- Page 1 R20 SPORT TREADMILL USER MANUAL Model Number: PM810 Customer Service Team: Activate Your Warranty: www.pacemaster.com/registration 888-699-8918 www.pacemaster.com/help IMPORTANT: READ AND SAVE THIS MANUAL support@pacemaster.com...
-
Page 3: Table Of Contents
PAGE 3 PACEMASTER R20 SPORT TREADMILL USER MANUAL TABLE OF CONTENTS Before You Begin Important Safety Instructions Assembly 6-10 Basic Assembly Tips Assembly Steps Treadmill Operation and Adjustments 11-16 Console Overview Screen Overview Using The Safety Key Moving The Treadmill... -
Page 4: Before You Begin
PAGE 4 PACEMASTER R20 SPORT TREADMILL USER MANUAL BEFORE YOU BEGIN Thank you for selecting PaceMaster R20 Sport Treadmill. Read this manual carefully before using the treadmill. If you have questions after reading this manual, please contact us. TREADMILL TERMS... -
Page 5: Important Safety Instructions
PAGE 5 PACEMASTER R20 SPORT TREADMILL USER MANUAL IMPORTANT SAFETY Until the treadmill is fully and properly assembled, do Various factors, including your movement, may not attempt to raise, lower, or move the treadmill. affect the accuracy of heart rate readings. -
Page 6: Assembly
PAGE 6 PACEMASTER R20 SPORT TREADMILL USER MANUAL ASSEMBLY BASIC ASSEMBLY TIPS • Read and understand the “Important Safety Instructions” before assembly. • Keep bystanders and children away from the product you are assembling at all times. • Do not connect power to the machine until instructed to do so. - Page 7 ASSEMBLY PAGE 7 PACEMASTER R20 SPORT TREADMILL USER MANUAL STEP 1 1. Route line A-1 through the upright columns (4) and expose 3. Insert the upright columns (4) into the main frame (1) and the connector. secure it with the wrench TOOL-3; fix with screw (26) and washer (31), do not completely tighten these screws yet.
- Page 8 ASSEMBLY ASSEMBLY PAGE 8 PACEMASTER R20 SPORT TREADMILL USER MANUAL STEP 2 1. Connect wires A-1 and A-2 as shown. 2. Place the console (59) in the upright columns (4).
- Page 9 ASSEMBLY PAGE 9 PACEMASTER R20 SPORT TREADMILL USER MANUAL STEP 3 1. Match up the handrails (6) with the console (59) and main frame 4. Use wrench TOOL-2 with hexagon socket head bolts (16) (1) and use the hexagon socket head bolts (98) spring washer to lock the right grip (56) into the console (59).
- Page 10 ASSEMBLY PAGE 10 PACEMASTER R20 SPORT TREADMILL USER MANUAL STEP 4 1. Insert the electronic cable line through the display device holder 5. Connect the fully assembled treadmill to power via an (2) and secure the display device (72) with wrench TOOL-2 and appropriate outlet.
-
Page 11: Treadmill Operation And Adjustments
PAGE 11 PACEMASTER R20 SPORT TREADMILL USER MANUAL TREADMILL OPERATION CONSOLE OVERVIEW AND ADJUSTMENTS DISPLAY SCREEN QUICKTAP SPEED BUTTONS QUICKTAP INCLINE BUTTONS FAN SWITCH BUTTON WITH INDICATOR LIGHTS INFORMATION BUTTON SPEED BUTTONS INCLINE BUTTONS BLUETOOTH BUTTON SAFETY KEY START, PAUSE, & STOP BUTTONS ®... -
Page 12: Screen Overview
TREADMILL OPERATION AND ADJUSTMENTS PAGE 12 PACEMASTER R20 SPORT TREADMILL USER MANUAL SCREEN OVERVIEW If you do not have an account, click “Create an START SCREEN account” and follow the account creation prompts. Default starting screen is set up to allow for quick workout start. - Page 13 TREADMILL OPERATION AND ADJUSTMENTS PAGE 13 PACEMASTER R20 SPORT TREADMILL USER MANUAL ADJUSTING WORKOUT LEVELS USER-DEFINED PROGRAM You can adjust your workout to the precise level and When you are logged into an account you can save intensity you desire: workouts and quickly select saved workouts.
- Page 14 TREADMILL OPERATION AND ADJUSTMENTS PAGE 14 PACEMASTER R20 SPORT TREADMILL USER MANUAL WORKOUT DATA Press the “APP” button to connect to your App. You will need access to Wi-Fi in order to connect to the App. When the treadmill is in a standby status, tap the “ME”...
-
Page 15: Using The Safety Key
TREADMILL OPERATION AND ADJUSTMENTS PAGE 15 PACEMASTER R20 SPORT TREADMILL USER MANUAL USING THE SAFETY KEY HOW TO USE THE SAFETY KEY AND TEST THE EMERGENCY STOP 3. IMPORTANT: Test the clip by carefully taking a few 1. Adjust the length of the Safety Key cord. It should be steps backward;... -
Page 16: Moving The Treadmill
TREADMILL OPERATION AND ADJUSTMENTS PAGE 16 PACEMASTER R20 SPORT TREADMILL USER MANUAL MOVING THE TREADMILL CAUTION 2. When the treadmill is tilted up enough to be Use extreme caution while moving the treadmill to avoid injury. weighted entirely on the front transport wheels, carefully move the treadmill. -
Page 17: Heart Rate Monitor
PAGE 17 PACEMASTER R20 SPORT TREADMILL USER MANUAL HEART RATE MONITOR The heart rate monitor is specially designed for accuracy, people who have normal heart rhythms. Heart rate comfort, and durability. To get the best performance from reading problems may be caused by medical con- the heart rate monitor, please read the instructions below. -
Page 18: Maintenance
PAGE 18 PACEMASTER R20 SPORT TREADMILL USER MANUAL MAINTENANCE BELT CARE AND LUBRICATION You must lubricate your treadmill belt annually (or more often if your treadmill is heavily used) in order to keep vital treadmill parts including the deck, belt, motor, and motor controller from prematurely wearing out. -
Page 19: Maintenance
MAINTENANCE PAGE 19 PACEMASTER R20 SPORT TREADMILL USER MANUAL 3. Using your treadmill’s handrails and safety switch for HOW TO CLEAN THE TREADMILL safety and support, walk on the treadmill at 2-3 mph. 1. Always unplug the treadmill before cleaning it. -
Page 20: Troubleshooting
PAGE 20 PACEMASTER R20 SPORT TREADMILL USER MANUAL TROUBLESHOOTING SYMPTOMS AND SOLUTIONS Most treadmill problems can be resolved quickly using the following steps. If there is a problem that you cannot easily solve, contact our Customer Service Team. A. SYMPTOM Sudden changes in speed while using the treadmill. - Page 21 TROUBLESHOOTING PAGE 21 PACEMASTER R20 SPORT TREADMILL USER MANUAL C. SYMPTOM Treadmill will not power on. SOLUTION 1. Verify that the power cord is plugged into a functional power outlet. 2. Make sure the power switch is set to ON. To reset the power, turn the power switch off, wait five minutes, and turn the switch back on.
-
Page 22: Parts List
PAGE 22 PACEMASTER R20 SPORT TREADMILL USER MANUAL PARTS LIST No Part Name Specifications Part Number No Part Name Specifications Part Number Main Frame Assembly 2070101060024 54 Pulse Plate 318.6 X 56.2 X 31.3 1031010000570 Display Device Holder 2070101030561 55 Left Grip 248.2 X 58.7 X 56.2... -
Page 23: Exploded Diagrams
PAGE 23 PACEMASTER R20 SPORT TREADMILL USER MANUAL EXPLODED DIAGRAMS DIAGRAM A... - Page 24 EXPLODED DIAGRAMS PAGE 24 PACEMASTER R20 SPORT TREADMILL USER MANUAL DIAGRAM B...
-
Page 25: Exploded Diagrams
EXPLODED DIAGRAMS PAGE 25 PACEMASTER R20 SPORT TREADMILL USER MANUAL DIAGRAM C... -
Page 26: Warranty Information
Register your product today. PaceMaster backs your treadmill with the warranty provided below. For PaceMaster to respond to any problems you may have, we need your warranty information on file. PaceMaster will send you a complimentary gift upon receiving your product warranty registration. -
Page 27: Ordering Replacement Parts
REPLACEMENT PARTS If replacement parts are necessary, use only genuine replacement parts and hardware supplied by PaceMaster or a PaceMaster certified service provider. Failure to use genuine replacement parts can cause a risk to users, keep the machine from operating correctly, and void the warranty. - Page 28 Customer Service Team: 888-699-8918 www.pacemaster.com/help support@pacemaster.com...
