SERVICE MANUAL
6
2003
22056
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
5
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED
POWERED SUBWOOFER
SP-DW103
TABLE OF CONTENTS
Area suffix
B ------------------------------- U.K.
E ----------- Continental Europe
No.22056
2003/6
Advertisement
Table of Contents
Related Manuals for JVC SP-DW103
Summary of Contents for JVC SP-DW103
-
Page 1: Table Of Contents
SERVICE MANUAL POWERED SUBWOOFER 22056 2003 SP-DW103 Area suffix B ------------------------------- U.K. E ----------- Continental Europe TABLE OF CONTENTS PRECAUTION............... . . 1-3 SPECIFIC SERVICE INSTRUCTIONS . - Page 2 SPECIFICATION Type Powered Subwoofer Bass-reflex type, (magnetically shielded type) Speaker unit 16.0 cm cone (× 1) Frequency range 30 Hz to 200 Hz 50 kΩ (LOW-LEVEL) 470 Ω (HIGH-LEVEL) Input impedance Input terminals INPUT 1 (LOW-LEVEL) INPUT 2 (HIGH-LEVEL) Power requirements AC 230 V , 50 Hz 100 W (45 Hz, 4 Ω, 10 % THD) Output power of built-in amp...
-
Page 3: Precaution
SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and voltmeter. many circuits and components specially for safety purpos- Move the resistor connection to each exposed metal es. For continued protection, no changes should be made part, particularly any exposed metal part having a return to the original design unless authorized in writing by the path to the chassis, and measure the AC voltage across... -
Page 4: Specific Service Instructions
SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. 1-4 (No.22056) -
Page 5: Disassembly
SECTION 3 DISASSEMBLY Disassembly method 3.1.1 Removing the Amplifier assembly. Amplifier assembly (See Fig1 and 2.) (1) Remove the eleven screws A attaching the amplifier as- sembly. (See Fig 1.) (2) Remove the amplifier assembly from the main body. (3) Disconnect the wire connector from the back side of the amplifier assembly. - Page 6 3.1.3 Removing the power cord. (See Fig 4 and 5) • Prior to performing the following procedures. remove the back panel. (1) Remove the two screw C attaching the bracket. (See Fig 4) (2) Pull out the bracket toward you. (3) Disconnect the power cord from the connection CN901 on the power supply assembly.
- Page 7 3.1.6 Removing the bottomplate. (See Fig 7.) (1) Remove the eight screws H attaching the bottom plate. Referense: When attaching the screw H. attach the plane and spring washers with them. (2) Pull out the bottom plate toward you. Spring washer Plane washer Fig.7 3.1.7 Removing the woofer.
-
Page 8: Adjustment
SECTION 4 ADJUSTMENT This service manual does not describe ADJUSTMENT. 1-8 (No.22056) -
Page 9: Trouble Shooting
SECTION 5 TROUBLE SHOOTING This service manual does not describe TROUBLE SHOOTING. (No.22056)1-9... - Page 10 SECTION 6 Description of major ICs AN79L05-T (IC592) : Regulator • Pin Layout • Block Diagram Common Voltage Error Amp. Reference Output Starter Terminal Pass Tr. Protection Current Limiter Input 1-10 (No.22056)
- Page 11 BA15218F-XE (IC101,IC102,IC103,IC104,IC501) : Dual operation amplifier • Pin layout OUT1 1 8 Vcc -IN1 2 7 OUT2 +IN1 3 6 -IN2 VEE 4 5 +IN2 • Block diagram OTHER Q114 OUTPUT (No.22056)1-11...
- Page 12 BU4584BF-X (IC505) : Hex schmitt inverter • Pin layout & Block diagram IR2113S-X (IC506) : Gate driver • Pin Layout VSS LIN HIN VDD LO COM VCC • Block Diagram DETECT LEVEL PULSE SHIFT FILTER LEVEL SHIFT PULSE DETECT LEVEL SHIFT DELAY 1-12 (No.22056)
- Page 13 NJM311M-XE (IC502) : Comparator • Pin Layout (TOP VIEW) +INPUT OUTPUT -INPUT BAL/STROBE NJM78L05A-T (IC591) : Regulator • Pin Layout 1.OUTPUT 2.GND 3.INPUT 1 2 3 • Block Diagram INPUT OUTPUT (No.22056)1-13...
- Page 14 STR-F6676 (IC951) : Switching regulator • Pin Layout • Block Diagram START O.V.P LATCH DRIVE Vth(1) REG. 1 2 3 4 5 O.S.C T.S.D Comp.1 Vth(2) O.C.P./F.B Iconst Comp.2 Rconst+ Rconst- TC74HC00AF-W (IC503) : Quad 2-input NAND gate • Pin layout & Block diagram TC74HC14AF-X (IC504, IC571) : Hex Schmitt inverter •...
- Page 15 (No.22056)1-15...
- Page 16 VICTOR COMPANY OF JAPAN, LIMITED AV & MULTIMEDIA COMPANY AUDIO/VIDEO SYSTEMS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.22056) Printed in Japan...
-
Page 17: Schematic Diagrams
SP-DW103 SCHEMATIC DIAGRAMS POWERED SUBWOOFER SP-DW103 CD-ROM No.SML200306 Area suffix B ------------------------------- U.K. E ----------- Continental Europe Contents Block diagrams Standard schematic diagrams 2-3 to 5 Printed circuit boards No.22056SCH COPYRIGHT 2003 VICTOR COMPANY OF JAPAN, LTD. 2003/06... - Page 18 SP-DW103 In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "...
-
Page 19: Block Diagram
SP-DW103 Block diagram AUTO POWER ON / STANDBY SW POWER MAINS IC501 PHASE SW PLUG ON -- CANCEL VOLUME NORMAL-- REVERSE VR501 Off set W9001 to 4 CN151 IC502 W9001 to 4 W1001 POWER-SUPPLY IC503 CIRCUIT IN PUT L / H AMP L.P FILTER /... - Page 20 SP-DW103 SP-DW103 Standard schematic diagram S1501 C1502 0.0033 CN861 R8601 R5034 D8601 D8602 R5021 IC503 TC74HC00AF-W R5028 SPR325MVW R5003 R5011 D5003 QGA2001C1-08 R5013 1SS133 S1001 VR101 R5036 CN151 20KB 4.7k Q5001 2SA1037AK W1001 IC501 IC502 QJB001-080701 BA15218F NJM311M-XE C1003 R1003...
- Page 21 SP-DW103 Printed circuit boards Main board (1/3) (Terminai board) CN101 D1003 W1001 D1002 R1016 IC103 R1041 R1033 C1022 C1021 C1018 R1044 R1001 C1017 C1011 R1032 C1037 R1028 IC102 C1004 J1001 C1023 K1001 C1010 C1008 R1010 IC101 D1001 C1032 IC104 C1033...
- Page 22 SP-DW103 Main board (2/3) (Amp board) R5905 CN505 D5716 R5911 D5013 C5907 C5909 C5711 C5024 L5903 Q5904 D5911 Q5905 RY502 D5703 C5023 R5747 CN102 R5914 L5904 R5906 TH501 L5902 R5057 Q5903 C5908 R5702 R5912 R5743 CN502 R5701 C5022 R5744 L5001...
- Page 23 SP-DW103 Main board (3/3) (Regulator board) EP951 C9512 C9511 C9509 R9518 R9522 C9508 C9507 Q9508 Q9509 R9519 R9523 D9510 D9509 R9526 R9525 Q9510 HS953 HS952 T9501 R9524 R9527 PC951 R9508 R9504 D9506 R9510 D9504 R9529 R9528 IC951 R9503 R9501 W9002...
