USER MANUAL MANUAL DE INSTRUCCIONES MIMO88SG...
Page 2
Graphic Symbol Explanation The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
4. CLEANING 5. FUNCTION LIST 6. FUNCTION DIAGRAM 7. TECHNICAL CHARACTERISTICS 8. BLOCK DIAGRAM All numbers subject to variation due to production tolerances. ECLER S.A. reserves the right to make changes or improvements in manufacturing or design which may affect specifications.
1. IMPORTANT REMARK Thank you for your confidence and for choosing our MIMO88SG matrix. It is VERY IMPORTANT to carefully read this manual, to fully understand its contents before any connection in order to maximize your use and get the best performance from this equipment.
3.2. Connection to an AC outlet and switching on The MIMO88SG operates under voltages between 90 and 264 V at 47 to 63 Hz. This device features an over dimensioned power supply that adapts to the mains voltage in any country of the world with no need to make any adjustments.
Management from EclerNet Manager application. Please refer to the EclerNet Manager software manual for more information. Possibility of direct connection (point to point) between a computer and a MIMO88SG unit. Connection to third party other devices. (Crestron, AMX, Vity, Medialon, etc. Registered trademarks of their manufacturers).
3.7. GPI Remote Control Ports The rear panel of the MIMO88SG offers 8 GPI inputs (10) for 0-10 VDC continuous control voltage. Each of these inputs can be connected to an external physical device (potentiometer, contact closure, continuously variable voltage 0-10V DC, etc.) and assigned to a MIMO88SG function, as for example: ...
3.9. Front panel controls and LED indicators The following elements are available on the MIMO88SG front panel: Input LED indicators (1): indicate the presence of audio signal at the unit’s input, and its intensity level (green, amber and red indicate in this order the increased intensity level) ...
5. FUNCTION LIST 1. Input signal indicators, INPUTS 2. Output signal indicators, OUTPUTS 3. Data traffic indicator, DATA 4. Power on indicator, POWER 5. Signal output screw terminal, OUT 6. Signal input screw terminal, IN 7. RJ-45 connector, ETHERNET 8. Screw terminals for digital remote control, REMOTE 9.
Page 10
Explicación de los Símbolos Gráficos El símbolo del relámpago con una flecha en la punta y dentro de un triangulo equilátero, tiene el propósito de alertar al usuario de la presencia de un voltaje peligroso y sin aislar dentro del aparato, y de una magnitud tal que puede constituir riesgo de descarga eléctrica para las personas.
Page 11
7. CARACTERÍSTICAS TÉCNICAS 8. DIAGRAMA DE BLOQUES Todos los datos están sujetos a variación debida a tolerancias de producción. ECLER S.A. se reserva el derecho de realizar cambios o mejoras en la fabricación o diseño que pudieran afectar las especificaciones.
En el interior del aparato no existen elementos manipulables por el usuario. 2. INTRODUCCIÓN MIMO88SG es una matriz digital de audio, totalmente programable y con las siguientes características principales: 8 entradas MICRO/LÍNEA simétricas (alimentación Phantom independiente por canal de entrada).
3.2. Conexión a red eléctrica y encendido El MIMO88SG funciona con tensión alterna de 90 a 264V y 47 a 63Hz. Este aparato equipa una fuente de alimentación sobredimensionada capaz de adaptarse sin ningún tipo de ajuste a la tensión de red de cualquier país del mundo.
Gestión desde la aplicación EclerNet Manager. Consulte el manual de la Aplicación EclerNet Manager para obtener más información. Posibilidad de conexión directa (punto a punto) de un ordenador con una unidad MIMO88SG. Conexión a otros aparatos de terceros. (Crestron, AMX, Vity, Medialon, etc. Marcas registradas por sus fabricantes).
3.7. Puertos GPI de control remoto MIMO88SG dispone en su panel posterior de 8 entradas GPI (10) de control por tensión continua, 0 a 10 VDC. Cada una de estas entradas puede conectarse a un dispositivo físico externo (un potenciómetro, un cierre de contacto, una tensión continua 0-10V variable, etc.) y asociarse a una función del MIMO88SG, como por...
3.9. Controles e indicadores LED del panel frontal MIMO88SG dispone en su panel frontal de los siguientes elementos: Indicadores LED de entradas (1): muestran la presencia de señal de audio en las entradas de la unidad, y su nivel de intensidad (colores verde, ámbar y rojo, que corresponden por este orden a un nivel creciente de intensidad) ...
5. LISTA DE FUNCIONES 1. Indicadores luminosos de señal de entrada, INPUTS 2. Indicadores luminosos de señal de salida, OUTPUTS 3. Indicador luminoso de tráfico de datos, DATA 4. Indicador luminoso de puesta en marcha, POWER 5. Terminales atornillables salida de señal, OUT 6.
7. TECHNICAL CHARACTERISTICS 7. CARACTERÍSTICAS TÉCNICAS 7. CARACTERISTIQUES TECHNIQUES 7. TECHNISCHE DATEN 2x 32/64bit Sampling Rate 48kHz Latency IN to OUT <2.9ms Converters Resolution 24bit AKM Dynamic Range AD:110dB, DA: 115dB Analog 8 Input/Output Terminal block (Symmetrical) Analog Input headroom +27dBV = +30dBu Max.
Page 19
Processing Input Level (x8) Range: from Off to 0 dB Mute: Yes Signal Polarity reverse: Yes Metering: VU+clip pre & post fader Output Level (x8) Range: from Off to 0 dB Mute: Yes Solo: Yes Signal Polarity reverse: Yes Metering: VU+clip pre & post fader Output Gain (x8) Range: from 0 to +6 dB Input Delay (x8)
Page 20
Output Limiter (x8) Bypass On-Off Threshold: from –36 dBV to +18 dBV Ratio: inf:1 (limiter) Attack time: from 0,1 ms. to 500 ms. Release time: from 10 ms. to 1000 ms. Built in Signal Generator Sine: from 20 Hz to 20 kHz Polarity: from 20 Hz to 20 kHz White noise Pink noise...
