- Page 1 Quick Start Guide WECB Version 1.0 Bridge Wireless Ethernet Coaxial...
-
Page 2: Minimum Requirements
• Windows® 8, 7, Vista®, or XP; Mac OS® X (10.5 or higher) • An installed Ethernet adapter (10/100/1000) • Any device that has a WiFi adapter. I.E. Xbox, IPad, IPhone Package Contents Wireless Ethernet Coaxial Bridge (WECB) COAX Cable Power Adapter Stand Splitter DXN-W224 Quick Start Guide... -
Page 3: Front Panel
A solid light indicates the 2.4 GHz Wi-Fi network is ready. 5 GHz LED A solid light indicates the 5 GHz Wi-Fi network is ready. A solid light indicates a connection on the Ethernet port. The LED will blink LAN LEDs (1-2) during data transmission. DXN-W224 Quick Start Guide... - Page 4 Connect one end of another coaxial cable to the Cable In port and the other Cable In end to the cable outlet on the wall. Power Port Connect the supplied power adapter to power your WECB. DXN-W224 Quick Start Guide...
-
Page 5: Hardware Installation
Connect one end of the coaxial cable to the Cable port located on the WECB’s back panel and attach the other end to your cable outlet inside the house or directly to the Wireless Gateway 2. Note: There is no MoCA mode switch for configuration on the WECB. DXN-W224 Quick Start Guide... -
Page 6: Software Installation
Software Installation D-Link WECB has a web-based configuration utility to allow control over certain coaxial networking parameters. The unit is shipped with default parameters that will allow operation on most coaxial network without any additional configuration. Note: If you are connecting to a Wireless Gateway 2, it will automatically configure the settings on your WECB.
