- Page 1 COMPACT COMPONENT SYSTEM POWERED SUBWOOFER SP-DWF31 INSTRUCTIONS LVT1305-001A...
- Page 2 IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.
-
Page 3: Warnings, Cautions And Others
Thank you for purchasing a JVC speaker. Before you begin using it, please read the instructions carefully to be sure you get the best possible performance. If you have any questions, consult your JVC dealer. Warnings, Cautions and Others To reduce the risk of electrical shocks, fire, etc.: 1. -
Page 4: Connections
Connections Before connecting this unit to the amplifier (or receiver), observe the following carefully. • Turn off the amplifier. • Make all connections before plugging in this unit. Amplifier or Receiver To SUBWOOFER OUT To LINE OUT or MONO Stereo audio cord (not Supplied) In the case that the receiver dose not have the SUBWOOFER OUT or MONO terminal. -
Page 5: Additional Information
– Turn down the volume of the playback source, turn off and on the source, then adjust the volume properly on the source. Specifications Type : Powered Subwoofer Bass-reflex type (magnetically shielded type) Speaker : 16.0 cm cone × 1 Frequency Range : 32 Hz Impedance : 4 Ω Input terminals : INPUT (LOW-LEVEL) Power requirements : AC 230 V Output power of built-in amp : 100 W (50 Hz, 4 Ω, 10 % THD) - Page 6 1204NSMCREJSC © 2005 Victor Company of Japan, Limited...
