ViewSonic E90fB-4 Service Manual page 7

10. Video Bandwidth: 210 MHz
11. Power Source:
Switching Mode Power Supply
AC 90 ~264V, 50/60Hz Universal Type
12. Operating Temperature: 0°C to 40°C Ambient
13. Humidity: 5% to 95% Relative, Non-Condensing
14. Weight: 18.0 kgs / 39.7 (lbs) (Net), 21.2 kgs / 46.7 (lbs) (Gross)
15. Dimensions
Width:
Height:
Depth:
16. External Connection:
15 Pin D-sub Connector
AC Power Cord
17. Power Consumption Modes :
On <75W typical (Green LED)
Sleep <5W(Amber LED)
Off <5W
18. Regulatiory/Safety
UL/CUL, FCC-B, CB, CE, DHHS, ICES 003, NOM, TUV/GS, TUV/Ergo, MPRII, GOST-R, SASO, BSMI, CCC,
PSB, Argentina-TUV/S, EPA Energy Star (Y2005 tier1)
ViewSonic Corporation
Machine
445 mm (17.6 inches)
424 mm (16.7 inches)
378 mm (14.9 inches) w/o base
465 mm (18.3 inches)
4
Package
540 mm
530 mm
570mm
Confidential-Do Not Copy
E90fB-4
