MOBILE PHONE
USER'S MANUAL
ELEMENT P006S
EN

Advertisement

Table of Contents
loading

Related Manuals for Sencor ELEMENT P006S

Summary of Contents for Sencor ELEMENT P006S

  • Page 1 MOBILE PHONE USER’S MANUAL ELEMENT P006S...

  • Page 3: Table Of Contents

    Contents Contents Basic information ........................4 Brief description of functions ................4 Safety instructions ......................5 Prior to use ......................... 10 Designation and description of the phone parts.......... 10 Inserting SIM and memory cards ..............13 Telephone on/off ....................18 Charging the battery ................... 18 Security password ....................

  • Page 4: Basic Information

    Basic information Basic information Brief description of functions Thank you for purchasing the Element mobile phone with colour display. This manual provides information on the functions, features and operation of the phone. The mobile phone is designed for the GSM networks environment; the phone allows you to operate two SIM cards in standby, but while you use one SIM card in a call, you can not call from a second card.

  • Page 5: Safety Instructions

    Safety instructions 2. Safety instructions WARNING: Pay attention to the following instructions. The manufacturer does not assume any responsibility towards a user that does not follow these recommendations or uses the smartphone in an unsuitable manner. By using the device unsuitably, the user risks violating the relevant acts.
  • Page 6 Safety instructions • If your phone supports “Aeroplane mode”, enable “Aeroplane mode” prior to boarding a plane. If your phone does not support this mode, switch the device off prior to boarding a plane, as your device can interfere with plane instruments. Please follow the instructions issued on the plane.
  • Page 7 Safety instructions • A high volume set on the mobile phone can result in damage to hearing, be careful when adjusting the volume. Using your phone to listen to loud music can have serious consequences. Be careful when adjusting the volume to listen to music.
  • Page 8 Safety instructions • When using network features, please do not download files infected with a virus, do not install damaged photos and ringtones. Our company is not liable for defects caused by the phone behaving abnormally after downloading files. • Follow local regulations for disposing of the battery.
  • Page 9 Safety instructions The phone is a device, the behaviour of which can be altered by the user via additional apps. Procedures and individual steps can therefore differ from those contained in this manual. Note on the service provider: The phone is configured from the factory to fully utilize available services.

  • Page 10: Prior To Use

    Prior to use 3. Prior to use Designation and description of the phone parts Device Speaker 8. Right software button 2. LCD display 9. End call key, phone on/off 3. Navigation keys 10. “Messages” key 4. Left software button 11. Contacts for charging in 5.
  • Page 11 Prior to use 14. Headphones connector 18. Flash (LED searchlight)/ 15. Micro USB input for flashlight charging 19. Charging stand 16. SOS button 20. Micro USB input in the 17. Camera/Video camera charging stand NOTICE: Use caution when opening and closing the phone cover. Do not expose the phone hinge to increased pressure, especially in case when the cover of the phone is open.
  • Page 12 Prior to use Buttons Functions Function keys M1, M2 Function keys are used for so-called. speed dialling (option to dial an assigned telephone number). “Messages” key In standby mode, press the key to enter the list of received messages. Number keys/ keyboard Serves to dial or enter numbers and symbols.

  • Page 13: Inserting Sim And Memory Cards

    Prior to use Inserting SIM and memory cards A SIM card must be inserted into the phone before it is first used. Your network operator will provide the SIM card. When purchasing services from the mobile network, you receive a SIM card together with details including your PIN code and the optional services that are available.
  • Page 14 Prior to use Insert the SIM card in the appropriate slots with contacts facing downwards so that the contacts on the SIM card touch the built-in SIM contacts in the phone. Insert the SIM 1 card into the upper right slot, with cut corner located in the lower right corner of the slot, insert SIM 2 card into the lower left slot, with the cut corner located in the upper left corner of the slot.
  • Page 15 Prior to use Place the memory card in the slot in the upper left corner of the space under the battery, which is protected by a locking metal plate. You will release the locking plate by pressing on it gently a move to the left. Insert the memory card under the locking plate with the contacts facing down so that the memory card contacts touch the built-in memory card contacts in the phone for memory card and the edge with cutouts faces...
  • Page 16 Prior to use NOTICE: If the memory card does not work, make sure it is properly installed and has good contact. The maximum size of supported memory cards is 8 GB. When inserting the battery in the phone, first connect the battery contacts with the contacts located in the phone (at the top) and then gently push the battery into the battery compartment.
  • Page 17 Prior to use To replace the back cover attach it to the body of the phone so that the locks of the cover gently fit into the slots on the phone. Then hold the back cover on the phone and with gentle pressure from the bottom of the phone push it towards the hinge of the phone until it snaps into place.

  • Page 18: Telephone On/Off

    Prior to use NOTICE: Some phone features such as voice calls, receiving and sending messages are possible and available only when at least one SIM card is inserted with activated operator functions and within reach of a wireless network. Check with your provider for services available on your SIM card and access to its network.

  • Page 19: Security Password

    Prior to use NOTICE: Use the original charger to ensure reliable mobile phone operation. Security password • The PIN is used to make it impossible to use your SIM card illegally. The PIN code is usually included with the SIM card. If you enter three consecutive times the wrong PIN, unlock it by entering the PUK code.

  • Page 20: Quick Calling Guide

    Quick calling guide 4. Quick calling guide In case that when you switch on the phone and the default language is English, proceed as follows through the telephone Menu: Menu/ Settings/ Phone settings/ Language and here select the required language from the menu.

  • Page 21: Speed Dial Of Extension

    Quick calling guide Speed dial of extension To enter a pause (e.g. for direct dialling to an extension number) after entering a phone number, press and hold “,”. The screen shows the symbol “P”, then continue to enter the extension number. When dialling, insert a short pause between the numbers for the switchboard to recognize the number correctly.

  • Page 22: Available Functions In The Phone Menu

    Available functions in the phone menu 5. Available functions in the phone menu Messages Message service is in fact a service of the telephone network. This offer functions properly depending on the type of your SIM card and on the services provided by your network operator.

  • Page 23: Calls

    Available functions in the phone menu Calls Call history Call history offers the list of calls and the option to delete records. Press Options in each list to select the desired function for the selected item, such as Call the selected telephone number, Send SMS, block a number by adding it to Blacklist (blacklist) or Delete entry from the call history.

  • Page 24: Organizer

    Available functions in the phone menu Blocked numbers (Blacklist): You can turn on or off the rejection of • blocked numbers function (Reject number). You can save in the list of blocked numbers (Blacklist numbers) up to 20 telephone numbers. Auto redial: You can switch this function on or off.

  • Page 25: Multimedia

    Available functions in the phone menu Speed dial You can assign to the function keys and to the number keys 2-9 a contact from the phone directory to use in the function Speed dialling. Press and hold the selected key in the standby screen mode to start dialling the assigned telephone number.

  • Page 26: Video Recorder

    Available functions in the phone menu of the picture. Press the key “2” to change the quality of the picture. Press the key “3” to change the colour effects of the picture. Press the key “4” to change the white balance. Press the key “5” to change the mode of the scene.
  • Page 27 Available functions in the phone menu recording. Press repeatedly the key “0” to stop/resume recording. Stop the recording by pressing the right software key. You will be prompted to save the recording. Press the left soft key to display the menu of available functions to switch to camera mode, camera settings, video and default storage.

  • Page 28: Settings

    Available functions in the phone menu NOTICE: Files for playback must be stored on the memory card in the folder “My music”. Voice Recorder You can use the phone to record sound. For the camera to fully function, it must have a memory card inserted in the telephone. Press the left software key (“Options”) to view the option to start recording a new record or a list of previously saved recordings.

  • Page 29: Dual Sim

    Available functions in the phone menu Dual SIM Sets active SIM cards (only the selected SIM or both SIM cards). Profiles Preset modes are Common Mode, “Silence” mode “Meeting” mode and “Outside” mode. Setting up some profiles can be customized. Type of notification / ringing, ringtone / message tone: Setup of ringtones of calls and messages for individual SIM cards (SIM1, SIM2).

  • Page 30: Restore Settings

    Available functions in the phone menu Security It allows setting of individual SIM cards and phone security. SIM 1 and 2 security: PIN code: Activation and deactivation of the PIN code. • Change PIN: Change PIN1 code. • Change PIN2: Change PIN2 code. •...

  • Page 31: Entering Text

    Entering text 6. Entering text The device offers several text input modes, you can enter text or data in your contacts, edit contact records, search for names and write SMS messages. If you want to change the way you enter text in the text mode, press the key “#”.

  • Page 32: Care And Maintenance

    Care and maintenance 7. Care and maintenance Battery care The device is powered by a battery. It is necessary to charge the battery when it is empty. You can achieve a maximum performance of a new battery only by charging it when it is fully discharged. If you do not use the charger, unplug it from the power outlet and from the device.
  • Page 33 Care and maintenance NOTICE: Use only the supplied or approved replacement accessories. Non-original accessories may damage your phone and may constitute breach of warranty conditions. EN 33 Copyright © 2016, Fast ČR, a. s. Revision 04/2017...

  • Page 34: Technical Specifications

    Technical specifications 8. Technical specifications Display Dimensions: 2,4“ TFT Resolution: 240 × 320 pixels Chipset CPU: MTK6261D Memory RAM: 32 MB ROM: 32 MB Micro SDHC card slot (up to 8 GB) Camera Back: 0,08 Mpx (VGA) Network/Connectivity Dual GSM 850/900/1800/1900 MHz Features Flashlight Vibration alert...
  • Page 35 The CE symbol shown on the unit, in the user's manual and on the package indicates the unit meets the basic requirements of guideline R&TTE, 1995/5/EC, Guideline for low voltage 73/23/EEC. The declaration of conformity can be found at www.sencor.cz. EN 35 Copyright © 2016, Fast ČR, a. s.
  • Page 36 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
  • Page 37 Warranty conditions Warranty card is not a part of the device packaging. This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty is limited to the following conditions. Warranty is referred only to the customer goods using for common domestic use.
  • Page 38 Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized service centers Visit www.sencor.eu for detailed information about authorized service centers. 38 EN Copyright © 2016, Fast ČR, a. s.
  • Page 39 Designed in Europe by Sencor , Made in China ® www.sencor.cz...
