Summary of Contents for Trikdis SP231
- Page 2 Attention! Read this user manual carefully. Representative of the company installing the alarm system will explain which security module SP231 functions needs to be activated to ensure proper security of the object. Copyright © 2015 UAB Trikdis. All rights reserved.
-
Page 3: Table Of Contents
Control panel SP231 Contents ABOUT YOUR ALARM SYSTEM ................... 4 MAIN TECHNICAL PARAMETERS ..................4 POWER SUPPLY ......................... 5 GENERAL ALARM SYSTEM OPERATION ................5 ................5 RANSMISSION OF ALARM SYSTEM MESSAGES .................... 5 LARM SYSTEM OPERATION MODES ......................5 LARM SYSTEM CONTROL ........................ -
Page 4: About Your Alarm System
Control panel SP231 1 About your alarm system Control panel SP231 is a part of security and fire alarm system that is designed to process sensor signals and control the alarm system with a built-in GSM modem that transmits alarm system messages to central monitoring station (CMS) and user mobile phones. -
Page 5: Power Supply
Delay zone is breached. 4.3 Alarm system control Alarm system may be controlled using the following devices: Trikdis keypad Protegus SK232LED W/B; Paradox keypads K32+, K32LED, K636, K10LED; iButton keys;... -
Page 6: Control Access
User code – four-digit or six-digit combination to arm/disarm the alarm system and temporarily bypass zones. It is recommended to provide a personal alarm system user code to every user. Module SP231 memory supports up to 39 user codes; ... -
Page 7: Alarm System Control Using Keypad Sk232Led B/W
Control panel SP231 5 Alarm system control using keypad SK232LED B/W Alarm system control keypad Trikdis SK232LED B/W supports the display of 32 zones and 2 partitions. Security and zone mode indicator Backlit buttons for setting operation modes and entering numbers... -
Page 8: Arming The Alarm System, Arm Mode
Control panel SP231 Notes: 1. Press [C] to deactivate the programming mode or delete an incorrectly entered value. 2. Alarm cannot be armed if at least one zone is breached. 5.1 Arming the alarm system, ARM mode To activate security mode ARM: 1. -
Page 9: Arming The Alarm System, Sleep Mode
Control panel SP231 5.3 Arming the alarm system, SLEEP mode Note. At least one zone must be changed to Interior STAY or Instant STAY, otherwise STAY mode is not allowed. To activate security mode SLEEP: 1. Press [SLEEP]. 2. Use the keypad to enter the alarm system user code. -
Page 10: Inversion Of Alarm System Mode
Control panel SP231 5.5 Inversion of alarm system mode Inversion of alarm system mode may be used for quicker control of the alarm system. Security modes ARM, STAY and SLEEP are changed to OFF/DISARM, OFF/DISARM is changed to ARM or STAY mode. -
Page 11: Resetting Two-Wire Fire (Smoke) Sensors
Control panel SP231 5.8 Resetting two-wire fire (smoke) sensors To reset sensor indication after activation of fire (smoke) sensors: Keep [ ] pressed for 3 seconds. a. Two-wire fire (smoke) sensors connected to input ZN8 will reset. b. PGM output will activate Fire Sensor Reset mode. -
Page 12: Programming User Codes
Control panel SP231 [5] Faulty GSM network registration /network / SIM operation [3]: Zones Numbers of breached zones (or their tampers) [4]: Databus Y/G Numbers of Y/G databus expanders that are experiencing troubles [5]: Databus MCI Numbers of MCI databus expanders that are experiencing troubles... -
Page 13: Editing User Codes
Control panel SP231 5.11.3 Editing User codes To edit current User codes: 1. Press [ ]. 2. Enter the Master user code. a. Button [ ] will start flashing. b. Backlit numbers on the keypad will indicate serial numbers of users whose codes are already entered. -
Page 14: Testing Of Message Transmission System
PGMx in order to program the module. Call the number of the SIM card inserted in the security module SP231. Alarm system mode will change to the opposite mode if the phone number is listed in the module memory and remote control mode is activated. -
Page 15: Control By Sms Messages
Control panel SP231 8 Control by SMS messages Alarm system may be controlled and part of control panel parameters may be changed using SMS messages. All module parameters may only be changed using TrikdisConfig. Note. Change default remote access code (123456) to one that only you would know, e.g. - Page 16 Control panel SP231 PSWxxxxxx ˽ 13 ˽ Set SIM2 card access to GSM network settings. APN – access name (up to 50 characters), APN#LOGIN2#PSW2# LOGIN – user name (up to 29 characters) PSW – user password (up to 29 characters) PSWxxxxxx ˽...
- Page 17 Control panel SP231 Information about the secured object Fill in the table. Keep this document in a secure location. Access codes Your Master access code is ______________________________ Other access codes: Code Control key No. Code Control key No. Zones Zone...
- Page 18 Control panel SP231 Zone Secured space Zone type ©1997-2015 Trikdis www.trikdis.com...
- Page 19 Control panel SP231 Temperature Maximum Minimum Sensor Serial number Controlled space temperature temperature Emergency call buttons Alarm system __________________________ Ambulance __________________________ Fire __________________________ Time intervals Time for entry _________________________ sec. Time for exit _________________________ sec. Siren operation time _________________________ sec.
