- Page 1 Operating Instructions Explore The High Definition World Website:www.jtechdigital.com Hot Line:1-888-610-2818[US] USER MANUAL J-Tech Digital® ProAV® Series HDMI 4X4 Matrix 4K HDMI1.4 Version Support 3D...
- Page 2 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Remark: The connection of the main adapter to the HDMI Matrix switch must be done at first, afterwards you can connect the main adapter to the power outlet.
- Page 3 any source (Blue-Ray player, HD DVD player, satellite receiver, game system, etc.) to be shown on the any of the four displays simultaneously, and supports 4K×2K, 3D, Deep Color. With its 3Gbps bandwidth and the additional features of the latest HDMI standards you can be sure of great HDMI distribution.
- Page 4 7. Full colorimetry including sYCC601, Adobe RGB, Adobe YCC601, xvYCC extended gamut color. 8. Operates for TMDS clock frequencies up to 300MHz. III. Package HDMI Matrix --------------------------------------------------------- 1PC Adaptor ---------------------------------------------------------------- 1PC Operation Manual ---------------------------------------------------- 1PC Remote Controller------------------------------------------------------1PC RS232 Serial Cable----------------------------------------------------1PC IV.
- Page 5 2. Input Ports 4 x HDMI Female input ports 3. Output Ports 4 x HDMI Female output ports 4. Power Supply DC 12V, 2.5A 5. ESD Protection Human Body Model: ± 8kV (air-gap discharge) ± 4kV (contact discharge) 6. Dimensions (mm) 115(W) X 270 (D) X 45 (H) 7.
- Page 6 1. ON/OFF: Power on/off switch. 2. POWER: This red LED illuminates when the device is connected with power supply. 3. IR IN: Remote control signal receive. 4. OUTPUT A: Press this button to select the input source to HDMI OUTPUT A, and these red LED illuminate when the output select to the corresponding input.
- Page 7 7. OUTPUT D: Press this button to select the input source to HDMI OUTPUT D, and these red LED illuminate when the output select to the corresponding input. Rear Panel 1. INPUT PORTS: LED1-4 illuminate when the HDMI signal plug in INPUT 1-4 port. INPUT 1-4 ports are where you connect the HDMI source.
- Page 8 4. DC 12V: Plug the 12V DC power supply into the unit and connect the adaptor to AC wall outlet. Right Panel 1. EDID Selector: Select HDMI output signal format via EDID Selector. Number EDID Selector Description 0000 Auto mode(default)
- Page 9 0001 1080I,Stereo Audio 2.0 0010 1080I,Dolby/DTS 5.1 0011 1080I,HD Audio 7.1 0100 1080P,Stereo Audio 2.0 0101 1080P,Dolby/DTS 5.1 0110 1080P,HD Audio 7.1 0111 3D,Stereo Audio 2.0 1000 3D,Dolby/DTS 5.1 1001 3D,HD Audio 7.1 1010 4K2K,Stereo Audio 2.0 1011 4K2K,Dolby/DTS 5.1 1100 4K2K,HD Audio 7.1...
- Page 10 1101 1024x768 DVI 1110 1920x1080 DVI 1111 PC Software control mode VI. Application Example...
- Page 11 VII. Remote control...
- Page 12 OUT A: Press 1\2\3\4 button will to select input source to HDMI OUT A, and the LED will indicate the corresponding input source. OUT B: Press 1\2\3\4 button to select input source to HDMI OUT B, and the LED will indicate the corresponding input source.
- Page 13 Installation Matrix controller is a green software. Just copy MatrixController.exe to PC which is used to control the Matrix by RS232 COM port or TCP/IP to complete installation. Preparation Connect PC and Matrix by RS232 cable (headers of both sides of cable should be FEMALE) or TCP/IP(local area network) ...
- Page 14 Select RS232 COM or TCP mode...
- Page 15 Select RS232 COM port Click to connect or disconnect PC and Matrix Select Matrix IP Connet to Matrix IP Search Matrix IP Configure Matrix IP and MAC Enable or disable IR /beep Device information display area ...
- Page 16 Select auto or static IP Rewrite the Matrix IP Rewrite the Matrix MAC...
- Page 17 “EDID control” page Set EDID mode for selected Input port or All Input ports, click “Set” button to complete...
- Page 18 action Select EDID Select Input port Copy EDID from Output port to selected Input port or All Input ports, click “Set” button to complete action. Select Output port Download EDID content to selected Input port or All Input ports, click “Download”...
- Page 19 “Matrix” page...
- Page 20 LED which display Input number for respective Output Click to select Input port for respective Output port Click to select previous or next Input port for respective Output port “FW upgrade” page...
- Page 21 Click to open FW file(file extension is “.fw”) Display the FW file path Displaying the progress of the software upgrade Click to upgrade the Matrix software Display the message of the software upgrade Clear the message of the software upgrade...
