- Page 1 Test Report No.: GETEC-E3-04-044 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 42” LCD TV/Monitor FCC ID : BEJL4200TC...
-
Page 2: Regulatory Information
Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “CE” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules. -
Page 3: Safety Precautions
Safety Precautions Please read these safety precautions carefully before using the monitor. If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death. Caution If you ignore the caution message, you may be slightly injured or the product may be damaged Precautions in installing the Monitor Warning Keep away from heat sources like electrical heaters. - Page 4 Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The monitor can be damaged, or you may be electrocuted. During a thunder or lightning storm, unplug the power cable or signal cable. - You may be electrocuted or a fire can break out.
- Page 5 Safety Precautions Caution Do not shock the monitor when moving it. - You may be electrocuted or the monitor can be damaged Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the monitor, the damaged monitor can cause electric shock or fire.
-
Page 6: Inserting Batteries Into Remote Controller
Accessories Please check the accessories in the product package. * The monitor and the accessories can be different from the figures shown here. Free Mount Type Desktop Stand Type Monitor Remote Controller/ Batteries (AAA x 2) Monitor Driver CD/ DVI-D Signal Cable 15-pin D-Sub Signal User's Guide/Cards Cable... -
Page 7: Name And Function Of The Parts
Name and Function of the Parts Rear View Back Cap - Open the back cap before you install the monitor. AV-IN COMP-1 Video PC Audio ANT IN AV-OUT COMP-2 Power Connector : Connect the power cord Wired Remote Control Port RS-232C Serial Ports PC Signal Inputs PC Sound Jack... -
Page 8: Connecting The Monitor
Connecting the Monitor First of all, see if the computer, monitor and the peripherals are turned off. Then, connect the signal input cable. When connecting with the DVI signal input cable. When connecting with the DSub signal input cable. (IBM compatible PC) When connecting with the DSub signal input cable. - Page 9 Turn on power by pressing the power button on the monitor. Power button Turn on the PC. Select an input signal. Press the SOURCE button on the remote controller to select the input signal. Or, press the SOURCE button at the front side of the monitor. SOURCE SET(SELECT) When connecting with a DVI-D signal input cable.
-
Page 10: Selecting And Adjusting The Screen
Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit • Press the button to turn on the power. Press the button again to Power Button turn it off. • This Indicator lights up green when the display operates normally. Power LED If the display is in DPM (Energy Saving) mode, this indicator color changes to amber. - Page 11 OSD Menu – When Connected to Your PC Icon Function Description Adjusts screen brightness, contrast and color that you prefer. PICTURE Adjusts the audio function. SOUND Adjusts the timer function. TIMER Adjusts the screen status according to the circumstances. SPECIAL Adjusts the screen video.
-
Page 12: Troubleshooting
Troubleshooting No image is displayed • See if the power cord is properly connected to the Is the monitor power cord outlet. connected? • See if the power switch is turned on. Does the power LED is turned on? • Adjust brightness ( ) and contrast ( ) again. -
Page 13: The Screen Image Looks Abnormal
Troubleshooting The screen image looks abnormal. • D-Sub analog signal – Press the “AUTO” button in Is the screen position wrong? the remote controller to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position OSD menu. -
Page 14: The Audio Function Does Not Work
Troubleshooting The audio function does not work. • See if the audio cable is connected properly. No sound? • Adjust the volume. • See if the sound is set properly. • See if the Sound is set to On in the PIP/POP/PBP No sound is available when the menu. -
Page 15: Lcd Panel
Specifications The product specifications can change without prior notice for product improvement. LCD Panel [L3200T] 32 inches (80.04 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 80.04 cm 0.5025 mm (Pixel Pitch) [L3700T] 37 inches (94.03 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 94.03 cm 0.5025 mm (Pixel Pitch) - Page 16 Specifications The product specifications can change without prior notice for product improvement. Dimensions &Weight Width x Height x Depth [L3200T] [1] 80.30 cm (31.61 inches) x 54.00cm (21.26 inches) x 18.00 cm (7.09 inches) [2] 80.30 cm (31.61 inches) x 49.30 cm (19.4 inches) x 9.99 cm (3.93 inches) [3] 96.40 cm (37.95 inches) x 54.00cm (21.26 inches) x 18.00 cm (7.09 inches) [4] 96.40 cm (37.95 inches) x 49.30 cm (19.4 inches) x 9.99 cm (3.93 inches) [L3700T]...
- Page 17 Specifications The product specifications can change without prior notice for product improvement. Video Signal Max. Resolution DSUB : 1600 X 1200 @60Hz DVI-D : 1360 X 768 @60Hz Recommended Resolution DSUB : WXGA 1360 X 768 @60Hz DVI-D : WXGA 1360 X 768 @60Hz Horizontal Frequency DSUB : 30 - 83 kHz DVI-D : 30 - 72 kHz...
-
Page 18: Power Led
Specifications PC Mode – Preset Mode Horizontal Vertical Horizontal Vertical Preset mode Frequency Frequency Frequency Frequency Preset mode (kHz) (Hz) (kHz) (Hz) 31.469 640 x 350 VESA 1024 x 768 60.123 31.468 720 x 400 VESA 1024 x 768 68.68 31.469 640 x 480 VESA...
