguide design deliver unmatched performance, sensitivity and
coverage. A patented JBL rigging mechanism and redesigned suspension system streamline deployment and setup. And refine-
ments to the physical design maximize reliability and versatility, while minimizing size and dramatically reducing weight. VTX A12 isn't
just a superior line array—it's a completely new way to approach tour sound.
PERFORMANCE
JBL Professional is the world's leading manufacturer of loudspeaker
systems, using custom designed and built drivers for optimal perfor-
mance.
VTX A12's new high-frequency (HF) section features three uniquely
designed drivers that combine the HF phasing-plug and waveguide into
one part, which helps provide better tolerances and increased sensi-
tivity above 6 kHz, while reducing distortion and overall weight.
Its all-new patented JBL Radiation Boundary Integrator combines
four 5.5" mid-frequency drivers into the high-frequency waveguide—
providing a smooth horn surface for the high-frequency section.
A lightweight 12" low-frequency woofer (LF) features a 4th generation
Differential Drive design, a new dual voice coil, dual magnet and a
host of proprietary JBL technologies for increased excursion, power
handling and sensitivity.
VTX A12 | Rigging Manual
Next-gen JBL loudspeaker technology
Completely rebuilt acoustic components for best-in-class SPL out-
put and 90-degree directivity down to 250 Hz
New highs, mids and lows
All-new high, mid and low frequency designs and components pro-
vide better tolerances, reduced distortion, and increased power
handling
Fast rigging
Quicker deployment with redesigned suspension system and pat-
ented internal locking mechanism for up to 1/4-degree increment
settings
Lightweight truck-friendliness
Lightest-in-class, completely redesigned frame with truck-friendly
dimensions
INNOVATIVE RIGGING
VTX A12 marks a giant leap forward in how the loudspeakers
are rigged and transported. To facilitate quicker deployment,
array elements are stacked four per vertical transporter cart
in a 10-degree collapsed position. A patented internal locking
mechanism makes it easy to set arrays at up to 1/4-degree
increments using selector pins.
ACCESSORIES
The completely redesigned VTX A12 Array Frame is the lightest
in its class. At 41 kg. (90 lbs) the lightweight frame allows the
system to be deployed in a variety of use cases and venues.
Both the cart and frame were purposefully engineered to meet
both U.S. and European truck pack dimensions to help produc-
tion companies transport the system more effectively.
