Pioneer Comfort adapter CA-D-PI.150 Quick Start Manual

Display driver and remote control interface
Hide thumbs

Advertisement

Quick Links

DISPLAY DRIVER AND REMOTE CONTROL INTERFACE
Car:
Comfort Adapter
IP-BUS connection for
CDC, DAB, ...
e
6
020094
Copyright © 2004 by Digatronics.
©
OPEL/VAUXHALL
Tools:
"SYSTEM REMOTE
!
CONTROL" output
must be connected to
the ISO connector !
!
* Note: please refer manual if function " remote display" is possible !
Rev. 2.0505.150/A
CA-D-PI.150
Radio's : CDR500 and CD2005
(exclusive models with CAN-Bus behind the radio !)
2 x
Pioneer
Equipment *
BEFORE INSTALLATION :
!!! DISCONNECT CAR BATTERY !!!
Astra (03/98 —>12/03)
Corsa (08/00 —>)
Omega (04/94 —>)
Sintra (03/97 —>)
Vectra (10/95 —>)
Zafira (04/99 —>)
PEE2102
