Server <-> Internet
TCP 5061
Server <-> ICPs
Server <-> LAN
TCP 5269
Internet <-> Server
TCP 22222 Server -> LAN
TCP 22223 Internet -> Server
TCP 4431 Internet -> Server
TCP 80 Server -> LAN
TCP 443 Server -> LAN
TCP 35008 Internet -> Server
TCP 8188 Server -> LAN
TCP 21 Internet -> Server
TCP >1023 Internet -> Server
TCP 21 Server -> LAN
TCP >1023 Server -> LAN
SIP TCP/TLS Support. This port is required for SIP signaling between MBG
and SIP devices that have been configured to use TCP/TLS to port 5061
(the default client configuration). This port may also be opened between
MBG and the ICPs.
MiCollab Client Support (Optional). To permit the MiCollab Client server to
connect to another MiCollab Client server using the XMPP protocol (if
required). Failure to do so will result in the federation features failing to
function.
Support for Mitel 68xx phones with MX-ONE (Optional). This port must be
permitted to enable unencrypted XML connections from the server to the
LAN-based MiVoice MX-ONE ICP.
Support for Mitel 68xx phones with MX-ONE (Optional). This port must be
permitted to enable encrypted XML connections from Internet-based 68xx
phones to the server.
Support for Mitel 68xx SIP phones with configuration server (Optional). This
port must be permitted to enable connections from Internet-based 68xx
phones to the server.
Support for Mitel 68xx SIP phones with configuration server (Optional). This
port must be permitted to enable HTTP connections from the server to the
LAN-based MiVoice MX-ONE configuration server.
Support for Mitel 68xx SIP phones with configuration server (Optional). This
port must be permitted to enable HTTPS connections from the server to the
LAN-based MiVoice MX-ONE configuration server.
MiContact Center Support (Optional). To enable use of the MiContact
Center solution, this port must be permitted from the Internet to the server.
MiContact Center Support (Optional). To enable use of the MiContact
Center solution, this port must be permitted from the server to the Contact
Center server on the LAN.
MiVoice Business Remote Upgrade (Optional). To permit MiVoice Business
software to be uploaded to the MBG server (FTP passive mode).
MiVoice Business Remote Upgrade (Optional). To permit MiVoice Business
software to be uploaded to the MBG server (FTP passive mode).
MiVoice Business Remote Upgrade (Optional). To permit MiVoice Business
software to be downloaded to the MiVoice Business (FTP passive mode).
MiVoice Business Remote Upgrade (Optional). To permit MiVoice Business
software to be downloaded to the MiVoice Business (FTP passive mode).
