- Page 1 SK-7000 User Manual...
-
Page 2: Table Of Contents
CONTENTS 1 GUIDE ....................1 1.1 Important Safety Instructions.........1 1.2 Unpacking ................2 1.3 PRODUCT OVERVIEW & ILLUSTRATION ....2 1.4 INSTALLATION OF METER ..........5 2 OUTLINE .....................5 3. THE MENU OSD INSTRUCTION..........6 3.1 Channel Find ................6 3.1.1 Country Setting .............7 3.1.2 Channel No ..............7 3.1.3Frequency .................7 3.1.4Bandwidth .................7 3.1.5Mode ...................7... - Page 3 3.6 System Setting ..............16 5.Technical Specification ............... 19 6.Trouble Shooting ................21...
-
Page 4: Guide
Digital DVBT Meter 1 GUIDE 1.1 Important Safety Instructions Thank you for choosing our product. Before installation, we would like to remind you some notes, which is very important for operating safely and properly, as follows: Be sure to read this user manual, before starting your operation. -
Page 5: Unpacking
Digital DVBT Meter 1.2 Unpacking Open the package and make sure it includes all below items, if any missing, please contact the reseller for replacement. 1.Digital SatelliteMeter 2.User’s manual 3.AV cable 4.Car charger cable 5.Power Adaptor 6.Strap of carrying case 7. - Page 6 Digital DVBT Meter Description FUNCTION LNB IN Connect to satellite antenna cable DC 12V OUTPUT DC 12V output for extern equipment AV OUT Connect to AV port for TV AV IN Connect to AV port for meter HDMI Use HDMI cable to connect for TV Power witch Turn on/off meter USB Port...
- Page 7 Digital DVBT Meter ANT 5V indicator light 12V/17v ANT 12V/17V indicator light LOCK Signal lock indicator light Charger (Note1) Charger indicator light Red & TTXT Red KEY &Teletextinterface Green & SUBT Green key & Subtitle interface Orange &TV/R Orange key & TV and radio switch BLUE &AUDIO Blue key &...
-
Page 8: Installation Ofmeter
Digital DVBT Meter 1.4 INSTALLATION OFMETER 2.OUTLINE d4.3 Inch High Definition TFT LCD Screen dFully DVB-T/DVB-T2, MPEG-2/MPEG-4 compliant dMPEG-2 / H.264 Hardware decoding dDigital meter for signal strength and quality dSupports scan of Auto,Manual dSound and Light Alarm for Locking Signal dSpeaker Integrated dSupport both AV out and AV in dANT short protect... -
Page 9: The Menu Osd Instruction
Digital DVBT Meter dDC12V output for monitor dSoftware upgrade via USB port dEasy to carry 3. THE MENU OSD INSTRUCTION If you have installed and connected the cables of the meter, pressing MENU key to display the Main Menu. Channel Find Program Info Channel Spectrum... -
Page 10: Country Setting
Digital DVBT Meter 3.1.1 Country Setting Press ◄►key to change the defaultcountry. 3.1.2 Channel No Press ◄►key to change the channel number. 3.1.3 Frequency Frequency of the current channel, Input the value by using the numeric keys. 3.1.4 Bandwidth Press ◄►key to change the bandwidth, we can select 5, 6, 7 or 8M. - Page 11 Digital DVBT Meter Quick Search Ch Scan: Press OK/F1 key to search current channel. Auto Scan : Press F2 key to auto blind search the current channel. Beep :Press F3 key to open beep tone. Zoom : Press F4 key toenlarge showing of the signal strength and quality.
-
Page 12: Program Info
Digital DVBT Meter 3.2 Program Info When we receive signal, we can scan some relative parameter information in this interface. -
Page 13: Channel
Digital DVBT Meter 3.3 Channel We have there options in this menu. 3.3.1&3.3.2TV List & Radio List When we enter into the TV List, we can edit TV Program. In the Radio List we have the same operation. - Page 14 Digital DVBT Meter Sort : Press F1keyinto the sort list. Use ▲▼ key to move the cursor, then press OK key to select the sort type of we want; then press ok key to confirm or move the cursor to “x”...
-
Page 15: Epg
Digital DVBT Meter Del : Press F3 key to select“Delete Select” or “DeleteALL”. Press ▲▼ key to select the program that we wantto delete, then press F3 key to label. When we deal with all the program need to be processed, press menu key to then press ok key to confirm the operation or select “x”;... -
Page 16: Spectrum
Digital DVBT Meter 3.4 Spectrum When we enter into this interface, we can press to scan some information about spectrum in different frequency point. Full/Ch : Press F1 key to make all the frequency points we can see on the window or to make some frequency points on it. -
Page 17: Multimedia
Digital DVBT Meter Locked : Press F3 key to lock all the current frequency points, and remain unchanged unless you press again Scan : When the frequency points have been locked, you can press F4 key to receive signal on a point. 3.5 Multimedia Will need to play the files in the USB stick and insert it into the machine. - Page 18 Digital DVBT Meter ○ Movie Press red key to option the mode of play files and text encode; then press menu key return. Press green key to Change the folder File view to detailed list. Press orange key to change mode to big Icon browsing. Press the arrow keys to move the cursor, then press ok key to enter the file.
- Page 19 Digital DVBT Meter F2 Key: pause. F3 Key: fast backward; press F1 key return. F4 Key: fast forward; press F1 key return. ○ Music /Photo Please refer to the Movie operating. 3.6 System Setting...
- Page 20 Digital DVBT Meter ○ Country Setting Press ◄► key to change the country ○ OSD Language Press ◄► key to change the OSD Language. ○ TV Format Press ◄► key to change the TV Format. ○ Video Output If we connect HDMI interface, we can press ◄► key. ○...
- Page 21 Digital DVBT Meter Will update the file into the U disk; then insert the machine; press ok key to update interface, use the direction key to select update file. Press ok key to update. Warning: During the upgrade processing, do not power off or pull out the U disk;otherwise it will damage the machine software, can not boot.
-
Page 22: Technical Specification
Digital DVBT Meter 4.Technical Specification TRANSMISSION STANDARDS DVB-S2/S, MPEG-2,MPEG-4,H.264 SATELLITE INPUT/DEMODULATION Connector Type FEMALE Type Input Frequency 48 to 862 MHz Signal Input Level -79.5dBm (MAX) ANT Supplyl 5V, Imax 200mA,12V/17V Imax 100mA Demodulation Type QPSK,16QAM.64QAM,256QAM LCD FEATURES LCD Type TFT TRANSMISSIVE Number of Dots 480(RGB) x272... - Page 23 Digital DVBT Meter Signal compatibility Support conversion for different video formats Video Format 4:3,16:9,By Pan & Scan and Letter Box conversion Audio decompression MPEG-1 Layer I/II ，MPEG-2 Layer I/II, Audio output mode Stereo, Mono,R/L DATA SERVICE PORT Connector Data protocol USB2.0 interface File management system NTFS,FAT32,FAT16...
-
Page 24: Trouble Shooting
Digital DVBT Meter 5.Trouble Shooting Problem Possible Causes What To Do No display light Power switch is Check to make sure power on. not onRun out of Even on adapter batteries No sound or AV IN jack insert, Pull out AV IN cable picture, but the but no front panel power... - Page 25 Digital DVBT Meter AV out No The system is Check the UHF channel fixed in picture(Video) connected by your system and tune the UHF SCART cable and properly. TV is not in AV mode. The key is not Out of battery Even on adapter working.
- Page 26 USER‘S MANUAL...
