ROKETA
GK-13(KTX-250W)(L5G)
Comprehensive Owner's Manual, Assembly Guide, and Parts List
(UNOFFICIAL)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GK-13 and is the answer not in the manual?

Questions and answers

Related Manuals for Roketa GK-13

Summary of Contents for Roketa GK-13

  • Page 1 ROKETA GK-13(KTX-250W)(L5G) Comprehensive Owner’s Manual, Assembly Guide, and Parts List (UNOFFICIAL)

  • Page 2: Table Of Contents

    Roketa GK-13 Combined Owner’s Manual Page CONTENTS FOREWORD................ A FEW WORDS ABOUT SAFETY........IMPORTANT SAFETY INFORMATION........ SAFETY LABELS..............ARE YOU READY TO DRIVE? ..........IS YOUR VEHICLE READY TO DRIVE? ......SAFE DRIVING PRECAUTIONS........... P.D.L .................… SPECIFICATIONS..............OPERATION................. SERVICE INSTRUCTIONS............

  • Page 4: Foreword

    FOREWORD Thank you for choosing our Go-Kart. We hope you will have fun with it. Before you start operate on the Go-Kart, please read through this Owner's Manual carefully as it contains important safety and maintenance information failure to follow the warnings contained in this manual can result in serious injuries.

  • Page 5: A Few Words About Safety

    A FEW WORDS ABOUT SAFETY In order to keep everyone safe, you must take responsibility for the safe operation of your Co-Kart. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual This information alerts you to potential hazards that could hurt you or others.

  • Page 6: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your Go-Kart will provide you with many years of service and pleasure. Providing you take responsibility for your own safety and understand the challenges you can meet while driving. There is much that you can do to protect yourself when you drive. You’ll find many helpful recommendations throughout this manual.
  • Page 7 IMPORTANT SAFETY INFORMATION Drive within Your Limits Pushing limits is another major cause of Go-Kart accidents, Never drive beyond your personal abilities or faster than conditions warrant. Remember that alcohol, drugs, fatigue, and inattention can significantly reduce your ability to make good judgments and drive safely.

  • Page 8: Safety Labels

    SAFETY LABELS This section presents some of the most important information and recommendations to help von drive your Go-Kart safely Please take a few moments to read these pages. The labels should be considered permanent parts of the Go-Kart. If a label comes off or becomes hard to read, contact your dealer for warning labels replacements.

  • Page 9: Are You Ready To Drive

    ARE YOU READY TO DRIVE? Before each drive, you need to make sure you and your Go-Kart are both ready to drive. To help get you prepared, this section discusses how to evaluate your driving readiness, what items you should check on your Go-Kart, and adjustments to make for your comfort, convenience, or safety.
  • Page 10 ARE YOU READY TO DRIVE ? Additional Driving Gear In addition to a helmet and eye protection, we also recommend: •  Sturdy off-road motorcycle boots to help protect your feet ankles, and lower legs •  Off-road motorcycle gloves to help protect your hands. • ...

  • Page 11: Is Your Vehicle Ready To Drive

    IS YOUR VEHICLE READY TO DRIVE ? Before each drive, it is important to inspect your Go Kart and make sure any problems you find are corrected. A pre-drive Inspection is a must. not only for safety, but because having a breakdown, or even a flat tire, can be a major inconvenience. If your Go-Kart has overturned or has been involved in a collision, do not drive it until your Go-Kart has been inspected by your dealer.
  • Page 12 IS YOUR VEHICLE READY TO DRIVE ? •  Leaks. Loose Parts Walk around your Go-Kart and look for anything that appears unusual, such as a leak or loose cable. •  Lights Make sure the headlight, brake light and tail light are working properly. • ...

  • Page 13: Safe Driving Precautions

    SAFE DRIVING PRECAUTIONS Off-road Use Only Your Go-Kart and its tires are designed and manufactured for off-road use only, not for pavement. Driving on pavement can affect handling and control You should not drive your Go-Kart on pavement. When driving off-road, also remember to always obey local off-road driving laws and regulations.
  • Page 14 SAFE DRIVING PRECAUTIONS Control Speed Driving at excessive speed increases the chance of an accident In choosing a proper speed, you need to consider the capability of your Go-Karl, the terrain, visibility and other operating conditions, plus your own skills and experience Use Care on Unfamiliar or Rough Terrain Before driving in a new area, always check the terrain thoroughly.
  • Page 15 P.D.I. a. Install RR (rear) Shocks and tighten the nuts. b. Install Ball Head, Tie Rod, tighten the Castle Nut and insert the cotter Pin. c.  Install Front Tires and tighten the nuts d.  Install Rear Tires, tighten the nuts and insert cotter Pin. e. ...

  • Page 16: Specifications

    SPECIFICATIONS DIMENSIONS item SQCKA SQ-GKI! I SQ-GKB Overall Length 2270 mm 2300 mm 2300 mm Overall Width 1160 mm 1415 mm 1640mm Overall Height 1152 mm 1232 mm 1470 mm Wheelbase 1720 mm 1785 mm 1780 mm Front Track 1180 mm 1415 mm 1360 mm Rear 1 rack...

  • Page 17: Operation

    OPERATION 1.  Operation Controls WARNING - Do not attempt to start or operate the engine until completely familiar with the location and use of each control necessary to operate this vehicle. The operator must know how to stop tins machine before starting and driving it.  ...

  • Page 18: Component Locations

    OPERATION 2.  Pre-Drive Inspection   Check for Engine Oil Level. Check for leaks, add oil if required.   Check for Fuel Level. Add fuel as necessary and do not overfill. Check for leaks.   Check the brakes. Depress the rear brake pedal several times, then check for proper brake pedal free play.
  • Page 19 OPERATION 3.  Passengers The vehicle allows for two riders only. Combined maximum weight of driver anti the passenger should not exceed 180Kg or 400lbs. 4.  Seat Adjustment The seat must always be securely fastened in the position which best affords the operator control of the foot pedals, steering wheel, and the remote stop button.
  • Page 20 OPERATION 6.  Starting And Operating instructions   Before starting the engine, be sure that the driver is seated properly in the Go-Kart and tighten the seatbelt.   Testing the Go-Kart in a open place at the beginning to learn how to start, turn and stop.  ...

  • Page 21: Service Instructions

    SERVICE INSTRUCTIONS 1.  Service Air Cleaner Service air cleaner every 80 hours, NOTE: Service more often under dusty condition.   Remove cleaner cover.   Remove cleaner elements 2, 3 (see picture   Fill a non-flammable cleaning agent into a basin and dip the filter element in it.  ...
  • Page 22 SERVICE INSTRUCTIONS 4.  Carburetor Adjustment Never make unnecessary adjustments. The factory recommended settings are correct for most applications. It's not necessary to disassemble the screw unless the carburetor needs to be replaced. Prepare a 50r/w tachometer before adjustment.   Warm up the engine (5-10min)  ...

  • Page 23: Repair

    SERVICE INSTRUCTIONS/ REPAIR 1.  Adjustment of Front And Rear Shock There are many adjustable positions on each shock The default position is in the middle set by manufacture (Sec picture 11), Use a round nut wrench as you adjust the shock. The tension of shock spring will increase as you screw clockwise, decrease as you screw counter- clockwise.
  • Page 24 2.  Rear Wheel Replacement Do not disassemble the castle nuts when you replace the front wheels. It is only necessary to tighten the nuts so that the wheel turns freely on the axle with minimum end play. (See picture 13) Tighten the nuts and put on the cotter Pin after replacing the wheels.
  • Page 28 FRAME ASSEMBLY Item Id Name: QTY (pcs/set) GK-13-250-01-01 INNER-HEX BALL-SHAPE-HEAD BOLT M6*20 GK-13-250-01-02 LOCKNUT M6 GK-13-250-01 -03 FR.BOTTOM PEDAL GK-13-250-01-04 LOCKNUT M8 GK-13-250-01-05 HEX FLANGE BOLT M8*20 GK-13-250-01-06 FR.CARRIER GK-13-250-01-07 HEX FLANGE BOLT M6*20 GK-13-250-01-08 FOOTREST GK-13-250-01-09 MAIN FRAME 59kg...
  • Page 30 WIRING ASSEMBLY Item Id Name: QTY (pcs/set) GK-13-250-02-01 HEADLIGHT ASSY GK-13-250-02-01-01 BULB, FR. LIGHT GK-13-250-02-01-02 FR. LIGHT COMP GK-13-250-02-02 HEX FLANGE BOLT M8*25 GK-13-250-02-03 RECTIFIER GK-13-250-02-04 C.D.I. GK-13-250-02-05 RELAY GK-13-250-02-06 FUSE GK-13-250-02-07 HEX FLANGE BOLT M6*30 GK-13-250-02-08 PLANE WASHER Φ6*18*1.4...
  • Page 32 ENGINE ASSEMBLY Item Id Name: QTY (pcs/set) GK-13-250-03-01 HEX FLANGE B0LT M10*1.25*55 GK-13-250-03-02 LOCK NUT M10*1.5 GK-13-250-03-03 BRACKET, ENGINE GK-13-250-03-04 CUSHION RUBBER, ENGINE GK-13-250-03-05 LOCK NUT M8*1.5 GK-13-250-03-06 SPLIT PIN Φ2.5*50 GK-13-250-03-07 HEX CONCAVE NUT M16*1.5 RR.TRANSMISSION GK-13-250-03-08 SHAFT200 GK-13-250-03-09...
  • Page 33 ONE WAY VALVE COMP GK-13-250-03-29-08 ELASTICITY FASTENER Φ8 GK-13-250-03-29-09 PIPE IN Φ4*8*600 GK-13-250-03-30 CARBRURETOR GK-13-250-03-31 AIR CLEANER ASSY GK-13-250-03-31 -01 CORE, AIR CLEANER GK-13-250-03-31-02 AIR CLEANER COMP GK-13-250-03-31 -03 SYPHON, AIR CLEANER GK-13-250-03-32 ELASTICITY FASTENER Φ22 GK-13-250-03-33 WATER PIPE Φ15*22*1600...
  • Page 35 REAR WHEEL ASSEMBLY Item Id Name: QTY (pcs/set) GK-1 3-250-04-01 HEX FLANGE BOLT M10*50 GK-13-250-04-02 LOCK NUT M10 GK-13-250-04-03 RR.SHOCK ABSORBER ASSY 370 GK-13-250-04-04 OIL SEAL 25*40*7 GK-1 3-250-04-05 FLANGE BUSH Φ17*25*7*35*2.5 GK-13-250-04-06 TAPER BEARING 30203 GK-1 3-250-04-07 FIXING SHAFT,RR.SWING ARM M16*180...
  • Page 36 REAR WHEEL ASSEMBLY Item Id Name: QTY (pcs/set) GK-13-250-04-26 CIRCLIP [INWARD C0NTRACTIVE) Φ86 GK-13-250-04-27 ADJUSTER, CHAIN GK-13-250-04-28 CIRCLIP[INWARD CONTRACTIVE] Φ69 GK-13-250-04-29 SPLIT PIN Φ3*50 GK-13-250-04-30 HEX CONCAVE NUT M18 GK-13-250-04-31 BRACKET RR.SPROCKET CENTER HOLE 23.5MM GK-13-250-04-32 HEX NUT M10 FOUR-SPACED NUT (WITH CLOCKWISE THREAD]...
  • Page 38 FRONT WHEEL ASSEMBLY Item Id Name: QTY (pcs/set) GK-1 3-250-05-01 HEX FLANGE BOLTM 10*50 GK-13-250-05-02 LOCK NUT M10 GK-13-250-05-03 FR.SHOCK ABSORBER 360 GK-13-250-05-04 FLANGE WASHER Φ2*36*6 GK-13-250-05-05 BUTTER JAWS GK-1 3-250-05-06 FIXING SEAT, FR.UPPER SWING ARM GK-13-250-05-07 SPACER Φ14*20*26 GK-13-250-05-08 FR.UPPER SWING ARM 213...
  • Page 39 FRONT WHEEL ASSEMBLY Item Id Name: QTY (pcs/set) GK-13-250-05-22-05 PLANE WASHER Φ10*20*2 GK-13-250-05-22-06 ELASTICITY WASHER Φ10 GK-13-250-05-22-07 HEX NUT M10 GK-13-250-05-23 FR.BRAKE DISC 3*130 GK-1 3-250-05-24 INNER-HEX BALL-SHAPE-HEAD BOLT M6*16 GK-13-250-05-25 SKIDPROOF NUT M6 GK-13-250-05-26 PLANE WASHER Φ6*12*1 GK-13-250-05-27 ELASTICITY WASHER Φ6 BOLT, FR.
  • Page 41 Item Id Name: QTY (pcs/set) GK-1 3-250-06-01 COPPER TUBE,R.FR.HYDRAULIC BRAKE800 GK-1 3-250-06-02 COPPER TUBE,L.FR.HYDRAULIC BRAKE600 GK-1 3-250-06-03 HEX FLANGE BOLT M10*1.25*25 GK-13-250-06-04 LOCK NUT M10*1.25 GK-13-250-06-05 HOLDING PIECE, REDIRECTOR GK-13-250-06-06 REDIRECTOR ASSY GK-13-250-06-06-01 SPLIT PIN Φ2.5*35 GK-13-250-06-06-02 HEX CONCAVE NUT M10*1.25 GK-1 3-250-06-06-03 BALL-AND-SOCKET JOINT,L.TURNING SHAFT...

  • Page 42: Steering Assembly

    STEERING ASSEMBLY Item Id Name: QTY (pcs/set) GK-13-250-06-26 STEERING WHEEL 320 GK-13-250-06-27 LOCKNUT M6 GK-1 3-250-06-28 INNER-HEX BALL-SHAPE-HEAD BOLT M6*16 GK-13-250-06-29 ON-OFF, BRAKE LIGHT GK-13-250-06-30 CHIEF PUMP, HYDRAULIC BRAKE GK-13-250-06-31 LOCK NUT M8*1.25 GK-13-250-06-32 INNER-HEX BOLT M8*1.25*30 GK-13-250-06-33 CONNECTOR,BRAKE MANDRIL...
  • Page 44 SEAT ASSEMBLY Item Id Name: QTY (pcs/set) GK-1 3-250-07-01 INNER-HEX BOLT M8*30 GK-13-250-07-02 HEX NUT M10 GK-13-250-07-03 HEX NUT M8 GK-13-250-07-04 BRACKET,SEAT GK-13-250-07-05 ADJUSTER,SEAT GK-13-250-07-06 SEAT GK-13-250-07-07 SAFE BELT ASSY...
