Thank you for purchasing PS600 from Polaroid. To safely use this device, please read this manual
carefully and keep it (together with the warranty card) in a safe place. If you pass the mobile storage system on
to another user, make sure that you hand over the instruction manual and warranty card as well. Please keep any
additional documents together with this manual.
CHARGE FIRST! Before reading through the manual, you can begin to charge up your PS600
by connecting it to the power supply provided and plugging it in at the wall.
Noncompliance with the safety instructions may cause injuries due to fire, electric shock, etc.
Instruction manual
PS600
Your mobile outlet to go
Mobile Storage System
Advertisement
Table of Contents
Related Manuals for Polaroid PS600
Summary of Contents for Polaroid PS600
- Page 1 Mobile Storage System Thank you for purchasing PS600 from Polaroid. To safely use this device, please read this manual carefully and keep it (together with the warranty card) in a safe place. If you pass the mobile storage system on to another user, make sure that you hand over the instruction manual and warranty card as well.
-
Page 2: Table Of Contents
Contents Set includes Introduction Safety instructions Lifting and transportation Get to know your PS600 Charging 6.1. What it can power 6.2. LCD battery display 6.3. Charging via solar panel 6.4. Charging via mains power supply Using the PS600 Technical specifications... - Page 3 Instruction manual PS600 Mobile Storage System...
-
Page 4: Set Includes
Instruction manual | PS600 Mobile Storage System 1. Set includes Item Quantity PS600 Mobile Storage System AC Wall Charger (2 pieces) Instruction manual and warranty card... -
Page 5: Introduction
• This instruction manual can be downloaded as a PDF file on our website: www.polaroidenergystorage.com. • Intended use: The Polaroid PS600 Mobile Storage System unit is intended as a power supply for electro- nic devices with a maximum power consumption of 300 W. Our product is not suitable to be used with equipment that relates to one‘s own personal safety and relies heavily on electricity, such as medical de-... -
Page 6: Safety Instructions
Instruction manual | PS600 Mobile Storage System 3. Safety instructions Please observe these instructions to ensure safe usage. Explanation of symbols This symbol together with word Noncompliance may very likely lead DANGER means to serious injury or death. This symbol together with word... - Page 7 Instruction manual | PS600 Mobile Storage System Danger Do NOT disassemble, repair or modify the unit or the battery. Doing so may result in electric shock, fire, etc. Do NOT place the unit close to or in a fire or expose it to heat. Keep out of direct sunlight.
- Page 8 Instruction manual | PS600 Mobile Storage System Warning Use and store the unit only in a clean and dry environment. Do not use and store in dusty and wet envoirnment. Failure to do so may result in a short circuit, smoke or fire if metal dust or small metallic parts comes in contact with the connections.
- Page 9 Instruction manual | PS600 Mobile Storage System Caution If rust, peculiar odors, overheating or other abnormal circumstances are observed, stop using the unit immedi- ately and contact the dealer or our customer service center. The unit complies with all legal requirements for transport of dangerous goods.
-
Page 10: Lifting And Transportation
Instruction manual | PS600 Mobile Storage System 4. Lifting and transportation 1. Using the handle to carry the unit. ATTENTION ATTENTION Keep the unit away from Hold the handle tight in your hand other objects when moving. before lifting and carrying. -
Page 11: Get To Know Your Ps600
Instruction manual | PS600 Mobile Storage System 5. Get to know your PS600... -
Page 12: Charging
6. Charging Before use or storage, plug your PS600 into the wall until it is fully charged. If at any point you see the battery icon flashing on the LCD Display, plug it into a power source, like an AC outlet or a solar panel as soon as possible. -
Page 13: Charging Via Solar Panel
6.4. Charging via mains power supply Using the AC wall charger provided, plug your PS600 into any outlet. You will know that the PS600 is charging when you see the red LED indicator blinking once per second. The PS600 is fully charged when all battery seg- ments stop blinking and remain solid. -
Page 14: Using The Ps600
• When charging devices using PS600, take note of how much remaining energy is shown on the LCD display. • If you plug in devices that have a high power requirement, the charge level of PS600 can drop quickly and you may not get be able to extract the entire 578 Wh of energy. - Page 15 PS600 is equipped with an advanced LCD display that shows important information related to your power consumption. 1. The input section on the upper section of the display indicates the power to the PS600 from your charging source (mains supply or solar panel). When charging from a solar panel, this charging power will change as you change the orientation of the solar panel relative to the sun.
-
Page 16: Technical Specifications
Instruction manual | PS600 Mobile Storage System 8. Technical specifications Charge times Wall charger (100 W) 6-7 hrs Solar panel (100 W) 6-7 hrs (Full Sun) Battery Cell type LG lithium ion Pack capacity 578Wh Lifecycles >300 Temperature control, Surge protection,... -
Page 17: Solar Panels
1. Solar panels don’t store energy from the sun, they collect it. Use your solar panel to charge your PS600 so that you can use it day or night to power your devices. 2. Not all solar charge times are created equal. -
Page 18: Frequently Asked Questions (Faqs)
How do I know if my PS600 is charged? To check the charge level of the PS600, refer to the LCD Battery Display. When lit up, you’ll see a battery outline with 5 segments, indicating the current charge level. You can turn on the battery display by pushing the display button. - Page 19 Mini Fridge (70 W) ~8 hrs When you’re deciding on what to power using your PS600 recharge, do some research into your device’s power consumption. For more quick tips and learning tools, please email our customer service for help. NOTE The above data are to be used only as reference points.
-
Page 20: Storage
2. Turning off all buttons As soon as the PS600 power supply unit is charged fully, turn off the main switch and the other ON/OFF buttons and remove the power cord from the AC mains connection. 3. Cleaning Wipe away any dirt using a damp cloth. -
Page 21: Disposal And Recycling
Instruction manual | PS600 Mobile Storage System 14. Disposal and recycling Lithium ion battery As soon as the end of the battery‘s service life is reached, the entire lithium ion battery can be recycled. Do not open or disassemble the unit. -
Page 22: Warranty And Customer Service
Instruction manual | PS600 Mobile Storage System 15. Warranty and customer service Contact distributor for technical support /customer service USA [Style Aisa Inc.] 101 Moonachie Ave Toll-Free: E-Mail: Moonachie, NJ 07074 888-765-5428 polaroidenergy@digitalsupportdesk.com EUROPE [GBT GmbH] An Gut Nazareth 18A... - Page 23 REPAIR TERMS AND CONDITIONS 1. In the case of device failure which can be attributed to poor workmanship, please take the original sales receipt with purchase date (invoice, etc.) to the retail store. In case of normal use, the power supply unit will be repaired or replaced free of charge within the one year warranty period.
- Page 24 This product is manufactured, distributed and sold by GBT GmbH. Polaroid, Polaroid & Pixel, Polaroid Classic Border Logo, and Polaroid Colour Spectrum are trademarks of PLR IP Holdings, LLC, used under licence. GBT GmbH provides a manufacturers war- ranty and support for this product. PLR IP Holding, LLC does not manufacture this product or provides a manufacturers warranty or support.
