RESOL Datalogger DL2
Mounting
Connection
Operation
EN
Manual
Thank you for buying this RESOL product.
Please read this manual carefully to get the best performance from this unit.
Please keep this manual carefully.
www.resol.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Datalogger DL2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Resol Datalogger DL2

Summary of Contents for Resol Datalogger DL2

  • Page 1 RESOL Datalogger DL2 Mounting Connection Operation Manual Thank you for buying this RESOL product. Please read this manual carefully to get the best performance from this unit. Please keep this manual carefully. www.resol.com...

  • Page 2: Table Of Contents

    Description of symbols Information about the product WARNING! Proper usage Warnings are indicated with a The datalogger DL2 may only be used in conjunction with con- warning triangle! trollers with VBus output in order to log and access data in ®...

  • Page 3: Overview

    DL2 to a PC, an SD card can be used. The DL2 is appropriate for all controllers with RESOL VBus . It can be connected directly to a PC or router for ®...

  • Page 4: Installation

    Connect the data cable (RESOL VBus , pos.3) to the ® « RESOL controller (pos.4). Extend, if necessary, with en- Router closed screw terminal and (twisted) two-wire cable. Plug mains adapter (Pos.2) into the mains socket. «...

  • Page 5: Operation

    Datalogger DL2 side view: LAN socket side view: SD card slot Operation The datalogger can be configured, read out and deleted via the integrated web interface. The DL2 is additionally equip- ped with a manual reset button. The following functions can...

  • Page 6: Fill Level Of Data Memory

    Datalogger DL2 Fill level of data memory The fill level LEDs visualise the current fill level of the data- logger, i.e. the internal memory capacity used. One bar corresponds to 10 % of the internal memory capacity: Permanent illumination means that the memory capacity is fully used.

  • Page 7: Access Via Internet

    If several dataloggers are found in the local network, they will be listed in the “RESOL devices found” list. The name men- tioned in this list is the device name which can be set on the “General”...

  • Page 8: Quickguide Configuration

    Datalogger DL2 Quickguide Configuration Change username and password for web interface « access (see 10.1) Adjust date and time (see 10.3) « Enable firmware update (see 10.4) « Change the remote access password for access to the « corresponding controller (see 10.5) Change the FTP password for file import (see 9.2)

  • Page 9: State

    Datalogger DL2 State The state window consists of two different sub-windows: “General” and “Network”. State: General 1: Current time setting of the DL2 1a: Time shift to GMT (in hours) 2: Time since last reset 3: Sum of all bytes received since last reset...

  • Page 10: Data

    • VBus Protocol Data: data are issued in a file format suitable for further pro- cessing in the RESOL ServiceCenter or in the RESOL Data Center Erase data In order to delete all data, click on the “Yes, erase all logged...

  • Page 11: Adapting Live Data

    Datalogger DL2 Adapting live data Adapting the units of the live data display Search and discover DL2 « Open web interface DL2 « Select the “Data” tab « Select “Customize” « Select “Temperature unit” « Do not convert (Use °C) = All temperatures are displayed in °C...

  • Page 12: Displaying Live Data In A System Scheme

    To do that, a system scheme of the individual solar thermal system has to be tagged with the necessary VBus display ® boxes in the RESOL ServiceCenter software and then exported into the DL2. To do so, proceed as follows: Select the tab “ Configuration” in the DL2 web inter- «...
  • Page 13 Datalogger DL2 Assign a jpeg-formatted system scheme as background « graphic in “VBuslogging / Designer” Place the VBus display boxes into the system ® « scheme Click „Export to DL2” when ready « Now the dialogue window „Export designer document to DL2”...

  • Page 14: Configuration

    Datalogger DL2 10. Configuration In the following sub-windows of the web interface, the set- tings of the DL2 can be changed. In order to save the changes, click on “Save changes”. « The “Print Configuration” button: In order to print the current configuration of the web «...

  • Page 15: Configuration: Time

    « These adjustments are required for accessing the controller via the datalogger by means of the Service Center Software or the RESOL Data Center. 10.6 About DL2 In this window, details about open source applications and libraries covered are shown.

  • Page 16: Imprint

    Another use outside the copyright requires manual and to the best of our knowledge and consent. As the approval of RESOL - Elektronische Regelungen GmbH. faults can never be excluded, please note: Your own calcu- This especially applies for copies, translations, microfilms lations and plans, under consideration of the current stan- and the storage into electronic systems.
