4.3 DMX Controller
By using a universal DMX Controller to control the units, you
will need to set DMX address from 1 to 512 so that the units
can receive DMX signal
Press the MENU button up to when the DMX Adress is show-
ing on the display.Pressing ENTER button and the display
will blink. Use DOWN and UP button to change the DMX512
address. Once the address has been selected,press the EN-
TER button to setup,to go back to the functions without any
change press the MENU button again.Hold and press the
MENU button about one second or wait for one minute to exit
the menu mode.
Please refer to the following diagram to address your DMX512
channel for the first 4 units.
Channel mode Unit 1 Address
9 channels
12 channels
16 channels

4.4 DMX 512 Configuration

9 Channel Mode:
Channel List Value
CH1 000-255
CH2 000-255
CH3 000-255
CH4
000-255
CH5
000-255
CH6 000-255
CH7 000-255
CH8 000-255
CH9 000-255
RAZOR 7 QUAD
ENGLISH VERSION
Unit 2 Address
1 10
1 13
1 17
Function
Pan(0-630)
Tilt(0-240)
Strobe
Red (0%-100%)
Green (0%-100%)
Blue (0%-100%)
White (0%-100%)
Dimmer (0%-100%)
Sound active
Unit 3 Address Unit 4 Address
19
25
33
28
37
49
