BK-UV002 Ver.1.0
Air Valve
SOLENOID VALVES 010 SERIES
INSTRUCTION MANUAL
Ver.1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the 010 SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Koganei 010 SERIES

  • Page 1 BK-UV002 Ver.1.0 Air Valve SOLENOID VALVES 010 SERIES INSTRUCTION MANUAL Ver.1.0...
  • Page 2 To remove it, insert a tool with a fine tip (such as a small screwdriver) into the rectangular hole on Cautions: 1. The 010 series valves are internal the side of the plug connector to push up on the pilot type solenoid valves. As a result, hook, and then pull out the lead wire.
  • Page 3 Fittings Recommended fittings 010-4E1 Connection port 4(A), 2(B) port 1(P) port Parts TS3-M3M TS3-M3M Quick fitting TL3-M3M TL3-M3M TLL3-M3M TLL3-M3M BF4BU-M3 BF4BU-M3 For urethane tube BF3BU-M3 BF3BU-M3 TAC fitting BF4-M3 BF4-M3 For nylon tube BF3.2-M3 BF3.2-M3 Muffler (for reference) ─ ─...
  • Page 4: Solenoid Valves

    SOLENOID VALVES SERIES Basic Models and Valve Functions Basic model Direct piping, F type manifold Sub-base piping, A type manifold Note Item 010-4E1 A010-4E1 Number of positions 2 positions Number of ports 5 ports Valve function Single solenoid Remark: For optional specifications and order code, see p.65. Note: A010-4E1, except one with a sub-base, is for A type manifolds only.
  • Page 5: Flow Rate

    Flow Rate Effective Area〔Cv〕 Basic model Standard (Single valve) Remarks ● For the case with quick fitting TSH4- 1(P)/4 (A ) M3M attached to the 1(P), 4(A), and 1(P)→4(A) 0.2 〔0.01〕 2(B) ports. Supply pressure 4(A)→5(R1) 0.3 〔0.02〕 010-4E1 ● Same values as for the case with quick (MPa)...
  • Page 6 010 Series Solenoid Valve Order Code ■ ■ ■ Mounting base/sub-base Muffler Wiring type ● Lead wire length: 300mm [11.8in.] is standard. Without mounting base and sub-base Without muffler Grommet type Blank Blank Blank Straight connector L connector with With mounting base...
  • Page 7 Operating Principle and Symbol 5-port Single solenoid 4 ( A) 5 ( R 1) 2 ( B) 1 ( P) 3 ( R ) 010-4E1 Solenoid cover De-energized Column Solenoid Plunger Plunger spring Plunger pin Major Parts and Materials Parts Materials 1 (...
  • Page 8 Dimensions of Solenoid Valve (mm) 010-4E1 010-4E1 Approximately 19.6 Manual override 2-φ2.1 Counterboreφ 3.2 Depth1 Mounting hole 1 ( P) 5 ( R ) 4 ( A) 3 ( R ) 2 ( B) 3-M3×0.5 A010-4E1-25 A010-4E1 Approximately 34.4 Manual override 2-φ...
  • Page 9 Options ●Mounting base: -21 ●Solenoid with straight connector: -PSL 010-SOL 4 ( A) 2-φ3.5 Mounting hole LED indicator ●Solenoid with L connector: -PLL 010-SOL ●Muffler: -75 010-MUFF (Only for A010-4E1-25) Code Model 010-4E1 48.5 50.5 44.5 43.5 For direct piping M3×0.5 LED indicator Made to Order...
  • Page 10: Unit Dimensions

    Dimensions of Manifold (mm) 010MBF 010MB□F Approximately 32.6 10.2 10.2 19.6 Manual override 4-M5×0.8 M3×0.5 (Both sides) 2-φ3.2 Mounting hole stn.1 stn. 2 stn. 3 stn. 4 010-4E1 Unit dimensions Block-off plate Model Model (-BP) 010MB2F 27.2 34.2 010MB12F 129.2 136.2 37.4 44.4 13F 139.4 146.4 47.6 54.6...
  • Page 11 Dimensions of Manifold (mm) 010MBA 010MB□A Approximately 38.6 19.6 10.2 10.2 Manual override 4-M5×0.8 ( Both sides ) 2-φ3.2 Mounting hole stn. 1 stn .2 stn. 3 stn. 4 A010-4E1 Unit dimensions 2-M3×0.5 Block-off plate (Per each station) (-BP) Model Model 010MB2A 27.2 34.2 010MB12A 129.2 136.2...
