Summary of Contents for Velodyne vFree

  • Page 1 user guide and warranty...
  • Page 2: Table Of Contents

    Contents Warnings, safety & care ....1 At a glance & specifications ..3 Controls .........4 Charging & pairing ......5 Button functions ......6 LED indicators .......7 Warranty ........8...
  • Page 3: Warnings, Safety & Care

    Warnings, safety & care • To reduce the risk of fire or electric shock, do not expose vFree headphones to rain or moisture, and do not open or attempt to open vFree headphones. •...
  • Page 4 Ringing in your ears or other discomfort can indicate that the volume is too high. Hearing health is critical to enjoyment and the quality of life. Protect your hearing by listening with your vFree headphones in a responsible manner that protects your long term hearing health. Velodyne Acoustics, Inc. is not responsible for hearing loss or damage resulting from the use of this product.
  • Page 5: At A Glance & Specifications

    At a glance Specifications Driver size: 34 mm Frequency response: 20 Hz - 20 kHz Frequency range: 2.4GHz - 2.4835GHz Sensitivity: 98dB/1 kHz/1 mW Impedance: 32 ohm Power supply: lithium-ion polymer battery, 3.7V/430mAh (rechargeable) Operating temperature: 0°C - 40°C Headrest Supports Bluetooth v2.1 + EDR, A2DP v1.2, AVRCP v1.0, HSP v1.2, HFP v1.6 Support codecs: SBC, AAC, apt-X...
  • Page 6: Controls

    Playback, volume, & phone controls Next Power | pair Volume + Previous Volume - Play | pause | answer | end call Important: Playback, volume, and phone control functionality varies by media device. For functionality information for your device, visit our website at www.velodyne.com.
  • Page 7: Charging & Pairing

    To begin charging, connect the USB cable (micro USB end) to the port at the bottom of the left ear cup. Connect the other end of the USB cable to any available USB port. Your vFree headphones will begin charging, as represented by the red LED status indicator.
  • Page 8: Button Functions

    Button functions Button Function Power | pair Long press (3 seconds) - power on Long press while off (5 seconds)- pairing Press and hold > 3 seconds - power off Play | pause | call Short press - play/pause Short press (while calling) - answer/end call Volume up (+) Increase volume (maximum level indicated by beep) Volume down (-)
  • Page 9: Led Indicators

    LED indications Power on Power off Clear | reset Low battery Bluetooth pairing mode Incoming call | outgoing call Standby (Bluetooth off) Active call | standby Standby | AAC Standby | apt-X LED Activity Function Fast flashing (blue) x 5 Power on Fast flashing (red) x 5 Power off...
  • Page 10: Warranty

    If VELODYNE determines that the unit is defective, VELODYNE will at VELODYNE’s option, repair or replace the product at no charge if the product is forwarded prepaid to a factory authorized service representative. Products forwarded to the factory authorized service representative should be shipped securely and properly packaged, insured and postage prepaid.
  • Page 11 Classic, iPod Nano, iPod Shuffle, iPod Touch, are trademarks of Apple Inc., registered in the United States and other countries. The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc., and any use of such marks by Velodyne Acoustics, Inc. is under license. The aptX mark and the aptX logo are trademarks of CSR plc or one of its group companies.
  • Page 12 Register your vFree headphones velodyne.com/warranty-registration Follow Velodyne Acoustics, Inc. velodyne.com twitter.com/velodyneaudio facebook.com/velodyne Velodyne Corporate Headquarters 345 Digital Drive Morgan Hill CA 95037...
