CHEROKEE ''ARROW"
SECTION V
SECTION V
GENERAL MAINTENANCE
This section of the Cherokee Arrow Handbook contains in-
formation which pertains to minor maintenance of the airplane.
For further maintenance assistance refer to the Service Manual
for this airplane. Any complex repairs or modification should be
accomplished by a Piper Certified Service Center or equivalent.
HYDRAULIC SYSTEM SERVICE
The fluid level of the hydraulic reservoir should be checked
every 50 hours by viewing the fluid level through the filler plug
hole in the hydraulic pump. Access to the pump is through the
panel at the right rear side of the baggage compartment.
To check fluid level, remove the filler plug located on the
forward side of the pump and ascertain that fluid is visible up to
the bottom of the filler plug hole. Should fluid be below the hole,
loosen the vent screw and add fluid, MIL-H-5606, through the
filler hole until full. Reinstall the filler plug and tighten the
vent screw.
LANDING GEAR SERVICE
The main wheels are Cleveland Aircraft Products, Model
#40-84, with Cleveland dual disk hydraulic brake assemblies,
Model #30-41. The main wheel tires are 6.00 x 6, four ply rating,
type III with tubes. The nose wheel is a Cleveland Aircraft
690203
42
