OWNER
OPERATOR'S
MANUAL
BCS Buddy Cart
92193040
Manual P/N: 6000181
Revision: 9/2016
Distributed by:
BCS America, LLC
5001 N Lagoon Avenue
Portland, OR 97217
info@bcsamerica.com
Please read and understand this manual and all instructions prior to operating or servicing this attachment.
bcsamerica.com
1-800-543-1040
Advertisement
Table of Contents
Related Manuals for BCS 92193040
Summary of Contents for BCS 92193040
- Page 1 OWNER OPERATOR’S MANUAL BCS Buddy Cart 92193040 Manual P/N: 6000181 Revision: 9/2016 Distributed by: BCS America, LLC 5001 N Lagoon Avenue Portland, OR 97217 info@bcsamerica.com Please read and understand this manual and all instructions prior to operating or servicing this attachment.
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this attachment. Follow all safety rules and operating instructions provided by your tractor manual. -
Page 3: Carton Contents
Carton Contents Carton Contents 6 (x1) 5 (x1) 9 (x1) 11 (x2) 25 (x1) 8 (x2) 23 (x1) 2 (x2) 22 (x2) 12 (x2) 1 (x1) 3 (x4) 21 (x12) 34 (x2) 24 (x3) 19 (x32) 20 (x34) 10 (x4) 4 (x1) 7 (x2) TOOLS REQUIRED FOR ASSEMBLY:... - Page 4 Assembly Instructions Assembly Instructions Assembly Instructions Assembly Instructions Attach Front Support and Latch Angle loosely to Brace Supports Attach Front Support and Latch Angle loosely to Brace Supports as shown using as shown using supplied hardware. Attach Front Support and Latch Angle loosely to Brace Supports Attach Front Support and Latch Angle loosely to Brace Supports as shown using supplied hardware.
- Page 5 Assembly Instructions Assembly Instructions Attach two axle holders to the axle supports as shown using the supplied Attach two axle holders to the axle supports as shown using the supplied hardware hardware. * NOTE: LOOSELY TIGHTEN BOLTS AT THIS TIME Attach latch angle to drawbar assembly with supplied hardware as shown Insert axle into undercarriage halfway as shown.
- Page 6 Assembly Instructions Assembly Instructions Assembly Instructions Slide axle completely through undercarriage. Align tongue with the front support Slide axle completely through undercarriage. Align drawbar with the Slide axle completely through undercarriage. Align drawbar with Insert axle into und and pull handle to latch. Attach washers and spacers as shown. front support and pull handle to latch.
-
Page 7: Operating Instructions
2. Before loading the Buddy Cart for initial use, allow a few minutes to become familiar with steering the cart while mounted to a BCS tractor. The Buddy Cart requires the operator to assist with maintaining a straight path. WARNING: Excessively sharp turns or hurried maneuvering may result in a “jack-knife”... -
Page 8: Warranty
After the three year warranty period, all replacement parts may be ordered by calling 1-800-543-1040. When ordering replacement parts, always give the following information: • Product: Buddy Cart • Model Number: 92193040 • Part Number: • Part Description: bcsamerica.com 1-800-543-1040... -
Page 9: Illustrated Parts List
