HiBoost F20-5S User Manual

Hide thumbs Also See for F20-5S:
Table of Contents

Advertisement

Quick Links

Download this manual
(F27/F23/F20-5S )
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F20-5S and is the answer not in the manual?

Questions and answers

Related Manuals for HiBoost F20-5S

Summary of Contents for HiBoost F20-5S

  • Page 1 (F27/F23/F20-5S )

  • Page 2: Table Of Contents

    Booster’s port description ....................5 LCD Introduce ........................6 Control Button operation ....................7 Manual gain control (MGC) .................... 7 Install Hiboost Booster system ..................8 Before you install ......................8 Installation overview....................8 1. Install Outdoor Antenna ................. 9 2.

  • Page 3: How It Works

    F27/F23/F20-5S are designed to help mobile users amplify weak signals of 2G, 3G and 4G. They are bi-directional amplifiers. The donor antenna receives the signals from the cell tower, amplifies it, and transmits to the signal booster. Then the indoor antenna will receive the signal and retransmit it to your mobile device.
  • Page 4 1.Outdoor Antenna 2. Booster 3.Indoor Panel Antenna 4. Coupler 5. Splitter Omni ceiling antenna Optional antenna kits Recommended Indoor panel antenna Wide Band Yagi antenna RF cables (3D,5D,8D) Outdoor ceiling mount dome antenna Indoor panel antenna Omni ceiling antenna Whip antenna Coupler Lightening protector Wilkinson Splitter (2,3,4 way)

  • Page 5: Features

    Embedded CPU, self-adaptive intelligent system to make booster system very  easy to install and better performance is guaranteed under complex and constantly changing RF environment. ISO: Intelligent isolation processing to avoid self-oscillation, quite wide  adjusting range to stabilize the signal strength/quality for clearer voice/ higher data speed and avoid interference to mobile network ALC: Intelligent ALC, quite wide adjusting range to improve the signal quality ...

  • Page 6: Lcd Introduce

    LCD1/LCD2/LCD3: Display area of working frequency. After power on the repeater, LCD1 and LCD3 will light all the time, LCD2 will display the working frequency in turn, the following is the display content corresponding to frequency. Frequency Content of LCD2 display 700MHz Lower A/B/C blocks 700MHz Upper C block CDMA800&GSM850...

  • Page 7: Control Button Operation

    There are 4 operation modes: long press ”AN2”, short press ”AN2”, short press “AN1” and short press “An3”.When the LCD is in the rotation display mode: • Short press ”AN2” will stop the rotation display mode, the LCD will stay on the display of frequency, gain or power.

  • Page 8: Install Hiboost Booster System

    • Make sure you have sufficient cable length between proposed outdoor/indoor antennas and the booster in case you don't purchase standard kits • Make sure the position where you install the booster is near to one existing electrical outlet, well ventilated, away from excessive heat, moisture, and direct sunlight.

  • Page 9: Install Outdoor Antenna

    1. Outdoor Antenna 2. Booster 3. Indoor Antenna 1. Install Outdoor Antenna 1.1 How to find the position with the strongest receiving signal The booster’s main function is to improve weak RF signal of an area. The receiving signal strength from the outdoor antenna directly affects the efficiency of indoor coverage.
  • Page 10 After 3s After 3s After 3s After 3s Display After 3s in turn You can long press the control button”AN2” for 3s, so that the LCD will enter to the page turning query mode ,then click “AN1” or “AN3” make the LCD stay in the output power interface.
  • Page 11 signal from A to E, and select a place with best signal strength for installation. It is recommended to use app over smart phone that can display signal level, since it is more accurate than checking the signal bars. The outdoor antenna should point to the tower for better signal strength or quality.

  • Page 12: Install Indoor Antenna

    feeder line to avoid water or other kinds of damage. 2. Install Indoor Antenna According to the requirement of practical application, please select Indoor panel antenna, or Omni-ceiling antenna as indoor antenna for coverage Install indoor panel as reference. Step1: Select a place on a wall projecting the area where you want reception. Normally, to provide an overall coverage, you will need to choose a corner.

  • Page 13: Booster Commissioning

    Step5: Connect the AC power cord to the signal booster, and then connect the plug to the electrical outlet to power on the booster Booster installation Connection from cable to booster 4. Booster Commissioning Overview: The booster has quite intelligent startup system, booster commissioning is an automatic process to guarantee its optimal performance.
  • Page 14 Check whether it is necessary to add more indoor antennas since barriers  block the signal penetration. 2. The rated output power is not reached. 1) Please adjust the outdoor antenna to get a stronger receiving signal in order to get higher output power (not necessarily to reach rated value as long as the coverage is enough) 2) please observe the LCD display, if the reading gain is less than rated value and "ISO"...
  • Page 15 Status Meaning Solve methods No loop back or Remain still NO action is needed no self-oscillation Flashing but actual gain Slight loop back is not more than 30dB less NO action is needed or self-oscillation than rated gain Working properly, but deep loop, below actions are recommended: Adjust the antennas’...
  • Page 16 are working to solve the self-oscillation or strong signal problems, so the problems have been solved already. In most cases, there is no need for you to do anything, except deep self-oscillation or too strong signals that we recommend your actions but not mandatory, since the booster still solves the problems.

  • Page 17: Trouble Shooting

    Problem Resolution The signal booster has no power. Check that the AC outlet is working. Try to fasten the connections between the different parts of the system. The booster’s power is on but the phone is Change the direction of donor antenna or its not connected into the network and still installation position.

  • Page 18: Specifications

    F20-5S Max .Gain 70± 3dB(UL)/75± 3dB(DL) F23-5S Max .Gain 75± 3dB(UL)/80± 3dB(DL) F27-5S Max .Gain 83± 3dB(UL)/83± 3dB(DL) 60~73dB/65~73dB/62~73dB/60~73dB/62~73dB(UL) F20-5S Nominal passband gain 65~78dB/65~78dB/65~78dB/59~78dB/67~78dB(DL) 65~78dB/70~78dB/67~78dB/65~78dB/67~78dB(UL) F23-5S Nominal passband gain 70~83dB/70~83dB/72~83dB/64~83dB/72~83dB(DL) 70~83dB/75~83dB/72~83dB/70~83dB/72~83dB(UL) F27-5S Nominal passband gain 70~83dB/70~83dB/72~83dB/64~83dB/72~83dB(DL) F20-5S Max .Output Power 20dBm(UL)/20dBm(DL) F23-5S Max .Output Power...
  • Page 19 请修改本页底部的公司信息,请注意空格，标点等细节： Address: 6210 N. Belt Line Rd., Ste. 110, Irving, TX, 75063 Phone: 972-870-5666 E-mail: info@huaptecus.com Website: www.huaptecus.com...

This manual is also suitable for:

F23F27
