AXIOMTEK GOT3187W-832-PCT User Manual

All-in-one 18.5” wxga tft fanless compact-size panel pc
Hide thumbs Also See for GOT3187W-832-PCT:
Table of Contents

Advertisement

Quick Links

Download this manual
GOT3187W-832-PCT
All-in-One
18.5" WXGA TFT Fanless
Compact-Size PANEL PC
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOT3187W-832-PCT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK GOT3187W-832-PCT

Summary of Contents for AXIOMTEK GOT3187W-832-PCT

  • Page 1 GOT3187W-832-PCT All-in-One 18.5” WXGA TFT Fanless Compact-Size PANEL PC User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Most electronic components are sensitive to static electrical charge. Disconnect the power cords from the GOT3187W-832-PCT Series before making any installation. Be sure both the system and the external devices are turned OFF. Sudden surge of power could ruin sensitive components. Make sure the GOT3187W-832-PCT Series is properly grounded.

  • Page 4: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ................1 CHAPTER 2 HARDWARE AND INSTALLATION ............7 ....................8 PEN BACK COVER ..................9 CARD NSTALLATION ................11 UMPER AND WITCH ETTINGS ................... 13 PORT ONNECTOR ....................... 14 THERNET / VESA ..............14 OUNTINGS ANEL HDD I...
  • Page 5 This page is intentionally left blank.

  • Page 7: Chapter 1 Introduction

     I/O Outlets  Package List General Description The GOT3187W-832-PCT adopts a 18.5-inch WXGA TFT LCD with 300-nit ® brightness and an Intel Atom™ processor D2550 1.86 GHz to provide excellent computing performance and thermal resistance. This fanless platform is especially designed for operating under heavy-duty environment including steel refinery, oil pipe, ship, machine maker operating systems and many more.

  • Page 8: Specifications

    The patent improves the system reliability and sustainability. WLAN Antenna Supported (optional) GOT3187W-832-PCT has a PCI Express Mini Card slot for optional add-ons such as wireless LAN card for 802.11 b/g connections & 3G/GPRS application, graphics-enhanced video card, universal analog TV/FM tuner/AV capture card, and more.

  • Page 9: System Specification

    GOT3187W-832-PCT User’s Manual Back  Ethernet  Two Gigabit Ethernet  Audio  One Line-out  Expansion  One Mini card  Storage  One slot for CF card  One SATA  Power connector  Phoenix power connector System Specification ...
  • Page 10 GOT3187W-832-PCT User’s Manual Back Dimensions and Outlines The following diagrams show the dimensions and outlines of GOT3187W-832-PCT. Introduction...
  • Page 11 GOT3187W-832-PCT User’s Manual Back I/O Outlets Please refer to the following illustration for I/O locations of the GOT3187W-832-PCT. Function Function POWER SWITCH (ATX) COM 2 (RS-232) Power Input connector (Screw) Ethernet (RJ-45) Dual USB 2.0 ports Dual USB 2.0 ports...

  • Page 12: Packing List

    When you receive the GOT3187W-832-PCT, the bundled package should contain the following items:  GOT3187W-832-PCT unit  Driver CD  Phoenix connector x 12  Panel mount kit  Screws for HDD If you cannot find the package or any items are missing, please contact Axiomtek distributors immediately. Introduction...

  • Page 13: Hardware And Installation

    Back Chapter 2 Hardware and Installation The GOT3187W-832-PCT provides rich I/O ports and flexible expansions for you to meet different demand, for example CF card. The chapter will show you how to install the hardware. It includes: Open back cover ...

  • Page 14: Open

    GOT3187W-832-PCT User’s Manual Back Open back cover This section tells users how to open back cover. Please follow the steps below. Step 1 Unscrew 8 screws on the back cover. Please refer the photo below. Step 2 Remove the back cover.

  • Page 15: Cf Card Installation

    GOT3187W-832-PCT User’s Manual Back CF card Installation ™ The GOT3187W-832-PCT provides one CF slot for users to install CompactFlash card. Please refer to the following instructions for installation: Step 1 Open the cover, unscrew 2 screws on the chassis. Step 2 Stick mylar on the CF card.
  • Page 16 GOT3187W-832-PCT User’s Manual Back Step 3 Insert the CF card to the CF card slot, then finding the CF cover from the system package and screw it. Hardware and Installation...

  • Page 17: Jumper And Switch Settings

    2 jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following illustration shows how to set up jumper. Before applying power to GOT3187W-832-PCT, please make sure all of the jumpers and switch are in factory default position. Below you can find a summary table and onboard default settings.
  • Page 18 Back 2.3.1 COM1 Configuration The COM1 & COM2 are standard DB-9 connectors. Those connectors are equipped with The GOT3187W-832-PCT has two serial ports. COM1 is RS-232/422/485, while COM2 is RS-232. The following table shows you set COM1 port mode: Description...

  • Page 19: Com Port Connector

    GOT3187W-832-PCT User’s Manual Back 2.3.3 Auto Power On (JP4) If JP4 is enabled for power input, the system will be automatically power on without pressing soft power button. If JP4 is disabled for power input, it is necessary to manually press soft power button to power on the system.

  • Page 20: Ethernet

    2.6 Mountings: Panel / Wall / VESA There are 4 application options for the GOT3187W-832-PCT, Panel/Wall/Desktop/VESA mountings. 2.6.1 VESA-ARM/Wall-Mount The GOT3187W-832-PCT provides VESA mount: 100x100 mm. Screw four screws to fix the kit in the back chassis. Wall mount: Hardware and Installation...
  • Page 21 GOT3187W-832-PCT User’s Manual Back VESA mount: Hardware and Installation...

  • Page 22: Hdd Installation

    GOT3187W-832-PCT User’s Manual Back 2.6.2 Panel-mount Kit Assembly The GOT3187W-832-PCT is designed for panel mount application. To mount the GOT3187W-832-PCT, the standard set of mounting kit (included in the system packaging) is needed. HDD Installation The GOT3187W-832-PCT provides a convenient Hard Disk Drive (HDD) bracket for users to install 2.5”...
  • Page 23 GOT3187W-832-PCT User’s Manual Back Step 3 Plug the cables to connectors and screw the HDD tray on the bracket. Installation completes. Hardware and Installation...

  • Page 24: Dram Installation

    GOT3187W-832-PCT User’s Manual Back DRAM Installation The GOT3187W-832-PCT provides one 204-pin DDR3 SODIMM socket that support system memory up to 4GB. Please follow steps below to install the memory modules: Step 1 Refer to section 2.1 to open the back cover and find out DIMM socket on main board (SBC87832).
  • Page 25 GOT3187W-832-PCT User’s Manual Back Step 3 Insert the DRAM to the DIMM socket, and then push it down firmly until it is clipped by the socket. Step 4 Installation completes. Hardware and Installation...

  • Page 26: Wireless Lan Card Installation

    GOT3187W-832-PCT User’s Manual Back Wireless LAN Card Installation The GOT3187W-832-PCT provides one Mini card slot for user to install one wireless LAN card. When installing the wireless LAN card, refer to the following instructions and illustration: Step 1 Refer to section 2.1 to open the back cover and find out mini-card slot on main board.
  • Page 27 GOT3187W-832-PCT User’s Manual Back Step 3 Find the Antenna cable and connect it wireless LAN card. …. Step 4 Remove the antenna plug from the top of back cover, and then install the antenna on the antenna connector Hardware and Installation...

  • Page 28: Power Input

    GOT3187W-832-PCT User’s Manual Back 2.10 Power Input GOT3187W-832-PCT equips with a phoenix type power connector. It adopts 10VDC to 30VDC. Please follow the signs on power connector to connect DC power source. －:Power negative +: Power positive G: Safety ground Note: The safety ground must be connected to ensure the unit working appropriately.
  • Page 29 GOT3187W-832-PCT User’s Manual Back This page is intentionally left blank. Hardware and Installation...

  • Page 30: Ami Bios Setup Utility

    GOT3187W-832-PCT User’s Manual Back Chapter 3 AMI BIOS Setup Utility This chapter provides users with detailed description how to set up basic system configuration through the AMIBIOS BIOS setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 31: Main Menu

    GOT3187W-832-PCT User’s Manual Back Main Menu When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below ...

  • Page 32: Advanced Menu

    GOT3187W-832-PCT User’s Manual Back Advanced Menu  Launch Storage OpROM This item can enable or disable boot option for legacy mass storage devices with option ROM. The Advanced menu also allows users to set configuration of the CPU and other system devices.
  • Page 33 GOT3187W-832-PCT User’s Manual Back  ACPI Settings You can use this screen to select options for the ACPI Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 34 GOT3187W-832-PCT User’s Manual Back  CPU Configuration This screen shows the CPU Configuration, and you can change the value of the selected option. Hyper-Threading Use this item to enable or disable Hyper-Threading Technology, which makes a single physical processor perform multi-tasking function as two logical ones.
  • Page 35 GOT3187W-832-PCT User’s Manual Back  IDE Configuration SATA Controller(s) The optional settings are: [Disabled]; [Enabled]. Configure SATA as The optional settings are: [IDE]; [AHCI]. AMI BIOS Setup Utility...
  • Page 36 GOT3187W-832-PCT User’s Manual Back  USB Configuration You can use this screen to select options for the USB Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 37 GOT3187W-832-PCT User’s Manual Back  NCT6627UD Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of...
  • Page 38 GOT3187W-832-PCT User’s Manual Back  PC Health Status This screen shows the Hardware Health Configuration, and a description of the selected item appears on the right side of the screen. AMI BIOS Setup Utility...

  • Page 39: Chipset Menu

    GOT3187W-832-PCT User’s Manual Back Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► Host Bridge Host Bridge For items marked with “”, please press <Enter>...
  • Page 40 GOT3187W-832-PCT User’s Manual Back  Memory Information This item is for memory frequency and timing settings. Press <Enter> to go to the sub menu. AMI BIOS Setup Utility...

  • Page 41: Boot Menu

    GOT3187W-832-PCT User’s Manual Back Boot Menu The Boot menu allows users to change boot options of the system.  Boot Settings Configuration Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. Bootup NumLock State Use this item to select the power-on state for the NumLock..

  • Page 42: Security Menu

    GOT3187W-832-PCT User’s Manual Back Security Menu The Security menu allows users to change the security settings for the system. Administrator Password This item indicates whether an administrator password has been set. If the password has been installed, Installed displays. If not, Not Installed displays.

  • Page 43: Save & Exit Menu

    GOT3187W-832-PCT User’s Manual Back Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values. Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect.
  • Page 44 GOT3187W-832-PCT User’s Manual Back Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select Yes to discard changes. Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option.
  • Page 45 GOT3187W-832-PCT User’s Manual Back This page is intentionally left blank. AMI BIOS Setup Utility...

  • Page 46: Chapter 4 Drivers Installation

    Chapter 4 Drivers Installation System GOT3187W-832-PCT supports Windows 7 32-bit and WES 7. To facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. Insert Driver CD and select the “\Driver”. Step 1 Step 2 Select all files and follow the installing procedure.

  • Page 47: Embedded O.s

    GOT3187W-832-PCT User’s Manual Back Embedded O.S. The GOT3187W-832-PCT provides the Windows 7 Embedded. The O.S. is supported devices which are listed below.  WES 7 Here are supported onboard devices: Onboard Multi I/O  SATA HDD   CRT/LCD display ...
