UPRIGHT FREEZER
Model Number : UF855L
INSTRUCTION MANUAL
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES
AND OPERATING INSTRUCTIONS.
Felix Storch, Inc
Summit Appliance Division
Write Serial Number (on back of unit) here:
770 Garrison Avenue
Bronx, New York 10474
_______________________________
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UF855L and is the answer not in the manual?

Questions and answers

Related Manuals for Summit UF855L

Summary of Contents for Summit UF855L

  • Page 1 UPRIGHT FREEZER Model Number : UF855L INSTRUCTION MANUAL BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc Summit Appliance Division Write Serial Number (on back of unit) here: 770 Garrison Avenue Bronx, New York 10474 _______________________________ www.summitappliance.com...

  • Page 2: Table Of Contents

    Table of Contents Important Safeguards ................. 2 - 3 Location of Parts ....................4 Installation Instructions ................4 – 8 1. Before using your appliance ..............4 2. Installing your appliance ................5 3. Reversing the door swing ..............5 – 8 4.

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS Before the freezer is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using this appliance, follow basic precautions, including the following: •...
  • Page 4 • The freezer must be installed with an electrical connection in accordance with state and local codes. A standard electrical supply (115-120V AC only, 60 Hz), properly grounded in accordance with the National Electrical Code and local codes and ordinances is required. •...

  • Page 5: Location Of Parts

    Location of Parts 1. Top cover 2. Large drawers (5) 3. Small drawer 4. Front leg 5. Adjustable leg 6. Thermostat 7. Door Installation Instructions 1. Before using your appliance a. Remove the exterior and interior packing, including the foam base and all adhesive tape. To remove any remaining tape or glue, rub the area briskly with your thumb.

  • Page 6: Installing Your Appliance

    2. Installing your appliance WARNING: Keep flammable materials and vapors such as gasoline away from the freezer. • Place your appliance in a well-ventilated area on a floor that is strong enough to support it when fully loaded. To level your appliance, adjust the leg at the front of the appliance. •...
  • Page 7 2. Remove the bolts, then remove the upper hinge that holds the door in place. Lift the door and place it on a padded surface to prevent scratching it. Remove the screws that hold the upper hinge pin, then transfer the hinge pin to the opposite side and tighten the screws.
  • Page 8 5. Rotate the former left leg 180 degrees and attach to the lower right corner, then rotate the former right leg 180 degrees and fasten to the bottom left corner. The door should be able to attach to the lower left hinge. Reattach the door to the correct side.

  • Page 9: Electrical Connection

    Plug the appliance into an exclusive, properly installed, grounded wall outlet. Any questions regarding power and/or grounding should be directed toward a certified electrician or an authorized Summit service center. • It is recommended that a separate circuit serving only this appliance be provided. Use a receptacle that cannot be turned off with a switch or pull chain.

  • Page 10: Cleaning And Maintenance

    set, the lower the temperature becomes. A medium setting is the most suitable for general operation. The freezer's temperature will vary depending on the quantity of foods stored and the frequency of the door opening. In order to maintain good cooling efficiency and save energy, we recommend that you do not overfill the freezer or open the door too frequently.

  • Page 11: Turning Off The Unit

    If possible, avoid turning off the freezer. Let it work for long periods of time, even if there is no food being stored. This will help keep the appliance working properly for a long time. If you must turn it off and not use it for a long period of time, turn the thermostat knob to 0 (OFF) and unplug the appliance.

  • Page 12: Troubleshooting

    Troubleshooting If your appliance is not working normally, you may be able to avoid the cost of a service call by checking the following list of common problems: 1. Troubleshooting guide Problem Possible cause Unit stops working. Thermostat is set at 0 (OFF). Power plug is not firmly set in socket.

  • Page 13: Circuit Diagram

    Circuit Diagram Disposal Instructions In the event of the unit being damaged beyond repair, please dispose of it according to local regulations for the disposal of appliances. Please take off the doors before you discard the appliance, to prevent children from being trapped inside.

  • Page 14: Limited Warranty

    Limited Warranty ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
