TECshow RAZOR 7 QUAD User Manual page 8

Function Delay
Select Function Delay, press ENTER button to confirm, pres-
ent mode will blink on the display. Use DOWN and UP but-
ton to select the No Delay or 1S/2S/3S Delay (Wait for 1/2/3
seconds before these Functions of 12CH are activated/deac-
tivated) mode. Once the mode has been selected, press the
ENTER button to setup, to go back to the functions without
any 9-change press the MENU button again. Hold and press
the MENU button about one second or wait for one minute to
exit the menu mode.
White Balance
Select White Balance, press the ENTER button to confirm,
present mode will blink on the display.Use the DOWN and
UP button to select the Red or Green or Blue. Once the mode
has been selected, press the ENTER button to setup, use the
DOWN and UP button to change the value (125~255). Once
the mode has been selected, press the ENTER button to set-
up, go back to the functions without any change press the
MENU button again. Hold and press the MENU button about
one second or wait for one minute to exit the menu mode.
Manu Test
Select Manu Test, press the ENTER button to confirm, present
mode will blink on the display. Use the DOWN and UP button to
select the Pan/ Tilt/ Red/ Green/ Blue/ White/Dimmer or Strobe.
Once the mode has been selected, press the ENTER button to
setup,use the DOWN and UP button to change the value (0~255).
Once the mode has been selected, press the ENTER button to
setup, go back to the functions without any change press the
MENU button again. Hold and press the MENU button about one
second or wait for one minute to exit the menu mode.
Auto-Test
Press the MENU button up to when the Auto-Test is blinking on
the display. Pressing ENTER button and the unit will run self-
test by built-in program. To go back to the functions press the
MENU button again. Hold and press the MENU button about
one second or wait for one minute to exit the menu mode.
Temperature
Press the MENU button up to when the Temperature Test is
blinking on the display.Pressing ENTER button and the dis-
play will show the temperature of the unit. To go back to the
functions press the MENU button again. Hold and press the
MENU button about one second or wait for one minute to exit
the menu mode.
RAZOR 7 QUAD
ENGLISH VERSION
Defaults Setting
Press the MENU button to show Defaults on the display. Press
the ENTER button and the display will blink. Use the DOWN
and UP button to select the YES or No. Once the Yes has been
selected, press the ENTER button and use the UP and Down
button to select the PRO Defaults or AUTO Defaults.
PRO Defaults: For professional users, detailed explanation
as followings:
Slave Mode Slave 1
Black Out Yes
Sound State Off
Pan Inverse No
Tilt Inverse No
Back Light Off
Function Delay 3S Delay
AUTO Defaults: Mostly automatic mode, for non profession-
al users, detailed explanation as followings:
Slave Mode Slave 1
Black Out No
Sound State On
Pan Inverse No
Tilt Inverse No
Back Light On
(Notice:Other settings are NOT changed while choosing De-
faults Setting!)
Press the ENTER and the corresponding functions will set
to defaults setting,to go back to the functions without any
change press the MENU button again.Hold and press the
MENU button about one second or wait for one minute to exit
the menu mode
Reset
Press the MENU button up to when the Reset is blinking on
the display.Pressing ENTER button and all channels of the
unit will return to their standard position.
3.3 Home Position Adjust
p. 8
