- Page 1 Continuous Flow Electric Water Heater INSTALLATION & OPERATION MANUAL CFEWH SERIES 2 – Three Phase www.microheat.com.au AS/NZS 60335.2.35 N29465 Licence No.: A/13670EA AS 3498 WM-022136...
-
Page 2: Table Of Contents
CFEWH Operation (contd) ..............16 Diagnostics and Error Descriptions..........17 Dimensions ..................19 MicroHeat Warranty ................20 MicroHeat Contact Details ..............21 CFEWH Mounting Template ...............23 CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 2 of 23... -
Page 3: Introduction - Cfewh
This equipment requires three phase 415 VAC. To avoid electric shock, this equipment must only be opened and installed by a qualified electrician or plumber. CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 3 of 23... -
Page 4: Cfewh Benefits
Significantly, the 100% “optimised” energy capability of the CFEWH results in far less than the full rated power being consumed. CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 4 of 23... -
Page 5: Pre-Installation - Checklist
Failure to comply with the installation and operating instructions or improper use voids the warranty CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 5 of 23... -
Page 6: Pre-Installation - Component Guide
Pan Phillips Head Self Tapping Screw x 2 – Exterior *Shown on page (12) Cover Screws Included in the packaging – provided separately in the small satchel CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 6 of 23... -
Page 7: Cfewh Installation Options
CFEWH Series 2-30 Cold Water IN Hot Water OUT Hand Basin 1 Hand Basin 2 Shower 2 Shower 1 CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 7 of 23... -
Page 8: Cfewh Specifications
10.7 15°C 11.1 12.3 20°C 11.5 12.9 14.3 25°C 10.3 13.8 15.5 17.2 30°C 10.7 12.9 17.2 19.3 21.0 CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 8 of 23... -
Page 9: Cfewh Installation Procedure
Turning hot water on will initiate the heating process and hot water should exit from of the point of use water outlet. The LED will illuminate as fast flashing GREEN. CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 9 of 23... -
Page 10: Cfewh Mounting & Installation
This will void the warranty. 4 x Mounting screw hole locations Figure 3 - Mounting Screw Location Red Area - No Drilling CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 10 of 23... -
Page 11: Cfewh Plumbing & Electrical Installation
– specifically in this instance where the specified water pressure limiting valve and shutoff valve type, as indicated, must be installed with this unit. CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 11 of 23... -
Page 12: Cfewh Electrical Installation
LED Indicator/Display PCB Plug and Cable Display PCB PCBA reset button Figure 4 - CFEWH Series 2 PCBA Assemblies CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 12 of 23... -
Page 13: Maximum Electrical Demand Calculation
TABLE C1 MAXIMUM DEMAND – SINGLE AND MULTIPLE DOMESTIC ELECTRICAL INSTALLATIONS AS/NZS 3000:2007 Electrical_installations AS/NZS 3000:2007 Electrical_installations CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 13 of 23... -
Page 14: Preparation For Use
The unit is now primed and ready for use. CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 14 of 23... -
Page 15: Cfewh Operation
Call MicroHeat 1300 981 325 and arrange for a MicroHeat Service Technician to rectify the problem. For a list of Error codes refer page (17). CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 15 of 23... -
Page 16: Cfewh Operation (Contd)
The amount of electrical energy (power) applied to heat the water is not allowed to exceed the rating of the CFEWH. In the case of the CFEWH Series 2 this will be limited to a maximum of 30kW (or other below 30kW). The CFEWH is digitally controlled, and incorporates an “Optimised Direct Energy Transfer”... -
Page 17: Diagnostics And Error Descriptions
The three LED indicators on the PCB will be illuminated when the unit is in standby, running or in error mode. GREEN ORANGE CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 17 of 23... - Page 18 Other than the Inlet Filter (13), the unit does not contain any user-serviceable parts. In case of malfunction, a trained service agent, licensed plumber or electrician is required. CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 18 of 23...
-
Page 19: Dimensions
Dimensions NOTES CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 19 of 23... -
Page 20: Microheat Warranty
Where a failed component or CFEWH is replaced or repaired under warranty, MicroHeat will incur all associated costs. However, where the CFEWH is installed outside the boundaries of a metropolitan area to be defined by MicroHeat or further than 35 km from an Accredited Service Agent, the cost of transport, insurance and travelling costs between the nearest MicroHeat Accredited Service Agent’s premises and... -
Page 21: Microheat Contact Details
Installation Phone: 1300 981 325 Email: info@microheat.com.au MicroHeat Technologies Pty Ltd 20 Pickering Road MULGRAVE VIC 3170 AUSTRALIA www.microheat.com.au CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 21 of 23... - Page 22 PAGE LEFT INTENTIONALLY BLAN CFEWH SERIES 2 – Three phase | INSTALLATION Manual © July 2017 | MicroHeat Technologies Pty LTD Page 22 of 23...
-
Page 23: Cfewh Mounting Template
CFEWH Mounting Template 8MM X 65MM (Minimum length) SCREWS CFEWH MOUNTING TEMPLATE...
