Changing the Decorative Frame

Always unplug your DF-1710 from the power source before removing the frame and/or mat to
prevent damage or injury.
The DF-1710 accepts most standard 16 x 20" decorative frames made of wood or other material that can be
screwed into. Change the frame by following these steps:
1) Lay the DF-1710 down flat on its face on a flat, clean surface, preferably covered with cloth or other non-
scratching material.
2) Unscrew the eight wood screws holding the metal offset clips to the decorative frame and rotate the clips
out of the way.
3) Lift the DF-1710 out of the frame. Make sure that the picture mat and non-glare acrylic remain in the
frame and set the DF-1710 aside where its LCD screen will not be damaged.
4) Place your new frame face down on a flat, clean, soft surface. If you intend to use the picture mat and/or
non-glare acrylic supplied with the DF-1710, transfer these to your new frame. If you're using your own
mat, make sure that a hole is cut at the remote control sensor location. A paper punch works well for this.
5) Loosen the machine screws holding the four black frame brackets to the sides of the DF-1710 so that the
brackets can slide.
6) After the protective glass or acrylic (if used) and mat are in your new frame (glass first, then mat). place
the DF-1710 on top of them. The edges of the DF-1710 frame brackets should go inside the rabbetted
notch in the picture frame.
7) Screw the eight metal offset clips into the back of your new frame such that they clamp the DF-1710
mounting brackets between themselves and the picture frame notch. Be sure that the screws used are not
so long that they break through the frame! Pilot holes can be drilled for ease and accuracy of screw
insertion.
8) Adjust the four black frame brackets in their slots so that they are snug against the inner surface of the
offset clips on the frame (this compensates for the varying notch depth of different frames and varying mat
and glass thicknesses) and re-tighten the machine screws holding the brackets to the DF-1710.
