- Page 2 COOLING BOXES COOLFREEZE CDF18, CDF26, CDF36, CDF46 Compressor Cooler Operating manual ..... 4 Autogoods “130”...
- Page 3 CoolFreeze CDF18 CDF26, CDF36, CDF46 TEMPERATURE BATTERY MONITOR ERROR HIGH 12/24V DC POWER COLD FREEZE 12/24V DC CDF26 POWER ° ERROR Autogoods “130”...
- Page 4 CoolFreeze CDF36, CDF46 ° POWER ERROR CDF26, CDF36, CDF46 Autogoods “130”...
-
Page 5: Table Of Contents
CoolFreeze Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it. The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation. -
Page 6: Explanation Of Symbols
CoolFreeze Explanation of symbols Explanation of symbols WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product. - Page 7 Safety instructions CoolFreeze • Children must be supervised to ensure that they do not play with the device. • Always keep and use the device out of the reach of children under the age of 8 years. • Do not store any explosive substances such as spray cans with a flammable propellant in the device.
-
Page 8: Scope Of Delivery
CoolFreeze Scope of delivery • Do not place the device near naked flames or other heat sources (heaters, direct sunlight, gas ovens etc.). • Danger of overheating! Ensure at all times that there is sufficient ventilation so that the heat that arises during operation does not build up. -
Page 9: Intended Use
Intended use CoolFreeze Intended use The compressor cooler is suitable for cooling and freezing foodstuffs. The compres- sor cooler is also suitable for use on boats. The compressor cooler is designed to be operated from a 12 Vg or 24 Vg on- board socket of a vehicle (e.g. - Page 10 CoolFreeze Function description Operating and display elements CDF18 Operating panel and connection socket (fig. 2, page 2): Item Description Explanation TEMPERATURE Temperature controller, cooling temperature at the end positions: COLD: +10 °C FREEZE: –18 °C POWER Operating display LED is lit green: Device is switched on and ready for operation LED is lit yellow:...
- Page 11 Function description CoolFreeze CDF26 Connection socket (fig. 3, page 2) and operating panel (fig. 4, page 2): Item Description Explanation Switches the cooler on or off when the button is pressed for OFF button between one and two seconds POWER Status indication LED lights up green: Compressor is on...
- Page 12 CoolFreeze Function description CDF36, CDF46 Connection socket (fig. 3, page 2) and operating panel (fig. 5, page 3): Item Description Explanation ON/OFF button Switches the cooler on or off when the button is pressed for between one and two seconds POWER Status indication LED lights up green:...
-
Page 13: Operation
Operation CoolFreeze Operation Before initial use NOTE Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the chapter “Cleaning and maintenance” on page 18). Energy saving tips •... - Page 14 CoolFreeze Operation Using the battery monitor If the cooler is operated when the vehicle ignition is switched off, the cooler switches off automatically as soon as the supply voltage falls below a set level. The cooler will switch back on once the battery has been recharged to the restart voltage level. NOTICE! Danger of damage! When switched off by the battery monitor, the battery will no longer be fully charged.
- Page 15 Operation CoolFreeze CDF26: Setting the battery monitor mode This is how to select the battery monitor mode: ➤ Switch on the cooler. ➤ Press the “SET” button three times. ➤ Use the “+” and “–” buttons to select the battery monitor mode. ✓...
- Page 16 CoolFreeze Operation CDF18: Switching on the cooler ➤ Slide the sliding switch “BATTERY MONITOR” to HIGH if you wish to operate from a starter battery or to “LOW” if you want to operate from a supply battery. ✓ The “POWER” LED is lit green. ✓...
-
Page 17: Setting The Temperature
Operation CoolFreeze Setting the temperature CDF26 ➤ Press the “SET” button once. ➤ Use the “+” and “–” buttons to set the cooling temperature. ✓ The set cooling temperature then appears in the display for a few seconds. The display flashes several times before it returns to the current temperature. CDF36, CDF46 ➤... - Page 18 CoolFreeze Operation Defrosting the cooler Humidity can form frost in the interior of the cooling device or on the vaporiser. This reduces the cooling capacity. Defrost the device in good time to avoid this. NOTICE! Danger of damaging the device! Never use hard or pointed tools to remove ice or to loosen objects which have frozen in place.
-
Page 19: Cleaning And Maintenance
Cleaning and maintenance CoolFreeze Cleaning and maintenance WARNING! Always disconnect the device from the power supply before you clean and service it. NOTICE! Risk of damage • Never clean the cooler under running water or in dish water. • Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the cooler. -
Page 20: Troubleshooting
CoolFreeze Troubleshooting Troubleshooting Fault Possible cause Suggested remedy Device does not No voltage is flowing The ignition must be switched on in function, LED does not from the DC power most vehicles to supply current to the glow. socket in your vehicle. DC power socket. -
Page 21: Technical Data
Technical data CoolFreeze Technical data CDF18 CDF26 Ref. no.: 9600000460 9600000183 Contains: 18 l 21 l Voltage: 12/24 Vg Rated current 12 Vg: 3.5 A 5.0 A 24 Vg: 1.9 A 2.5 A Cooling capacity: +10 °C to –18 °C Climate class: N or T Ambient temperature:... - Page 22 CoolFreeze Technical data CDF36 CDF46 Ref. no.: 9600000461 9600000462 Contains: 31 l 39 l Voltage: 12/24 Vg Rated current 12 Vg: 5.0 A 5.0 A 24 Vg: 2.5 A 2.5 A Cooling capacity: +10 °C to –15 °C Climate class: N or T Ambient temperature: +16 °C –...
