Summary of Contents for SatKing SK-500A
-
Page 2: Table Of Contents
English CONTENTS 1. GUIDE ......................2 1.1 IMPORTANT SAFETY INSTRUCTIONS ..................2 1.2 UNPACKING ..........................2 1.3 PRODUCT OVERVIEW& ILLUSTRATION ................3 1.4 INSTALLATION OF METER .......................4 2. OUTLINE ......................5 3. THE MENU OSD INSTRUCTION ..............6 3.1 DVB-T2 ............................6 3.2 DVB-C .............................8 3.3 CHANNEL ............................9 3.4 SPECTRUM ..........................10 3.5 MULTIMEDIA ..........................11 3.6 SYSTEM SETTING ........................ -
Page 3: Guide
1. GUIDE 1.1 IMPORTANT SAFETY INSTRUCTIONS Thank you for choosing our product. Before installation, we would like to remind you some notes, which is very important for operating safely and properly, as follows: • Be sure to read this user manual before starting your operation. • You must install the dish with correct direction and angle. -
Page 4: Product Overview& Illustration
English 1.3 PRODUCT OVERVIEW& ILLUSTRATION Description FUNCTION LNB In Connect to satellite antenna cable AV OUT Connect to AV port for TV AV IN Connect to AV port for meter USB Port Connect to USB memory DC Slot Connect to adaptor input Power Switch Turn on/off meter Speaker... -
Page 5: Installation Of Meter
Description FUNCTION Show the main menu on the screen or jump back to 22 MENU previous menu in sub-menu setting conditions 23 EXIT Escape from present menu and save the settings 24 0-9 Number key to select channels or enter programming 25 INFO INFO key 26 MUTE... -
Page 6: Outline
English 2. OUTLINE • 3.5 Inch High Definition TFT LCD Screen • Fully DVB-T/DVB-T2/DVB-C, MPEG-2/MPEG-4 compliant • H.264 Hardware decoding • Digital meter for signal strength and quality • Supports scan of Auto,Manual • Sound and Light Alarm for Locking Signal • Speaker Integrated • Support both AV out and AV in • Support both HD out and HD in... -
Page 7: The Menu Osd Instruction
3. THE MENU OSD INSTRUCTION If you have installed and connected the cables to the receiver, pressing MENU to display the Main Menu. • DVB-T2 • DVB-C • Channel • Spectrum • Multimedia • System Setting Press the keys of YZA B to move the cursor up or down in the menu interface, then use to confirm a selection. - Page 8 English T2/T+T2, you can select one you want. 3.1.6 BEEP TONE Press AB key to switch beep tone ON/OFF. If we open the beep tone, when we enter into the search screen, the beep of lock alarm will open. 3.1.7 ANTENNA SETTING Press A B key to change the antenna power, we have there types including 12v/18V/24v, you can select one you want.
-
Page 9: Dvb-C
• S/Q: Press orange key to enlarge showing of the signal strength and quality. • Constellation: Press the blue key into the constellation. 3.2 DVB-C Select DVB-C, then press OK into the Scan Setup. 3.2.1 COUNTRY SETTING Press A B key to change the default country. 3.2.2 CHANNEL NO Press A B key to change the channel number. -
Page 10: Channel
English 3.2.5 QUICK SEARCH Please refer to 3.1.9 QUICK SEARCH. 3.3 CHANNEL We have four options in this menu. 3.3.1 PROGRAM INFO When we receive signal, we can scan some r e l a t i ve p a r a m e te r i n f o r m a t i o n i n t h i s interface. -
Page 11: Spectrum
• Del Press orange key to select “Delete Select” or “Delete ALL”. Press YZ key to select the program that we want to delete, then press orange key, it will appear a “x“ label on the program’s right side. When we have dealt with all the programs need to be processed, press MENU... -
Page 12: Multimedia
English • Full/Ch: Press red key to make all the frequency points we can see on the window or to make some frequency points on it. • Zoom: Press green key to enlarge showing the point you current select, and press again it will be back. -
Page 13: System Setting
• Movie Will need to play the files in the USB and insert it into the machine. • Movie Press red key to the mode option of play files and text encode, then press MENU return. Press green key to change the folder file viewing to detailed list. Press orange key to change mode to big Icon browsing. - Page 14 English Press A B key to change the TV Format. • Video Output If we connect HDMI interface, we can press AB key. • TV Resolution On the basis of the Video Output choice, we can press AB key to change the TV resolution.
- Page 15 • System Info In the system setting, press INFO to check the system version.
-
Page 16: Technical Specification
English 4. TECHNICAL SPECIFICATION TRANSMISSION STANDARDS DVB‐T/T2/C DVB‐T/T2/C INPUT/DEMODULATION Connector Type Female Type Input Frequency 48 to 862 MHz Signal Input Level ‐79.5dBm (MAX) ANT Supply 12V, 18V/24V Imax 100mA Demodulation Type QPSK,16QAM.64QAM,256QAM LCD FEATURES LCD Type TFT Transmissive Number of Dots 480(RGB) x272 Active area (WxH) 95.04x53.86 mm2... - Page 17 Connector Data Protocol USB2.0 interface File Management System NTFS,FAT32,FAT16 File Format wma,mp3,mp4,avi,jpg,jpeg,bmp,img MICROPROCESSOR Microprocessor NOVATEK Clock Frequency 500MHz POWER SUPPLY Li‐Ion Battery 7.4V/3000mAh(The machine behind labeling shall prevail) Adapter OUTPUT :DC12V/1.5A, INTUPT :100‐240VAC 50/60Hz(Will be subject to actual configuration) Power Consumption Max.
-
Page 18: Trouble Shooting
English 5. TROUBLE SHOOTING Problem Possible Causes What To Do No display light up Power switch is not Check to make sure power on Run out of batteries on. Even on adapter No sound or picture, AV IN jack insert, but no but the front panel video input Pull out AV IN cable...
