- Page 1 OWNER'S MANUAL OPERATION • CARE • SERVICE BATTERY SWEEPER KS-33.5 BR 24 VOLT JULY 1995 083395...
-
Page 2: Table Of Contents
TABLE OF CONTENTS MACHINE SPECIFICATIONS ................2 SERVICE INFORMATION ..................3 IMPORTANT SAFETY INSTRUCTIONS .............. 3 BATTERY INSTALLATION ..................4 WARNING ......................4 BATTERY CHARGING INSTRUCTIONS .............. 4 INSTRUMENTS AND CONTROLS ............... 5 HOW TO USE THE MACHINE ................6 ADJUSTMENT OF BRUSHES ................ -
Page 3: Machine Specifications
MACHINE SPECIFICATIONS Model No..........KS-33.5BR Type of Sweeper ........Rider Battery System Voltage ......24 Volt Batteries ..........Two 12 Volt, 125AH, P/N 25782 Cleaning Width ........With Side Brush: 33.5 in. (85cm) Main Brush Only: 23.6 in. (60cm) Side Brush Diameter ...... -
Page 4: Service Information
SERVICE INFORMATION SAVE THESE INSTRUCTIONS To obtain consistent performance over the life of your READ THIS MANUAL BEFORE Kent equipment, read through these instructions and ATTEMPTING TO ASSEMBLE OR USE save them for future reference. If you require service, THIS MACHINE! contact the dealer from which the machine was pur- chased or an authorized service station. -
Page 5: Battery Installation
electrical parts of the machine dry. For storage, keep the machine in a building. ÿ Make sure that all labels, decals, warnings, cautions, and instructions are fastened to the machine. ÿ Do not turn the steering wheel sharply when the machine is in motion. -
Page 6: Instruments And Controls
INSTRUMENTS AND CONTROLS 1. Display 8. Side brush lever 2. Main brush warning light 9. Flap raising pedal 3. Light switch 10. Brake blocking device 4. Voltmeter/hour meter selector 11. Brake pedal 5. Brush and vacuum switch 12. Suction blocking control 6. -
Page 7: How To Use The Machine
HOW TO USE THE MACHINE a) Switch on the machine, turn key 6, wait about 3 seconds until the display indicates battery level. b) Turn on main brush (button 5). c) Activate the side brush by lowering lever 8. d) Check that suction blocking device is not engaged (12). e) Disengage parking brake (10). -
Page 8: Adjustment Of Brushes
ADJUSTMENT OF BRUSHES How to adjust main brush: (This operation should be carried out on a level floor.) a) Loosen nuts (Figure C) on both sides of machine and place brush on floor. b) Lower the brush 1/8 in. by means of the height adjustment nuts on each side of the machine (Figure B). If the above adjustment has been carried out correctly the brush should leave a 23.6 in. -
Page 9: How To Replace Brushes
HOW TO REPLACE BRUSHES Main brush: a) Remove the dirt container - lower lever (Figure C), keep firm hold on container and remove it by means of internal handle (Figure D). b) Remove seat cover and right side hatch (removable). c) Disengage the brush control belt stretcher by unhooking the spring (Figure B). -
Page 10: How To Clean Filters
HOW TO CLEAN FILTERS For a thorough cleaning of filters, carry out the following steps: a) Remove the seat cover and filter cover. b) Remove hard knobs and pull out the fixing support by pulling back the filter shaker knob (Figure C). c) Remove filters - first the two on the sides and then the central one (Figure B). -
Page 11: Replacement Of Carbon Brushes
REPLACEMENT OF CARBON BRUSHES ON ELECTRIC MOTORS AND FUSES 1) Drive motor (front wheel) (Figure C). 2) Carbon brush protection cap ( N. 2) (Figure C, Pos. 1). 3) Side brush motor (Figure D). 4) Carbon brush protection (N. 2) (Figure D, Pos. 4). 5) Fan/main brush motor (Figure B). -
Page 12: Batteries - Periodic Maintenance
BATTERIES - PERIODIC MAINTENANCE WARNING: All periodic and extraordinary maintenance must be carried out by competent personnel or by an authorized Service Center: every every every CHECK: on delivery 10 hrs. 50 hrs. 100 hrs. ÿ Battery liquid level ÿ Battery voltage level ÿ... -
Page 13: Wiring Diagram
Kent/Euroclean 14600 21st Avenue North Plymouth, MN, 55447-3408 www.eurocleanusa.com Phone: 800-334-1083 © 2002 Printed in USA Fax: 866-261-4779...
