General Information

Pre-disassembly Instructions

Before proceeding with the disassembly procedure, make sure that you do the following:
1.
Turn off the power to the system and all peripherals.
2.
Unplug the AC adapter and all power and signal cables from the system.
3.
Place the system on a flat, stable surface.
4.
Remove any dummy card that might still be inside the card slot.

Disassembly Process

The disassembly process is divided into the following stages:
The flowcharts provided in the succeeding disassembly sections illustrate the entire disassembly sequence.
Observe the order of the sequence to avoid damage to any of the hardware components. For example, if you
want to remove the main board, you must first remove the keyboard, then disassemble the inside assembly
frame in that order.
Main Screw List
Item
A
B
C
D
E
F
G
H
I
J
K
42
Downloaded from
www.Manualslib.com
External module disassembly
Main unit disassembly
LCD module disassembly
Screw
M2 x L4
M2 x L3
M2.5 X L3.5
M3 x L3
M2.5 x L6
M2.5 x L11
M2 x L2.5
M2.5 x L5
M2 x L6
M2 x L3
M2.5 x L4
manuals search engine
Color
Black
86.00E13.524
Silver
86.9A522.3R0
Silver
86.9A563.3R5
Black
86.00E90.743
Black
86.00E12.536
Black
Silver
86.9A562.2R5
Black
Black
86.00K64.524
Black
86.00K60.630
SIlver
86.00K04.734
Part No.
86.1A353.110
86.00F87.735
Chapter 3
