Basic Settings

Adjust the angle so that an object (such as
the tire blocks) serving as a reference along
Basic settings refer to those settings that are
the horizontal lines is displayed.
mandatory. Basic settings are set during initial
setup. These settings can be changed later.
A. Centerline
Adjust the monitor connected to the rear view
camera. Adjust so that the vehicle centerline is
displayed in the center of the screen.
Note:
The centerline serves as a reference for vehicle
width when parked (orange line).
Horizontal lines
1. Press the ENTER button.
Note:
2. Adjust so that the centerline is in the
Adjustment can be made within the range of –511
center of the screen using the + and
to +511.
Some portions may not be able to be seen depend-
– buttons.
ing on the settings.
Adjust so that the number of lines is the
3. Press the ENTER button.
same on both sides of the screen.
When performing this procedure starting
from "First Time Setup", proceed to
section C entitled "Position (Horizontal)".
When performing this procedure starting
from "Changing Basic Settings or Other
Settings", return to step 5 of "Changing
Basic Settings or Other Settings".
C. Position (Horizontal)
Adjust the horizontal of the rear view camera
Note:
image as viewed from the location where the
Adjustment can be made within the range of –63
rear view camera is installed.
to +63.
1. Press the ENTER button.
3. Press the ENTER button.
2. Adjust the horizontal position with
When performing this procedure starting
the + and – buttons.
from "First Time Setup", proceed to
Adjust so that the center of the parking
section B entitled "Position (Rotate)".
space is displayed in the center of the
When performing this procedure starting
camera screen in the horizontal direction.
from "Changing Basic Settings or Other
Settings", return to step 5 of "Changing
Basic Settings or Other Settings".
B. Position (Rotate)
Adjust the rotation of the rear view camera
image as viewed from the location where the
rear view camera is installed.
1. Press the ENTER button.
2. Adjust the angle with the + and
Horizontal direction centerline
– buttons.
Note:
Adjustment can be made within the range of –63
to +63.
En
E. View Angle
3. Press the ENTER button.
When performing this procedure starting
Adjust the view angle (high angle mode) as
from "First Time Setup", proceed to
viewed from directly overhead.
section D entitled "View Diagonal".
When performing this procedure starting
1. Press the ENTER button.
from "Changing Basic Settings or Other
2. Adjust the angle with the + and
Settings", return to step 5 of "Changing
– buttons.
Basic Settings or Other Settings".
Adjust the angle so that the white lines are
D. View Diagonal
aligned with the vertical lines.
Adjust the inclination of the rear view camera
image as viewed from the location where the
rear view camera is installed.
1. Press the ENTER button.
2. Adjust view diagonal with the + and
– buttons.
Adjust view diagonal so that the white
lines of the parking space are displayed
symmetrically.
Vertical lines
Note:
Adjustment can be made within the range of –511
to +511.
3. Press the ENTER button.
When performing this procedure starting
from "First Time Setup", proceed to section
F entitled "Vertical Guideline (Width)".
When performing this procedure starting
from "Changing Basic Settings or Other
Centerline
Settings", return to step 5 of "Changing
Basic Settings or Other Settings".
Note:
Adjustment can be made within the range of –255
to +255.
3. Press the ENTER button.
When performing this procedure starting
from "First Time Setup", proceed to
section E entitled "View Angle".
When performing this procedure starting
from "Changing Basic Settings or Other
Settings", return to step 5 of "Changing
Basic Settings or Other Settings".
En
F. Vertical Guideline (Width)
Changing Basic Settings or

Other Settings

Adjust the width within the vertical guidelines.
1. Press the ENTER button.
Basic settings set during initial setup can be
2. Adjust the position with the + and
changed. In addition, other settings can also
– buttons.
be made such as View (Wide/Zoom) and
Adjust the position using the white lines of
Guideline (Shape) on "Advanced Settings".
the parking space as a reference.
Begin the setup procedure after parking the
vehicle at the location where photographs
are to be taken by referring to the section on
"Preparations Before Beginning Setup".
1. Put the vehicle in reverse.
Note:
When performing setup, always make sure to set
the parking brake and step on the brake to make
sure the car is stopped.
2. Simultaneously press the ENTER
and + buttons.
Vertical guidelines
3. Press the ENTER button four times.
Note:
Adjustment can be made within the range of –255
4. Take the photograph.
to +255.
Take the photograph to be used for setup.
3. Press the ENTER button.
Take the photograph while referring to the
section on "Taking Photographs".
4. Press the ENTER button twice.
5. Select the parameter to be set with
When performing this procedure starting
from "First Time Setup", proceed to step 6
the + and – buttons and then press
of "First Time Setup".
the ENTER button.
When performing this procedure starting
from "Changing Basic Settings or Other
Settings", return to step 5 of "Changing
Basic Settings or Other Settings".
Basic Settings

Advanced Settings

Set the basic settings
Set the advanced settings
while referring to
while referring to
"Basic Settings".
"Advanced Settings".
6. Select OK and press the ENTER
button.
The settings are stored in memory.
Note:
Please make sure to read the caution and then
press the ENTER button to go to the next step.
Photograph data is deleted when setup is ended.
This camera and associated electronic guides are
intended solely as a driving aid. This unit is not
a substitute for you attentiveness, judgement, and
care while driving, moving, or parking your vehi-
cle. Always observe safe driving rules and driving
laws, even if they contradict the unit instructions.
En
C. Guideline (Distance)
Advanced Settings
The distance between the horizontal guidelines
Advanced settings such as View (Wide/Zoom)
can be adjusted. The horizontal guidelines are
and Guideline (Shape) can be set using
displayed at the interval shown in Fig. 2 during
advanced settings.
the initial setup when the camera has been
A. View (Wide/Zoom)
installed at the position shown in Fig. 1.
Fig. 2
This adjustment is only necessary when only
ground is displayed or when the display is too
Fig. 1
small or illegible when viewed with the high
angle mode because of the height of the rear
view camera.
50˚
1. Press the ENTER button.
1.5 m / 5 ft.
2. Adjust the view elevation with the +
and – buttons.
Note:
Note:
Adjustment can be made within the range of –63
The horizontal guidelines consist of three refer-
to +63.
ence lines that serve as a reference when parking
3. Press the ENTER button.
(green, yellow and red lines).
In the case the "view angle" of the basic settings
Return to step 5 of "Changing Basic
has been adjusted from the factory adjustment,
Settings or Other Settings".
the distances between the horizontal guidelines as
B. Guideline (Shape)
shown in Fig. 2 (approx. 1 m, 1 m and 2 m) will
be different.
Adjust the inclination of the vehicle vertical
1. Press the ENTER button.
guidelines (shape) when there is a considerable
2. Adjust the angle with the + and
discrepancy with the vehicle width towards the
– buttons.
back of the field of view.
1. Press the ENTER button.
2. Adjust the angle with the + and
– buttons.
Horizontal guidelines
Note:
Adjustment can be made within the range of –255
to +255.
Vertical guidelines
3. Press the ENTER button.
Note:
4. Press the ENTER button twice.
Adjustment can be made within the range of –127
Return to step 5 of "Changing Basic
to +127.
Settings or Other Settings".
3. Press the ENTER button.
4. Press the ENTER button twice.
Return to step 5 of "Changing Basic
Settings or Other Settings".
Note:
The vertical guidelines (shape) setting reflect the
screen display of view angle and vertical guideline
(width).
En
Approx.
2 m / 7 ft.
Approx.
1 m / 3 ft.
Approx.
1 m / 3 ft.
